Ultimate Support Nucleus-Z Navigator 18116 Installation guide

Included Parts with the Keyboard Desk - BOX 3
Instructions for
Assembling Keyboard Desk
Keyboard Desk Main Surface x1
Keyboard Desk Leg - Left x1
Keyboard Desk Leg - Right x1
Keyboard Spreader Bar Assembly x1
Work Surface Stiffener x1
#8 x .75"Pan Head Wood Screw x50
Work Surface Bracket x4
Leg Leveler Assembly x4
Please check to see you have all parts before
starting. Once all parts are conrmed begin assembly.
970.776.1920 . www.ultimatesupport.com
Copyright 2017, Ultimate Support Systems . All Rights Reserved

Lay the left keyboard desk leg
down with the holes facing up.
Screw on two work surface
brackets. Then screw on leg
leveler assembly. Repeat on
right keyboard desk leg.
Lay keyboard desk main
surface down with holes and
grooves facing up. Place work
surface stiffener into keyboard
desk main surface center
groove. Use ten screws to
attach.
Attach left leg to main desk
surface using six provided
screws. Repeat on right leg.
Stand up keyboard desk.
Place spreader bar in between
both legs. Attach bar with four
screw on both sides.
Work Surface
Bracket ( 2 Per Side )
Pan Head Wood
Screw (#8 x .75")
Pan Head Wood
Screw (#8 x .75")
Center Grove
Pan Head Wood
Screw (#8 x .75")
Pan Head Wood
Screw (#8 x .75")
Work Surface
Stiffener
Keyboard Desk
Main Surface
Keyboard
Spreader Bar
Assembly
Leg Leveler
Assembly
Keyboard Desk
( Lef t Side)
