Uniden iGO CAM 75 User manual

iGO CAM 75/75R
Accident CAM
Vehicle Recorder
For more exciting new products please visit our website:
Australia: www.uniden.com.au

2
UNIDEN iGO CAM 75/75R Vehicle Recorder
Important Safety Instructions
NOTE
Uniden does not represent this product to be waterproof. Do not
expose this product to Rain or Moisture.
NOTE
This product is intended for use in a motor vehicle. Don’t install
the device where it will block the driver’s view of the road
(including the mirrors!) or the deployment of the airbag.
NOTE
Keep your attention on the road! Don’t try to operate or focus
on any device while driving. If you have to concentrate on a
device, pull off the road for a few minutes.
NOTE
Ensure that the camera lens is kept clean and there is nothing
blocking the lens.
NOTE
Don’t leave the device in direct sunlight for a long period of time
or where the temperature could go above 60°C.
NOTE
You should examine, check and/or verify the device at least
once a month including the associated SD card, to ensure the
recording are working properly.
NOTE
Never attempt to disassemble, repair or make any modications
to your device.

Important Safety Instructions ............................................. 2
What’s In The Box...................................................................4
Make Sure These Items Arrived in the Box .................................................4
Controls & Indicators ............................................................5
Installation ............................................................................ 7
Location ..................................................................................................................7
Installing the Front Camera .............................................................................7
Installing the Rear Camera ...............................................................................8
GPS Reception Information .............................................................................8
Operation .............................................................................. 9
Micro SD Card .......................................................................................................9
Power Information ............................................................................................10
Power On ............................................................................................................. 10
Power O ............................................................................................................. 10
Record Mode .......................................................................................................11
Menu Settings ...................................................................................................12
Photo Mode ....................................................................................................... 16
Playback Mode ................................................................................................ 16
Uniden Player .....................................................................................................17
Using the App .....................................................................................................18
Troubleshooting ................................................................................................20
Specication .......................................................................................................21
Warranty ..............................................................................22
3
UNIDEN iGO CAM 75/75R Vehicle Recorder
Contents

4
UNIDEN iGO CAM 75/75R Vehicle Recorder
Make Sure These Items Arrived in the Box
• If any item is missing or damaged, contact your place of purchase
immediately. Never use damaged products!
• Internal camera (IC90) available as optinal accessories.
• Need help? Get answers at our website:
www.uniden.com.au for Australian model.
• Car Cigarette Charger
• Slide Cover with 3M Sticker
• Windscreen Protective Film
iGO CAM 75/75R with
GPS Magnetic Mount
What’s In The Box
16
3
16
3
iGo Cam 75R includes
Rear Camera (RC90) 6m Rear Camera Cable
iGo Cam 75/75R includes

Controls & Indicators
UNIDEN iGO CAM 75/75R 5Vehicle Recorder
123
4 5 67
8
9
10 11
12
13
14 15
Front Camera
Rear Camera
16
3

6Vehicle RecorderUNIDEN iGO CAM 75/75R
Ref Component Description
1 LCD Screen
2 Speaker
3 Camera Lens
4Press & hold for 2 seconds to turn power on.
Press & hold for 3 seconds to turn power off.
Switch the display on/off.
5Press and hold to turn on/off audio recording.
In Menu list, press to shift to the previous selection.
6OK Press to start or stop video recording.
Press to conrm a selection in the Menu.
Press to conrm a change in the settings.
Press to take snapshot in photo mode.
7Press to change camera viewing screen when internal/rear
camera is connected.
Press and hold to switch the Wi-Fi access point on.
In Menu list, press to shift to the next selection.
8 MIC Records sound.
9MPress to open the Settings Menu.
Press to manually lock the current recording le while
recording.
Press and hold to switch between Record, Picture and
Playback mode when the device is not recording.
10 Reset If the device fails to operate properly, try resetting the device.
Press the reset button by using a ne pen or paperclip.
11 GPS Module
12 Mini USB Port Insert DC car charger mini USB cable.
13 Rear Camera
Port
Connect the rear camera connector cable (not included with
iGo Cam 75/75R) . Please check label.
14 Micro SD
Card Slot
Insert micro SD Card (up to 128GB min Class U3)
15 Internal Cam-
era Port
Connect the internal/cabin camera. Internal camera is sold
seperately.
16 Rear Camera
Output
Connect the rear camera connector cable (not included with
iGo Cam 75/75R). Please check label.

7
UNIDEN iGO CAM 75/75R Vehicle Recorder
Installation
Location
To have a better view, try to install the front camera at the center of the
windshield. Make sure the lens is located in a place where the windshield is
clean to ensure the view is clear. The recommended rear camera installation
location is dead centre of the rear windshield.
Make sure the device is not installed in a place where it will interfere with the
airbag. Make sure the GPS will not be obstructed by the windshield’s sun
control lm (window tint).
Installing the Front Camera
1. Slide the sticker mount bracket into the device bracket slot and make sure
it ts tightly.
2. Clean the area you desire to have the dash cam placed before sticking the
device.
3. Peel off the sticker protective lm from the 3M sticker on the GPS module.
4. Press and apply force on the mount onto the windshield behind the rear-
view mirror.
5. Arrange and hide the cables to avoid obstruction for the driver’s view.
6. Adjust the viewing angle of the camera. We recommend the camera should
point slightly downwards ~10° below eye level.
NOTE
Do not install the product in a location where it can obstruct
the driver’s eld of vision.

Installing the Rear Camera (for iGoCam 75R)
Always check the label on the rear camera cable before connecting the
camera to the rear camera and front camera. This is to ensure the cable is
connected to the corresponding connector port. Otherwise, the rear camera
video feed will not display on the front camera screen.
1. Peel off the sticker protective lm from the 3M sticker on the rear camera.
2. Mount the rear camera and apply force on the mount onto the centre rear
of the windshield.
3. Check the label on the rear camera cable before connecting one end to the
rear camera and the other end to the front camera.
4. Arrange and hide the cables to avoid obstruction for the driver’s rear view.
5. Adjust the viewing angle of the camera. We recommend the camera should
point slightly downwards ~10° below eye level.
When the rear camera is connected to the front camera and it is currently
powered on, the rear camera will be displayed in the right side of the LCD
screen. The recording resolution for the rear camera is 1080P.
NOTE
Please ensure the rear camera connection cable is connected/
disconnected when the device power is o or it will damage
the product.
GPS Reception information
Surroundings with tall buildings, tunnels or poor weather conditions may
result in poor GPS reception or even lose GPS signal. Over-tinting or a rain
sensor on the windshield can affect GPS reception.
If the signal is unstable even when you are driving, please try changing the
installation spot of your dash camera. For the rst time use, it takes about
15~20 minutes to get GPS signal, and after that, it normally takes about 3
minutes.
NOTE
Sticker mount is difcult to remove after it is installed and will
not stick well on a curved/textured or wet surface.
8Vehicle RecorderUNIDEN iGO CAM 75/75R

Micro SD Card
NOTE
A compatible micro SD card (not supplied) has to be inserted
before you start using the unit. Ensure that the unit is turned off
before inserting or removing the micro SD card.
The device can support micro SDHC cards (High Capacity SD) or SDXC
cards (Extended Capacity SD) up to 128GB in capacity. A micro SD card of at
least 16GB capacity and minimum speed of Class U3 is required.
Insert a formatted micro SD card gently in the slot at the side of the unit. To
remove the card from the slot, press the edge of the micro SD card inwards
for it to pop out and then pull it out of the slot.
It is important to format the micro SD card before using it, so as to avoid any
damage to the les created on iGO CAM 75/75R.
Uniden only recommends using good quality MLC/SLC micro SD cards.
Please ensure that the SD card used is rated for Dash Cam use.
Video Storage Capacity
Refer to the table below for reference for the recording time for different card
capacity and some of the recording resolution.
Resolution 16GB 32GB 64GB 128GB
Single Channel Recording (Front camera only)
1440P 45 mins 90 mins 180 mins 360 mins
1080P 55 mins 110 mins 220 mins 440 mins
Dual Channel Recording (Front and Rear camera)
1440P + 1080P 40 mins 80 mins 160 mins 320 mins
1080P + 1080P 50 mins 100 mins 200 mins 400 mins
Triple Channel Recording (Front , Rear and Internal camera)
1440P + 1080P + 1080P 35 mins 70 mins 140 mins 280 mins
1080P + 1080P + 1080P 45 mins 90 mins 180 mins 360 mins
Operation
9Vehicle RecorderUNIDEN iGO CAM 75/75R

10
UNIDEN iGO CAM 75/75R Vehicle Recorder
Power On
NOTE
When connected to a car charger with power, the device will
automatically power on and start recording.
1. Connect the DC car adaptor to the power connector USB port found on
the device.
2. Connect the other end of the DC car adaptor to your car’s cigarette
lighter.
3. The device will power on automatically when the car supplies the power
to the device.
4. The red dot on the screen will start ashing and recording starts
automatically.
At other times, press and hold the power button for at least 2 seconds.
NOTE
Be sure insert the SD card before powering up the device.
Format the SD card before you start recording for the rst time.
Power Off
When the car’s engine is turned off, the device will automatically turn off in a
few seconds.
At other times, press and hold the power button for at least 3 seconds to turn
off the device. Do no eject the SD card immediately to prevent damage to the
last recorded le.
If you wish to switch the device back on, press and hold the power button for
at least 2 seconds.
NOTE
Only use the DC car adaptor that comes with your device. Any
other adaptor might damage the device.
Power Information
The device is designed mainly for in-vehicle use, drawing on vehicle power
or the vehicle battery when using the Hard Wire Kit (HWK-2). The iGO
CAM 75/75R has an in-built high quality, long life supercapacitor. It provides
enough backup power to ensure any recording in progress is stored safely
before shutting the camera off.

11
UNIDEN iGO CAM 75/75R Vehicle Recorder
Record Mode
NOTE
To record a video, ensure that a valid micro SD card (not
supplied) is inserted in the given slot. Also note, that inserting/
removing the SD card when the device is recording causes the
device to shutdown and in worst case malfunction.
Using the iGO CAM 75/75R you can record videos.
Press and hold the Mbutton to switch between Record, Picture and Playback
modes.
Recording
When connected to a car charger with power, the unit automatically goes into
the record mode and starts recording.
A ashing red dot icon and a recording timer indicates that the device is
recording. To stop recording, press OK and the red dot disappears, indicating
that the recording has stopped.
Protect the Current Recording
While recording, if you want to lock the current recordings, then press the
Mbutton. Those recordings have been locked and will not be overwritten by
normal video recordings.
This also applies when the G-Sensor registers an impact while recording.
Rear Camera
Rear Camera helps you capture rear footages. Insert the rear camera cable
into the front camera and the rear camera. The footage from the rear camera
should be visible on the screen.
Always check the label on the rear camera cable to ensure the cable is
connected to the corresponding connector port. Otherwise, the rear camera
video feed will not display on the front camera screen.

Main Menu Setting Description
Recording
Video
Resolution
Set the recording resolution for the
front camera. The options available are:
2560x1440P and 1920x1080P. Higher
resolutions will give you a sharper image,
but take up more memory on the card. The
rear camera and internal camera resolution
is xed at 1080P.
Loop
Recording
Use this option to set the length of each
video clip. If you choose the option ‘Off’ then
the recorder will not loop record and the les
will not be overwritten on the micro SD card.
Audio
Recording
Use this setting to enable or disable audio
recording.
Time Lapse
Recording
Time Lapse setting helps you compress a
long recording to just under a few seconds.
By default, the option is turned off.
The options available are Off, 5 fps,
2 fps and 1 fps.
For example, if you opt for 1 fps, then an
image is captured every 1 second. The
captured images are then stitched together
to playback in 30 fps.
12
UNIDEN iGO CAM 75/75R Vehicle Recorder
Menu Settings
NOTE
Please note, you cannot access the Menu Settings while the
device is recording. To access the Menu settings, you will need
to stop recording by pressing the OK button.
Press Mbutton to open the Menu Settings. Press Monce more to exit from
the Menu settings or return to previous page. Otherwise press and hold M to
ope
Press the relevant UP and DOWN keys to scan through the options, under
each menu setting. Press OK to select the required option.

13 Vehicle RecorderUNIDEN iGO CAM 75/75R
Recording
Mirror Rear
Enable to display and record in mirrored
image for rear and internal camera.
Disable to display and record in real image
for rear and internal camera.
Motion
Detection
Enable this setting to allow the unit to record
only when only the front camera detects
movement.
WDR Enable/disable the Wide Dynamic Range
(WDR) feature to improves the overall
exposure throughout your entire image.
Anti-Flicker Change depending on the electrical power
frequency in your area (Default setting is
50Hz and you may not have to change this
setting).
G Sensor This functions helps protect/lock video
les in case of a sudden impact/collision.
You can change the sensitivity level of the
G-sensor.
Exposure Set the brightness sensitivity for better effect
in different lighting condition
Playback
Normal
Recording
Normal video recordings are save in this
folder.
Event
Recording
Locked/event recordings are save in this
folder.
Photo All the snapshots are save in this folder.
Parking Mode Parking mode only works with the optional
Hard Wire Kit (HWK-2). The unit must have
sufcient external power supplied in order to
record in parking mode.
Impact Detection:
This mode turns on the unit if it detects
impact and will record for 60 seconds.
Time Lapse Recording:
Once the ACC current is cut off, the unit
will start time-lapse recording (1 fps and
playback in 30fps).

14 Vehicle RecorderUNIDEN iGO CAM 75/75R
Date & Time Set the date, time and the date display
format.
Safety
Camera
Alert
Set the alerts distance when there is a
xed Speed/Red Light/Red Light-Speed or
Average Speed Camera.
Viewing
Mode
Choose to either have Live view or the
speedometer displayed on the LCD.
Speed Sign
Alert
Recognise the road speed limit sign and
alert the driver. If there are two or more
speed limit sign in close proximity, will only
alert once. This feature only works when the
speed limit sign is clearly visible.
Fatigue
Reminder
Set alert timer to periodically reminding you
to take a break before continuing to drive.
Wi-Fi Turn on the WiFi access point and display
the SSID and password for App data
transfer or view recorded les. Wi-Fi access
point needs to be turn off before return to
access the device.
Watermark
Date & Time Opt to have the date and time displayed on
the recordings.
Speed Opt to have the date and time displayed on
the recordings.
GPS Opt to have the GPS coordinates displayed
on the recordings.
Storage
Format
SD Card
Reminder
Set a reminder to remind every 15, 30, or 60
days to format your micro SD card. Before
you format your micro SD card, always
remember to save whichever footage clips
or photos you would like to keep before
formatting, all data on the micro SD card will
be deleted during the process of formatting.
Format SD
Card
Use this option to format the SD card. (All
les will be permanently erased.)
Storage
Information
Indicates the capacity of the inserted micro
SD card.

15
UNIDEN iGO CAM 75/75R Vehicle Recorder
Settings
Key Beep Enable or disable this feature to sound a
tone or go mute when you press the keys.
LCD Auto
Off
Set the LCD display off timer. Off to disable
this feature.
IR LED This setting only pops up when internal
camera (not included) is connected.
Car Plate
Stamp
Edit the car plate stamp. Use the UP/DOWN
keys to select a number or an alphabet.
Press M to move to the next character and
press OK to conrm and exit.
Time Zone Set the correct time zone for the GPS to get
the correct time settings for the device.
Daylight
Saving TIme
Enable or disable daylight saving time.
GPS
Information
To view the GPS signal connection status
and strength.
Factory
Default
Settings
Resets the device to factory settings. Note
that restoring defaults will not erase data on
the SD card.
Version Display the device rmware version.

16
UNIDEN iGO CAM 75/75R Vehicle Recorder
Photo Mode
Press and hold the Mbutton in record mode to switch to the photo mode. The
photo icon will display on the top left corner of the screen.
Press the OK button to take a photo.
Playback Mode
Press and hold the Mbutton in photo mode to switch to the playback mode.
The device stores video and photos on the SD Card. Playback mode will
allow you to review the saved videos and photos and playback the video with
audio.
When in the Playback mode, select the folder and toggle the les by pressing
the UP and DOWN keys to scan through the various video/image les and
press OK button to play a video le.
During video playback pressing the UP or DOWN keys to select the options
for. Press OK button to conrm selection.
NOTE
To return to Record Mode, press and hold the M button. Press
OK to start recording.

17
UNIDEN iGO CAM 75/75R Vehicle Recorder
Uniden Player
Uniden Player allows you to view the recordings on the iGO CAM 75/75R and
trace them on a map. The software is supported on Windows 7, Windows 8
and Windows 10.
Installing Uniden Player
Download the Uniden Player from the Uniden website. You may need to
unzip the le using the appropriate archiving software before you can use the
player. Double click on the Uniden Player icon.
Access the Recorded Files
Before playing the recorded les on the Uniden Player, ensure that you can
access the les easily.
Remove the micro SD card from the recorder, and access the card (les) on
the computer via a card reader (not provided).
Ensure that the PC is connected to the internet to view the map screen.
1. Click on the Open icon to open the les on to the Uniden Player.
2. Click on the PLAY button (Playback Controls) to start playback.
Click on the ‘Snapshot’ icon to take photos of the recording. These photos will
automatically save into a folder named ‘screenshot’. This folder is located in
the Uniden Player folder stored in your PC.
NOTE
Uniden Player version is subject to change without notice. See
Uniden website to download the latest GPS Player.
Video
Playback
Screen
Playback
Controls
Driving
Direction
Map
Driving
Speed
Snapshot
Open

18
UNIDEN iGO CAM 75/75R Vehicle Recorder
Using the App
iGO 75/75R App allows you to control the iGo CAM 75/75R via WiFi. You can
easily preview, browsing les, playback and transfer the les in the SD card
into your mobile phone. The app also allows you modify some of the device
setting.
The iGo CAM 75/75R WiFi access point is off by default and you will need to
turn it on to allows your mobile phone to connect to it.
NOTE
Connect your mobile phone to your iGo CAM 75/75R within a
line of sight range of 10m.
NOTE
Press and hold the EMERGENCY button to turn on/off the WiFi
access point.
1. Search and download the “iGoCam” App from the App Store for iOS
devices or Play Store for Android devices.
2. Turn on the WiFi access point of the iGo CAM 75/75R. The SSID and
the SSID and password can be found in menu settings.
3. Go to your mobile phone WiFi setting and connect to the iGo CAM
75/75R access point. The SSID usually starts with iGOCAM75_.... and
the default password is 12345678.
4. Go back to the app and tap “Connect Device”
Camera
Tap to view live video stream from the camera, take
a snapshot, and view camera settings.
Album
Tap the Album tab to view or playback downloaded
photos or videos.
About
Tap to view app information and clear cache data.

19
UNIDEN iGO CAM 75/75R Vehicle Recorder
NOTE
You can change Wi-Fi SSID and password in the Camera
Settings using the app.
Snapshot
Take a quick snapshot.
Album
Tap the Album icon to view saved photos or videos on the SD card. You can
tap to the video le to play directly or download the video le to the mobile
phone storage.
Recording Switch
Start/stop the connected iGo Cam recording.
Camera View Switch
If a rear camera is connected, you can switch camera views.
Microphone
Turn on/off the connected iGo Cam camera audio recording.
Settings
Modify camera settings.
Live View
Settings
Microphone
Camera view switch
Album
Snapshot
Recording switch

20 Vehicle RecorderUNIDEN iGO CAM 75/75R
Listed below are some of the problems and the possible solutions.
General Problems Possible Solutions
The device cannot take
photos or record videos
• Ensure that the SD card is inserted
correctly and use the device to format the
SD Card.
• Use the recommended type of SD card
(minimum 16GB Class U3) rated for dash
came use.
The device automatically
stops when recording
Video is unclear Ensure that there are no ngerprints or dirt on
the lens. Ensure that the lens is always kept
clean.
Cross-stripe interference
in an image
This is due to the light frequency. Change the
light frequency depending on the light source.
The device crashes/
freezes
Press the ‘Reset’ button, with a pin, to restart
the device.
SD Card Error Please format the SD card and use
recommended card only. Please make sure
the SD card is recommended dash cam use.
Display turns off after a
few minutes
Please check the LCD Auto Off setting and
select Off.
Memory card is full Please allow loop recording to overwrite
older recording les or delete unwanted les
including emergency recordings.
Camera feels warm
during operation
It is normal for the camera to get warm during
operation. Please bear in mind that the if the
camera is exposed to high temperature for
a long period of time, it might fail to boot up.
Cool it down and try again.
The recorded video
doesn’t show mapping
information on the
Uniden Player.
Please ensure the PC is connected to internet.
If you still need help, visit our website or call our customer service.
Troubleshooting
