Unico PowerSpin C8604 User manual

PowerSpin™C8604
4 Place Horizontal Spin Centrifuge
OPERATION MANUAL
182 Ridge Road, Suite E, Dayton, NJ 08810, USA
800-588-9776 Fax: [phone] www.unicosci.com

2
⎯CAUTION ⎯
Read this manual completely before operating the centrifuge
Introduction:
UNICO®is constantly working to improve our products with the latest technological
innovations. UNICO®PowerSpin™C8604 Four place centrifuge is designed with
features to meet the safety and functionality needs in today’s medical and health care
industries.
Description/ Intended Use:
The UNICO® PowerSpin™C8604 Four place centrifuge with digital variable speed
control and electronic timer and zero RPM safety lid latch system are specially designed
to run for years of demanding laboratory work in clinical labs, industrial or biological labs
where separation for blood or other materials is desirable.
Features:
•Push button keypad controls, easy to use while wearing gloves
•Four place horizontal spin rotor for use with standard 50ml tubes
•Digital variable speed control with speed range from 1,000 RPM to 3,400 RPM
•Automatic Speed (RPM) and G-Force (RCF) real-time digital display
•Electronic 1-60 minute timer with beep signal at end of run
•Automatic time and speed memory reset to the last run for repetitive protocols
•Memorized time and speed settings: The centrifuge will memorize the last time and
speed settings when the unit is turned off. It will resume the previous time and speed
settings when the unit is turned on
•Maintenance free brushless AC motor
•Safety: Zero RPM lid latch protection - The centrifuge lid cannot be opened until the
unit stops spinning. It will not run unless the lid is properly closed.
•Suction cup rubber feet for stable bench top operation
•Power switch with indicator light tells when unit is powered on
•Power on/off switch located on back of unit
Construction:
The enclosure of the PowerSpin C8604 centrifuge is made of easy to clean and disinfect
high impact plastic. The internal rotor chamber is made of stainless steel. A safety device
is installed to prevent the lid from opening while the centrifuge is running. The motor is
mounted on rubber mounts to provide quiet running and less vibration. The Stainless
Steel rotor chamber can be easily cleaned and disinfected.
Accessories:
Each PowerSpin C8604 centrifuge comes equipped with a 4 place horizontal spin rotor
with pre-installed tube shields.

3
Unpacking and Installation:
The centrifuge is packed in cushioning Styrofoam in a box for maximum protection
during shipping. Please examine the unit upon receiving and retain all packing until the
unit has been tested. The warranty excludes any damage caused by shipping. Inspect for
any possible shipping damage. If you note any damage, please contact your sales
representative. Please save and store the original packaging. If it becomes necessary to
return the instrument to us, we ask that it be returned in the original packaging.
Unpack the shipping carton carefully and verify that the shipment is complete. It should
include the following items:
PowerSpin C8604 centrifuge 1 unit
Power cord 1 pc.
Operation Manual 1 pc.
Wrench 1 pc.
Screwdriver 1 pc.
Follow simple procedures below to prepare the centrifuge for use:
1. Remove the centrifuge from its packaging and place it on a sturdy flat, dry surface.
Do not plug-in or turn on the centrifuge!
2. MANDATORY: Place the centrifuge gently on its side. Using the enclosed
wrench, remove the two hex-pins in the center of the base. These are installed to
protect the unit during shipping and must be removed prior to using the centrifuge.
Please save these pins along with the packaging. You will need to re-install them if
the centrifuge will be shipped in the future.
3. Locate the small hole on the upper right corner of the left side of the centrifuge.
This is the Emergency lid latch manual override designed to open the
electronically controlled lid latch in the event of a power loss. Using a small
screw driver (or a rod with 4.5mm or less in diameter); insert the tool into the
emergency lid-opening hole as showed below. Push the tool to release the safety
lock and open the lid.
Special packing cushion foam is packed inside the rotor chamber of the centrifuge
to protect the rotor and shields during shipping.
REMOVE THIS FOAM PRIOR TO OPERATION OF THE CENTRIFUGE.
Top lid
Emergency
Lid-opening Front
4. The centrifuge rotor is pre-installed. No rotor installation or calibration is required.
5. The power inlet is located in the back of the centrifuge. Plug in one end of the
power cord to the inlet and the other end to an 115V power outlet.
Left Side

4
Caution: Make sure the voltage of the power source matches the voltage input of
centrifuge.
Control Panel and Key Pad Controls
The PowerSpin C8604 centrifuge control panel appears as per the diagram below:
ddd
Timer, Time Setting and Time Setting Change
Timer setting: Use the up or down arrow to preset the running time. The timer range is
1 to 60 minutes in 1 min. increments. While running, the display will show the
timer count down in real time.
Time setting review change during operation:
1) To check time setting during operation, press either up or down arrow.
2) To change timer setting during operation, press and hold the up or down arrow
button for more than 2 seconds. To increase time setting, press and hold up
arrow, otherwise, down arrow button.
Speed Setting and Speed Setting Change:
Speed Setting: Use the up or down arrow to preset the running speed. The speed range is
From 1,000 to 3,400 RPM in 100 RPM increments. The display will show
Actual running speed and RCF (g) force in real time.
Speed Setting Check and Change During Operation:
3) To check speed setting during operation, press either up or down arrow.
4) To change speed setting during operation, press and hold the up or down arrow
button for more than 2 seconds. To increase speed setting, press and hold up
arrow, otherwise, down arrow button.
Start Button: Press Start button to spin sample. The centrifuge will not spin if the lid is
not closed or not properly closed.
Speed Timer
START
STOP
OPEN
▼▲
RCF: xxxxx Status: Running
Spd: xxxx Time: xxxxx
▲ ▼

5
Note: Make sure the samples are balanced in the rotor!
Stop Button: Press to stop the centrifuge at anytime.
Open Button: Press the Open button to open the lid. The Open button will only open the
lid when the rotor is not spinning.
Emergency Lid-opening:
The lid features an electronically controlled safety system to prevent it from being
opened accidentally while the centrifuge is spinning. However, situations may
arise when the lid needs to be opened manually (For example if you lose electrical
power and samples are still in the centrifuge).
To open manually, locate the small hole on the upper right corner of the left side of
the centrifuge. Using a small screw driver (or a rod with 4.5mm or less in
diameter); insert the tool into the lid-opening hole; push the tool to release the
safety lock and open the lid.
Electronic Cycle Counter:
The centrifuge will count the total cycles of usage. To check the cycle usage, press
and hold Stop Button for 4 seconds, the total to date number of cycles will be
displayed. Note: Cycles of usage is not total spinning time. It represents the total
times the centrifuge has run.
Operation:
1. Plug the centrifuge into a grounded outlet. Make sure the voltage is correct
2. Turn the power switch on the rear panel of the unit “On”
3. Open the lid by pressing the Open button on the front control panel
4. Load your specimen tubes into the tube shields of the horizontal rotor
** CAUTION **
Make sure that the specimen tubes are balanced.
Always balance rotor with tubes of equal size, fill and weight!
(See safety section below)
5. Close the lid firmly
6. Set the timer to the desired time by pressing the up or down arrow
7. Set the speed to the desired RPM setting by pressing the up or down arrow
8. Press the Start button to start the run
9. After the centrifuge rotor has come to a complete stop (three beeping sounds),
the lid safety latch will automatically be released. It is now safe to open the
lid and remove your specimens
Note: When the centrifuge run is complete, the timer will be automatically reset to
the last timer setting and the centrifuge is ready for the next run.

6
Safety:
Your PowerSpin C8604 centrifuge is a carefully designed and built instrument. Please
take note of the following safety precautions.
Lid with zero rpm lid latch (electronically operated):
NEVER ATTEMPT TO OPEN THE LID UNTIL THE ROTOR HAS COME TO
COMPLETE STOP!
Load Balance:
Always make sure that the load is balanced before operating the instrument.
It is very important that tubes with equal loads are placed opposite each other in the rotor.
Also, when spinning a single specimen tube, another specimen tube of the same size filled
with water (or an equal volume of another liquid) must be in-place directly opposite from
the specimen tube to maintain balance. If the centrifuge is not properly balanced, damage
could occur.
CAUTION: If excessive noise or vibration is noticed during a run, immediately press
“Stop” to turn off the centrifuge and recheck the balance.
Maintenance:
Be sure to disconnect the power cord before attempting to clean the centrifuge.
This centrifuge is designed to be relatively maintenance free. The motor is a brushless
type and has permanently sealed bearings so oiling is not necessary. A surface cleaner
such as Formula 409 can be used to clean the outside of the instrument. The rotor chamber
and cover can be disinfected with a mild solution of bleach or other disinfecting liquid and
allowed to dry. Do not drench or immerse the unit in any liquid!
CAUTION: Do not use any cleaning “SOLVENTS” on any part of the centrifuge as the
chemicals can cause damage to the instrument.
Periodic Rotor and Tube Holders inspection and replacement
Rotors and Tube Holders should be removed and inspected for defects at least every 6
months or each time the rotor is removed for cleaning.
Calibration:
According to Code of Federal Regulations Title 21, centrifuges require verification or
calibration as follows:
1) Before initial use; 2) after repair or adjustments; and 3) 6 month after use. The
centrifuge timer, however, should be checked for accuracy at least every 3 month. The
timer is an electronic timer is designed to be accurate to 5min ± 10sec. The speed should
fall within ±100rpm of the speed display. Since the speed displayed on the centrifuge is
from a real time digital sensor mounted in the motor, it reflects the real running speed of
the rotor.

7
Electrical Shock Hazard:
Do not attempt to operate this instrument near water or liquid spill. Unplug the unit before
cleaning or repairing. Periodically check the condition of the power cord for cuts or
damage. Do not operate with a damaged cord.
Biohazard:
If a tube breaks, a biological hazard may exist. Unplug the instrument. Clean using
approved laboratory procedures. Always wear the proper protective clothing and gloves.
Use a suitable disinfectant and dispose of the sample properly. Refer to the guidelines set
forth by OSHA, etc.
Centrifuge Service:
If you feel that your centrifuge needs factory service, please contact the UNICO customer
service department for assistance. Simple problems may be resolved over the telephone. If
the instrument needs to be returned to UNICO, an R.G.A. (return goods authorization)
number will be issued. Please reference the R.G.A. number on the paperwork packed with
the instrument, and on the outside of the carton.
REPAIRS OR MODIFICATIONS MADE TO THE CENTRIFUGE BY AN
UNAUTORIZED PARTY WILL VOID THE WARRANTY.
Problem Solving:
1. Centrifuge does not start:
a) Check to determine if centrifuge is plugged in.
b) Check that lid is properly closed.
d) Check that Power switch in the back of unit is in the “on” position.
e) Check that the power indicator light (with the switch) is lit. A failure of the
power light to illuminate could indicate a need for a new fuse when the unit is
properly plugged in, switch is turned on and the lid is closed.
2. Excessive noise when running. If the noise is irregular or different in tone, be
sure that there is no paper or debris in the rotor or rotor chamber. Make sure
the load is balanced in the rotor.
3. Indicator light fails to light:
a) Unit is not turned on or no power supply.
b) Fuse is blown.
4. Fuse Replacement:

8
Caution: DISCONNECT THE POWER CORD BEFORE REPLACING FUSE.
Follow the procedures below to replace the fuse:
a) Unplug the power cord. Turn the on/off switch to “off”
b) Remove the power cord from the power inlet on the back of the centrifuge.
c) Locate the fuse holder. The fuse holder is a part of the power inlet.
On/off switch Inlet
Fuse Holder
d) Use a Philip type screwdriver to take the snap-in type holder cover off.
Remove the blown fuse and replace it with the same type and rating fuse
which is:
250V 4A
e) Put the snap-in fuse holder back.
5. Intermittent motor operation or no operation:
Contact your representative for possible motor replacement.
Specifications:
Speed: 1,000 - 3,400 RPM
Speed accuracy: +/- 25 RPM
Digital Timer: 1-60 Minutes
Rotor: 4 Place Horizontal Spin
Capacity: Four x 50ml
Dimension (L x W x H): 13 ¾ ” x 15” x 11”
Net Weight: 32 lbs.
|
O

9
Warranty:
This instrument is warranted against defects in materials and workmanship for a period of
one (1) year from the date of shipment to the customer. This warranty is limited to the
repair and replacement of parts, which prove to be defective during the warranty period.
This warranty is not valid for parts damaged, lost, or which fail because of accident, fire,
theft, acts of nature, negligence, or the use of chemicals, which have a deleterious effect.
This warranty is conditioned upon the manufacturer retaining the option of replacing parts
up to and including the entire instrument.
Note: This warranty will not extend to any repairs or modifications made to the instrument
by some party other than the manufacturer or a party authorized by Unico. Also, this
warranty shall be in effect only upon the notice of the defect to the manufacturer or it’s
authorized distributor, or dealer, within five (5) days after the occurrence of said defect
No other warranty of any kind is made expresses or implied. The warranty described
above shall be the sole and exclusive remedy available to the purchaser. Correction of
defects, in the manner and for the period of time described above, shall constitute
complete fulfillment of all liabilities and responsibilities of the manufacturer to the
purchaser with respect to the product, and shall constitute full satisfaction of all claims,
whether based on contract, negligence, strict liability or otherwise. In no event shall the
manufacturer be liable, or in any way responsible for any damages or defects in the
product that were caused by repairs or attempted repairs performed by anyone other than
the manufacturer’s dealer or station, nor shall the manufacturer be liable or in any way
responsible for any incidental or consequential economic or property damages. Some
states do not allow the exclusion of incidental or consequential damage, so the above
exclusion may not apply to you.

10
PowerSpin MX C8606, C8604, C8624 and M24 Trouble Shooting
Problem Cause Solution
1Error 1
(Initialization failure)
Initialization failure: Main control board
related.
1. Loose connection(s)
2. Defective transistor (TR1) (p/n
BATA06-600B)
3. Defective chip (U6) (p/n MOC3022)
4. Main board damaged
1. Check all connectors.
2. Replace TR1 transistor
on main board
3. Replace U6 chip on
main board
4. Replace the main
board
2Error2
(Lid unable to open)
Lid unable to open
1. Loose connection from lock to
main board
2. Lock-driven motor disengaged
or defective
3. Lock pin on lid “too long”
1. Secure the connection
(J4 on board)
2. Adjust or replace the
motor
3. Adjust the lid pin
(Use emergency opening
on left side)
3Centrifuge is unable to
sit on flat table surface
The transportation protection locking
screws not removed
Remove the two locking screws
located underneath the
centrifuge base.
4No power to
centrifuge 1. Power cord is not plugged in
2. On/Off switch is at Off
3. Fuse blew
1. Plug in the power cord
on the back.
2. Turn on the switch
3. Replace the fuse
5Touch button no
response (no response
sound)
1. Loose connection or connection
reversed.
2. Touch panel defective
1. Exercise the connector
(J2 on main).
2. Replace touch panel
6Display show
“Running” but motor
is not running.
1. Connector J6 loose
2. Transistor(TR1) failed
(BTA06-600B)
3. U6 chip failed (MOC3022)
4. Relay (K3) failed (p/n G2R-2-
12VDC)
1. Secure the connector
2. Replace the transistor
3. Replace the chip
4. Replace the relay
7Running normal but
no RPM /RCF display 1. Loose connection (J1) between
main and speed sensor board
2. Speed sensor (opt-coupler)
failed
3. Chip(U1 on main) failed (p/n
LM339)
1. Secure the connector
2. Replace the sensor
board
3. Replace U1 chip on
main board
8 Lid open but display
show READY 1. Loose connection: lock sensor
board to main board (J7)
2. Lock sensor opt-coupler
failed(MOCH25A)
1. Secure the connection
2. Replace the opt-
coupler (older version)
9Sample separation
failed 1. Running speed/RCF is not
enough
2. Running time is not enough
3. Rotor is not secured to the
motor shaft
1. Increase the RPM
2. Increase total running
time
3. Engage the rotor to
motor shaft.
10 Centrifuge shaking 1. Load is not balanced.
2. Short tube adapters not evenly
placed
3. Motor cushion failed
1. Balance the load.
2. Even the short tube
adapters.
3. Replace motor
cushions

11
UNICO PowerSpin™C8604 Centrifuge
Parts and Nomenclature
Lid
Rotor
Spindle
Nut
Emergency
Lid
opening
Manual
override
hole
RPM, RCF
and timer
display
window
Horizontal
Rotor
Power
indicator
light
Stop, Start
& Open
keys
Speed and
Timer
Setting
keys
