INSTALLATION MANUAL UNIMI-1BASE ECO PLASTIC TM
www.unimisolution.com Copyright © 2021 Unimi Solutions AB Reg pat: EP2668063B
US9376831B2
Unimi-1Base ECO PlasticTM pre-cast foundation with adaptor for EV
charging station anchoring

INSTALLATION MANUAL UNIMI-1BASE ECO PLASTIC TM
www.unimisolution.com Copyright © 2021 Unimi Solutions AB Reg pat: EP2668063B
US9376831B2
•The Unimi-1Base ECO PlasticTM foundation is designed for anchoring of EV charging stations in
the ground, predominantly in the outdoor public environment.
•This installation manual serves as guidelines and function alongside any local building codes.
If in conflict, the local building codes supersede these instructions.
•The foundation is equipped with 4x110 mm (4 inch) cable conduit inlets positioned in 90-
degree angles from one another allowing easy multiple cable entry. Unused entry holes shall
be covered with the supplied plastic conduit covers.
•The foundation needs to be placed in a cavity large enough so that the excavated ground
masses can be trampled/vibrated both underneath and on the sides of the foundation. Ensure
that the masses are packed thoroughly so that they fill the compartments of the foundation
ensuring a stable installation result.
•Recommended min cavity dimensions are 800x800x800 mm depending on ground
stomp/vibrator used. (Please refer to foundation specs at the last page of this manual)
•It is further recommended that the surrounding masses are of self-draining material such as
mixed stone gravel or macadam with packable characteristics.
•The top of the foundation shall be flush with the final ground surface level, allowing
pedestrians and lighter traffic to pass over it without the foundation constituting a tripping or
driving hazard if the foundation is installed in “dormant” mode with a manhole cover over it.
(Manhole cover supplied separately)

INSTALLATION MANUAL UNIMI-1BASE ECO PLASTIC TM
www.unimisolution.com Copyright © 2021 Unimi Solutions AB Reg pat: EP2668063B
US9376831B2
•Suggested orientation of the attaching beam inside the foundation is according to the picture
on previous side
•Most adaptors will be fastened using only one center screw (M12x90 mm) making the
adaptor rotatable at the foundation top, however if larger charging stations are anchored all
three attachment points might be needed and then the orientation of the beam will become
important
•Before attaching the station specific adaptor, make sure that the foundation rim is clear of
any small gravel that might make the adaptor wiggle after installation
•Attach the adaptor with the accompanying M12x90 mm screw(s) (1-3 pcs) thru the bracket
of the adaptor into the beam inside of the foundation
•Maximum torque on the screw is 18 Nm. Greater torque will start to deform the bracket
which is part of the patented functionality serving as a protection to keep the position of the
foundation intact in the ground in case of any vehicle driving into the charging station.
•The below picture serves as a conceptual drawing –the adaptor and EV charging station
dimensions may vary depending on station manufacturer
EV charging station
(ABB Terra Wallbox as example)

INSTALLATION MANUAL UNIMI-1BASE ECO PLASTIC TM
www.unimisolution.com Copyright © 2021 Unimi Solutions AB Reg pat: EP2668063B
US9376831B2
•If optional integrated Unimi-1base ECO Plastic crash protections are part of the installation,
these shall be installed so the pervading screws (1) of the bollards are just above ground
level. This to ensure easy switch of damaged poles (2) in case of any vehicle crashing into it
•Unimi-1Bse ECO Plastic has pre-drilled holes used as attachment points for the crash
protection (3)

INSTALLATION MANUAL UNIMI-1BASE ECO PLASTIC TM
www.unimisolution.com Copyright © 2021 Unimi Solutions AB Reg pat: EP2668063B
US9376831B2
A charging ready street in Reykjavik, Iceland showing 3 future proof, scalable, pre-prepared Unimi-1bases with
crash protections. In the distance, two installed EV charging stations serving current EV charging demand
