Uniden EXI2926 User manual

†To activate the Caller ID features, you must
subscribe through your telephone company.
900MHz
CORDLESS
with caller id/call waiting†
owner’s manual
EEXXII22992266
EXI2926-ENG/03/07 3/7/02 1:47 PM Page i

www.uniden.com
EXI2926-ENG/03/07 3/7/02 1:47 PM Page ii

Contents
4-way conferencing 28
Using your EXI2926 intercom 29
Transferring calls 30
Using the speakerphone 30
Memory Features
Storing phone numbers and names 31
Steps for entering names and special characters 33
Making calls with memory dialing 35
Chain dialing 36
Editing a stored name and/or phone number 36
Erasing a stored name and phone number 38
Caller ID Features
Caller ID 40
When the telephone rings 40
Viewing the Caller ID message list 41
Using the Caller ID list 42
Deleting information from the Caller ID list 44
Using CIDCW (Caller ID on Call Waiting) 45
Additional Information
Changing the digital security code 46
Installing the beltclip 47
Headset installation 47
Note on power sources 48
Maintenance 48
Troubleshooting 49
General information 50
Precautions and Warranty 51
Industrial Canada Information 53
Index 54
Welcome/Features 2
Quick Reference Guide 3
Controls and Functions 4
Getting Started
Read this first 6
Checking the package contents 7
Setting up the phone 8
Mounting the base unit on a wall 13
Terminology 15
Setting menu options 15
Basics
Making and receiving calls 19
Adjusting the handset ringer and
earpiece volume 20
Redial 21
Tone dialing switch-over 21
Traveling out-of-range 21
Selecting a different channel 22
Using the page feature 22
Flash and call waiting 22
Answering a call from the base 23
Answering a call from the handset 23
Making a call from the base 24
Making a call from the handset 24
Placing a call on hold 25
Using the speakerphone mute feature 25
2-Line Features
2-Line operation 26
3-way conferencing 27
EXI2926-ENG/03/07 3/7/02 1:47 PM Page iii

[ 2 ]
The EXI2926 features include
AAuuttooTTaallkk
TT MMand
AAuuttooSSttaannddbbyy
TT MM. AutoTalk allows you to answer a call by just
removing the handset from the base so you don´t have to waste time pushing buttons. AutoStandby allows
you to hang up by simply returning the handset to the base.
The
UUllttrraaCClleeaarrPPlluuss
TT MMtrue compander circuitry virtually eliminates background noise. This innovative
technology, together with 20 different channels, provides you with the best possible reception during all
your conversations.
To protect you against misbilled calls which might result from your phone being activated by other
equipment, the EXI2926 has
RRaannddoommCCooddee
TT MMdigital security which automatically selects one of over 65,000
digital security codes for the handset and base. Also, the
AAuuttooSSeeccuurree
TT MMfeature electronically locks your
phone when the handset is in the base.
BBeessuurreettoovviissiittoouurrwweebbssiittee::wwwwww..uunniiddeenn..ccoomm
Uniden®is a registered trademark of Uniden America Corporation.
AutoTalk, AutoStandby, UltraClear Plus, Random Code, and AutoSecure are trademarks of Uniden America Corporation.
Welcome
Features
Congratulations on your purchase of the Uniden EXI2926 cordless telephone.
This phone is designed and engineered to exacting standards for reliability,
long life and outstanding performance.
NNoottee::SSoommeeiilllluussttrraattiioonnssiinntthhiissmmaannuuaallmmaayyddiiffffeerrffrroommtthheeaaccttuuaalluunniittffoorr
eexxppllaannaattiioonnppuurrppoosseess..
•900 MHz Extended Range
•2-Line Operation with lntercom
•Caller ID and Call Waiting Caller ID
•80 Number Caller ID Memory
(40 for each line)
•30 Number Memory
•32 Digit Redial
•Bi-lingual Display Option
•Flash and Pause
•Tone/Pulse Dialing
•14 Day Standby Battery Life
•7 Hour Talk Time
•Handset Earpiece and Ringer Volume Control
•Speakerphone
•3-Way and 4-Way Conference Operation
EXI2926-ENG/03/07 3/7/02 1:47 PM Page 2

Press and hold call id/hold.
Use up
▲ /int’com or dn ▼ /conf to move the cursor
to language.
Press sel/vol to select Eng (English) or Fr.
(French).
Press call id/hold and return the handset to the base.
QUICK REFERENCE GUIDE [ 3 ]
INSTALL THE HANDSET BATTERY
Remove the cover.
Connect the battery
pack connector with
the correct polarity.
Replace the cover.
PLUG INTO AC POWER
Plug the AC adapter cord into the base unit and into a standard
120V AC outlet.
Place the handset on the base.
Step 1 Charging the Battery Step 2 Installing/Adjusting
Step 3 Setting Up the Caller ID/Language
Note:You must charge the battery continuously for 15-20
hours before using the phone.
CONNECT THE PHONE LINES
Plug the telephone cord into the base jack marked
line 1/2 and then into a telephone wall jack.
Your phone is set for tone dialing.
If your local network requires
pulse dialing, please see
“Choosing the dialing mode”
on page 12.
Connect a second telephone cord to the base jack marked line 2 only if
your second telephone line is installed in a separate outlet.
TO CHANGE CALLER ID OPTIONS
Press and hold call id/hold.
Select “Line 1”or “Line 2”with the
up ▲ /int’com or dn ▼ /conf , then press #/ s .
Use up
▲ /int’com and dn ▼ /conf to move the cursor
to an option.
Press sel/vol to change the option setting.
Press call id/hold and return the handset to the base.
TO CHOOSE THE LANGUAGE
QUICK REFERENCE GUIDE
Note: Three Caller ID options are available: Auto Talk,
CIDCW (Caller ID on Call Waiting) and Area Code. Please
refer to “Using Caller ID” in your owner’s manual for an
explanation of each option.
EXI2926-ENG/03/07 3/7/02 1:47 PM Page 3

CONTROLS AND FUNCTIONS[ 4 ]
Controls and Functions
1. Handset Antenna
2. Optional Headset Jack
3. Beltclip Holes
4. Handset Battery Compartment
5. Handset Earpiece
6. LCD Display
7. Line 1 Key
8. Down Cursor ▼ /Character Select/
Conference Key
9. */ t (Left Cursor)/Tone
10. Caller ID/Hold Key
11. Select/Volume Key
12. Handset Microphone and Ringer Speaker
13. Memory Key (m)
14. Line 2 Key
15. Up Cursor ▲ /Character Select/
Intercom Key
16. #/ s (Right Cursor)
17. Delete/Flash Key
18. Redial/P (Pause) Key
19. Chan (Channel) Key
20. Handset Charging Contacts
1
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
2
4
3
EXI2926-ENG/03/07 3/7/02 1:47 PM Page 4

CONTROLS AND FUNCTIONS [ 5 ]
21. Handset Retainer Clip
22. Line 1 Status LED
23. Status LED
24. Memory Key
25. Intercom Key
26. Redial/Pause Key
27. Flash Key
28. Base Charging Contacts
29. */Tone Key
30. Base Speaker
31. Line 1 Key
32. Conference Key
33. Line 2 Key
34. Line 2 Status LED
35. Hold Key
36. Mute Key
37. Base Antenna
38. Base Speaker Volume Control
39. Base Microphone
40. Ring Volume Switch (2nd Line)
41. Ring Volume Switch (1st Line)
42. DC Power Input
43. Phone Jack (2nd Line)
44. Phone Jack (1- and 2- Line)
21
22
23
24
25
26
27
28 29
30
31
32
33
34
35
36
37
38
39
40 41 42 43 44
EXI2926-ENG/03/07 3/7/02 1:47 PM Page 5

GETTING STARTED[ 6 ]
Read This First
This cordless telephone must be set up before use. Follow these steps:
AAbboouutttthheeddiiggiittaallsseeccuurriittyyccooddee
This cordless telephone uses a
digital security code to prevent
unauthorized access to your
base unit. This security code
prevents other cordless
handsets from making calls
through your base unit.
A random security code will be
assigned automatically between
your base unit and handset
when you charge the battery
pack for the first time.
If you want to change the
security code, see page 46.
SStteepp11((ppaaggee77))
Unpack the telephone and accessories.
SStteepp22((ppaaggee88))
Next, choose the best location
to set up the base unit.
SStteepp33((ppaaggee99ttoo1144))
Then, insert the battery pack into
the handset. Connect the base unit.
You must charge the battery pack for
1155--2200hhoouurrssbbeeffoorreepplluuggggiinnggiinnttootthhee
tteelleepphhoonneelliinneeaanndduussiinnggtthheepphhoonnee..
tip
To realize the full capabilities of
your two-line phone, contact
the phone company requesting a
two-line subscription.
EXI2926-ENG/03/07 3/7/02 1:47 PM Page 6

GETTING STARTED [ 7 ]
GETTING STARTED
Checking the Package Contents
Make sure you have received the following items in the package. If any of these items are missing or
damaged, contact the Uniden Parts Department (see below).
••HHaannddsseett
••BBaasseeuunniitt
••AACCaaddaapptteerr((AADD--442200))
••RReecchhaarrggeeaabblleebbaatttteerryyppaacckk((BBTT--990055))
••TTeelleepphhoonneelliinneeccoorrdd((22lliinneeccaappaabbllee))
••WWaallllmmoouunnttaaddaapptteerr
••BBeellttcclliipp
••TThhiissOOwwnneerr´´ssMMaannuuaall
••RReeggiissttrraattiioonnCCaarrdd
Uniden Parts Department at [phone]
Hours: M-F 7:00 a.m. to 5:00 p.m. CST.
We can also be reached on the web at wwwwww..uunniiddeenn..ccoomm.
EXI2926-ENG/03/07 3/7/02 1:47 PM Page 7

GETTING STARTED[ 8 ]
Setting up the Phone
DDootthheeffoolllloowwiinnggsstteeppss::
A. Choose the best location C. Connect the base unit
B. Install the battery pack D. Choosing the dialing mode
AA..CChhoooosseetthheebbeessttllooccaattiioonn
Before choosing a location for your new phone, read the INSTALLATION CONSIDERATIONS
included in the PRECAUTIONS AND IMPORTANT SAFET Y INSTRUCTIONS. Here are some
important guidelines you should consider:
•The location should be close to both a phone jack and a continuous power outlet
which is not switchable.
•Keep the base and handset away from sources of electrical noise such as motors,
microwave ovens, and fluorescent lighting.
•Be sure there is sufficient space to raise the base antenna to a vertical position.
•The base can be placed on a desk, tabletop, or mounted on a standard wall plate.
•If your second phone line has a separate modular jack, place your phone so you can
access both jacks.
AAvvooiiddeexxcceessssiivveemmooiissttuurree,,
eexxttrreemmeellyylloowwtteemmppeerraattuurreess,,
dduusstt,,mmeecchhaanniiccaallvviibbrraattiioonn,,oorrsshhoocckk
AAvvooiiddhheeaattssoouurrcceess,,ssuucchhaass
rraaddiiaattoorrss,,aaiirrdduuccttss,,aannddssuunnlliigghhtt
AAvvooiiddtteelleevviissiioonnsseettssaanndd
ootthheerreelleeccttrroonniicceeqquuiippmmeenntt
AAvvooiiddnnooiisseessoouurrcceessssuucchhaassaawwiinnddoowwbbyy
aassttrreeeettwwiitthhhheeaavvyyttrraaffffiicc
AAvvooiiddmmiiccrroowwaavveeoovveennss
AAvvooiiddppeerrssoonnaallccoommppuutteerrss
AAvvooiiddootthheerrccoorrddlleesssstteelleepphhoonneess
CChhoooosseeaacceennttrraallllooccaattiioonn
EXI2926-ENG/03/07 3/7/02 1:47 PM Page 8

[ 9 ]GETTING STARTED [ 9 ]
BB..IInnssttaalllltthheebbaatttteerryyppaacckk
CChhaarrggeetthheebbaatttteerryyppaacckkffoorraattlleeaasstt1155--2200hhoouurrssbbeeffoorreepplluuggggiinnggtthheepphhoonneelliinnee
iinnttooyyoouurrpphhoonnee..
1) Press in on the battery cover release and slide the cover
down until it comes off.
2) Connect the battery pack connector observing correct
polarity (black and red wires) to the jack inside the
battery compartment.
Do not exert any force on this connection. It could
cause damage to the battery or handset. The plastic
connector will fit together only one way. Once you are
certain that you have made a good connection, then
insert the battery pack into the battery compartment.
Do not pinch the wires.
3) Securely close the battery compartment cover by sliding
it up until it snaps into place.
4) Place the handset on the base unit. Remove the
beltclip, if attached, for face up charging.
GETTING STARTED
note
UUsseeoonnllyytthheeUUnniiddeenn
BBaatttteerryy((BBTT--990055))
ssuupppplliieeddwwiitthhyyoouurr
pphhoonnee..Replacement
batteries are also
available through
the Uniden Parts
Department (See
page 7).
EXI2926-ENG/03/07 3/7/02 1:47 PM Page 9

[ 10 ]
note
GETTING STARTED[ 10 ]
BBaatttteerryyuusseettiimmee((ppeerrcchhaarrggee))
From fully charged
•Seven hours continuous use.
•Fourteen days when the handset is in the standby mode.
LLoowwbbaatttteerryyaalleerrtt
When the battery pack is very low and needs to be charged,
the phone is programmed to eliminate functions in order to
save power. If the phone is not in use, ”Low Battery”
appears on the LCD and none of the keys will operate.
If the phone is in use, ”Low Battery”flashes and the
handset beeps. Complete your conversation as quickly as
possible and return the handset to the base unit for charging.
CClleeaanniinnggtthheecchhaarrggiinnggccoonnttaaccttss
TToommaaiinnttaaiinnaaggooooddcchhaarrggee,,iittiissiimmppoorrttaannttttoocclleeaanntthhee
bbaatttteerryyccoonnttaaccttssoonntthheehhaannddsseettaannddbbaasseeuunniittwwiitthhaa
ddrryyccllootthhoorraappeenncciilleerraasseerraabboouuttoonncceeaammoonntthh..
DDoonnoottuusseeaannyylliiqquuiiddssoorrssoollvveennttss..
Even when the battery
pack is not being used,
it will gradually
discharge over a long
period of time. For
optimum performance,
be sure to return the
handset to the base
unit after each
telephone call.
The handset memory backup can hold names and all settings stored in memory even if the
battery pack is completely discharged.
note
EXI2926-ENG/03/07 3/7/02 1:47 PM Page 10

[ 11 ]
Place the power cord so
that it does not create a
trip hazard or where it
could become chafed
and create a fire or
electrical hazard.
!
GETTING STARTED [ 11 ]
GETTING STARTED
CC..CCoonnnneecctttthheebbaasseeuunniitt
1) Connect the AC adapter to the DC IN 9V
jack and a standard 120V AC wall outlet.
2) Set the base on a desk or tabletop,
and place the handset on the base
unit as shown. Remove the beltclip,
if attached for face up charging.
(For wall mounting, see ”Mounting the
Base Unit on a Wall”, on page 13 and 14).
3) Raise the antenna to a vertical position.
4) Make sure the status LED is illuminated. If the LED is not
illuminated, check to see that the AC adapter is plugged
in and the handset makes good contact with the base
charging contacts.
note
•The handset can be
placed face up or face
down in the base for
charging.
•You must remove the
beltclip, if attached,
for face up charging.
••UUsseeoonnllyytthheessuupppplliieeddAADD--442200AACCaaddaapptteerr..DDoonnoottuusseeaannyyootthheerrAACCaaddaapptteerr..
•Connect the AC adapter to a continuous power supply.
•Place the base unit close to the AC outlet so that you can unplug the AC adapter easily.
note
EXI2926-ENG/03/07 3/7/02 1:47 PM Page 11

GETTING STARTED[ 12 ]
•After installing the battery pack in the handset, cchhaarrggeeyyoouurrhhaannddsseettaattlleeaasstt
1155--2200hhoouurrssbbeeffoorreepplluuggggiinnggiinnttootthheepphhoonneelliinnee. Once the handset battery pack
is fully charged, connect the telephone line cord to the base and telephone wall
outlet.
5) Connect the telephone line cord to the TEL LINE 1-2 jack
and a telephone outlet once the handset is fully charged.
MMoodduullaarr
tip
If your telephone outlet isn´t
modular, contact your telephone
company for assistance.
note
For 2 line subscriptions,
•If the two phone lines
are in one modular
jack, connect using
TEL LINE 1-2 jack.
•If the two phone lines
are on two separate
modular jacks, connect
using both TEL LINE
1-2 and TEL LINE 2
jacks. DD..CChhoooossiinnggtthheeddiiaalliinnggmmooddee
Most phone systems use tone dialing which sends DTMF tones through the phone
lines. However some phone systems still use pulse dialing such as in rural areas.
The default setting is tone dialing. Depending on your dialing system, set the
mode as follows:
1) Press and hold flash on the base until you hear a confirmation tone.
2) To set the dial mode for pulse dialing, press #on the base. Or to set the dial
mode for tone dialing, press */tone on the base. A confirmation tone sounds
to indicate the setting is complete.
•If you are not sure of your dialing system, set for tone dialing. Make a trial call.
If the call connects, leave the setting as is, otherwise set for pulse dialing.
•If your phone dialing system requires pulse dialing and you need to send DTMF
tones for certain situations during a call, you may "switch-over" to tone dialing.
(Refer to "Tone Dialing Switch-over").
EXI2926-ENG/03/07 3/7/02 1:47 PM Page 12

[ 13 ]
SSeettttiinnggtthheehhaannddsseettrreettaaiinneerrcclliippffoorrwwaallllmmoouunnttiinngg
1) On the base unit, pull the handset retainer out
of the slot. Rotate it clockwise 180 degrees.
2) Flip the retainer from front to back.
Slide it back into the slot so that the lip
of the retainer is up and the
▼ is down.
The retainer holds the handset in place.
SSttaannddaarrddwwaallllppllaatteemmoouunnttiinngg
This phone can be mounted on any standard telephone wall plate.
1) Snap the wall mount adapter into the
notches on the base.
2) Plug the AC adapter to the DC IN 9V jack.
3) Wrap the AC adapter cord inside the
molded wiring channel as shown.
4) Plug the AC adapter into a standard 120V
AC wall outlet.
5) Place the handset on the base unit and
charge for 15-20 hours.
6) Plug the telephone line cord into the TEL LINE jack.
Wrap the cord inside the molded wiring channel as shown.
GETTING STARTED
GETTING STARTED [ 13 ]
Mounting the Base Unit on a Wall
1
2
DO NOT use an outlet
controlled by a wall
switch.
!
note
If you have wall
mounted the base,
you must remove the
beltclip to hang the
handset with the display
facing forward.
EXI2926-ENG/03/07 3/7/02 1:47 PM Page 13

[ 14 ] GETTING STARTED[ 14 ]
7) Plug the telephone line cord into the telephone outlet.
8) Raise the antenna to a vertical position.
9) Align the mounting slots on the base with the mounting posts on the wall then
push in and down until the phone is firmly seated.
DDiirreeccttwwaallllmmoouunnttiinngg
If you don´t have a standard wall plate, you can mount your phone directly to the
wall. Before doing this, consider the following:
•Avoid electrical cables, pipes, or other items behind the mounting location,
that could cause a hazard when inserting screws into the wall.
•Try to mount your phone within 6-10 feet of a working phone jack to avoid
excessive cord lengths.
•Make sure the wall material is capable of supporting the weight of the base
and handset.
•Use #10 screws (minimum length of 1-3/8 inches) with anchoring devices
suitable for the wall material where the base unit will be placed.
1) Insert two mounting screws into the wall, (with
their appropriate anchoring device), 3-15/16
inches apart. Allow about 1/8 of an inch between
the wall and screwheads for mounting the phone.
2) Set the retainer clip if necessary.
3) Refer to steps 1 through 9 on pages 13 and 14 to
mount the telephone.
EXI2926-ENG/03/07 3/7/02 1:47 PM Page 14

GETTING STARTED [ 15 ]
GETTING STARTED
Terminology
Throughout this manual, terms such as Standby and Talk Mode are used. Below is
the terminology explanation.
•SSttaannddbbyyMMooddee- The handset is not in use, off the base and line 1 or line 2 has
not been pressed. A dial tone is not present.
•TTaallkkMMooddee- The handset is off the base and line 1 or line 2 has been pressed
enabling a dial tone.
Setting Menu Options
There are four setup options available. They are Caller ID options [AutoTalk, CIDCW
(Caller ID on Call Waiting), Area Code], and Language. See page 17 for Area Code
setup instructions.
AutoTalk allows you to answer the phone without pressing line 1 or line 2.
If the phone rings when AutoTalk is on, simply remove the handset from the base
and the phone automatically answers the call. Or if the handset is not on the
base, press any key to answer the call. If the phone rings when AutoTalk is off,
you must press line 1 or line 2 to answer the call.
CCaalllleerrIIDDoonnCCaallllWWaaiittiinngg((CCIIDDCCWW))performs the same as regular Caller ID on a call
waiting number. YYoouummuussttssuubbssccrriibbeettooCCIIDDCCWWffrroommyyoouurrpphhoonneeccoommppaannyyiinnoorrddeerr
ttoouusseetthhiissffeeaattuurree..
EXI2926-ENG/03/07 3/7/02 1:47 PM Page 15

TToocchhaannggeeyyoouurrAAuuttooTTaallkkaannddCCIIDDCCWW::
1) When the phone is in the standby
mode, press and hold call id/hold until
the Caller ID setting screen appears.
2) Press
▲ up/int’com or dn ▼ /conf to select ”Line 1”or ”Line 2”.
3) Press #/ s .
The following screen appears.
4) Press ▲ up/int’com or dn ▼ /conf to
move the cursor to the selection
that you would like to change.
Press the sel/vol key to toggle between ”On”and ”Off”. Press sel/vol.
5) After you have made your selections, press call id/hold or return the handset to
the base.
[ 16 ] GETTING STARTED
note
•Make sure your battery
pack is fully charged
before setting Caller ID
options.
1 Line 1
2 Line 2
3 Language:Eng
1 Auto Talk:Off
2 CIDCW :On
3 Area Co e:
•Please return the
handset to the base
after you set CIDCW.
EXI2926-ENG/03/07 3/7/02 1:47 PM Page 16

If you enter a 3-digit area code number in the ”Area Co e”option, your
local area code does not appear in the Caller ID messages. Do not program this
option, if your calling area requires 10-digit dialing. When reviewing Caller ID
messages, you will see only the local seven digit number. For calls received from
outside your local area code, you will see a full 10-digit number.
1) When the phone is in the standby
mode, press and hold call id/hold
until the Caller ID setting screen
appears.
2) Press
▲ up/int’com or dn ▼ /conf to select ”Line 1”or ”Line 2”.
3) Press #/
s .
4) Press
▲ up/int’com or dn ▼ /conf to select ”Area Co e”.
5) Press sel/vol.
6) Use the dial buttons (0to 9 ) to
enter the 3-digit area code.
7) Press sel/vol. A tone sounds and the displayed area code is entered.
8) Press call id/hold to complete the setting. Or return the handset to the base
unit. The handset returns to standby mode.
TTooEEnntteerrYYoouurrAArreeaaCCooddee
1 Line 1
2 Line 2
3 Language:Eng
GETTING STARTED [ 17 ]
GETTING STARTED
note
If your calling area
requires 10-digit dialing,
do not program this
option.
1 Auto Talk:Off
2 CIDCW :On
3 Area Co e:
When the area code has already been stored in memory, the
stored area code will be displayed. To change it, use the
delete/flash and number keypad to enter the new area code.
Then press sel/vol. To complete the setting, press call id/hold
or return the handset to the base unit.
817
note
EXI2926-ENG/03/07 3/7/02 1:47 PM Page 17

SSeettttiinnggtthheellaanngguuaaggee
1) When the phone is in the standby mode, Press and
hold call id/hold. The following screen appears.
2) Press 3or press dn
▼ /conf twice to select ”Language”.
3) Press sel/vol to toggle between ”Eng”(English) and
”Fr.”(French) for each setting.
4) Press call id/hold or return the handset to the base unit.
The handset returns to the standby mode.
1 Line 1
2 Line 2
3 Language:Eng
[ 18 ] GETTING STARTED
EXI2926-ENG/03/07 3/7/02 1:47 PM Page 18
