Unimax GDT120 User manual

???
???
??????
WARRANTY CARD
Product: 230V - 12 M EXTENSION CABLE/PLUG WITH SELF-WINDING FUNCTION
Type: GDT120
Date of manufacture:
Date of sale, stamp, signature:
Serial number (product series):
Repair centre notes:
Without the correctly filled warranty card or without proof of purchase receipt, including
the product type (invoice, purchase receipt) no warranty claim will be processed.
1. KH Trading machines and tools are covered by 6/24 months warranty, starting on the date of
purchase, as described in the Civil Code (proof of purchase or invoice receipt must be
enclosed with the warranty card when making a claim).
2. This warranty does not cover defects caused by unprofessional handling, machine overloads, not
complying with instructions contained in this manual, using accessories that are not approved,
unauthorized repair, regular wear and tear and damages occurred during transport. Further, this
warranty does not cover parts and accessories such as the motor, carbon brushes, seals and
hot-air operated parts and parts that need to be changed regularly.
3. If the repair is to be found as not covered by the warranty policy, all costs including the repair and ship-
ping to and from the repair centre will be paid by the customer, according to valid price list. See www.
4. When making a claim, you must present the warranty card, showing the date of the purchase, the
serial number of the machine, vendor stamp and signature of sales clerk, as well as the proof of
purchase receipt.
5. Warranty claim shall be made at the vendor shop where you bought your machine or you may mail
it to a service centre. The vendor is obligated to fill out the warranty card (date of sale, serial
number, vendor stamp and signature). All these information must be filled in at the time of sale.
6. The warranty period will be extended for the period of time for which the machine has been in the
service centre possession. If the repair or defect is not covered by the warranty policy, all costs including
the repair and shipping will be paid by the owner of the machine / tool. We recommend sending the
machine in its original packaging. Please, also enclose brief description of the defect with the packaging.
7. Before sending the machine for repair, clean it thoroughly. If the received machine is dirty, it may
be rejected by the service shop or you may be charged a cleaning fee.
SERVICE
Logistic centre Klecany
Topolová 483
250 67 Klecany
Czech Republic
Claim department phone number: 266 190 156 T-mobile: [phone]
266 190 111 O2: 601 218 255
Fax: [phone] Vodafone: 608 227 255
http://www.KHnet.cz
Email: ser[email protected]
223300VV--1122MMEEXXTTEENNSSIIOONN
CCAABBLLEE//PPLLUUGGWWIITTHH
SSEELLFF--WWIINNDDIINNGGFFUUNNCCTTIIOONN
USER'S MANUAL
GDT120

2
Dear customer. Thank you for purchasing equipment from KH Trading, s.r.o.
Our company is ready to offer you our services - before, during and after you buy our product.
If you have any question, comment or idea, please contact our business centre. We will do our best to address
your comment or question in timely matter.
Before first use, please read this manual carefully. It is your responsibility to study all instructions,
necessary for safe use and operation and to understand all risks that may be involved during the use
of power machines.
WARNING! Do not try to use this machine before reading this entire manual and before you know
how to handle it. Keep this manual for future reference.
Pay special attention to safety instructions. Not complying with safety rules may cause injury to the
operating person or to people standing by or it may cause damage to the machine or to the work
piece.
Pay special attention to safety notes and safety labels on the machine.
Never remove or damage them.
Please, write information such as the invoice number
and the number of the sale receipt here in this box.
WARNING: This extension cable set with automatic winding action has been manufactured from high-quality
parts. Moveable notch/latch mechanism controls the length and cable tension during winding
action or during work. Convenient design requires small storage place. It is very simple,
comfortable and safe to use. Covers protect the reeling mechanism and the cable against damages
and extend the operational life of your equipment. VDE certificate ensures high cable quality and
flexibility. You may easily mount the 12 m extension cable/plug on a wall or a ceiling. The cable
length may be set according to your requirements. You may turn the product around in 180° to
cover most of the space in your workshop or a warehouse.
The accuracy of instructions, graphs and information contained herein, depends on the printing date. Due to
continuous product improvement, the manufacturer reserves the right to change technical parameters of the
product, without prior customer notification.
Voltage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .~250V
Maximum current . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .16 A
Maximum load . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3 kW
Self-winding extension cable with plug and rubber cover
Input cable H07RN - F . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3 x 1.5 mm2x 1.0 m
Output cable H07RN - F . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3 x 1.5 mm2x 12 m
Net weight . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4.6 kg
Gross weight . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4.9 kg
Packaging dimensions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .315 x 270 x 170 mm
DESCRIPTION
TECHNICAL SPECIFICATION
REPAIR AND MAINTENANCE REPORT
Report and maintenance report:
DATE SERVICE SHOP REPAIR AND MAINTENANCE REPORT

REVISION REPORT
The user is obligated to perform tests and revisions of electrical equipment of the machine
in accordance with valid rules and regulations. Result report:
DATE REVISION TECHNICIAN
Number / SIGNATURE
REVISION REPORT
3
???
•This device may be used by a qualified person, 18 years or older who has been
trained in work and environmental safety procedures.
•Any person using this equipment must possess a medical certificate
demonstrating his eligibility to operate this equipment.
Symbols used in this manual
Warning!
This symbol informs you about the risk of personal injury or damage to the machine
or materials.
Caution! You are using electrically powered machine!
Electrical hazard.
Risk of being caught by spinning machine parts!
Caution! Loose clothing or body parts may get caught by moving machine parts.
Warning!
Danger of damage.
Note:
Additional information.
Use personal safety gear.
General instructions
•Plastic bags and packaging materials pose danger for small children and animals.
•Make sure you know how to control your tool or machine and that you are familiar with its operating
procedure. Know the hazards that may occur, if not used correctly.
•If other person is using this machine make sure that he knows how to safely operate this equipment and
that he is familiar with hazards and risk that may occur, if not used correctly.
•Pay special attention to safety notes and safety labels on the machine. Never remove or damage them.
If the warning label becomes unreadable, please contact your vendor.
•Keep your working place clean. Dirty and disorganized workplace may cause accidents.
•Never work in tight spaces or in purely lit rooms. Make sure the floor is solid and stable and that you can
move around easily. Always keep stable posture.
•Keep focusing and use common sense. Do not continue working if you cannot pay attention.
•Maintain your tools clean and in safe working conditions.
•Handles must be kept free of grease and dirt.
•Make sure no children, unauthorized persons or animals have access to your workshop.
•Never put your hands or legs inside the working area.
•Never leave your machine unattended during operation.
•Use only for purposes for which it has been designed.
SAFETY PRECAUTIONS

4
•Use personal protective gear such as safety goggles, ear protection, respirator, safe working shoes etc.
•Do not overreach, use both hands.
•Never work under the influence of alcohol or other drugs.
•Do not use the machine/tool if you feel dizzy or week.
•Any modifications or improvements to the machine are strictly prohibited. DO NOT USE if you discover
bent part, crack or other damage to your machine.
•Never perform any maintenance during operation.
•If you see any unusual sign or hear any strange sound, switch of the machine immediately.
•Do not forget to remove all wrenches and/or screwdrivers from the machine.
•Before use, make sure all screws are tightened securely.
•Perform maintenance regularly. Before use make sure the machine is in good working conditions
and without any damage.
•Use only original spare parts during repairs.
•Using accessories or extension pieces not approved by the manufacturer may cause injuries.
•Use this machine only for work that could be handled by it. Do not overload tools, accessories or the
machine. For large work volume use more powerful machine.
•Do not overload the machine. Measure the work load in such way, so it could be done with comfortable
speed. Damages due to machine overload are not covered by the warranty policy.
•Do not expose to extremely high temperature or direct sunlight.
•This machine is not designed for use in humid environments or under water.
•If you are not using your equipment, store it in a dry and locked place, out of reach of children.
•Before switching your machine on, make sure that all safety elements work as designed. Make sure all
moving parts are in good working conditions.
•Inspect all parts for cracks and damages. Make sure movable parts are not stuck and set properly.
Also take into consideration other conditions that may have a negative effect on the proper function of
your machine.
•If not stated otherwise in this manual, all damaged parts and safety elements must be repaired
or changed.
Fine mechanics
•Never use a vise to hold you device.
•Protect your machine from fall and impact.
Assembly
•Do not use the machine unless completely assembled.
Electrical equipment
•Observe all basic safety rules when using electrical equipment to prevent risk of fire, injuries by electrical
shock and other hazards. Before using this device, read this manual entirely and follow all safety
instructions.
•Make sure the power cable plug is plugged into the correct wall outlet. The voltage in the wall outlet must
be the same as shown on the specification label to prevent damage to the electric motor. Too low voltage
will not provide your machine with enough power.
9
???
PART LISTING
1. Right decorative cover
2. Right cover
3. Spindle spring
4. Cable core
5. Positioning ball
6. Cable
7. Cable fastening clamp
8. Self-locking jaw
9. Pull spring
10. Dielectric piece
11. Brass ring
12. Middle cable axis
13. Brass plug
17. Middle cable axis cover
18. Supporting seat
19. Foldable seat
20. Console
21. Left decorative cover
22. Cable
23. Left cover
24. House guiding seat
25. Hose guiding support
26. Hose guiding support
27. Bushing

8
???
DETAILED PART DRAWING
5
•Before connecting the machine to the wall outlet make sure that the main switch is in the "OFF" position.
When you finished your work, disconnect the power plug from the wall outlet and switch off the main
switch.
•Never carry electrical tools and appliances by their power cord. When disconnecting the plug from the
wall outlet, never pull the cable by its cord.
•Protect the power cable from high temperatures, oils, paint thinners and make sure that the cable is not
hanging over sharp edges.
•Inspect the power cable regularly. If damaged have it replaced by qualified technician. Inspect extension
cables regularly. If damaged, have it replaced.
•If you need to use an extension cable, use cable with appropriate power rating. Use only completely
unwound. Inspect extension cables for damages regularly. Damaged cable must be repaired or changed
immediately.
•Before performing any maintenance, repair or adjustment, switch off the main switch and disconnect the
power cable from the wall outlet.
•Make sure that machine may not be switched on accidentally. Do not keep your fingers close to the main
switch, unless absolutely necessary.
•If you mount your machine to the work table, release the safety button after installation.
•Do not use in environments where explosives are stored or used (paint shops, warehouse with
flammables etc.).
•Do not use in humid environments or if wet.
Power equipment
•If your machine is equipped with depressed springs, use suitable device to release them slowly and
safely.
•Make sure no part is left inside the packaging box before throwing the packaging materials out. If so, take
it out and install it. Use the part listing for check-up and the installation drawing for guidance.
•Console mount. You may mount your extension cable set on a wall, using a revolving console (pic. 3) or to
other place (ceiling etc.) In order to turn the cable set around in 180°, make sure that there is a free
space of 500 mm on both sides of the cable set. Mount the console on wall or ceiling, using the supplied
screws, spring washers and flat washers. The console has a two mounting holes with distance between
them of 130 mm. (See picture 4).
ASSEMBLY
pic. 3 pic. 4

Correct operation and control
•If you pulled out sufficient cable length, continue pulling it slowly until you hear "click". The cable is now
secured against reeling back.
•If you need longer cable, continue puling it, until you hear "click" again.
•If you want to wind the cable back, pull it out about 400 mm until you hear "click". Then release the cable
and it will reel in automatically.
•Do not help the cable during the reverse reeling action. The cable turns on the spindle may get loose and
the cable will not be wound up properly. In such case you must pull the cable out completely and let it reel
in again. That way you prevent cable deformation and ensure correct cable storage on the spindle.
•Hold the cable slightly during reverse reeling to prevent injuries due to a cable swing.
•Do not attempt to reel the cable in cold environment as cold cable looses its flexibility. Move the cable set
to a warm room. Make sure to bend the cable in large radiuses to prevent cable damage. Reel the cable
back in after it reached its usual temperature.
•Before performing any maintenance make sure the cable is disconnected from the wall outlet.
•Protect the cable from water to prevent injuries by electric current.
•Inspect the cable regularly.
•Clean dirty cable or the covers of the cable set with neutral cleaning solution or alcohol. Using aggressive
solutions may damage the cable or the covers.
•Store the cable in dry and safe place to ensure its perfect conditions and long operational life.
•Maintain your tools clean. Dirt may enter the inner mechanism of your machine and cause damage.
•Do not use aggressive cleaning solution or paint thinners to clean the machine.
•Clean plastic parts with cloth dipped in soup water.
•If you are not using your equipment, store it in a dry place.
When the operational life of your device is over, dispose off it in accordance with valid rules and regulations.
Your product is made of metal and plastic parts that may be recycled when separated.
1. Disassemble all parts.
2. Separate all parts according to the material they are made of (e.g. metals, rubber, plastics, etc.).
Take the separated parts to the recycling facility near you for further processing.
3. Electrical waste (used electrical power tools, electric motors, recharging equipment, electronics,
accumulators, batteries etc.).
Dear customer. In accordance with the valid regional rules and regulations describing the management of
electrical waste, electrical waste is considered dangerous. Disposal of electrical waste must be therefore
handled as dangerous waste in accordance with waste management rules valid in the state you are in.
It is prohibited to mix electrical waste with regular household waste.
You may return your used electrical appliance to a recycling facility near you. More information about
electrical and dangerous waste disposal may be obtained from your local authority or from the Internet.
6
DISPOSAL
OPERATION
MAINTENANCE
7
If the machine breaks down, send it back to the vendor for quick repair.
Please, enclose brief description of the defect. That makes repair easier. If the machine is still covered by
warranty, enclose the warranty card and proof of purchase receipt. After the warranty period expires, we
repair your machine for a special price.
To prevent possible damages during shipping, packed the machine carefully or use the original packaging
material. We are not liable for shipping damages due to incorrect packaging of your machine. If making
a claim at the shipping company the level and method of packaging plays a major role during claim evaluation
process.
Note: Pictures and contents in this manual may slightly differ from the actual product or accessories.
It is due to continuous improvement of our products. Such small differences have no effect on the product
functionality.
CAUTION
