Uniden ELITE 8815 Series User manual

Series Owner's Manual
OWNER'S MANUAL
ELITE 8815/8815+1

Welcome 1
Features 1
Terminology 2
Controls & Functions 3
Setting up the Phone 7
Expanding Your Phone 12
Optional Headset Installation 16
Using the Interface 17
Main Menu Options 22
System Setup Menu 23
Using the Bluetooth Feature 36
Using Your Phone 41
Using the Phonebook 55
Caller ID Features 62
Choose the best location 7
Install the rechargeable
battery pack 8
Low battery alert 9
Cleaning the battery charging
contacts 9
Connect the base and
charge the handset 10
Backwards/Forwards
Compatibility 12
Connect the expansion
handset's charger 13
Register the Handset 13
Register an Expansion handset
to main base 14
Changing the Digital Security
Code 15
Installing the Holster 15
Installing the Beltclip
(Extra Handset Only) 16
Example of the standby mode
display 17
Display Icons 18
Soft Key Function 19
Entering text 21
Using Bluetooth Headset 36
De-register the Bluetooth
Headset 40
Making Calls 41
Receiving a call/Open to
Answer set to OFF 43
Hanging Up 43
Switching to the Handset
Speakerphone During a Call 43
Moving out of range 44
Call Waiting 44
Placing a Call on Hold 45
Conferencing 46
Redialing Calls 48
Using the Handset Volume
Setting Menu 49
Mute 51
Mute the Microphone 51
Tone Dialing Switch Over
(Australia only) 52
Privacy Mode 52
Find Handset 52
Reminder (Handset only) 53
Creating and Editing Phonebook
Entries 55
Storing Caller ID or Redial
Numbers in the Phonebook 58
Storing and Editing Numbers
from the Dial Operation 58
Managing the Phonebook 59
Checking the number of
stored entries 60
Changing the sorting order 60
Naming phonebook groups 61
Making Calls with the
Phonebook 61
Using the Caller ID List 62
Deleting Caller ID numbers 63
Contents

Using One Touch Voice
Mail Access 63
Multi-Handset Features 64
Note on Power Sources 68
General Information 69
Troubleshooting 70
Index 75
Warranty 80
Using DirectLink Mode 64
Room/Baby Monitor 65
Intercom 66
Transferring a Call 67
Power Failure 68
Battery replacement and
handling 68
Warning 68
AC Adapter Information 69
Battery Information 69
Bluetooth Trouble Shooting 72
System Reset 73
Liquid Damage 74
Contents

Congratulations on your purchase of the Uniden cordless telephone. This cordless phone
is designed and engineered to exacting standards for reliability, long life, and outstanding
performance.
Note: Some illustrations in this manual may differ from the actual unit for
explanation purposes.
• 5.8GHz Digital Expandable
• Compatible with Bluetooth Enabled Headsets***
• Caller ID*
Caller ID on Call Waiting*
Name Tag (POP ID)**
Distinctive Ring**
• 100 Phonebook Names (4 Numbers Per Name)
• Recordable Ringer Tones
• Calendar with Schedule Reminder Capability
* The Caller ID and Caller ID on Call Waiting features require subscription to the
services provided by your network supplier. There is usually a fee for these services.
Caller ID on Call Waiting is currently unavailable in New Zealand.
** These features rely on the Caller ID service to function.
***The ELITE8815/ELITE88515+1 flip phone handset only is Bluetooth capable.
•
•
•
Be sure to visit our Website: www.uniden.com.au or www.uniden.co.nz
Welcome
Features
[1]

Terminology
• The handset is not in use. If it is off the cradle, no line has been
activated. No dial tone is present.
• A telephone line has been activated on the handset, enabling a dial tone.
ELITE8815+1 extra handset (ELITE8805 model)
trademarks are owned by their proprietor and used by Uniden Australia
and Uniden New Zealand under license.
Standby mode:
Talk mode:
Extra Handset:
BLUETOOTH
• Flip-phone handset. ELITE8815 and ELITE8815+1 main base handset.
•
Flip Handset:
WELCOME/FEATURES
/TERMINOLOGY
[2]

Controls & Functions
ELITE8815/ELITE8815+1 Flip Phone Handset
1. New Message LED
2. Speakerphone Speaker and Ringer
3. Sub LCD
4. Handset Earpiece
5. LCD display
6. key
(P.50 & 51)
7. (phonebook)/ (P.55 & 20)
8. (P.41 &44)
9. (P.20 & 45 & 66)
10. (P.52)
11. Soft keys (P.19)
12. (message)/ (P.63 & 20)
13. (P.20)
14. (Caller ID)/ (P.62 &20)
15. (P.48 &20)
16. (P.43)
17. (P.73)
18. Handset Microphone
19. Handset Charging Contacts
20. Handset Antenna
21. Headset Jack Cover
22. (speaker phone)(P.42)
23. Handset Battery Compartment
Speaker Volume up/down
Talk/flash
Back/hold/int'com
/tone
Menu/select
Cid
Redial/
End
#
*
[3]

24. Base Antenna
25. Base Charge Contacts
26. (handset)(P.52)
27. Handset Charge LED
28. Jack
29. Jack
30. Registration button
Find hs
AC ADAPTER
TEL LINE
CONTROLS & FUNCTIONS
[4]
27
29
28
30
25
24
26

ELITE8815+1 Extra Handset
1
2
3
4
5
8
7
13
14
10
11
9
17
19
18
16
15
6 12
1. New Message LED
2. Volume (up)(P.51)
3. Volume (down)(P.51)
4. (P.41 & 44)
5.
(P.20, 45 & 67)
6. (P.52)
7. Ear Speaker
8. Soft keys (P.19)
9. (P.43)
10. Joystick (P.20)
11. Phone (P.42)
12. (P.73)
13. Handset Microphone
14. Handset Charging Contacts
15. Handset Antenna
16. Beltclip Hole
17. Speakerphone Speaker and Ringer
18. Headset Jack
19. Handset Battery Compartment
Talk/flash
Back/hold/intercom
/tone
end
Speaker
#
*
[5]

ELITE8815+1 Extra Handset Charger
[6]
20. Charge LED
21. Charge Contacts
22. jackDC IN 9V
20
21
22
CONTROLS & FUNCTIONS

For maximum
range:
!
!
Do not hold the
handset where
you would block
the signal.
Metal and
reinforced
concrete may
affect cordless
telephone
performance.
Setting up the Phone
Choose the best location
When choosing a location for your new phone, here are some important guidelines you
should consider:
• The location should be close to both a phone jack and a continuous power outlet (one
which is not connected to a switch).
• The base and handset should be kept away from sources of electrical noise such as
motors, Microwave ovens, and fluorescent lighting.
• For better reception, place the base as high as possible.
• The base should be placed in an open area for optimum range and reception.
• If your home has specially wired alarm equipment connected to phone line, be sure that
installing the system does not disable your alarm equipment.
• If you have questions about what will disable alarm equipment, contact your telephone
company or a qualified installer.
Avoid noise sources such as a window
by a street with heavy traffic
Avoid heat sources, such as radiators,
air ducts, and sunlight
Choose a central location
Avoid other cordless telephones
Avoid personal computers
Avoid excessive moisture, extremely
low temperatures, dust, mechanical
vibration, or shock
Avoid microwave ovens
Avoid television sets and
other electronic equipment
[7]

Install the rechargeable battery pack
Follow the steps below if you need to install a battery.
1) Press down on the handset battery case cover (use the finger indention for a better grip)
and slide the cover downward to remove.
2) Place the battery pack in the battery compartment with the connectors on the battery and
on the compartment aligned.
3) Place the battery case cover back on the handset and slide it upwards until it clicks into
place.
Use only the
Uniden (BT-0002)
rechargeable
battery pack
supplied with your
cordless
telephone.
SETTING UP THE PHONE
[8]

Low battery alert
The battery pack needs to be charged when:
Cleaning the battery charging contacts
Caution:
When the battery pack is very low, the phone is programmed to eliminate functions in order
to save power.
- The empty battery icon appears.
- appears in the display.
If the phone is in standby mode, none of the keys will operate. If
you are on a call, complete your conversation as quickly as
possible, and return the handset to the cradle.
To maintain a good charge, clean the charging contacts on the handset once a
month. Dampen a cloth with plain water. Gently rub the damp cloth over the
charging contacts until all visible dirt is removed. Dry the contacts thoroughly
before returning the handset to the cradle.
Do not use paint thinner, benzene,
alcohol, or other chemical products. Doing so
may discolor the surface of the telephone
and damage the finish.
Low Battery
!
!
!
Even when the
battery pack is not
being used, it will
gradually discharge
over a long period of
time.
For optimum
performance, be
sure to return the
handset to the
cradle after each
telephone call.
If the handset is left
off of the base, the
actual talk mode
duration will be
reduced respective
to the amount of
time the handset is
off the cradle.
30/05 SUN 10:10A
Low Battery
New CID: 10
[9]

Connect the base and charge the handset
1) Connect the AC adapter to the jack.
Place the base close to the AC outlet to
avoid long extension cords.
2) Connect the AC adapter to a continuous
power supply (i.e.,an outlet that is not
controlled by a switch).
3) Close the handset and place it in the base
with the smaller LCD screen facing forward.
4) Make sure that the LED illuminates.
If the LED does not illuminate, check to see that the AC adapter is plugged in and the
handset makes good contact with the base charging contacts.
5)
AC ADAPTER
charge
Charge your handset at least 10 hours before plugging into the phone line.
!
!
!
Use only the
supplied AAD-
8815 AC adapter.
Do not use any
other AC adapter.
Do not place the
power cord where it
creates a trip
hazard or where it
could become
chafed and create a
fire or electrical
hazard.
Don't place the
base in direct
sunlight or subject it
to high
temperatures. The
battery may not
charge properly.
SETTING UP THE PHONE
[10]
To AC ADAPTER

[11]
6) Once the handset battery pack is fully
charged, connect the telephone line cord to
the jack and to a telephone outlet.
If your phone line also has High Speed Internet
please ensure you are using an approved line
filter before connecting the telephone cord.
TEL LINE
High Speed Internet
Australia
Tel Line adapter
(supplied)
If your telephone outlet
isn't modular, contact
your telephone
company.

Expanding Your Phone
Your phone can support a total of ten
handsets. Expansion handsets do not need
to be connected to a phone jack.
Expansion handsets allow you to use
additional features such as DirectLink
Mode and up to 3-way conference calling.
Expansion handsets need to be registered
to the base before they will operate.
Your phone is compatible with other Uniden 5.8GHz Digital
Expandable Handsets. Compatible models include the ELITE
and ELITE (Please check www.uniden.com.au or
www.uniden.co.nz for an updated list of expansion handset
compatible with this series.)
Your ELITE8815+1 includes an extra non-flip phone handset.
Use only the BT-0003 rechargeable battery pack supplied for the Extra Handset.
To install the BT-0003 rechargeable battery pack follow the same instructions as for the Flip
Handset (see page 8). Low battery alert and maintenance of the charge contacts are the
same as for the Flip Handset (see page 9).
Backwards/Forwards Compatibility
8855
8805.
ELITE8815+1 Extra Handset
EXPANDING YOUR PHONE
!
!
Advanced
features may
not be
supported by
older handsets.
If you have any
trouble with your
phone, visit our
web site at
www.uniden.com.au
or
www.uniden.co.nz
[12]
10 Handsets

Connect the expansion handset's charger
The handset is powered by a rechargeable
battery pack. The battery recharges
automatically when the handset is placed
in the charger.
1) Connect the AC adapter to the jack
and to a standard 240V AC wall outlet.
2) Set the charger on a desk or tabletop, and
place the handset in the charger with the
LCD screen facing forward.
3) Make sure that the LED illuminates.
If the LED does not illuminate, check to see
that the AC adapter is plugged in and the
handset makes good contact with the
charger charging contacts.
4) Charge the handset battery pack for at least
15 - 20 hours before using your new cordless
telephone for the first time.
Handsets supplied with the phone are registered to the base by the factory. Pre-
registered handsets display a handset ID number. Handsets that have not been
registered display
in the LCD.
will also appear in the sub LCD of a flip handset that has not been registered.
When you register an extra handset to the base, the handset ID will be assigned. Only one
handset can be registered at a time.
DC IN 9V
charge
Register the Handset
MUST place the handset in base to register! Models may
vary, refer to Owners Manual for help Handset must be
registered
Use only the
supplied AAD-600S
AC adapter. Do not
use any other AC
adapter.
[13]

Registration button
Register an Expansion handset to main base
Before the expansion handset is registered, the battery pack MUST be charged for
hours .
While the handset is registering, will appear in the LCD. When
is displayed, the handset has been registered to the base. If
appears, please try these steps again.
15-20
To register a Flip Handset, simply place it in the main base.
To register an ELITE8805 handset, follow the steps below:
Handset Registering
Registration complete
Registration failed
1 Press and hold the Registration
button at the underside of the base.
2 Keep pressing the Registration
button until the handset charge
LED on main base starts to blink.
3 On the handset, press and hold the
key until you hear a beep.#
EXPANDING YOUR PHONE
[14]

Changing the Digital Security Code
Installing the Holster
The digital security code is an identification code used to connect the handset and
the base unit. Normally, setting the code is not necessary. In the rare situation that
you suspect another cordless telephone is using the same security code, you can
change the code. To change the digital security code:
1. De-register all the handsets you have (see page 73).
2. Re-register each handset by following the steps on page 14.
- Line up the groove on the back of the handset with the groove
on the holster. The handset fits in the holster only one way.
- Slide the phone into the holster.
- Use the spring clip to attach the holster to your belt or pocket.
You must remove
the holster to
charge the
handset.
[15]

OPTIONAL HEADSET
INSTALLATION
To use with a
Bluetooth
headset, see
page 36.
®
[16]
Installing the Beltclip
Optional Headset Installation
(Extra Handset Only)
To attach the beltclip
To remove the beltclip
Insert the beltclip into the holes on each side of the handset.
Press down until it clicks.
Pull either side of the beltclip to release the tabs from the holes.
Your phone may be used with an optional headset.
To use an optional headset, insert the headset plug
into the headset jack.
Your phone is ready for hands- free conversations.
(Headsets may be purchased by visiting our website
at www.uniden.com.au or www.uniden.co.nz .)

Using the Interface
Example of the standby mode display
•Handset
Battery icon
Date, Day of the week, and time
Number of new caller ID calls received
Date and time/Battery icon
•Sub-LCD
(Flip Handset Only)
Number of new caller ID calls received
30/05 SUN 10:10A
New CID: 10
30/11 12:00A
New CID: 10
[17]
