Ultrakoki CS900 User manual

Ultrakoki A must-see for CS900 out of the box - A
1
Please take out the two rubber protection gaskets at
this position for storage. If you take the scale to travel,
please plug back the gasket for protection.
Please charge with the attached charging line. Please
note that the USB symbol of the line is facing up.
Please note that the charging head must be
inserted to the end
The charging symbol must be displayed when charging.
In order to protect the battery life, it takes about 4
hours to fully charge with a small current.
It can still be used in charging.
1. Read this article out of the box
2. Please refer to the instruction manual
before using CS900
3. For any usage and operation problems,
please read the problem guide

Ultrakoki A must-see for CS900 out of the box - B
2
The maximum load of a coffee scale is: 1 kg on the upper scale and 2 kg on the
lower scale. Because the upper scale is a floating design, it cannot achieve over-
loading protection, so when it is hit by more than 2 kg, it will cause Err2 damage.
In order to strengthen the
transportation protection, two black
rubber sheets will be added, which
must be removed during use and
installed during transportation.
The upper scale cup holder must not be
pressed by hand or lifted directly, not to be
impacted.

Ultrakoki up
Put on insulation rubber sleeve
1. Loosen the copper nut, remove the cup
holder, and replace the copper nut 。
2. Put on the red rubber protective sleeve 。
3. Put on the fixed rubber ring and put it into
the suitcase to cover with soft clothes 。
How is the rubber sleeve of the accessory used?
3
Fixing sequence for replacing the
cup holder
1. First tighten the copper nut at the back 。
2. Then tighten the front brass nut 。
UP scale travel protection mode
If the original black box cannot be used for packing, this
method can be used to properly protect the scale from
damage caused by putting it into the suitcase.
Ultrakoki
A must-see for CS900 out of the box - C

Ultrakoki A must-see for CS900 out of the box - D
You can scan the QR code on the box directly
You can also scan the QR code directly
Please select browser to open the page
Apple mobile phone
You can click this QR code and go
directly to applestore to download it
You can also directly search the coffeesecret
in the apple store to download the app
Android mobile phone
You can click the QR code to
enter the right page
You can click this location to
start downloading the app
How to download app?

Ultrakoki A must-see for CS900 out of the box - E
There are many steps to install the Android
version. Each mobile phone has some differences
Don't worry about the risk, continue to click
download
Don't worry about the warning, please
click Install
Coffeesecret.apk click download

Ultrakoki A must-see for CS900 out of the box - F
Turn on the scale, click app to connect
the Bluetooth
Enter the app and start searching for
the Bluetooth signal for 15 seconds
Search the scale code cs-900, click to
enter the binding link
Cs-900 is the basic name of the scale. If you want
to change the name, you can go to the setting
page of the app to make changes after connecting
After the normal connection, you can press the
function key of the scale to change the mode,
and the app will change accordingly
The weight display of app will only show the
weight change when the brewing starts, and
will not change in other times
How to bind app and scale?

Ultrakoki A must-see for CS900 out of the box - G
How to connect the thermometer?
The thermometer must be wired
together with the scale, not separately
1. Turn the thermometer on
2. Unbind the original
binding
3. After searching again, click the
scale and thermometer to
bind them together
4. After binding, the app displays
the temperature
5. Bluetooth symbol on
How to charge the battery ？
Magnetic
charge
Charge
display
