Unika AR3600I User manual

AR3600I AC LINE VOLTAGE REGULATOR
User Instructions
This booklet contains important information concerning the proper and safe operation of your new amplifier..
Index
01 General Information
04 Installation
05 Operation
10 Specification
INPUT VOLTAGE
OUTPUT VOLTAGE
LN
REGULATED
OUTPUTS
5%
OVER
IN
REGULATION
5%
UNDER
OUTPUT CURRENT
UNiKA
P R O F E S S I O N A L A U D I O
AR-3600 I
INPUT RANGE:
88-264VAC 30A MAXIMUM
O
T
R
S
E
S
S
E
E
R
T
P
L I N E R E G U L A T O R
1 2 0 V 3 0 A O U T P U T
A C .
P R O F E S S I O N A L A U D I O

Congratulations on your purchase of a AR3600I AC Line Voltage Regulator. The
AR3600I is the perfect accessory to any audio, video, or computer rack-mount system
requiring clean, filtered, and regulated AC power for optimum operation. It is the
ultimate high current regulating product for audio, video, computer, and broadcast
professionals.
IMPORTANT PRECAUTIONS!
1. Carefully check the shipping carton for damage that may have occurred during
shipping. If the carton appears to be damaged, carefully inspect your unit for any
damage and be sure all accessories necessary to operate the system have arrived
intact. In the event damage has been found or parts are missing, please contact the
authorized dealer for further instructions.
2. To reduce the risk of electric shock, do not open the unit. There is no user
replaceable parts inside. Please contact the authorized dealer for any requirements
on technical support.
3. The AR3600I is a complex electronic instrument with various wiring options. You
cannot simply “plug in and go”. Take the time to read this manual, especially the
sections on Installation and Operation. For any questions in doubt, please contact
the authorized dealer for further assistance.
GENERAL INFORMATION
FEATURES OF THE AR3600I
Delivers 120 VAC ±4% anywhere within capture ranges of 88 to 134 and 170 to 264
volts AC, 50/60 Hz, single phase
7 regulated, conditioned outlets (1 front, 6 rear)
Input capacity 30 amps; output capacity 22.5 to 30 amps
Provision for remote turn-on/turn-off; multiple units may be turned on
simultaneously or in a delayed sequence
Multiple-stage transient (spike) suppression
Multiple-stage RFI filtering
Low stray magnetic field leakage
Compact 5.2” rack-mount unit weighs only 53 lbs (24 kg)
1
General Information Installation Operation Specification
AR3600I AC LINE VOLTAGE REGULATOR

AR3600I DESCRIPTION
The AR-3600I is intended to protect computer, audio, video and other electronic equipment from
problems caused by AC line voltage irregularities - sags, brownouts or over voltages that can
cause sensitive digital equipment to malfunction, or, in extreme cases, to sustain damage. It
accepts single phase input AC voltages anywhere within two capture ranges, 88 to 134V (low
range) or 170 to 264V (high range) and converts them to the North American standard 120 volts.
The AR3600I will detect the different of the input voltage and automatically switch over to the
appropriate operating voltage range.Voltages outside the ranges may be converted to usable
levels, depending on how far out of range they are and what is considered usable. For example,
any voltage from 80 to 267 will be converted to 120V ±4%. See Figure 1.
The AR-3600I can handle loads totaling up to 30 amperes as long as the input voltage is equal
to or above 120 volts (low range) or 240 volts (high range). For voltages below those levels, its
capacity must be derated at approximately one-quarter ampere per volt. See Figure 2 below.
In live performance situations, where each act requires a special AC configuration, accidental
connection to incorrect AC voltages occurs surprisingly often with disastrous consequences.
Because of its dual range auto switch over capability, the AR-3600I can protect against a
catastrophic error in AC mains wiring. This feature also makes the AR-3600I ideal as a
component of a power distribution scheme suitable for worldwide use, accommodating national
voltages of 100, 120, 220, 240, or others, with equal ease and without the need for
readjustment.
Figure 1
OUTPUT VOLTAGE VS. INPUT VOLTAGE
Figure 2
AVAILABLE OUTPUT CURRENT VS. INPUT VOLTAGE
2
General Information Installation Operation Specification
AR3600I AC LINE VOLTAGE REGULATOR

3
The AR-3600I uses a design based on a 25-tap toroidal autotransformer. The
toroidal design assures minimal leakage of stray magnetic fields in a highly efficient,
compact package.
The AR-3600I’s circuitry monitors the incoming line voltage with each cycle. If a
voltage change requires that a different tap be selected, the new tap is electronically
switched in precisely at the zero-crossing, to avoid distorting the AC waveform. If
necessary, the AR-3600I can switch taps as often as once each cycle. Most
commercial voltage regulators using multiple-tapped transformers switch taps with
relays at uncontrolled times, thereby creating voltage spikes! And unlike voltage
regulators that employ Ferro resonant transformers, the AR-3600I is not sensitive to
small errors in line frequency, making it ideal for use with generators.
The AR-3600I has six convenience outlets on its rear panel, and one on the front
panel. All outlets are regulated, spike-suppressed, and filtered against RFI with a 3-
pole filter. There are no controls except a master circuit breaker, which serves as an
on-off switch. One or more units may be turned on remotely, either simultaneously or
in sequence, by switching an internally-derived DC control line.
The AR-3600I is housed in a three space (5.2” high and 17” deep) rack-mount
chassis, and weighs only 53 lbs (24 kg). It is made of extremely rugged heavy gauge
black powder coat steel. Allow it to be secured in both front and rear. It comes
equipped with a male IEC-309 power input and a female IEC-309 power link output
sockets.
AR3600I LIMITATIONS
AC power is, to some extent, unpredictable. The available voltage may vary
from place to place and from moment to moment. The waveform may not be a
perfect sine wave, and high or low frequency noise may be present. AC power
also varies from country to country in terms of voltage and frequency.
The AR3600I is intended to reduce to the greatest extent possible, the impact
of these irregularities. However, you should be aware that there are certain
things it cannot do. These include, but are not limited to:
1. Protecting against direct lightning strikes.
2. Protecting from complete loss of power (blackouts).
3. Performing frequency conversion from 50Hz to 60 Hz or vice versa.
4. Isolating ungrounded equipment.
General Information Installation Operation Specification
AR3600I AC LINE VOLTAGE REGULATOR

4
INSTALLATION
SUPPLY CABLE WIRING
Because of the myriad differences in electrical code
requirements around the world, plus the varying cable
length needs in individual installations, it is not possible
to include a complete supply cable with your AR3600I.
Two cable-mount IEC-60309 connector, one each of
male and female type (Figure 7 & 8) that mates with the
AR3600I’s male IEC-309 power input and female IEC-
309 power link output sockets are supplied (Figure 3),
but it is up to the user to connect it to a cable with the
appropriate gauge, number of conductors, length, and source-end connector. This section
is intended to assist in determining the kind of cable to use, and in attaching it to the IEC-
309 socket.
SELECTING THE CABLE
For nominal 120 VAC operation, 3 conductor cable of at least 10 AWG* (.101”/2.56mm
diameter) should be used, depending on distance from the power source.
For nominal 220-240 VAC operation, 3 conductor cable of at least 14 AWG
(.064”/1.62mm diameter) should be used, depending on distance from the power source.
Rubber-jacketed cable is highly recommended for best flexibility and abrasion resistance.
It is permissible to use 4 conductor cable, but it is not necessary to do so and is not
recommended.
EFFECTS OF CABLE LENGTH
When dealing with high currents such as those handled by the AR3600I, the supply cable
itself must be considered part of the load. As such, the length, gauge, and temperature
rating of the insulation must be taken into account. The minimum wire gauges we suggest
may not be large enough when the cable run is longer than about 20 feet (7 meters). The
smaller the cable conductors are, the more fluctuation of input voltage there will be. This
is due to the greater voltage drop. For example, the recommended minimums will result in
a drop of approximately 1.0 volt for each 30 feet (10 meters) of cable.
Increasing the cable by one AWG size will reduce the drop to 1 volt per 45 feet (15
meters). Bigger is definitely better in this case.
SOURCE-END CONNECTOR
The connector used at the source end should be rated at least 220V-15A for high range
operation, or 120V-30A for low range operation. If in doubt, consult a licensed electrician
when installing your AR3600I.
General Information Operation SpecificationInstallation
AR3600I AC LINE VOLTAGE REGULATOR
Figure 3

5
RACK MOUNTING
Because its toroidal transformer design has minimal magnetic leakage, the AR3600I
may be successfully installed in the same rack as other equipment. Though small for
a device capable of handling 30 amps, this leakage is not zero. It is wise to avoid
positioning the AR3600I immediately adjacent to equipment which handles low-level
signals, such as preamps, mike mixers, etc. Power amps or other high level devices
would make better “rack neighbors.” If excessive hum or buzz is present in the audio
signal, you may be able to reduce or eliminate it by leaving more empty spaces next
to the AR3600I.
Suggested rack locations would be near the top or bottom, with the bottom preferred
due to the AR3600I weight. Because the AR3600I generates considerable heat,
leaving at least one empty space above and one below is recommended to aid in
convective cooling. As with any rack-mount equipment, be sure to use 10-32
machine screws for mounting in the rack’s tapped holes. In particular, beware of 10-
24 screws, which may fit, if forced, but will strip the threads. To avoid marring the
front panel finish, use plastic washers under the screw heads.
OPERATION
FRONT PANEL FEATURES
INPUT VOLTMETER: Large size 7 segment 3 digit LED display, indicate the input
voltage in either of two ranges. The appropriate range is selected automatically.
OUTPUT AMMETER: Large size 7 segment 3 digit LED display with decimal,
indicates the output current.
OUTPUT VOLTMETER: Large size 7 segment 3 digit LED display, indicates the
output voltage.
OUTPUT VOLTAGE LED INDICATORS: This display indicates whether the output
voltage is within 5% of nominal 120V. It will light green when IN REGULATION, &
yellow if 5% OVER or 5% UNDER.
The yellow lights come on only when the input voltage is extremely far from normal.
However, that doesn’t necessarily mean your equipment won’t work (even 10%
below 120V is 108V, which is still adequate for most 120V equipment.)
INPUT VOLTAGE RANGE SELECTION: The AR3600I will detect the different of the
input voltage and automatically switch over to the appropriate operating voltage
range 80~134V (Low range) or 170~264V (High range).
General Information SpecificationInstallation Operation
AR3600I AC LINE VOLTAGE REGULATOR

INPUT VOLTAGE
OUTPUT VOLTAGE
LN
REGULATED
OUTPUTS
5%
OVER
IN
REGULATION
5%
UNDER
OUTPUT CURRENT
UNiKA
P R O F E S S I O N A L A U D I O
AR-3600 I
INPUT RANGE:
88-264VAC 30A MAXIMUM
O
T
R
S
E
S
S
E
E
R
T
P
L I N E R E G U L A T O R
1 2 0 V 3 0 A O U T P U T
A C .
6
Over/Under Voltage
and “In Regulation”
Indicators
AC Power Switch and
30 Amp Magnetic Circuit
Breaker
Output Voltage
HIGH RANGE BREAKER: The AR3600I’s basic current rating is 30 amps output at
120 VAC. The current at the input (where the circuit breakers are located) will be the
same as the output only if the input voltage is also 120V (low range). If the AR3600I
is powered from a 220/240 volt source (high range), the input current will be
approximately half, or 15 amps, to produce the rated 120V, 30A at the output.
Therefore, safety considerations require a separate 15A breaker which is active only
when a high range (170 volts or higher) supply voltage is used. This breaker trips by
popping out. If it trips, decrease the load on the AR3600I and push it in to reset.
POWER SWITCH: This is the AR3600I’s main on-off switch. It is actually a 30
ampere magnetic-trip circuit breaker rated for use as a switch. If the current drawn
through the AR3600I exceeds 30 amps at any time, the breaker will trip by snapping
into the off position. If this happens, decrease the load on the AR3600I and turn it
back on.
After turning the Power switch on, there is a delay of approximately 3 seconds
before power is available at the AR3600I’s output.
Current Breaker for off shore
220-240V operation
General Information Installation SpecificationOperation
AR3600I AC LINE VOLTAGE REGULATOR
Output Current Input Voltage
Figure 4

LINE AC
120V 50 / 60Hz
M A X I M U M L O A D AV 1 2 0 V 5 0 / 6 0 H z
REMOTE
ON / OFF
WARNING! SEE OWNERS
MANUAL FOR OPERATING
INSTRUCTIONS
REGULATOR OUTPUTS
MAXIMUM LOAD
SWITCHED OUTLETS 13A
LNLNLN
LNLNLN
AR-3600 I
L I N E R E G U L A T O R
1 2 0 V 3 0 A O U T P U T
A C .
TERMINAL STRIP FOR REMOTE OPERATION: Connection to this screw-terminal
strip allows for a single AR3600I to be turned on remotely, or for multiple AR-3600Is
to be turned on remotely, either simultaneously or in a delayed sequence. A built-in
delay of approximately half a second is available to stagger the potentially large
inrush currents that occur when certain types of equipment are powered up
simultaneously. Using such a delayed sequence can avoid blowing a house breaker
when all the A3600Is are powered from the same circuit. See the section on
Remote/Delayed Operation later in this manual for details. Note: No connections or
jumpers are needed for normal AR3600I operation.
REGULATED OUTLETS: There are 7 regulated outlets on the AR3600I, one in front
and the balance in the rear. While the combined load formed by all equipment
plugged into all 7 outlets may not exceed 30 amps, the load on any one individual
outlet may not exceed 13 amps, which is the maximum permissible for the type of
connector used.
7
6 Switched Regulated Outlets
Remote Turn On Connector
30A power Inlet
General Information Installation SpecificationOperation
AR3600I AC LINE VOLTAGE REGULATOR
30A power outlet One individual outlet may not exceed 13 amps
Figure 5

REMOTE/DELAYED OPERATION
It is possible to control one or a group of remotely located AR3600Is using wiring
carrying only a low control voltage. This can be very convenient in certain situations;
for example, turning on amplifiers on a stage from a sound booth in the rear of a hall.
The control signal can be safely routed through wiring no heavier than an unused
microphone line. The control signal is DC, so it will not cause noise in adjacent audio
lines. The necessary voltages are generated internally in the AR3600I; all that is
needed is wiring and a SPST switch.
All connections for remote operation are made through the screw terminal strip on
the rear panel.
There are three recommended configurations:
Single AR3600I, local turn-on only: Turn-on/off is with the Power switch on the front
panel. No wires or jumpers should be connected to the terminal strip.
Single AR3600I, remote turn-on: Connect a switch between the Remote Out and
Remote In terminals. Leave the front panel Power switch in the ON position. When
the switch is open, the AR3600I is on; when closed, the AR3600I, is off.
Multiple AR3600Is, remote turn-on in delayed sequence: A built-in delay of
approximately a quarter second is automatically provided to stagger the potentially
large inrush currents that occur when certain types of equipment are powered up
simultaneously. Using such a delayed sequence can avoid blowing a house breaker
when all the AR3600Is are powered from the same circuit.
To create a remote delayed sequence, all front panel Power switches must be left in
the ON position. All Ground terminals must be connected together. The Delay Out of
the first AR3600I (the one that will turn on first) is connected to the Remote Out of
the second unit. The Delay Out of the second AR3600I is connected to the Remote
Out of the third unit, and so forth for additional units.
The master on-off switch must be connected to the Remote In and Remote Out
terminals of the first unit. See the following illustration.
8
AR-3600I #1
1 2 3 4
1 2 3 4
1 2 3 4
The diagram above illustrates a set of three AR3600Is
connected for remote turn-on in delayed sequence. When
the switch is opened, unit 1 turns on after 3 seconds. Unit
2 turns on a quarter second later, and unit 3 turns on a
quarter second after unit 2.
AR-3600I #2
AR-3600I #3
General Information Installation SpecificationOperation
AR3600I AC LINE VOLTAGE REGULATOR
Figure 6

DEFINITIONS
VOLTAGE REGULATION – The A.C. line voltage is a number indicating the nominal
electrical potential that has been adopted by a region for powering electrical
equipment of all kinds. In the United States and Canada it is 120 volts; in Japan, 100
volts; and in many other countries 220 to 240 volts. The actual voltage can fall below or
rise above this nominal level due to brownouts, power cutbacks, use of substandard
wiring, and other causes. These deviations can cause poor performance or
malfunction. A regulator is a device which, through use of a transformer, corrects the
voltage deviation by stepping it up or down so that it is as close as possible to the
nominal level.
SPIKE – A pulse of energy on the power line. Spikes can have voltages as high as 6000 volts.
Though they are usually of very short duration, the energy they contain can be
considerable, enough to damage sensitive solid-state components in audio and
computer equipment. Spikes can also foul switch contacts and degrade wiring
insulation. They are an unavoidable component of electric power. They are caused
unpredictably by electric motors switching on or off (on the premises or outside), utility
company maintenance operations, lightning strikes, and other factors. Spikes (also
called surges or transients) are absorbed by special components in the AR3600I to
provide safe voltage levels to protect your equipment.
RFI / EMI INTERFERENCE – Noise from RFI (Radio Frequency Interference) or EMI
(Electro Magnetic Interference) involves lower voltages and less energy than is found
in spikes, but it is continuous rather than transient in nature. It is not likely to cause
damage, but it can certainly be annoying, producing static in audio circuits, “snow” on
video screens, or garbled data in computers. Noise can be introduced into AC lines by
nearby radio transmitters, certain kinds of lighting, electric motors, and others.
Because noise occurs at higher frequencies than the 50 or 60 Hz AC line, it can be
effectively reduced through use of low-pass filtering.
9
General Information Installation SpecificationOperation
AR3600I AC LINE VOLTAGE REGULATOR

AR3600I SPECIFICATIONS
Current rating:
30 amperes for input voltages of 120 (low range) or 240 (high range) or higher; derate at .25A
per volt to a minimum of 22.5A
Input Voltage Ranges:
Functional range 80 to 267VAC; provides regulation ±4% in ranges 88-134 and 170-264 VAC
Meter Accuracy:
Voltmeter ±2 VAC; Ammeter, ± 10%; factory calibrated
Spike Protection Modes:
Line to neutral, neutral to ground, line to ground
Clamping Voltage, line to neutral, neutral to ground:
250 Volts peak (130V rms=184V peak)
Clamping Voltage, line to ground:
500 Volts peak
Response time:
1 nanosecond
Maximum surge current:
5,000 amps (8 x 20 ps pulse)
Maximum spike energy:
455 joules total
Noise attenuation: Transverse:
>50 dB, 1 to 120 MHZ
Dimensions:
132mm H x 483mm W x 428mm D
Weight:
24Kg
Construction:
All steel chassis, powder coated; supplied with front handles and rear rack ears; FR-4 glass
epoxy circuit boards
10
General Information Installation Operation Specification
AR3600I AC LINE VOLTAGE REGULATOR

11
Supply Cable Wiring
The back panel of the AR3600I provides
a mounted IEC-309 male connector. A
separate IEC-60309 female cable
mounting power outlet is included with
your AR3600I. Please see page 4 for
cable recommended.
UNiKA recommends use of wire ferrules (not included) to terminate stranded wire in coupling connector.
General Information Installation Operation Specification
AR3600I AC LINE VOLTAGE REGULATOR
Figure 7
Blue 32A 3 Contact
High Current In-line Socket.
Figure 8
Blue 32A 3 Contact
High Current In-line Plug.
A male IEC-60309 cable mounting power
inlet is also included with your AR3600I.
Neutral(N)
Live (Hot)(L)
Ground(G)
Live (Hot)(L)
Ground(G)
Neutral(N)
Live (Hot)(L)
Neutral(N)
Ground(G)
Figure 9 Figure 10

P R O F E S S I O N A L A U D I O
