Unibright DMX1RGBW User manual
Wall mounted RGB/W DMX512 controller
Parameter
Touch sensitive
Glass interface
Feature
DMX1RGBW
Control 4 zones synchronously and separately
Save up to 4 color in each zone
Part No. Operation Voltage DIMENSIONS
ø/h (mm)
OUTPUT
DMX1RGBW 12-24VDC 86x86x29.1
DMX512 Signal
Product Size
29.1
86.0
86.0
Installation
12-24VDC
Power Supply
Button introduction
Wiring diagram
D- GN D
Power Supply
12-24VDC
Vin D +
DMX1RGBW
GND
LN
110V-230VAC
Short press: switch on/off of
lighting
Long press:to dim brightness
of any zone
Short press: starting running mode
or pause mode, there are 10 bulid-in
modes
Long press:to adjust running speed.
Button 1,2,3,4 are zone numbers
Long press switch on/off each zone.
Short press is to choose a zone.
To synchronize several zones, short
press 2 or more buttons one after
another.
5
Pin1 :Data+
Pin2 :Data-
Pin7 :GND
Pin8 :GND
12345678
DMX
Fema le
SIGN AL DMX SI GNAL
Male
DMX
RJ45
SIGN AL
3
5
4
GND
GND
V+
V+
1/R -
2/G -
3/B -
4/W 1-
5/W 2-
+
Bac k Enter Up Down
D+
D-
D+
D-
GND
1
2
3
5
4
1
2
12345678
Pin1 :GND
Pin2 :D-
Pin3 :D+
Pin1 :GND
Pin2 :D-
Pin3 :D+
RGB/W or CDW LED strip
W
Power Supply
12-36VDC L
N
110V-230VAC
Pin1 :Data+
Pin2 :Data-
Pin7 :GND
Pin8 :GND
12345678
DMX
Fema le
SIGN AL DMX
Male
SIGN AL
DMX
RJ45
SIGN AL
3
5
4
GND
GND
V+
V+
1/R -
2/G -
3/B -
4/W 1-
5/W 2-
+
Bac k Enter Up Down
D+
D-
D+
D-
GND
1
2
3
5
4
1
2
12345678
Pin1 :GND
Pin2 :D-
Pin3 :D+
Pin1 :GND
Pin2 :D-
Pin3 :D+
RGB/W or CDW LED strip
W
Power Supply
12-36VDC L
N
110V-230VAC
DMXREC
DMXREC
Safety & Warnings
1) The product shall be installed and serviced by a qualified person.
2) IP20.Please avoid the sun and rain. When installed outdoors, please ensure it is mounted in a water proof
enclosure.
3) Always be sure to mount this unit in an area with proper ventilation to avoid overheating.
4) Please check if the output voltage of any LED power supplies used comply with the working voltage of the
product.
5) Never connect any cables while power is on and always assure correct connections to avoid short circuits
before switching on.
6)
7) For update information please consult your supplier.
Please ensure that the cable is secured tightly in the connector
Operation
After connect well with DMX decoders, please set the DMX decoders
address as below:
DMX decoder’s address 001 is controlled by Zone 1
DMX decoder’s address 005 is controlled by Zone 2
DMX decoder’s address 009 is controlled by Zone 3
DMX decoder’s address 013 is controlled by Zone 4
Short press zone number is to choose a zone, long press zone
number
is turn on/off that zone individually
To synchronize several zones, short press 2 or more buttons one after
another, then touch the color wheel
a.how to operate zone button
b.how to save color or mode
Choose a zone(for example zone1) to do the control, if you like a color or playing mode, long press S button,
until the indicator turns pink color , then touch any one of the number 1~4(for example 2), the led will flash
means saved. by this way each zone can save 4 colors or modes.,
How to get that saved color or mode :short press zone number---->short press S, then short press the number
you saved (for example 2 )
Zone number
indicator
UNI-BRIGHT bvba – Belcrownlaan 13Q, 2100 Antwerpen, Belgium
Tel : +323 641 61 40 Fax: +323 645 18 31 email: [email protected]
www.unibright.be
VERSION 1 - 02/24
