UFO MicroLED 1000P User manual

UFO LIGHTING
FIBRE OPTIC &LED LIGHTING SYSTEMS
REVISION B2
MICROLED 1000P LIGHT SOURCE
USER GUIDE
PLEASE READ THIS USER GUIDE BEFORE INSTALLING, OPERATING OR
PERFORMING MAINTENANCE ON THE LIGHT SOURCE UNIT
.

INTRODUCTION
Than you for purchasing this UFO light source.
The UFO MicroLED range of light sources utilises an RGBW LED array and is suitable
for use with either glass or PMMA fibre optic harness.
MicroLED light sources require a 100-240V AC power connection to power the PSU or driver.
To ensure that the light source is set up optimally and gives a long service life, please read this
user guide before installing, operating or performing any maintenance on the unit.
This light source is suitable for indoor use only unless it is situated in a weatherproof enclosure.
MODELS COVERED BY THIS USER GUIDE
UFO MIC 1000P
IMPORTANT
This product must be installed in accordance with the applicable installation code, by a person
familiar with the construction and operation of the product, and the hazards involved.
These light sources are not mains dimmable.
The LED array in this light source is not replaceable. When it reaches end of life the whole unit
must be replaced.
Type Y Attachme t: If the external flexible cable or cord of this luminaire or associated
PSU/driver is damaged. It shall be exclusively replaced by the manufacturer or his service agent
or a similar qualified person to avoid a hazard.
Locatio : Do not locate this light source closer than 200mm from any flammable surface.
Cleara ce / Ve tilatio : It is imperative that a gap of 200mm is le around the unit. This is to
allow air to circulate and prevent overheating. The location must have free ventilation and must
not have an ambient temperature higher than that specified for the luminaire.
Mou ti g: This is a fixed luminaire. See mounting plate instructions on page 3 for fixing to a
surface.
War i g: Never loo directly into the luminaire LED light source.
War i g: The luminaire should be positioned so that prolonged staring into the
luminaire at a distance closer than 0.33m is not expected.
2MICROLED 1000P USER GUIDE

3UFO LIGHTING
INSTALLATION
ATTACH THE LIGHT SOURCE TO ITS MOUNTING PLATE [IF FIXED INSTALLATION]
The light source is powered either by a 12V power supply unit or a 12V constant voltage driver.
Power supplies are available to suit UK, European and USA power outlets. The UK model is
shown below.
POWER SUPPLY REQUIREMENTS
Plug the jac plug into the soc et in the bac of the light source, and the unit is now ready for
connection.

4UFO LIGHTING
INSTALLATION AND OPERATION
There are 2 connections required - the fibre port and the mains supply. The fibre port should be
connected first. Connect and secure the fibre optic connector into the front of the unit and
secure using the M5 loc ing screw.
Plug the mains plug into the electrical supply soc et. Switch on the power, the LED indicator
will illuminate, and the light source will start up automatically. If no light is produced consult
the troubleshooting section of this manual.
Note that these light sources are not mains dimmable.
CONNECTION
The light source has 2 colour cycles, each with 3 different speed settings, the colours are
detailed in the table below:
OPERATION
Cyc e Co our 1 Co our 2 Co our 3 Co our 4 Co our 5 Co our 6 Co our 7
1 White Red Orange Jade Green Cyan B ue
2 Pink Red Orange Jade Green Cyan B ue
The light source is controlled using the 2 push buttons on the rear of the unit.
The upper button stops and starts the colour cycle.
The lower button is used to select the cycle speed as follows:
Push the lower button repeatedly until the colour white is displayed. The light source is now in
Cycle 1 Speed A as detailed in the table below. Each push reduces the speed. On the third push,
the colour red will be displayed. The light source is now in Cycle 2 Speed A.
At any time the cycle can be stopped on a colour and started again using the upper push
button.
Cyc e Speed A - Fastest Speed B - S ower Speed C - S owest
1 (White Start) Push once Push once Push once
2 (Red Start) Push once Push once Push once

TROUBLESHOOTING
MICROLED 1000P USER GUIDE 5
Note: please complete relevant troubleshooting procedures before returning the unit to us for
further investigation.
Prob em Possib e Cause(s) Remedy
Unit is dead -
LED power
indicator is not
i uminated
Mains supp y off Check supp y and reinstate
Loose mains p ugs Check p ugs
PSU fai ed Rep ace PSU
Unit is dead - no
ight output but
LED power
indicator is s
i uminated
LED array fai ure Rep ace LED unit
Poor ight
output on fibre
Unit needs c eaning
Carefu y c ean LED Lens
with dry c oth
C ean fibre common end
Fibre port connector not
p ugged in correct y
Ensure p ugged in correct y
and secured with ocking
screw
Staonary on
one co our
Upper buon has been
pressed Press upper buon once
LED driver has fai ed Rep ace LED unit
Co our cyc e
cannot be
stopped
LED driver has fai ed Rep ace LED unit

6UFO LIGHTING
TECHNICAL SPECIFICATIONS
Descripon Detai s
Port connector size 30mm diameter
Fibre type G ass / PMMA
Mains Supp y Vo tage 110-240 VAC, 47-63Hz, 0.58A
PSU Output 12V DC, 2A, 24W max.
Power Consumpon 2 - 5W in co our cyc e mode
Min Ambient Temperature -10°C
Max Ambient Temperature +45°C
Led Type RGBW
LED Life 50,000 hours typica
Contro / Effects Manua co our change
Materia ABS
Finish B ack, white or si ver
Dimensions (L x W x H) / Weight 132mm x 98mm x 67mm / 316g
MAINTENANCE
MAINTENANCE LOG
Date Maintenance Undertaken
Note: a record of all maintenance MUST be ept in the table above, indicating what maintenance
was underta en and when. This MUST be dated for warranty purposes.

NOTES
MICROLED 1000P USER GUIDE 7



