USER’S MANUAL
UCONNECT®4.3/8.4

Introduction
CONTENTS
䡵Uconnect威4.3...........................2
▫(1) ON/OFF & VOLUME .................3
▫(2)(3) CLIMATE CONTROLS ...............3
▫(4)PLAYER...........................3
▫(5) RADIO ............................3
▫(6) SETTINGS..........................3
▫(7) MORE.............................3
▫(8) SCREEN OFF .......................4
▫(9) ENTER/BROWSE & TUNE/SCROLL ......4
▫(10) CD SLOT..........................4
䡵Uconnect威8.4 & 8.4Nav ....................5
▫(1) ON/OFF VOLUME ...................6
▫(2) CLIMATE CONTROLS (Manual Controls) . . .6
▫(3) RADIO ............................6
▫(4)PLAYER...........................6
▫(5) CONTROLS.........................6
▫(6) CLIMATE (On-Screen Controls)...........7
▫(7)NAV..............................7
▫(8) PHONE ...........................7
▫(9) MORE.............................7
▫(10) ENTER/BROWSE & TUNE/SCROLL......7
▫(11) SD CARD SLOT .....................7
▫(12) CD/DVD SLOT .....................7
1

Uconnect姞4.3
1 — ON/OFF & Volume Control 5 — Radio hard-key 8 — Screen Off hard-key
2 — Manual Climate Controls 6 — Settings hard-key 9 — Enter/Browse & Tune/Scroll knob
3 — Climate Controls hard-key 7 — More hard-key 10 — CD slot
4 — Player hard-key
2 Introduction

(1) ON/OFF & VOLUME
Press the ON/OFF button to turn the system ON or OFF.
Rotate the rotary knob to adjust the Volume.
NOTE: If the ignition is switched OFF with the radio in
standby mode, the radio memorizes the standby mode
when the ignition is turned ON again. Press the ON/OFF
VOLUME Control to turn the radio ON. It is possible to
eject the CD and to display the time if the system is off.
(2)(3) CLIMATE CONTROLS
Manual Climate Controls and Climate Control Hard-key.
Refer to Climate Controls in your vehicles Owner’s
Manual on the DVD for further details.
(4) PLAYER
Press the PLAYER hard-key to access media sources such
as: Disc, USB Device and AUX as long as the requested
media is present.
(5) RADIO
Press the RADIO hard-key to enter the Radio Mode. The
different tuner modes; AM, FM and SAT can be selected
by touching the corresponding soft-keys in the Radio
Mode.
(6) SETTINGS
Press the SETTINGS hard-key to access the Settings list.
Clock, Display, Audio, Bluetooth and SiriusXM™ Settings
are described in this manual. See your vehicles Owner’s
Manual on the DVD for more details.
(7) MORE
Press the MORE hard-key to access additional options.
Options available such as: Uconnect威Phone and Com-
pass can be accessed by touching the corresponding
soft-key in the More Menu.
1
Introduction 3

(8) SCREEN OFF
Press the SCREEN OFF hard-key to turn the touch-screen
OFF. To turn the screen back ON, just touch the screen.
(9) ENTER/BROWSE & TUNE/SCROLL
Press the ENTER/BROWSE button to accept a high-
lighted selection on the screen. Rotate the TUNE/
SCROLL rotary knob to scroll through a list or tune a
radio station.
(10) CD SLOT
When inserting a disc, make sure the label is facing up.
Press the Eject button to eject the disc.
4 Introduction

Uconnect姞8.4 & 8.4Nav
1 — ON/OFF & Volume Control 5 — Controls soft-key 9— More soft-key
2 — Manual Climate Control 6 — Climate soft-key 10— Enter/Browse & Tune/Scroll knob
3 — Radio soft-key 7 — Nav soft-key 11 — SD Card slot
4 — Player soft-key 8 — Phone soft-key 12 — CD/DVD slot
1
Introduction 5

(1) ON/OFF VOLUME
Press the ON/OFF button to turn the unit ON or OFF.
Rotate the rotary knob to adjust the Volume.
NOTE: If the ignition is switched OFF with the radio in
standby mode, the radio memorizes the standby mode
when the ignition is turned ON again. Press the ON/OFF
VOLUME Control to turn the radio ON. It is possible to
eject the CD and to display the time if the system is off.
The navigation software is always working when the
ignition is switched ON, even if the radio is in standby
mode. It is possible to eject the CD and to display the
time if the unit is switched off.
(2) CLIMATE CONTROLS (Manual Controls)
Refer to Climate Controls in your vehicles Owner’s
Manual on the DVD for further details.
(3) RADIO
Press the Radio soft-key to enter the Radio Mode. The
different tuner modes; AM, FM and SAT can be selected
by touching the corresponding soft-keys in the Radio
Mode.
(4) PLAYER
Press the Player soft-key to access media sources such as:
Disc, USB Device and AUX as long as the requested
media is present.
(5) CONTROLS
Press the Controls soft-key to access the Settings list.
Controls such as; Heated Seats, Heated Steering Wheel,
Ventilated Seats, etc. can be selected or turned ON/OFF
by touching the corresponding soft-key.
6 Introduction

(6) CLIMATE (On-Screen Controls)
Refer to Climate Controls in your vehicles Owner’s
Manual on the DVD for further details.
(7) NAV
Press the Nav soft-key to access the Navigation feature.
Refer to the Navigation section in this manual for further
details.
(8) PHONE
Press the Phone soft-key to access the Uconnect威Phone
feature. Refer to the Uconnect威Phone section in the
Owner’s Manual on the DVD for further details.
(9) MORE
Press the More soft-key to access additional options.
Options available such as: Settings and SiriusXM™
Travel Link can be accessed by touching the correspond-
ing soft-key in the More Menu.
(10) ENTER/BROWSE & TUNE/SCROLL
Press the ENTER/BROWSE button to accept a high-
lighted selection on the screen. Rotate the TUNE/
SCROLL rotary knob to scroll through a list or tune a
radio station.
(11) SD CARD SLOT
Insert an SD Card containing audio media in order to
play them through the vehicles sound system.
(12) CD/DVD SLOT
When inserting a disc, make sure the label is facing up.
Press the Eject button to eject the disc.
1
Introduction 7

Uconnect姞4.3
CONTENTS
䡵Radio Mode............................11
▫Overview ............................11
▫Common Radio Functions ................11
▫Seek and Direct Tune Functions ............13
▫Setting Presets.........................15
▫Audio ..............................16
▫SiriusXM™ Satellite Radio Mode ...........17
䡵Disc Mode.............................22
▫Overview ............................22
▫Seek Up/Down........................23
▫Browse..............................23
▫Source ..............................24
▫Info ................................24
▫Shuffle ..............................24
▫Audio ..............................24
䡵USB/iPod Mode ........................25
▫Overview ............................25
▫Seek Up/Down........................25
▫Browse..............................26
▫Source ..............................26
2

▫Info ................................26
▫Shuffle ..............................26
▫Audio ..............................26
䡵AUX Mode ............................27
▫Overview ............................27
▫Source ..............................27
▫Audio ..............................27
䡵Bluetooth威Mode ........................28
▫Overview ............................28
▫Seek Up/Down........................28
▫Source ..............................29
▫Info ................................29
▫Audio ..............................29
䡵More & Settings.........................30
▫More Main Menu ......................30
▫Clock Setting .........................30
▫Settings Main Menu ....................31
▫Display .............................33
10 Uconnect姞4.3

Radio Mode
Overview
The radio is equipped with the following modes:
•FM
•AM
•SAT SiriusXM™ Satellite Radio (if equipped)
Touch the Radio hard-key, upper left corner, to enter the
Radio Mode. The different tuner modes; AM, FM, and
SAT, can then, be selected by touching the corresponding
soft-keys on the screen.
Common Radio Functions
The following operations offer the same functionality
across all Radio Modes, and further instructions are
provided where differences exit.
2
Uconnect姞4.3 11

ON/OFF & Volume Control
Push the ON/OFF Volume control knob to turn
on the radio. Push the ON/OFF Volume con-
trol knob a second time to turn off the radio.
The electronic volume control turns continuously
(360 degrees) in either direction, without stopping. Turn-
ing the Volume control knob clockwise increases the
volume, and anti-clockwise decreases it.
When the audio system is turned on, the sound will be
set at the same volume level as last played.
Enter/Browse & Tune/Scroll Control
Turn the rotary TUNE/SCROLL control knob
clockwise to increase or counterclockwise to
decrease the radio station frequency. Push the
ENTER/BROWSE button to choose a selection.
Info
Touch the info soft-key to display channel number/
frequency, song title, genre and artist. This feature is only
available in FM and SAT modes.
Exit
The Exit soft-key, provides a means to close the Direct
Tune Screen.
Go
Touch the green GO soft-key to allow you to commit an
entry, at which time, the radio will tune to the entered
Channel, and close the Direct Tune Screen. The GO
soft-key is only for SiriusXM™ Satellite radio mode.
12 Uconnect姞4.3

Seek and Direct Tune Functions
The Seek Up and Down functions are activated by
touching the double arrow soft-keys to the right and left
of the radio station display, or by pressing the left
Steering Wheel Audio Control (if equipped) up or down.
Seek Up
Touch and release the Seek Up soft-key to tune the radio
to the next listenable station or channel.
During a Seek Up function, if the radio reaches the
starting station after passing through the entire band two
times, the radio will stop at the station where it began.
Fast Seek Up
Touch and hold the Seek Up soft-key to advance the radio
through the available stations or channels at a faster rate,
the radio stops at the next available station or channel
when the soft-key is released.
Seek Down
Touch and release the Seek Down soft-key to tune the
radio to the next listenable station or channel.
During a Seek Down function, if the radio reaches the
starting station after passing through the entire band two
times, the radio will stop at the station where it began.
Fast Seek Down
Touch and hold the Seek Down soft-key to advance the
radio through the available stations or channel at a faster
rate, the radio stops at the next available station or
channel when the soft-key is released.
2
Uconnect姞4.3 13

Direct Tune
The Direct Tune soft-key screen is available in AM, FM,
and SAT radio modes and can be used to direct tune the
radio to a desired station or channel. Press the Tune
soft-key located at the bottom of the radio screen.
Press the available number soft-key to begin selecting a
desired station. Once a number has been entered, any
numbers that are no longer possible (stations that cannot
be reached) will become deactivated / grayed out.
If you accidently entered the wrong station number,
touch the CLR soft-key to clear the radio station numbers
and reenter the correct station number.
Once the last digit of a station has been entered, the
DIRECT TUNE screen will close and the system will
automatically tune to that station.
The selected Station or Channel number is displayed in
the Direct Tune text box.
14 Uconnect姞4.3

Setting Presets
The Presets are available for all Radio Modes, and are
activated by touching any of the four Preset soft keys,
located at the top of the screen.
When you are receiving a station that you wish to
commit into memory, press and hold the desired num-
bered soft-key for more that 2 seconds or until you hear
a confirmation beep.
The Radio stores up to 12 presets in each of the Radio
modes. A set of 4 presets are visible at the top of the radio
screen.
2
Uconnect姞4.3 15

All Presets Button
Touching the ⬙all⬙soft-key on the radio home screen will
display all of the preset stations for that mode.
Return to Main Radio Screen
You can return to the Main Radio Screen, by either
touching Exit soft-key or pressing the Radio hard-key.
Audio
1. Press the SETTINGS hard-key on the right side of the
unit.
2. Then scroll down and press the Audio soft-key to get
to the Audio menu.
3. The Audio Menu shows the following options for you
to customize your audio settings.
•Equalizer
Touch the Equalizer soft-key to adjust the Bass, Mid
and Treble. Use the + or - soft-key to adjust the
equalizer to your desired settings. Press the back arrow
soft-key when done.
16 Uconnect姞4.3

•Balance/Fade
Touch the Balance/Fade soft-key to adjust the sound
from the speakers. Use the arrow soft-key to adjust
the sound level from the front and rear or right and
left side speakers. Touch the Center ⬙C⬙soft-key to
reset the balance and fade to the factory setting. Press
the back arrow soft-key when done.
•Speed Adjusted Volume
Touch the Speed Adjusted Volume soft-key to select
between OFF, 1, 2 or 3. This will decrease the radio
volume relative to a decrease in vehicle speed. Press
the back arrow soft-key when done.
4. Touch the Exit soft-key to exit from the Audio Menu.
SiriusXM™ Satellite Radio Mode
SiriusXM™ Satellite radio uses direct satellite-to-receiver
broadcasting technology to provide clear digital sound,
coast to coast. The subscription service provider is
SiriusXM™ Satellite Radio. This service offers over
130 channels of music, sports, news, entertainment, and
programming for children, directly from its satellites and
broadcasting studios. A one-year SiriusXM™ Satellite
Radio subscription is included.
SiriusXM™ and all related marks and logos are trademarks
of SiriusXM™ Radio Inc. and its subsidiaries. SiriusXM™
Radio requires a subscription, sold separately after trial
subscription included with vehicle purchase. Prices and
programming are provided by SiriusXM™ and are subject
to change. Subscriptions governed by Terms & Conditions
available at sirius.com/serviceterms. SiriusXM™ Radio
U.S. service only available to those at least 18 years of age
in the 48 contiguous United States, D.C., and PR. Service
available in Canada; see www.siriuscanada.ca.
2
Uconnect姞4.3 17

This functionality is only available for radios equipped
with a Satellite receiver. In order to receive satellite radio,
the vehicle needs to be outside with a clear view to the
sky.
If the screen shows Acquiring Signal, you might have to
change the vehicle’s position in order to receive a signal.
In most cases, the satellite radio does not receive a signal
in underground parking garages or tunnels.
No Subscription
Radios equipped with a Satellite receiver, require a
subscription to the SiriusXM™ Service. When the Radio
does not have the necessary subscription, the Radio is
able to receive the Traffic/Weather channel only.
Acquiring SiriusXM™ Subscription
To activate the SiriusXM™ subscription, call the toll free
number on the SiriusXM™ Settings. You will need to
provide the Sirius ID (SID) located on your vehicle’s
screen.
18 Uconnect姞4.3
