ULTRA BRIGHT UB-SFPL-S-4 Series User manual

LIGHT CHARACTERISTICS
Light Source 4-Ultra High Intensity 8mm LEDs
Lumens output 5 To 60 Lumens * Varies with
Brightness Levels
Available LED Colors White 3000 – 3500k
Light Mode Constant
Visible Range 300m-500m+ Depending on Settings
Horizontal Output (degrees) 360 Degrees
Vertical Divergence (degrees) 180 Degrees
LED Life Expectancy (hours) > 100,000 hrs
ELECTRICAL CHARACTERISTICS
Circuit Protection Integrated / Overcharge / Over
Discharge / Constant Current
Nominal Voltage (v) 3.2v
Power / Brightness Levels 7 Levels, User Adjustable with Magnet
Autonomy (hours) 8 to 60hrs *On full Charge
* Varies with brightness setting
Temperature Range -10 to 70 C
SOLAR CHARACTERISTICS
Solar Module Type Tempered Glass + Monocrystalline Cell
Power (watts) 1.10 Watts
Solar Module Efficiency (%) 17 – 18 % Super High Efficiency Cells
POWER SUPPLY
Battery Type LiFePo4 (Lithium Phosphate)
Battery Size 1pcs IFR 18500
Battery Capacity (mAh) 1000 mA
Nominal Voltage (v) 3.2v
Battery Service Life 3-6 years
*(Varies with local Environment & use)
Battery Service Access Yes: User Changeable / Replaceable
PHYSICAL CHARACTERISTICS
Body Material Die Cast Aluminum + Powder Coat
Lens Material Bayer UV Stabilized Poly Carbonate
External Lens Design Smooth / Clear
Internal Lens design Vertical 360 Deg. Lenticular
Water Proof Rating IP 68 – Fully Waterproof
Mounting Option 1: fits 3.5x3.5” or 4x4” post
Option 2: fits 5x5” post
Height 2-5/8”
Width / Width 5.50 x 5.50 “
Weight 1.20 lbs
OTHER
Other Options & Sizes Please Contact
2yr Limited Warranty * Information subject to change without notice
Picturedwith4x4”BaseonVinylPost
SOLAR FENCE POST LIGHT
www.solarfencelights.com
SolarFencePostLight:

UltraBrightTechnologiesSolarFencePostLightisthemost
advance,powerful,robust,solarlightavailable.PatentPending
magnettechnologyallowsuserstoeasilyadjustbetween7‐
brightnesslevelstomeetseasonalperformanceexpectations.

Tiredofreplacingsolarlightseveryyear?Noworries,UltraBright
Technologiessolarfencepostlightismadetolastaslongasyour
fence.Die‐CastAluminumConstruction,Advancelithiumphosphate
battery,fullywater‐proofIP68electronics,andtemperedglass
laminatedsolarpanelensureextraordinaryservicelife.

BaseConfiguredOption
•Option1:FitsPostSizes:3.5x3.5”Wood&4x4”VinylPost
•Model:UB‐SFPL‐S‐4‐X‐X
CopyrightProtectedDesign
PATENTSPENDING
UltraBrightTech
P.O.Box414
105W.SimonSt.
Laotto,IN46763
Phone:260‐918‐2758
Fax:260‐918‐3540
E‐mail[email protected]
Web:www.solarfencelights.com,www.ultrabrighttechnologies.com

1.2 Watt Tempered Glass
Solar Panel: Rated at 15yrs
Automatic night
activation
Set Screw
Internal Adaptor for
3.5x3.5” Wood Post 4 Super High
Intensity Jumbo
Size 8mm LED
IP 68 Fully Sealed &
Water Proof Electronics
Base Fits 4x4”
Vinyl Post Sleeves
Die Cast
Aluminum
Top Unit
Die Cast
Aluminum
Lens Cage
4‐10XMorePowerfulSolarPanel
5‐20XBrighterLight
10xLongerServiceLife
LithiumPhosphateBattery
7AdjustableBrightnessLevels
IP68WaterproofElectronics
SOLAR FENCE POST LIGHT
www.solarfencelights.com
Powder Coat Finish
*NOTE:Informationisageneralreferenceincomparisontothebestsolarfencepostlightswewereabletofindonthemarket.
CopyrightProtectedDesign
PATENTSPENDINGWaterProofing
IP684‐SeasonRated
Vapor Vent
Magnet Switch
Adjustable Brightness Levels
UltraBrightTech
P.O.Box414
105W.SimonSt.
Laotto,IN46763
Phone:260‐918‐2758
Fax:260‐918‐3540
E‐mail[email protected]
Web:www.solarfencelights.com,www.ultrabrighttechnologies.com

CAUTION:PLEASEKEEPOURENVIRONMENTCLEAN!BATTERIESMUSTBERECYCLEDORDISPOSEDOFPROPERLY.
InstallingBatteries&Cover
MountingHardwareSuggestions–NotIncluded
MountTypeHardwareStainlessSteelRecommended
NoThroughHole#6‐10SizeSetscrewsforsecuringtopost
NoThroughHoleWoodGlueorPVC‐Compositefriendlyglue
LiFePo4TypeBattery:
Volts:3.2vCellSize:18500Capacity:1000mA


DONOTUSE:standard1.2vNiMhorNiCdtypeRechargeablebatteries
Caution!Whenpluggingbatteryconnectors
together,alignnotchesbeforeconnectingboth
connectors.Failuretodosocouldresultin
permanentdamagetothelight.
BatteryInformation
BATTERY MAINTENANCE
For prolonged storage when not using the product please follow these procedures.
1. Charge Batteries inside product on sunny day.
2. Before nightfall, open the light and FULLY disconnect the battery from the product.
3. Store battery and product in warm/dry location.
4. Note: Batteries can be damaged from sub-zero temperatures when not in use.
Solar Fence Post Light
MODEL: UB-SFPL-L-X-X-X
UltraBrightTech
P.O.Box414
105W.SimonSt.
Laotto,IN46763
Phone:260‐918‐2758
Fax:260‐918‐3540
E‐mail[email protected]
Web:www.solarfencelights.com,www.ultrabrighttechnologies.com

Useascrewdrivertoremovethebase.Next,
removethereflectorandlens.Removethe6‐
screwsonbatterycoverandsiliconepad.
ConnecttheBattery:Caution!Alignnotchesbefore
joiningbothconnectors.Forcingorconnecting
backwardsmaydamagethelightortheconnector.
SOLAR PILING LITE – 8”
MODEL: LL-SPL-8-X-X
Replacethesiliconepadandbatterycoverinposition.Usea
screwdriverand6screwstotightenthecoverensuringthat
eachscrewisequallytightensuringawaterproofseal.
Useascrewdrivertoreattachthebottomtothefixture.
4
UltraBrightTech
P.O.Box414
105W.SimonSt.
Laotto,IN46763
Phone:260‐918‐2758
Fax:260‐918‐3540
E‐mail[email protected]
Web:www.solarfencelights.com,www.ultrabrighttechnologies.com
1
Fixture&Base
PhillipsScrewdriver
BatteryCover
&SiliconePad
Fixture
Battery
2
3

Power
Setting
*Run
Times
100%6‐8hrs
80%7‐9hrs
65%10‐12hrs
50%13‐14hrs
35%15‐17hrs
20%17‐22hrs
OFF OFF
6
3
SOLAR PILING LITE – 8”
MODEL: LL-SPL-8-X-X
NEWMAGNET
SWITCHOPERATION
CHANGINGBRIGHTNESSLEVELS

Wavethemagnetoverthesolar
panelatnightuntilyoufindthe
activationareawhichchanges
thebrightnesslevel.

Makeaquickup&downmotion
overthisareatochangebetween
brightnesslevels&OFF.

NOTE:movingtoo
slowlymayactivatethe
magnetswitchmultiple
timesgoingthrough
multiplelevelsatonce.
Aquickmotionwillhelp.
•TESTING:Placeentirelightinadarkroom.Lightshouldturnon,ifnot,swipethemagnetoverthesolarpaneluntillightturnson.
•Runtimeswillvarysignificantlybasedonfactorssuchas;SunExposure,Season,AngleofSunlight,GeographicLocation,Shading,
InstalledLocation/Position,BatteryCondition,andmostimportantlytheBrightnessSettingincomparisontotheyearlyseason.
•Thefollowingruntimesshouldonlybeusedasageneralreferenceandarenotguaranteed.Consideryourlocalenvironment
•Lowerbrightnesssettingsuselesspowerandleavemorereservepowerforcloudydayswherelessrechargingtakesplace.

NOTE:RUNTIMESAREBASEDONAFULLCHARGE:MANYFACTORSMAYPREVENTAFULLCHARGESEEBELOW
WaterProofElectronics
IP68
4‐SeasonRated
Adjustpower&runtimesonthefly!
UltraBrightTech
P.O.Box414
105W.SimonSt.
Laotto,IN46763
Phone:260‐918‐2758
Fax:260‐918‐3540
E‐mail[email protected]
Web:www.solarfencelights.com,www.ultrabrighttechnologies.com
Ensureallscrewsaretight,andbecarefulnotto
overtighten.Placelightontopof4x4composite
postcoveroruseadaptorfor4x4woodpost.
Placethelightontopofthepost.Markthehole
locationsonthepost.Drillasmallpilotholeforthe
setscrews.ReplaceLightandsecurewithscrews.
5
4x4
Post
Sleeve
4x4
Wood
Post

Owner Registration Card
Please fill out and affix proper postage and return this owner
registration card within 10 days to insure that your new Solar Fence
Post Light is covered by the limited warranty.
Purchaser’s Name .
Address .
State . Zip .
Purchase Date: . Number of Lights: .
Where Purchased (Store Name): .
Model No UB-SFPL-S-4-X-X
UPC No. Varies On Different Models
Ultra Bright Technologies
P.O. Box 414, Laotto, IN 46763
Ultra Bright Technologies 1-Year Limited Warranty
The retailer warrants the Solar Lights to be free from defects in workmanship and material present
at time of shipment from the factory for a period of one year after the date of purchase by the
original purchaser. We agree to correct such defects without charge or at our option replace with a
comparable or superior model if the product is returned to the retailer. To obtain warranty service,
you must present a copy of the receipt as proof of purchase. All costs of removing and reinstalling
the product are you responsibility. Damage to any part such as by accident or misuse or improper
installation or by affixing any accessories, is not covered by this warranty. There is no other
express warranty. The retailer hereby disclaims any and all warranties, including but not limited
to, those of merchantability and fitness for a particular purpose to the extent permitted by law. The
duration of any implied warranty, which cannot be disclaimed, is limited to the time period as
specified in the express warranty. Some states do no allow limitation on how long an implied
warranty lasts, so the above limitation may not apply to you. The retailer shall not be liable for
incidental, consequential, or special damages arising out of or in connection with product use or
performance except as may otherwise be accorded by law. Some states do not allow the exclusion
of incidental or consequential damage, so the above exclusion or limitation may apply to you.
This warranty gives specific legal rights, and you may also have other rights, which vary from
state to state. This warranty supersedes all prior warranties.
