Owner’s Manual Supplement
Uconnect 5.0/5.0 NAV
Second Edition Rev 1
Uconnect 5.0/5.0 NAV
Printed in the USA
16UC5PMC-526-AB
©2015 FCA US LLC. All Rights Reserved.
Chrysler, Dodge, Jeep, Ram, Mopar and Uconnect are trademarks of FCA US LLC.
FIAT is a registered trademark of FCA Group Marketing S.p.A.,
used under license by FCA US LLC.

TABLE OF CONTENTS
SECTION PAGE
1SAFETY GUIDELINES .........................................................3
2INTRODUCTION .............................................................9
3ALL ABOUT UCONNECT ......................................................17
4RADIO MODE ...............................................................21
5MEDIA MODE ..............................................................29
6VOICE RECOGNITION QUICK TIPS ............................................35
7UCONNECT PHONE ..........................................................45
8MORE BUTTON .............................................................53
9NAVIGATION ...............................................................55
1
2
3
4
5
6
7
8
9

SAFETY GUIDELINES
CONTENTS
䡵SAFETY GUIDELINES .....................4
▫Safe Usage Of The Uconnect System..........4
▫Touchscreen ...........................5
䡵CYBERSECURITY ........................5
1

SAFETY GUIDELINES
WARNING!
ALWAYS drive safely with your hands on the
steering wheel. You have full responsibility and
assume all risks related to the use of the Uconnect
features and applications in this vehicle. Only use
Uconnect when it is safe to do so. Failure to do so
may result in an accident involving serious injury
or death.
Ensure all persons read this manual carefully before
using the system. It contains instructions on how to use
the system in a safe and effective manner.
Please read and follow these safety precautions. Failure
to do so may result in injury or property damage.
•Glance at screen only when safe to do so. If prolonged
viewing of the screen is required, park in a safe
location and set the parking brake
•Stop use immediately if a problem occurs. Failure to
do so may cause injury or damage to the product.
Return it to your authorized dealer to repair.
•Ensure the volume level of the system is set to a level
that still allows you to hear outside traffic and emer-
gency vehicles.
Safe Usage Of The Uconnect System
•Read all instructions in this manual carefully before
using your system to ensure proper usage!
•Your system is a sophisticated electronic device. Do
not let young children use your system.
4 SAFETY GUIDELINES

•Permanent hearing loss may occur if you play your
music or the system at loud volumes. Exercise caution
when setting the volume on your system.
•Keep drinks, rain and other sources of moisture away
from your system. Besides damage to your system,
moisture can cause electric shocks as with any elec-
tronic device.
NOTE: Many features of this system are speed depen-
dent. For your own safety, it is not possible to use some
of the touchscreen features while the vehicle is in motion.
Touchscreen
•Do NOT attach any object to the touchscreen, doing
so can result in damage to the touchscreen.
•Do not press the touchscreen with any hard or sharp
objects (pen, USB stick, jewelry, etc.) which could
scratch the touchscreen surface!
•Do not spray any liquid or caustic chemicals directly
on the screen! Use a clean and dry micro fiber lens
cleaning cloth in order to clean the touchscreen.
•If necessary, use a lint-free cloth dampened with a
cleaning solution, such as isopropyl alcohol or an
isopropyl alcohol and water solution ratio of 50:50. Be
sure to follow the solvent manufacturer’s precautions
and directions.
CYBERSECURITY
Your vehicle may be a connected vehicle and may be
equipped with both wired and wireless networks. These
networks allow your vehicle to send and receive infor-
mation. This information allows systems and features in
your vehicle to function properly.
Your vehicle may be equipped with certain security
features to reduce the risk of unauthorized and unlawful
access to vehicle systems and wireless communications.
1
SAFETY GUIDELINES 5

Vehicle software technology continues to evolve over
time and FCA US LLC, working with its suppliers,
evaluates and takes appropriate steps as needed. Similar
to a computer or other devices, your vehicle may require
software updates to improve the usability and perfor-
mance of your systems or to reduce the potential risk of
unauthorized and unlawful access to your vehicle sys-
tems.
The risk of unauthorized and unlawful access to your
vehicle systems may still exist, even if the most recent
version of vehicle software (such as Uconnect software) is
installed.
WARNING!
•It is not possible to know or to predict all of the
possible outcomes if your vehicle’s systems are
breached. It may be possible that vehicle systems,
including safety related systems, could be im-
paired or a loss of vehicle control could occur that
may result in an accident involving serious injury
or death.
•ONLY insert media (e.g., USB, SD card, or CD) into
your vehicle if it came from a trusted source. Media
of unknown origin could possibly contain mali-
cious software, and if installed in your vehicle, it
may increase the possibility for vehicle systems to
be breached.
•As always, if you experience unusual vehicle be-
havior, take your vehicle to your nearest authorized
dealer immediately.
6 SAFETY GUIDELINES

NOTE:
•FCA or your dealer may contact you directly regarding
software updates.
•To help further improve vehicle security and minimize
the potential risk of a security breach, vehicle owners
should:
•Routinely check
www.driveuconnect.com/software-update to
learn about available Uconnect software updates.
•Only connect and use trusted media devices (e.g.
personal mobile phones, USBs, CDs).
Privacy of any wireless and wired communications can-
not be assured. Third parties may unlawfully intercept
information and private communications without your
consent. For further information, refer to “Onboard Di-
agnostic System (OBD II) Cybersecurity” in “Maintaining
Your Vehicle” in your Owner’s Manual on the DVD.
1
SAFETY GUIDELINES 7

INTRODUCTION
CONTENTS
䡵UCONNECT 5.0 SYSTEM ..................10
䡵UCONNECT 5.0 SYSTEM W/NAVIGATION — IF
EQUIPPED ............................13
2

UCONNECT 5.0 SYSTEM
10 INTRODUCTION

CAUTION!
Do NOT attach any object to the touchscreen,
doing so can result in breaking the touchscreen.
1 — SCREEN ON/OFF
Push the SCREEN ON/OFF button on the faceplate to
turn the touchscreen ON or OFF.
2 — SETTINGS
Push the SETTINGS button to access the Uconnect setting
features.
3 — BACK
Push the BACK button to return to a previous menu or
screen.
4 — ENTER/BROWSE & TUNE/SCROLL
Push the ENTER/BROWSE button to accept a high-
lighted selection on the screen. Rotate the TUNE/
SCROLL rotary knob to scroll through a list, tune a radio
station or skip tracks in Media Mode.
5 — MORE
Push the MORE button on the faceplate to access addi-
tional options such as: Trip, Clock and Outside Temp.
6 — PHONE
Push the PHONE button to access the Uconnect Phone
feature.
7 — COMPASS
Push the COMPASS button on the faceplate to display
the current direction of the vehicle.
2
INTRODUCTION 11

8 — MEDIA
Pushing the MEDIA button will allow you to switch to
Media mode (USB/iPOD, AUX or Bluetooth.)
9 — RADIO
Push the RADIO button on the faceplate to enter Radio
Mode. The different tuner modes; AM, FM and SXM – If
Equipped can be selected by pushing the corresponding
button on the touchscreen while in the Radio Mode.
10 — ON/VOLUME
Rotate the rotary knob to adjust the Volume. Push the
ON/VOLUME button to turn on the system. Push the
ON/VOLUME button a second time to turn off the
system.
11 — MUTE
Push the MUTE button for activation/deactivation of the
volume.
12 INTRODUCTION

UCONNECT 5.0 SYSTEM W/NAVIGATION — IF EQUIPPED
2
INTRODUCTION 13

CAUTION!
Do NOT attach any object to the touchscreen,
doing so can result in breaking the touchscreen.
1 — SCREEN ON/OFF
Push the SCREEN ON/OFF button on the faceplate to
turn the touchscreen ON or OFF.
2 — SETTINGS
Push the SETTINGS button to access the Uconnect setting
features.
3 — BACK
Push the BACK button to return to a previous menu or
screen.
4 — ENTER/BROWSE & TUNE/SCROLL
Push the ENTER/BROWSE button to accept a high-
lighted selection on the screen. Rotate the TUNE/
SCROLL rotary knob to scroll through a list, tune a radio
station or skip tracks in Media Mode.
5 — MORE
Push the MORE button on the faceplate to access addi-
tional options such as: Trip, Clock, Outside Temp or
Compass.
6 — PHONE
Push the PHONE button to access the Uconnect Phone
feature.
7 — NAVIGATION
Push the NAV button to access the navigation feature.
14 INTRODUCTION

8 — MEDIA
Pushing the MEDIA button will allow you to switch to
Media mode (USB/iPOD, AUX or Bluetooth.)
9 — RADIO
Push the RADIO button on the faceplate to enter Radio
Mode. The different tuner modes; AM, FM and SXM – If
Equipped can be selected by pushing the corresponding
button on the touchscreen while in the Radio Mode.
10 — ON/VOLUME
Rotate the rotary knob to adjust the Volume. Push the
ON/VOLUME button to turn on the system. Push the
ON/VOLUME button a second time to turn off the
system.
11 — MUTE
Push the MUTE button for activation/deactivation of the
volume.
2
INTRODUCTION 15

ALL ABOUT UCONNECT
CONTENTS
䡵WHAT IS UCONNECT? ...................18
䡵IDENTIFYING YOUR RADIO ...............20
3

WHAT IS UCONNECT?
Before you drive, familiarize yourself with the easy-to-
use Uconnect System.
•The Uconnect Voice Command And Uconnect Phone
Buttons On Your Steering Wheel
•The buttons let you use your voice to give commands,
make phone calls, respond to text messages hands-
free, enter navigation destinations and control your
radio and media devices.
1 — Push To MUTE
2 — Push To Initiate Or To Answer A Phone Call, Send Or Re-
ceive A Text
3 — Push To Begin Radio, Media, Navigation, Apps And Climate
Functions
4 — Push To End Call
18 ALL ABOUT UCONNECT

1 — Uconnect Phone Hang Up Button 8 — Settings Button
2 — Uconnect Voice Command Button 9 — Back Button
3 — Uconnect Phone Mute Button 10 — Browse/Enter — Tune/Scroll
4 — Uconnect Phone Pick Up Button 11 — More Button
5 — Volume Knob 12 — Media Button
6 — Mute Button 13 — Audio Jack
7 — Screen On/Off Button 14 — USB Port
3
ALL ABOUT UCONNECT 19
