PowerSpin™C8624
24 Place Centrifuge
OPERATION MANUAL
182 Ridge Road, Suite E, Dayton, NJ 08810, USA
800-588-9776 Fax: [phone] Web: www.unicosci.com

2
⎯CAUTION ⎯
Read this manual before operating PowerSpin C8624 centrifuge
Introduction:
UNICO®has been providing quality laboratory equipment for the medical labs for 12
years. We are constantly working to improve our products with the latest technological
innovations. UNICO®PowerSpin™C8624 24 place centrifuge is released to meet the
needs and offer safety features needed in the fast growing medical and health care
industries.
Description/ Intended Use:
The UNICO® PowerSpin™C8624 24 place centrifuges with digital variable speed control
and electronic timer are specially designed to run for years of demanding laboratory work
in clinical labs, physician’s offices as well as in any chemical, industrial or biological labs
where separation for blood or other materials is desirable.
Features:
•Push button keypad controls.
•24 place angled rotor for use with standard 3 to 15 ml tubes (glass or plastic).
(An optional adapter is required for tubes less than 10 ml or 100mm length)
•Digital speed control with speed range from 1,000rpm to 3,400 rpm.
•Automatic and speed / RCF digital display simultaneously.
•Electronic 60 minutes timer with beeping signal at end of run.
•Automatic time and speed reset to the last time speed and time setting for repeated job.
•Memorized time and speed settings: The centrifuge will memorize the last time and
speed settings when the unit is turned off. It will resume the previous time and speed
settings when the unit is turned on.
•Maintenance free brushless AC motor
•Safety: Zero RPM lid latch protection - The centrifuge lid cannot be opened until the
unit stops spinning. It will not run unless the lid is properly closed.
•Suction cup rubber feet for stable bench top operation
•Power switch with indicator light tells when unit is powered on.
•Power on/off switch located on back of unit.
Construction:
The enclosure of the PowerSpin C8624 24 place centrifuges is made of high impact
plastic. The internal rotor chamber is made of stainless steel. A safety device is installed to
prevent the lid from opening while the centrifuge is running. The motor is mounted on
rubber mounts to provide quiet running and less vibration. The Stainless Steel rotor
chamber can be easily cleaned and disinfected.
Accessories:
Each Power Spin C8624 centrifuge comes equipped with angled rotor with 24-place tube
shields already installed.

Unpacking and Installation:
The centrifuge is first packed in Styrofoam and then put in a carton box for shipping.
Please examine the unit upon receiving and retain all packing until the unit has been
tested. The warranty excludes any damage caused by shipping.
Inspect for any possible shipping damage. If you note any damage, please contact your
sales representative. Save the original packaging. If it becomes necessary to return the
instrument to us, we ask that it be returned in the original packaging.
Unpack the shipping carton carefully and verify that the shipment is complete. It should
include the following items:
PowerSpin C8624 centrifuge 1 unit
Power cord 1 pc.
Operation manual 1 pc.
No on-site installation is required. Follow simple procedures below to set the centrifuge
up:
Note: The rotor is protected by cushion foam in the rotor chamber.
Do not operate the centrifuge before the foam is removed!!
1. Take the centrifuge from the Styrofoam and place it on a sturdy flat surface.
Do not turn on the centrifuge!
2. Use a small screw driver (or a rod with Ø4.5mm or less in diameter) to open the
lid. Insert the tool into the emergency lid-opening hole on the up-right corner on
the left side (as showed below). Push the tool to release the safety lock and open
the lid.
Special packing cushion foam is packed inside the chamber of the centrifuge to
prevent the rotor and shields from moving during shipping.
REMOVE THIS FOAM PRIOR TO OPERATION OF THE CENTRIFUGE.
Top lid
Emergency
Lid-opening Front
3
Left Side
3. The centrifuge rotor is pre-installed. No rotor installation or calibration is required.
4. The power inlet is located in the back of the centrifuge. Plug in one end of the
power cord to the inlet and the other end to an 115V power outlet.
Caution: Make sure the voltage of the power source matches the voltage input of
centrifuge.

Control Panel and Key Pad Controls
The C8624 centrifuge control panel looks like this:
4
ddd
OPEN
STOP
START
RCF: xxxxx Status: Running
Spd: xxxx Time: xxxxx
Speed Timer
▼▲▲ ▼
Timer, Time Setting and Time Setting Change
Timer setting: Use the up or down arrow to preset the running time. The timer range is
from 1 minutes to 60 minutes. The display will show counting down time.
Time setting review change during operation:
1) To check time setting during operation, press either up or down arrow.
2) To change timer setting during operation, press and hold the up or down arrow
button for more than 2 seconds. To increase time setting, press and hold up
arrow, otherwise, down arrow button.
Speed Setting and Speed Setting Change
Speed setting: Use the up or down arrow to preset the running speed. The speed range is
from 1,000rpm to 3,400rpm in 100rpm increments. The display will show
actual running speed and RCF (g) level.
Speed setting review change during operation:
3) To check speed setting during operation, press either up or down arrow.
4) To change speed setting during operation, press and hold the up or down arrow
button for more than 2 seconds. To increase speed setting, press and hold up
arrow, otherwise, down arrow button.
Start Button: Press Start button to spin sample. The centrifuge will not spin if the lid is
not closed or not properly closed.
Note: Make sure the samples are balanced!!

5
Stop Button: Stop the centrifuge at anytime.
Open Button: Open the centrifuge lid only when the centrifuge is not spinning.
Emergency Lid-opening:
The lid is designed to prevent it from being opened accidentally while the
centrifuge is spinning. There may be situation when the lid needs to be opened
manually (For example if you lose electrical power and samples are still in the
centrifuge).
To open the lid manually, use the lid-opening tool (or a small screw driver). Insert
the tool into the emergency lid-opening hole on the up-right corner on the left side
(as showed in Installation Section). Push the tool in to release the safety lock and
open the lid.
Electronic cycle counter:
The centrifuge will count the total cycles of usage. To check the cycle usage, press
and hold Stop Button for 4 seconds, the total to date number of cycles will be
displayed.
Note: Cycles of usage is not total spinning time. It represents the total times the
centrifuge has spun.
Operation:
1. Plug the centrifuge into a power source outlet. Make sure the voltage is correct.
2. Open the lid by pressing the Open button on the control panel.
3. Place the specimen tubes into the tube shields of the horizontal rotor.
CAUTION!!
Make sure that the specimen tubes are balanced.
Always balance rotor with tubes of equal size and equal fill.
(See safety section below)
4. Close the lid firmly.
5. Set the timer to the desired time by pressing the up or down arrow. To speed
up time setting, press and hold the arrow button.
6. Press the Start button to start the spin
7. After the centrifuge rotor has come to a complete stop (three beeping sounds),
the lid will automatically be released. Open the lid.
Note: When the centrifuge run is complete, the timer will be automatically reset to
the last timer setting and the centrifuge is ready for the next run.

6
Safety:
Your PowerSpin C8624 centrifuge is a carefully designed and built instrument. When
operated properly, it presents no safety hazards, however, please take note of these safety
precautions.
Lid with zero rpm lid latch (electronically operated):
NEVER ATTEMPT TO OPEN THE LID UNTIL THE ROTOR HAS COME TO
COMPLETE STOP!
Load Balance:
Always make sure that the load is balanced before operating the instrument.
It is very important that tubes with equal loads are placed opposite each other in the rotor.
Also, when spinning a single specimen tube, another specimen tube of the same size filled
with water must be installed directly across from the specimen tube to maintain balance. If
the centrifuge is not properly balanced, damage could occur. If excessive noise or
vibration is noticed during a run, stop the centrifuge and recheck the balance.
Maintenance:
Be sure to disconnect the power before attempting to clean.
This centrifuge is designed to be relatively maintenance free. The motor is a brushless
type and has permanently sealed bearings so oiling is not necessary. A surface cleaner
such as Formula 409 can be used to clean the outside of the instrument. The rotor chamber
and cover can be disinfected with a mild solution of bleach or other disinfecting liquid and
allowed to dry. Do not drench or immerse the unit in any liquid!
Calibration:
It is recommended that your centrifuge’s RPM be calibrated at least every 6 months. This
period is suggested by both the FDA and C.L.I.A. guidelines. The speed should fall within
±100rpm of the speed display. Since the speed displayed on Unico C8624 is from a real
time digital sensor mounted on the motor shaft, it reflects the real running speed of the
rotor. The timer is an electronic timer and no calibration is required.
Electrical Shock Hazard:
Do not attempt to operate this instrument near water or liquid spill. Unplug the unit before
cleaning or repairing. Periodically check the condition of the power cord for cuts or
damage. Do not operate with a damaged cord.
Biohazard:
If a tube breaks, a biological hazard may exist. Unplug the instrument. Clean using
approved laboratory procedures. Always wear the proper protective clothing and gloves.
Use a suitable disinfectant and dispose of the sample properly. Refer to the guidelines set
forth by OSHA, CLIA, etc.

7
Service:
If you feel that your centrifuge needs factory service, please call us and speak to a
customer service representative to determine the nature of the problem. Simple problems
may be resolvable over the telephone. If the instrument needs to be returned to Unico, a
R.G.A. (return goods authorization) number will be issued. Please reference the R.G.A.
number on the paperwork packed with the instrument, and on the outside of the carton.
REPAIRS OR MODIFICATIONS MADE TO THE CENTRIFUGE BY AN
UNAUTORIZED PARTY WILL VOID THE WARRANTY.
Problem Solving:
1. Centrifuge does not start:
a) Check to determine if centrifuge is plugged in.
b) Check that lid is properly closed.
d) Check that Power switch in the back of unit is in the “on” position.
e) Check that the power indicator light (with the switch) is lit. A failure of the
power light to illuminate could indicate a need for a new fuse when the unit is
properly plugged in, switch is turned on and the lid is closed.
2. Excessive noise when running. If the noise is irregular or different in tone, be
sure that there is no paper or debris in the rotor or rotor chamber. Make sure
the load is balanced in the rotor.
3. Indicator light fails to light:
a) Unit is not turned on or no power supply.
b) Fuse is blown.
4. Fuse Replacement:
Caution: DISCONNECT THE POWER CORD BEFORE REPLACING FUSE.
Follow the procedures below to replace the fuse:
a) Unplug the power cord. Turn the on/off switch to “off”
b) Remove the power cord from the power inlet on the back of the centrifuge.
c) Locate the fuse holder. The fuse holder is a part of the power inlet.

8
On/off switch Inlet
Fuse Holder
|
O
d) Use a Philip type screwdriver to take the snap-in type holder cover off.
Remove the blown fuse and replace it with the same type and rating fuse
which is:
250V 4A
e) Put the snap-in fuse holder back.
5. Intermittent motor operation or no operation:
Contact your representative for possible motor replacement.
Specifications:
Speed 1,000 - 3,400 RPM
Speed accuracy Real speed digital sensor
Digital Timer 1-60 Minutes
Rotor 24 place angled
Capacity 24 x 10ml (nominal)
3 – 15ml tube range
Dimension (L x W x H): 13 ¾ ” x 15” x 11”
Net Weight 31 lbs

9
Warranty:
This instrument is warranted against defects in materials and workmanship for a period of
one (1) year from the date of shipment to the customer. This warranty is limited to the
repair and replacement of parts, which prove to be defective during the warranty period.
This warranty is not valid for parts damaged, lost, or which fail because of accident, fire,
theft, acts of nature, negligence, or the use of chemicals, which have a deleterious effect.
This warranty is conditioned upon the manufacturer retaining the option of replacing parts
up to and including the entire instrument.
Note: This warranty will not extend to any repairs or modifications made to the instrument
by some party other than the manufacturer or a party authorized by Unico. Also, this
warranty shall be in effect only upon the notice of the defect to the manufacturer or it’s
authorized distributor, or dealer, within five (5) days after the occurrence of said defect
No other warranty of any kind is made expresses or implied. The warranty described
above shall be the sole and exclusive remedy available to the purchaser. Correction of
defects, in the manner and for the period of time described above, shall constitute
complete fulfillment of all liabilities and responsibilities of the manufacturer to the
purchaser with respect to the product, and shall constitute full satisfaction of all claims,
whether based on contract, negligence, strict liability or otherwise. In no event shall the
manufacturer be liable, or in any way responsible for any damages or defects in the
product that were caused by repairs or attempted repairs performed by anyone other than
the manufacturer’s dealer or station, nor shall the manufacturer be liable or in any way
responsible for any incidental or consequential economic or property damages. Some
states do not allow the exclusion of incidental or consequential damage, so the above
exclusion may not apply to you.

10
PowerSpin MX C8606, C8624 and M24 Trouble Shooting
Problem Cause Solution
1 Error 1
(Initialization failure)
Initialization failure: Main control board
related.
1. Loose connection(s)
2. Defective transistor (TR1) (p/n
BATA06-600B)
3. Defective chip (U6) (p/n MOC3022)
4. Main board damaged
1. Check all connectors.
2. Replace TR1 transistor
on main board
3. Replace U6 chip on
main board
4. Replace the main
board
2 Error2
(Lid unable to open)
Lid unable to open
1. Loose connection from lock to
main board
2. Lock-driven motor disengaged
or defective
3. Lock pin on lid “too long”
1. Secure the connection
(J4 on board)
2. Adjust or replace the
motor
3. Adjust the lid pin
(Use emergency opening
on left side)
3 Centrifuge is unable to
sit on flat table surface
The transportation protection locking
screws not removed
Remove the two locking screws
located underneath the
centrifuge base.
4 No power to
centrifuge
1. Power cord is not plugged in
2. On/Off switch is at Off
3. Fuse blew
1. Plug in the power cord
on the back.
2. Turn on the switch
3. Replace the fuse
5 Touch button no
response (no response
sound)
1. Loose connection or connection
reversed.
2. Touch panel defective
1. Exercise the connector
(J2 on main).
2. Replace touch panel
6 Display show
“Running” but motor
is not running.
1. Connector J6 loose
2. Transistor(TR1) failed
(BTA06-600B)
3. U6 chip failed (MOC3022)
4. Relay (K3) failed (p/n G2R-2-
12VDC)
1. Secure the connector
2. Replace the transistor
3. Replace the chip
4. Replace the relay
7 Running normal but
no RPM /RCF display
1. Loose connection (J1) between
main and speed sensor board
2. Speed sensor (opt-coupler)
failed
3. Chip(U1 on main) failed (p/n
LM339)
1. Secure the connector
2. Replace the sensor
board
3. Replace U1 chip on
main board
8 Lid open but display
show READY
1. Loose connection: lock sensor
board to main board (J7)
2. Lock sensor opt-coupler
failed(MOCH25A)
1. Secure the connection
2. Replace the opt-
coupler (older version)
9 Sample separation
failed
1. Running speed/RCF is not
enough
2. Running time is not enough
3. Rotor is not secured to the
motor shaft
1. Increase the RPM
2. Increase total running
time
3. Engage the rotor to
motor shaft.
10 Centrifuge shaking 1. Load is not balanced.
2. Short tube adapters not evenly
placed
3. Motor cushion failed
1. Balance the load.
2. Even the short tube
adapters.
3. Replace motor
cushions

PowerSpin C8624 Centrifuge
Parts and Nomenclature
Lid
Rotor
Emergency
lid-opening
(left side)
Control
panel
Start, Stop, Open buttons
Digital Timer & Speed Control
Safety
lock
On/off
switch
(on back
side)
Power
indicator
Model C8624
11
