Installation Manual Unimi-1baseHPC
Introduction:
Unimi-1baseHPC is intended for installation of larger rapid charging stations.
By attaching an adaptor element at the top, each Unimi-1baseHPC can accommodate a wide variety of
different chargers.
The upward face and cable inlet of the adaptor element may look different from time to time depending on
station model however the outer rectangular size and attachment pattern towards the Unimi-1baseHPC is
always the same.
Local building codes and regulations always supersede these guidelines and it will be the responsibility of
the installer to install the Unimi-1baseHPC in such a manner that they are not in conflict.
Top of a Unimi-1baseHPC foundation attached with an adaptor for a Tritium 150 kW rapid
charger

Unimi
Kap
-
Kostnb. K00717
Dok namn Produktbeskrivning
Mallens filnamn
Produktbeskrivning.doc
Dok dat
-
Aktuellt filnamn
Produktbeskrivning –Unimi-1baseHPC
Gäller fr o m
2020-06-08
Rev
02
Godkänd
2014Draft01-
20
Sid
Unimi-1baseHPC dimensions:
•Length (at the base) 1200 mm
•Depth (at the base) 1200 mm
•Length (at the top) 720 mm
•Depth (at the top) 590 mm
•Height 775mm
•Weight 1270 kg
Measurements top view
Installation procedure:
1. To off-load the Unimi-1baseHPC either use fork-lift for the EUR pallet on which the foundation is
loaded or use a lift sling attached to the two lifting anchors positioned at either long side of the
foundation.
2. The cavity where the Unimi-1baseHPC shall be installed should be large and deep enough so
that the underlying ground can be prepared in such a way that water will drain away from
underneath the station. Ideally, draining layer of gravel should penetrate below ground frost level
of where the installation site is situated. The cavity should allow work with ground stomp machine
both below and at the sides of the foundation. The local conditions and machinery used by the
installer will be the determining factor for the size of the cavity. As a minimum we recommend 300
mm wider on each side than the foot of the base (1800x1800 mm).
3. The intention is to have the top of the Unimi-1baseHPC foundation flush with surrounding ground
level (excluding the adaptor element that will add 10 mm at the top after installation). Depending
on local conditions such as water drainage it may be required that the foundation top protrudes
from final ground surface. This should not exceed 100 mm if integrated Unimi-1baseHPC crash
protections will be installed on the foundation.
4. If possible, with regards to the above, we recommend that 200 mm in each direction from the
foundation top shall be flush. Although not a necessity, this will make future swap of adaptors to
other station brands easier as those adaptors may have to be off set from foundation center
5. When installing the Unimi-1baseHPC pay close attention to the orientation of the foundation so
that it is aligned with the station design and intended facing towards charging vehicles and users
6. The Unimi-1baseHPC has 1x112 mm conduit inlet and 1x51 mm conduit inlet in each direction.
Unused conduit openings will be covered with plastic lids
a. From June 2020 there will be a pan European version of Unimi-1baseHPC that will have
2x142 mm conduit openings on one of the short sides and on one of the long sides. This
to better align with the standards used in different regions of Europe
7. If necessary, plastic attachment adaptors may be used between the foundation conduit inlet holes
and the plastic conduits. Installation expansion foam may also be used. (None of these supplied
with foundation)

Unimi
Kap
-
Kostnb. K00717
Dok namn Produktbeskrivning
Mallens filnamn
Produktbeskrivning.doc
Dok dat
-
Aktuellt filnamn
Produktbeskrivning –Unimi-1baseHPC
Gäller fr o m
2020-06-08
Rev
02
Godkänd
2014Draft01-
20
Sid
Different stages of installation. Rightmost picture showing a Tritium charger installed
using an adaptor between the foundation top and base of charging station.
8. If integrated protection bollards shall be installed they can be attached on all sides of the Unimi-
1baseHPC via the 2xM16 concrete anchors. The protection bollards can be adjusted up and
down alongside the foundation wall. Note that the attaching screws of the cylinders shall be just
above ground surface to allow easy switch of damaged poles.
Further questions can be answered at i[email protected] or bu calling [phone]
Note: The encircled attacment screws of the protection bollards should be positioned above
final ground level
