UDIAG BST300 User manual

Udiag BST300 Battery Tester
User Manual
www.udiagtech.com

Content
1 Introduction........................................................................................................................................... 3
1.1 Product Introduction......................................................................................................................... 3
1.2 Specification ...................................................................................................................................... 3
1.3 Product Function............................................................................................................................... 3
2 Operating Instruction........................................................................................................................... 4
2.1 Battery Test........................................................................................................................................ 4
2.1.1 Before Testing ................................................................................................................................ 4
2.1.2 Check Connection.......................................................................................................................... 4
2.1.3 Reverse Connection....................................................................................................................... 4
2. 1.4 Tester Startup ................................................................................................................................ 4
2.1.5 Hidden Function ............................................................................................................................. 4
2.1.6 IN-VEHICLE or OUT-OF-VEHICLE................................................................................................. 4
2.1.7 Select Battery Charge State .......................................................................................................... 5
2.1.8 Select Battery Type ........................................................................................................................ 5
2.1.9 Battery System Standard and Rating ........................................................................................... 5
2.1.10 Battery Test Result....................................................................................................................... 6
2.2. Cranking Test ................................................................................................................................... 7
2.3 Charging System and Rectifier Diode Test..................................................................................... 7
2.3.1 Test Procedures ............................................................................................................................. 7
2.3.2 Charging Test Result ..................................................................................................................... 8
3 FAQ........................................................................................................................................................ 8
3.1 Screen Not Light................................................................................................................................ 8
3.2 Current Clamp Common Fault ......................................................................................................... 8
4 Packing List .......................................................................................................................................... 8
5 Warranty................................................................................................................................................ 8
2

1 Introduction
1.1 Product Introduction
BST300 Battery Tester adopts currently the world's most advanced conductance testing technology
to easily, quickly and accurately measure the actual cold cranking amps capability of the vehicle
starting battery, health state of the battery itself, and common fault of the vehicle starting system
and charging system, which can help maintenance personnel to find the problem quickly and
accurately.
1.2 Specification
Voltage Measure Range: 6-16 DVC
Test battery Type: All lead-acid starter battery (Lead-acid, EFB, AGM, GEL...)
Technology: Conductance Technique
Temperature condition: -18℃~ +70℃
Cover Material: Acid-resistant ABS plastic
Tolerance: CCA<±10; Voltage±0.5%
Cable length: 0.75m(BST300)
Certificate: CE & ROHS
Language: English, French, Spanish, Italian, German
International standards and test range
Cranking
Amps
Standard
CCA 100-2000
BC
100-2000
CA 100-2000
MCA 100-2000
JIS
26A17--N200Z
DIN 100-1400
IEC 100-1400
EN
100-2000
SAE 100-1400
GB 30-220Ah
3
1.3 Product Function
 Battery test is mainly targeted to analyze the battery health status to calculate the actual cold cranking
capability of the battery and the aging extent, which provide reliable analysis evidence for the test and mainte-
nance of the battery. It notifies the user to replace battery in advance when the battery is getting aged.
 Cranking test is mainly to test and analyze the starting motor. Through testing the actual required cranking
current and cranking voltage of the starting motor, it can find out whether the starting motor works fine. There
are several reasons why the starting motor is abnormal: lubricating system fault causing the starting loaded
torque increasing or rotor friction of the starting motor causing the increasing friction of the starting motor itself.
 Charging test is to check and analyze the charging system, including generator, rectifier, rectifier diode,
etc., thus tofind out whether the output voltage of the generator is normal, the rectifier diode works fine and the
charging current is normal. Suppose one of the above mentioned parts is not in normal situation, it will lead to
overcharge or incomplete charge of the battery, thus the battery will be quickly damaged and also greatly short-
en the using life of other loaded electrical appliance.

2 Operating Instruction
2.1 Battery Test
2.1.1 Before Testing
 Clean battery poles with metal wire brush and alkaline cleaner to avoid the tolerance caused by oil and dust to
the test result.
 For Group31 or side-installed battery, connect and fix the terminal wiring connector. Otherwise, inaccurate test
result will be caused due to wrong installation or dirty or bad wiring connectors.
 While testing, ensure none of the in-vehicle electrical appliance is on, doors are closed and the ignition key is
in OFF status.
 Connect the red test clamp with battery anode and the black test clamp with cathode.
2.1.2 Check Connection
Shake the clamps back and forth to make sure they are well connected. Tester requires the two clamps are well
connected with the battery poles; otherwise, the test cannot go on. When enter the battery test program, screen
prompts "Check Connection" (See below picture).
Do clean the poles and re-connect in the right way.
2.1.3 Reverse Connection
Tester has reverse connection protection function. When clamps are reversely connected, tester will prompt
"Reverse Connection" (See below picture), but it damages neither the tester nor the automotive load.
NOTE: For parallel connected batteries, break off the cathode connection first, then do single test to each
battery. Suppose cathode connection is not cut off, there will be error in test result.
2. 1.4 Tester Startup
BST300－Connecting the test clamp with the battery.
2.1.5 Hidden Function
BST300: Press DOWN key to choose DISPLAY Resistance or Rated CCA.
2.1.6 IN-VEHICLE or OUT-OF-VEHICLE
After starting up, the battery will prompt to select batter location. Press UP/DOWN key to select in-vehicle or
out-of-vehicle, then press OK key to confirm.
 When surface charge detected by the tester, it prompts "SURFACE CHARGE, TURN LIGHTS ON".
 Turn lights on as prompted to eliminate battery surface charge, tester will then display the following messages
as below images.
 Now the tester detects the surface charge has been eliminated, turn lights off as prompted, then press OK key.
The tester will recover automatic test.
CKECK
CONNECTION
REERSE
CONNECTION
SURFACE CHARGE
DETECTED
TURN LIGHTS ON
HEADLIGHTS ON
TURN LIGHTS OFF
4

2.1.7 Select Battery Charge State
Press UP/DOWN key to select battery charge status: Before Charge or After Charge, then press OK key to
confirm. This way can ensure a more accurate test result.
NOTE: In Vehicle, select Before Charge for Cold Vehicle and After Charge for Hot Vehicle.
2.1.8 Select Battery Type
Press UP/DOWN key to select battery type, i.e. Regular Flooded, AGM Flat Plate, AGM Spiral, and Gel battery.
Press UP/DOWN key to select battery type and press OK key to confirm. When it's on IN-VEHICLE test, battery
installation way shall also be selected, e.g. TOP, SIDE or REMOTE (This selection is no need for
OUT-OF-VEHICLE), then press OK key to confirm. REMOTE is adopted for some in vehicle battery which is too
tightly installed to use the test clamps to connect the battery poles.
NOTE: For REMOTE test, there will be a little tolerance. For any doubt, take off the battery and select
"OUT-OF-VEHICLE" to re-test.
2.1.9 Battery System Standard and Rating
Use UP/DOWN key to select according to the actual system standard and rating marked on the battery. See in
the below picture, the arrow indicated location.
.
STLECT CHARGE
BEFORE CHARGING
SELECT CHARCE
AFTER CHARGING
CCA Cold Cranking Amps, specified by SAE&BCI, most frequently used value for
starting battery at 0°F (-18°C)
BCI Battery Council International standard
CA Cranking Amps standard, effective starting current value at 0°C
MCA
Marine Cranking Amps standard, effective starting current value at 0°CJapan Industrial
Standard, displayed on the battery as combination of the numbers and letters, e.g. 55D23,
80D26.
DIN German Auto Industry Committee Standard
IEC Internal Electro technical Commission Standard
EN European Automobile Industry Association Standard
SAE Society of Automotive Engineers Standard
GB China National Standard
CELECT INPUT
CCA
SET PATING
500A CCA
TESTING
***
Input correct test standard and rating, press OK key, tester starts to test, and dynamic interface
"TESTING" prompted. See above. 5

2.1.10 Battery Test Result
Testing Result Description
Battery test result includes 5 types as following
NOTE: If "Replace" resulted from IN-VEHICLE mode, it might be the reason that vehicle cable is not well
connected with the battery. Ensure to cut off the cable and retest the battery under OUT-OF-VEHICLE before
making a decision to replace battery.
After testing, if need to return, press “RETURN” key to directly return to the startup interface. If it is
"OUT-OF-VEHICLE" test state, press OK key, it will print the test result. If it is "IN-VEHICLE" test state, press OK
key will bring to Cranking Test.
State of Charging
Measured CCA
State of Health
Voltage
Result Rated CCA
SOH: 96% SOC: 98%
12.64V 490A
Rating 500A
GOOD BATTERY
Good battery
The battery is without any problem.
Please be relaxed to use!
GOOD BATTERY
SOH: 78% SOC: 30%
12.20V 440A
Rating 500A
GOOD, RECHARGE
Good, Recharge
Good battery but low current.
Recharge before using.
SOH: 46% SOC: 80%
12.68V 340A
Rating 500A
REPLACE
Replace
The battery is near to or already
reached the end of the using life.
Replace battery, otherwise, bigger
danger will be followed.
SOH: 0% SOC: 20%
10.60V 0A
Rating 500A
BAD CELL, REPLACE
Bad Cell, replace
Battery interior damaged, broken cell
or short circuit, replace battery
SOH: 39% SOC: 20%
12.08V 310A
Rating 500A
CHARGE-RETEST
Charge-Retest
Unstable battery shall be recharged
and retested to avoid error. If same
test result appears after recharge
and retest, the battery is regarded
as damaged. Replace the battery.
6

NOTE: If "Replace" resulted from IN-VEHICLE mode, it might be the reason that vehicle cable is not
well connected with the battery. Ensure to cut off the cable and retest the battery under
OUT-OF-VEHICLE before making a decision to replace battery.
After testing, if need to return, press “RETURN” key to directly return to the startup interface. If it is
"OUT-OF-VEHICLE" test state, press OK key, it will print the test result. If it is "IN-VEHICLE" test
state, press OK key will bring to Cranking Test.
2.2. Cranking Test
Connect with current clamp in advance. Under bad connection, tester will not test the actual
cranking amps accurately.
 Starting the engine as prompted, tester will automatically complete the cranking test and display
the result.
 Normally, cranking voltage value lower than 9.6V is regarded as abnormal, higher than 9.6V is OK.
Test result includes actual cranking voltage, actual cranking amps, and actual cranking time.
 When cranking test is abnormal, battery test result will also be displayed at the same time. See
below image
After testing finished, do not shut down the engine, press OK key to enter Charging Test.
2.3 Charging System and Rectifier Diode Test
2.3.1 Test Procedures
 When enter the charging test, tester will prompt "Charging Test?" Press OK key to start the
charging test.
NOTE: Do not shut down the engine during the test. All electrical appliance and device are in OFF
state. Turn on/off any electrical appliance in the vehicle during the test will affect the accuracy of the
test result.
 Tester will do the following tests in a sequence: For ripple test, tester will display the real time ripple
and meanwhile, shows ripple volt and charging volt values at the bottom line.
 After the ripple test, tester will automatically start the loaded voltage test.
 Loaded Volt Test takes about 3 seconds, then it hints "Step on accelerator to increase engine
rotating speed". Operate accordingly to increase the engine rotating speed to 3000turns or
above, and keep for 5 seconds.
 Tester starts the charging volt test after increase rev detected. The result displays the effective
charging volts, ripple test result and charging test result.
 If no increase rev detected, it shall be the fault of generator regulator or connection with battery
failed. Tester will try 3 times to further detect, if still failed, it will skip the increase rev detect and
the test result displays "No Volt Output". Check the connection between generator and battery,
then retest.
CRANKING TEST
START ENGINE
RPM DETECTED
TTMES 780MS
AMPS 540A
CRANKING NORMAL
10.13.V
TIMES 1020MS
AMPS 320A
CRANKING LOW
REPLACE 9.12V
CHARGING TEST ?
7

2.3.2 Charging Test Result:
 Charging Volt: Normal. The generator output normal, no problem detected.
 Charging Volt: Low. Check drive belt of the generator whether slip or running off. Check the
connection between generator and battery is normal or not. If both of the drive belt and the
connection are in good condition, follow the manufacturer's suggestion to eliminate generator
fault.
 Charging Volt: High. Since most of the vehicle generators are using internal regulator, the
generator assembly has to be replaced.(Some old style cars are using external regulator, then
directly replace the regulator.) The normal high volt of the voltage regulator is maximum
14.7±0.5V.If charging volt is too high, it will overcharge the battery. Therefore, the battery life will
be shortened and troubles will be caused.
 No Volt Output. No generator volt output is detected. Check the generator connection cable, the
drive belt of generator and engine whether normal or not.
 Diode Test: Through the test of charging current ripple, tester will find out whether the diode is
normal or not. When ripple volt is too high, it proves at least one diode is damaged. Check and
replace the diode.
**************************************************************************************************
3 FAQ
3.1 Screen Not Light
Check whether the Power is turned on.
 Check connection with the battery whether it's well connected.
 Battery voltage is too low to drive the tester (< 1.0V). Fully charge the battery and retest.
 Internal 9V battery may need to be replaced. Replace the 9V battery and retest.
3.2 Current Clamp Common Fault
"Low Voltage" indicator flashes, replace the internal 9V battery of the current clamp.
 Displayed current value is 0A/1A/2A, or over 900A, or messy code, no Reset before the test or the
actual current exceeds the measure range.
4 Packing List
5 Warranty
This warranty is expressly limited to persons who purchase Udiag products for purposes of resale or
use in the ordinary course of the buyer’s business. Udiag electronic product is warranted against
defects in materials and workmanship for one year from date of delivery to the user. This warranty
does not cover any part that has been abused, altered, used for a purpose other than for which it was
intended, or used in a manner inconsistent with instructions regarding use. The exclusive remedy for
any automotive part found to be defective is repair or replacement, and Udiag shall not be liable for
any consequential or incidental damages.
●1X BST300 battery tester main unit
●1X User Manual
NOTE: Carefully check the device parts list
before using. Any doubt, contact us
immediately.
8
