Uconnect 5.0 User manual

OWNER’S MANUAL
SUPPLEMENT
UCONNECT 5.0

TABLE OF CONTENTS
SECTION PAGE
1SAFETY GUIDELINES ..............................................................3
2IDENTIFYING YOUR RADIO ........................................................9
3RADIO MODE ...................................................................15
4MEDIA MODE ...................................................................21
5UCONNECT PHONE ..............................................................27
6UCONNECT 5.0/5.0 NAV VOICE RECOGNITION QUICK TIPS .............................33
7UCONNECT SETTINGS ............................................................41
8MORE BUTTON ..................................................................43
1
2
3
4
5
6
7
8

SAFETY GUIDELINES
CONTENTS
䡵SAFE USAGE OF THE UCONNECT SYSTEM......4
▫Touchscreen ............................4
▫Disc Player .............................4
▫FCC Declaration .........................5
▫Information About Radio Frequency Radiation....5
䡵CYBERSECURITY .........................6
1

SAFE USAGE OF THE UCONNECT SYSTEM
•Read all instructions in this manual carefully before
using your system to ensure proper usage!
•Permanent hearing loss may occur if you play your
music or the system at loud volumes. Exercise caution
when setting the volume on your system.
•Keep drinks, rain and other sources of moisture away
from your system. Besides damage to your system,
moisture can cause electric shocks as with any electronic
device.
NOTE: Many features of this system are speed dependent.
For your own safety, it is not possible to use some of the
touchscreen features while the vehicle is in motion.
Touchscreen
•Do NOT attach any object to the touchscreen, doing so
can result in damage to the touchscreen.
•Do not press the touchscreen with any hard or sharp
objects (pen, USB stick, jewelry, etc.) which could scratch
the touchscreen surface!
•Do not spray any liquid or caustic chemicals directly on
the screen! Use a clean and dry micro fiber lens cleaning
cloth in order to clean the touchscreen.
•If necessary, use a lint-free cloth dampened with a
cleaning solution, such as isopropyl alcohol or an iso-
propyl alcohol and water solution ratio of 50:50. Be sure
to follow the solvent manufacturer’s precautions and
directions.
Disc Player
•Do not insert any damaged, warped, scratched or dirty
discs into the Disc Player.
•Discs that have been modified with an adhesive label
should not be used in the Disc Player.
•Do not insert more than one disc at a time into the drive
slot.
4 SAFETY GUIDELINES

FCC Declaration
This device complies with Part 15 of the FCC Rules and
with Industry Canada license-exempt RSS standard(s).
Operation is subject to the following two conditions:
1. This device may not cause harmful interference.
2. This device must accept any interference received, in-
cluding interference that may cause undesired opera-
tion.
NOTE: This equipment has been tested and found to
comply with the limits for a Class B digital device, pursu-
ant to Part 15 of the FCC Rules. These limits are designed
to provide reasonable protection against harmful interfer-
ence in a residential installation. This equipment generates,
uses and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may
cause harmful interference to radio communications. How-
ever, there is no guarantee that interference will not occur
in a particular installation.
If this equipment does cause harmful interference to radio
or television reception, which can be determined by turn-
ing the equipment off and on, the user is encouraged to try
to correct the interference by one or more of the following
measures:
•Increase the separation between the equipment and
receiver.
•Consult the dealer or an experienced radio technician for
help.
Information About Radio Frequency Radiation
Exposure To Radio Frequency Radiation
The radiated output power of the this internal wireless
radio is far below the FCC radio frequency exposure limits.
Nevertheless, the wireless radio shall be used in such a
manner that the radio is 20 cm (200 mm) or further from
the human body.
The internal wireless radio operates within guidelines
found in radio frequency safety standards and recommen-
dations, which reflect the consensus of the scientific com-
munity.
1
SAFETY GUIDELINES 5

The radio manufacturer believes the internal wireless radio
is safe for use by consumers. The level of energy emitted is
far less than the electromagnetic energy emitted by wire-
less devices such as mobile phones. However, the use of
wireless radios may be restricted in some situations or
environments, such as aboard airplanes. If you are unsure
of restrictions, you are encouraged to ask for authorization
before turning on the wireless radio.
CYBERSECURITY
Your vehicle may be a connected vehicle and may be
equipped with both wired and wireless networks. These
networks allow your vehicle to send and receive informa-
tion. This information allows systems and features in your
vehicle to function properly.
Your vehicle may be equipped with certain security fea-
tures to reduce the risk of unauthorized and unlawful
access to vehicle systems and wireless communications.
Vehicle software technology continues to evolve over time
and FCA US LLC, working with its suppliers, evaluates
and takes appropriate steps as needed. Similar to a com-
puter or other devices, your vehicle may require software
updates to improve the usability and performance of your
systems or to reduce the potential risk of unauthorized and
unlawful access to your vehicle systems.
The risk of unauthorized and unlawful access to your
vehicle systems may still exist, even if the most recent
version of vehicle software (such as Uconnect software) is
installed.
WARNING!
•It is not possible to know or to predict all of the
possible outcomes if your vehicle’s systems are
breached. It may be possible that vehicle systems,
including safety related systems, could be impaired
or a loss of vehicle control could occur that may
result in an accident involving serious injury or
death.
•ONLY insert media (e.g., USB, SD card, or CD) into
your vehicle if it came from a trusted source. Media
of unknown origin could possibly contain malicious
software, and if installed in your vehicle, it may
increase the possibility for vehicle systems to be
breached.
•As always, if you experience unusual vehicle behav-
ior, take your vehicle to your nearest authorized
dealer immediately.
6 SAFETY GUIDELINES

NOTE:
•FCA or your dealer may contact you directly regarding
software updates.
•To help further improve vehicle security and minimize
the potential risk of a security breach, vehicle owners
should:
•
Routinely check www.driveuconnect.com/software-update
to learn about available Uconnect software updates.
•Only connect and use trusted media devices (e.g.
personal mobile phones, USBs, CDs).
Privacy of any wireless and wired communications cannot
be assured. Third parties may unlawfully intercept infor-
mation and private communications without your consent.
For further information, refer to “Onboard Diagnostic
System (OBD II) Cybersecurity” in your Owner’s Manual.
1
SAFETY GUIDELINES 7

IDENTIFYING YOUR RADIO
CONTENTS
䡵IDENTIFYING YOUR RADIO ................10
▫Uconnect 5.0 System With Integrated Center
Stack ................................11
▫Uconnect 5.0 System w/o Integrated Center
Stack ................................12
2

IDENTIFYING YOUR RADIO
Uconnect 5.0 w/Integrated Center Stack
Uconnect 5.0 w/o Integrated Center Stack
Key Features:
•5” Touchscreen
•Three buttons on either side of the display
•Hands-free/Bluetooth
•SiriusXM Satellite Radio (If Equipped)
10 IDENTIFYING YOUR RADIO

Uconnect 5.0 System With Integrated Center Stack
1 — RADIO
Push the RADIO button on the faceplate to enter Radio
Mode. The different tuner modes; AM, FM and SXM (if
equipped), can be selected by pressing the corresponding
buttons on the touchscreen in Radio Mode.
2 — COMPASS
Push the COMPASS button on the faceplate to display the
current direction of the vehicle.
3 — CLIMATE
Push the CLIMATE button on the faceplate to access the
Climate Controls.
4 — MORE
Push the MORE button on the faceplate to access
additional options.
5 — ENTER/BROWSE & TUNE/SCROLL
Push the ENTER/BROWSE button to accept a highlighted
selection on the screen. Rotate the TUNE/SCROLL rotary
knob to scroll through a list or tune a radio station.
6 — BACK
Push the BACK button to return to a previous menu or
screen.
7 — SCREEN OFF
Push the SCREEN OFF button to turn the touchscreen OFF.
To turn the touchscreen back ON, just press the screen.
8 — VOLUME/MUTE
Rotate the knob to adjust the Volume. Push the VOLUME/
MUTE button to mute the system.
2
IDENTIFYING YOUR RADIO 11

9 — PHONE
Push the PHONE button on the faceplate to access the
Uconnect Phone feature.
10 — MEDIA
Pushing the MEDIA button on the faceplate will allow you
to switch to Media mode (USB/iPOD, AUX, SD Card,
Bluetooth and CD — if equipped).
Uconnect 5.0 System w/o Integrated Center Stack
1 — RADIO
Push the RADIO button on the faceplate to enter Radio
Mode. The different tuner modes; AM, FM and SXM (if
equipped), can be selected by pressing the corresponding
buttons on the touchscreen in Radio Mode.
2 — COMPASS
Push the COMPASS button on the faceplate to display the
current direction of the vehicle.
3 — SETTINGS
Push the SETTINGS button on the faceplate to display the
customer programmable features.
4 — MORE
Push the MORE button on the faceplate to access
additional options.
5 — ENTER/BROWSE & TUNE/SCROLL
Push the ENTER/BROWSE button to accept a highlighted
selection on the screen. Rotate the TUNE/SCROLL rotary
knob to scroll through a list or tune a radio station.
12 IDENTIFYING YOUR RADIO

6 — BACK
Push the BACK button to return to a previous menu or
screen.
7 — SCREEN OFF
Push the SCREEN OFF button to turn the touchscreen OFF.
To turn the touchscreen back ON, just press the screen.
8 — VOLUME/MUTE
Rotate the rotary knob to adjust the Volume. Push the
VOLUME/MUTE button to mute the system.
9 — PHONE
Push the PHONE button on the faceplate to access the
Uconnect Phone feature.
10 — MEDIA
Pushing the MEDIA button on the faceplate will allow you
to switch to Media mode (USB/iPOD, AUX, SD Card,
Bluetooth and CD — if equipped).
2
IDENTIFYING YOUR RADIO 13

RADIO MODE
CONTENTS
䡵RADIO MODE OPERATION .................16
▫Volume/Mute ..........................16
▫Enter/Browse & Tune/Scroll Control..........16
▫Seek Functions .........................16
▫Setting Presets ..........................17
▫SiriusXM Satellite Radio Mode — If Equipped . . .17
▫SiriusXM All Access Package ...............18
▫Audio................................19
▫Clock Setting...........................20
3

RADIO MODE OPERATION
Push the RADIO button on the faceplate to enter Radio
Mode. The different tuner modes; AM, FM, and SXM, can
then be selected by pressing the corresponding button on
the touchscreen in the Radio mode.
Volume/Mute
Rotate the VOLUME/MUTE rotary knob to adjust the
Volume. When the audio system is turned on, the sound
will be set at the same volume level as last played.
Push the VOLUME/MUTE button to mute the system.
Push the VOLUME/MUTE button again to unmute the
system.
Enter/Browse & Tune/Scroll Control
Turn the rotary TUNE/SCROLL control knob clockwise to
increase or counterclockwise to decrease the radio station
frequency. Push the ENTER/BROWSE button to choose a
selection.
Seek Functions
Seek Up
Press and release the “Seek Up” button on the touch-
screen to tune the radio to the next listenable station or
channel.
During a Seek Up function, if the radio reaches the starting
station after passing through the entire band two times, the
radio will stop at the station where it began.
1 — Station Presets
2 — All Presets
3 — SEEK Up
4 — Audio
5 — Info
6 — Tune
7 — AM/FM/SXM
8 — SEEK Down
16 RADIO MODE

Fast Seek Up
Press and hold the “Seek Up” button on the touch-
screen to advance the radio through the available sta-
tions or channels at a faster rate, the radio stops at the
next available station or channel when the button on the
touchscreen is released.
Seek Down
Press and release the “Seek Down” button on the
touchscreen to tune the radio to the next listenable
station or channel.
During a Seek Down function, if the radio reaches the
starting station after passing through the entire band two
times, the radio will stop at the station where it began.
Fast Seek Down
Press and hold the “Seek Down” button on the touch-
screen to advance the radio through the available sta-
tions or channel at a faster rate, the radio stops at the
next available station or channel when the button on the
touchscreen is released.
Setting Presets
The Presets are available for all Radio Modes, and are
activated by pressing any of the four “Preset” buttons on
the touchscreen, located at the top of the screen.
When you are receiving a station that you wish to commit
into memory, press and hold the desired numbered button
on the touchscreen for more that two seconds or until you
hear a confirmation beep.
The Radio stores up to 12 presets in each of the Radio
modes. Four presets are visible at the top of the radio
screen.
Pressing the “All” button on the touchscreen will display
all of the preset stations for that mode.
SiriusXM Satellite Radio Mode — If Equipped
SiriusXM Satellite Radio uses direct satellite-to-receiver
broadcasting technology to provide clear, coast to coast
radio content. SiriusXM is a subscription based service.
3
RADIO MODE 17

SiriusXM All Access Package
All satellite radio equipped vehicles come with a one year
trial to the Sirius All Access package, providing over 160
channels of the best programming for all the places life
takes you.
•In your vehicle — You’ll get every channel available on
your radio, including all the premium programming like
Howard Stern, every NFL game, every MLB game, every
NASCAR race, Oprah Radio and more.
•On the go — With a SiriusXM Internet Radio subscrip-
tion included with the All Access trial, you’ll get
SiriusXM on your computer, smarthphone, or tablet.
Including:
•A huge On Demand catalog.
•Xtra Channels featuring SiriusXM Latino — A collection
of Spanish-language channels.
•MySXM — Allowing you to personalize your favorite
music channels.
Go to
www.siriusxm.com/getallaccess for more informa-
tion. SiriusXM services require subscriptions, sold sepa-
rately after the 12-month trial included with your new
vehicle purchase. If you decide to continue your service at
the end of your trial subscription, the plan you choose
will automatically renew and bill at then-current rates
until you call SiriusXM at 1-866-635-2349 to cancel. See
SiriusXM Customer Agreement for complete terms at
www.siriusxm.com . All fees and programming subject to
change. Our satellite service is available only to those at
least 18 and older in the 48 contiguous USA and D.C. Our
SiriusXM satellite service is also available in PR (with
coverage limitations). Our Internet radio service is avail-
able throughout our satellite service area and in AK and
HI. © 2016 SiriusXM Radio Inc. Sirius, XM and all related
marks and logos are trademarks of Sirius XM Radio Inc.
Service available in Canada; see
www.siriusxm.ca .
This functionality is only available for radios equipped
with a Satellite receiver. To receive satellite radio, the
vehicle needs to be outside with a clear view to the sky.
If the touchscreen shows “Acquiring Signal”, you may
have to change the vehicle’s position to receive a signal. In
most cases, the satellite radio does not receive a signal in
underground parking garages or tunnels.
18 RADIO MODE

Audio
1. Push the SETTINGS button on the right side of the
radio faceplate. If the settings button is not present,
push the MORE button on the faceplate then the
“Settings ” button on the touchscreen.
2. Scroll down and press the “Audio” button on the
touchscreen to open the Audio menu.
3. The Audio Menu shows the following options for you to
customize your audio settings:
•Equalizer
— Press the “Equalizer” button on the
touchscreen to adjust the Bass, Mid and Treble.
Use the “+” or “–” buttons on the touchscreen to
adjust the equalizer to your desired settings. Press
the “Back Arrow” button on the touchscreen
when done.
•Balance/Fade — Press the “Balance/Fade” button
on the touchscreen to adjust the sound from the
speakers. Use the “arrow” button on the touch-
screen to adjust the sound level from the front and
rear or right and left side speakers. Press the
Center “C” button on the touchscreen to reset the
balance and fade to the factory setting. Press the
“Back Arrow” button on the touchscreen when
done.
•Speed Adjustable — Press the “Speed Adjusted
Volume” button on the touchscreen to select be-
tween OFF, 1, 2 or 3. This will decrease the radio
volume relative to a decrease in vehicle speed.
Press the “Back Arrow” button on the touchscreen
when done.
•Loudness — Press the “Loudness” button on the
touchscreen to select the Loudness feature. When
this feature is activated it improves sound quality
at lower volumes.
3
RADIO MODE 19
