Uni-Com Micro-Switch/24 FEP-32024T User manual

!
Micro-Switch/24
!"#$%&'#()*())+,$-#
./-0'%$#12-'#3'4/&5/'#678'94#
:;<'%#+.=*+.=>?#
#
13@AB()!"CAB#
!
!
USER’S!MANUAL!
! !

!
!
!
!
!
!
!
!
!
!
!
!
!
! !
!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!! !
FCC Certifications
!
This Equipment has been tested and found to comply with the limits
for a Class A digital device, pursuant to part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against
harmful interference when the equipment is operated in a
commercial environment. This equipment generates, uses, and can
radiate radio frequency energy and, if not installed and used in
accordance with the instruction manual, may cause harmful
interference to radio communications.
Operation of this equipment in a residential area is likely to cause
harmful interference in which case the user will be required to
correct the interference at his own expense.
!
This device complies with Part 15 of the FCC Rules. Operation is
subject to the following two conditions: (1) this device may not
cause harmful interference, and (2) this device must accept any
interference received; including interference that may cause
undesired operation.
!
CE Mark Warning
This equipment complies with the requirements relating to
electromagnetic compatibility, EN 55022 class A for ITE, the
essential protection requirement of Council Directive 2004/108/EC
on the approximation of the laws of the Member States relating to
electromagnetic compatibility.
!
Company has an on-going policy of upgrading its products and it
may be possible that information in this document is not up-to-date.
Please check with your local distributors for the latest information.
No part of this document can be copied or reproduced in any form
without written consent from the company.
!
Trademarks:
All trade names and trademarks are the properties of their
respective companies.
Copyright © 2011, All Rights Reserved.
!
!
!
1

!
!
!
!
!
!
!
!
!
!
!
!
!
!
Key Features
!
!Complies with 10M BASE-T specifications of the IEEE 802.3
standard
!Complies with 100M BASE-TX specifications of the IEEE
802.3u standard
!Supports full and half duplex for 10/100Mbps
!Provides 256K Bytes packet buffer
!Wire-speed packet filtering and forwarding rate
!Provides 8K MAC address Table
!Store-and-forward architecture filters fragment & CRC error
packets
!Supports IEEE 802.3az energy efficient ethernet
!Supports auto MDI/MDI-X crossover detecting and auto
correction
!RoHS compliant
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
2

!
!
!
!
!
!
!
!
!
!
!
!
!
!
!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!! !
Front Panel
!
Please refer to the following description for the front panel:
!
!
Ethernet Ports:
This Switch includes 24* Fast Ethernet ports.
!
LED Definition:
!
LED Status Operation
Power
Steady Green
Power is on
Off
Power is off
Link/Act
Steady Green
The port is connected
Blinking Green
The port is transmitting/receiving data.
Off
No connection
!
Rear Panel
!
Power Connector:
Plug in the female connector of the provided power cord into this
connector, and the male into a power outlet. Supported input
voltages range from 100-240V AC, and 50-60 Hz. The rear panel is
shown as below:
!
!
!
!
!
!
!
!
3

!
!
!
!
!
!
!
!
!
!
!
!
!
! !
Installation
!
Before you install the switch, please check the following items in the
package：
!
"One 24-port Fast Ethernet Switch
"One Power cord
"One user manual
"Four rubber feet
"Rack-mount brackets and screws (optional)
!
In the following there are two ways for your installation. You can
select one that suits you.
!
Desktop Installation
!
1. Install the switch on a level surface that can support the weight of
the unit & the relevant components, and attach the rubber feet to
the bottom. The rubber feet cushion the switch and helps protect
the case from scratches.
2. Plug the switch to electrical source with the provided power cord.
!
Rack-Mount Installation
!
Rack mounting facilitate to an orderly installation when series of
network devices being installed.
!
1. Disconnect all the cables from the switch.
2. Place the unit the right way up on a hard, flat surface with the
front facing you.
3. Locate a mounting bracket over the mounting holes on one
side of the unit.
4. Insert the screws and fully tighten with a suitable screwdriver.
5. Repeat the two previous steps for the other side of the unit.
6. Insert the unit into the rack and secure with suitable screws
7. Reconnect all the cables.
!
Concerning about the installation environment, we strongly
recommend:
!
1. The switch is placed with appropriate ventilation environment. A
minimum 25 mm space around the unit is recommended.
2. The switch and the relevant components are away from sources
of electrical noise such as radios, transmitters and broadband
amplifiers.
3. Avoid from environments beyond recommend moisture.
!
4

!
!
!
!
!
!
!
!
!
!
!
!
!
!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!! !
Station Connection
!
Connect each station to the switch by twisted-pair cable. Plug one
RJ-45 connector into a RJ-45 port of the switch, and plug the other
RJ-45 connector into the station’s network adapter. Power on the
switch and then system is ready.
!
Switches Connection
!
In making a switch interconnection, you could use any port to
connect another switch with straight or crossover cable. As all the
ports support auto MDI / MDI-X function, using a straight cable to
make a switch-to-switch connection is allowed.
For cable selection, see the following table：
Network Speed
Cable Type
Max. Length
10Mbps
Cat. 3, 4, 5 UTP/STP
100 meters
100Mbps
Cat. 5 UTP/STP
100 meters
Network Application
!
5

!
!
!
!
!
!
!
!
!
!
!
!
!
! !
Specification
Standard
IEEE 802.3 10 BASE-T
IEEE 802.3u 100 BASE-TX
IEEE 802.3az(EEE)
IEEE 802.3x
Interface
24* 10/100 Mbps RJ-45 Ethernet ports
Cable
Connections
RJ-45 (10BASE-T): Category 3,4,5
UTP/STP
RJ-45 (100BASE-TX): Category 5
UTP/STP
!
Network Speed
!
10/100 Mbps Auto-negotiation
!
MAC Address
!
8K entries
!
Buffer Memory
!
256K Bytes
Dimension
267mm(L)*161.5mm(W)*42mm(H)
Temperature
Operating: 0℃~40℃ (32℉~104℉),
Storage: -40°C ~ 70°C (-40℉~158°F)
!
Humidity
Operating: 10% ~ 90% RH, non-condensing
Storage: 5%~95% RH, non-condensing
!
Power Supply
!
AC 100~240V/50~60Hz
EMI
FCC, CE Class A
!
!
!
!
6

565 Brea Canyon Rd., Ste A
Walnut, CA91789, USA
Phone: [phone] Fax: [phone]
www.unicomlink.com e-mail: [email protected]
www.unihomenetworkingbox.com
@UNICOM 2005. UNICOM and “A Network Systems Solution” are trademarks of UNICOM Electric, Inc.
All rights reserved. Specifications subject to change without notice.
Rev: 01.05
