Underhill EasyOut 2in1 User manual

SPRINKLER REMOVAL TOOL
FOR ROTORS & SPRAY HEADS
Easy
The Ultimate Tool for Repairs & Modifications
It’s as Easy as 1-2-3-4!
Sprinkler Removal & Replace
No Digging
No Damage
to Turf
Saves Time
and Money
TELESCOPING ROD
minimizes dirt from
entering fitting
guides sprinkler body
SPECIAL ASSIST
TORQUE WRENCH Check out our
convenient
store display
options

Place tool over rod and inside sprinkler body
Rotate tool counter clockwise to remove body
STEP 2
Remove cap and inside components
Insert telescopic rod to desired length into sprinkler body & fitting
STEP 1
STEP 3
Place new sprinkler body over rod and into ground
Push down and rotate tool clockwise to connect sprinkler
body to pipe and remove rod
STEP 4
Replace new sprinkler components and cap
THE ULTIMATE ALL-IN-ONE DEVICE FOR REPAIRS/MODIFICATIONS
RAISE SPRINKLER
•
OPTION
It’s a snap with EasyOut™…
Easily increase the spray head height
to grade by removing the sprinkler
and screw on a standard PVC or
Cut-Off fitting to the bottom of the
sprinkler. Add additional fittings
to increase height.
Remove existing sprinkler Attach drip tubing to 7mm
barb drip fitting
Pass drip tubing through tool,
Attach drip fitting to Hex on
tool, Screw drip fitting/tubing
to pipe
Converting spray
heads to drip using
EasyOut™tool is
simple and fast.
SPRAY HEAD DRIP CONVERSION • OPTION
Scan for more info:
UNDERHILL INTERNATIONAL CORP.
www.underhill.us • tel: [phone]
Easy
SPRINKLER REMOVAL TOOL FOR ROTORS & SPRAY HEADS
Fits Major Spray Head( ½˝ inlet ) BrandsRotors
(¾˝ inlet)
&
Hunter
Rain Bird
Toro
K-Rain
Irritrol
Weathermatic
Hydro-Rain
Orbit
Fits all bodies up to max 2½˝ I.D.
Remove & Replace
Heads in minutes
or less
3
EasyCap™makes plugging off any
unwanted sprinklers super easy & fast…
A BIG labor savings.
Remove spray head and insert the
EasyCap™fitting (part # A-EO-05EC) to
the bottom of the EasyOut™ tool and
screw in the EasyCap™fitting…that’s it!
SPRAY HEAD CAP-OFF
•
OPTION ½˝
NPT
ordering
Part #:
A-EO-SRT-RS EasyOut™2in1 Sprinkler Removal
Tool for Rotors & Spray Heads
A-EO-05EC EasyCap™½” female FPT fitting
Form No. EO2in1-A20
