UnionSpecial M312G User manual

ORIGINAL INSTRUCTIONS, ENGINEER’S ANDORIGINAL INSTRUCTIONS, ENGINEER’S AND
ORIGINAL INSTRUCTIONS, ENGINEER’S ANDORIGINAL INSTRUCTIONS, ENGINEER’S AND
ORIGINAL INSTRUCTIONS, ENGINEER’S AND
ILLUSTRAILLUSTRA
ILLUSTRAILLUSTRA
ILLUSTRATED PTED P
TED PTED P
TED PARAR
ARAR
ARTS MANUALTS MANUAL
TS MANUALTS MANUAL
TS MANUAL
FOR CARPET STRIP CUTTING MACHINE M312G, AFOR CARPET STRIP CUTTING MACHINE M312G, A
FOR CARPET STRIP CUTTING MACHINE M312G, AFOR CARPET STRIP CUTTING MACHINE M312G, A
FOR CARPET STRIP CUTTING MACHINE M312G, A
FOR CARPET BORDER EDGINGFOR CARPET BORDER EDGING
FOR CARPET BORDER EDGINGFOR CARPET BORDER EDGING
FOR CARPET BORDER EDGING
MANUAL NO. 306ENMANUAL NO. 306EN
MANUAL NO. 306ENMANUAL NO. 306EN
MANUAL NO. 306EN
10/2012

I
Third Edition © 2009
Printed in Germany
Subject to change without notice.

1
UNION SPECIAL CARPET STRIP CUTTING MACHINE M312GUNION SPECIAL CARPET STRIP CUTTING MACHINE M312G
UNION SPECIAL CARPET STRIP CUTTING MACHINE M312GUNION SPECIAL CARPET STRIP CUTTING MACHINE M312G
UNION SPECIAL CARPET STRIP CUTTING MACHINE M312G
FOR CARPET BORDER EDGINGFOR CARPET BORDER EDGING
FOR CARPET BORDER EDGINGFOR CARPET BORDER EDGING
FOR CARPET BORDER EDGING
The machine has a rotating carrierrotating carrier
rotating carrierrotating carrier
rotating carrier for 3 cutting blade drive shafts. Each drive shaft is equipped with
4 revolving cutting blades. The machine comes factory adjusted with a distance of the blades on
each of the drive shafts of 60, 70 and 80 mm (different dimensions on request). The lower shaft has
clearance cuts for the knives which are spaced 5 mm apart.
Equipped with a maintenance free motor 230/400V / 3 ph / 50 c/s, 0.37 kW. Safety switch if Plexiglas
cover is opened. Foot switch, control lamp indicating „ready for operation“.
Dimensions: approx. 900 x 400 x 400 mm. Weight: 79 kg.
Packing: carton 118 x 65 x 75 mm. Weight: 89 kg gross.
Emission value relating to the work place:
·Change of cutting width of the 3 knife drive shafts without any tools.
·Knife drive shafts can be easily removed for re-sharpening or for changing the distances between
the blades for different cutting width.
·Cutting blades made out of high quality steel, dia 102 mm. Increase of knife life due to cutting
without a counter shear blade. Suitable for all known carpet types.
·High cutting productivity of up to 26 m/min (depending on carpet material).
·Start/Stop by foot switch.
·Two pull-out support arms, approx. 400 mm long, allow easier handling of wider carpet pieces.
Cutting Machine M312ACutting Machine M312A
Cutting Machine M312ACutting Machine M312A
Cutting Machine M312A
Same as M312G, but single phase motor 230V / 50 c/s, 0.37 kW.
SAFETY RULESSAFETY RULES
SAFETY RULESSAFETY RULES
SAFETY RULES
Maintenance, repair and conversion work must be done only by trained technicians or special
skilled personnel under condsideration of the instructions.
Any work on the electrical equipment must be done by an electrician or under direction and
supervision of special skilled personnel.
Work on parts and equipment under electrical power is not permitted. Permissible exceptions are
described in the applicable section of standard sheet EN 50 110 / VDE 0105.
ATTENTION!ATTENTION!
ATTENTION!ATTENTION!
ATTENTION!
Before doing maintenance and repair work the carpet strip cutting machine
has to be disconnected by turning off the main switch or pulling the power
supply plug from the mains.

2
INSTRUCTIONS CARPET STRIP CUTTING MACHINE M312G, AINSTRUCTIONS CARPET STRIP CUTTING MACHINE M312G, A
INSTRUCTIONS CARPET STRIP CUTTING MACHINE M312G, AINSTRUCTIONS CARPET STRIP CUTTING MACHINE M312G, A
INSTRUCTIONS CARPET STRIP CUTTING MACHINE M312G, A
Switchboard
A = Clutch lever (Position: Motor shifted) 999-272NA68
B = Clutch lever (Postition: Motor neutral) 999-272NA68
C = Plug for foot switch 998-94K
D = Switch on (1) Switch off (0) 998-224E
E = Notch 999-271-14
F = Control lamp 999-272NA60
Put power supply plug into the socket and turn on machine.
The cutting blade drive shaft has to turn in direction towards the operator. If not, polarity has to be
reversed.
If switch is set to 0 power and control lamp are off.
If switch is set to 1 control lamp is on, machine is turned on. By actuating the foot switch carpet strip
cutting machine can be started.
Machine can only be started by actuating the foot switch.
The carrier is equipped with 3 cutting blade drive shafts containing 4 revolving cutting blades. These
come adjusted with a different distance of the blades on each of the drive shafts (6, 7 and 8 cm).
To interchange a cutting blade drive shaft against one of the two others you have to proceed as
follows:
1. Switch off carpet strip cutting machine.
2. Move clutch lever down to touch position (B).
3. Open cover.
4. Loosen tommy screw on the right hand of the carrier by hand until resistance is noticable.
5. Pull notch (E), turn tommy screw counterclockwise, release notch (E) and continue turning
until desired cutting blade drive shaft faces the countershaft and noticeable clicks into place.
6. Tighten tommy screw by turning it clockwise.
7. Replace clutch lever to position (A).
8. Close cover.
Putting into servicePutting into service
Putting into servicePutting into service
Putting into service

3
CC
CC
Changing the cutting blade drive shafthanging the cutting blade drive shaft
hanging the cutting blade drive shafthanging the cutting blade drive shaft
hanging the cutting blade drive shaft
1. Turn off carpet strip cutting machine.
2. Move clutch lever down to touch position (B) .
3. Open cover.
4. Loosen tommy screw by hand until resistance is noticable.
5. Pull notch (E), turn tommy screw in counterclockwise direction, release notch (E) and continue
turning until cutting blade drive shaft slightly clicks into place and the cutting blade drive shaft
flange is located at the right bulging of the bracket plate.
6. Remove two allen screws with the wrench (delivered with the accessories) out of the bearing
housing and remove cutting blade drive shaft. Put in new cutting blade drive shaft, screw in
allen screws, fasten them lightly and turn tommy screw in counterclockwise direction until
cutting blade drive shaft faces the counter shaft and noticeable clicks into place.
7. Fasten tommy screw by turning clockwise.
8. Move clutch lever in position (A) upwards.
9 Close cover.
The press pads are designed to fit cutting widths of 60, 70 or 80 mm. Press pads are resilient and their
height do not have to be adjusted when cutting different rug thicknesses.
When using cutting widths differing from these sizes a complete press pad with the required strip
width has to be ordered.
Installation of press pad is relatively simple. Push in press pad traverse bar to the stop in the drilled
hole, after that adjust the press pads to be just in contact with the counter shaft and tighten with two
allen screws at the backside of the frame.
Make sure that the ground cut edge always points to the left.
Caution:Caution:
Caution:Caution:
Caution:
Carpet glue residues have to be removed from the grooves of the lower counter shaft daily. PluggedCarpet glue residues have to be removed from the grooves of the lower counter shaft daily. Plugged
Carpet glue residues have to be removed from the grooves of the lower counter shaft daily. PluggedCarpet glue residues have to be removed from the grooves of the lower counter shaft daily. Plugged
Carpet glue residues have to be removed from the grooves of the lower counter shaft daily. Plugged
up grooves can cause breakage of driving mechanism.up grooves can cause breakage of driving mechanism.
up grooves can cause breakage of driving mechanism.up grooves can cause breakage of driving mechanism.
up grooves can cause breakage of driving mechanism.
Cleaning of the lower counter shaft:Cleaning of the lower counter shaft:
Cleaning of the lower counter shaft:Cleaning of the lower counter shaft:
Cleaning of the lower counter shaft:
1.1.
1.1.
1. Bring shaft carrier in intermediate position (shaft change position).Bring shaft carrier in intermediate position (shaft change position).
Bring shaft carrier in intermediate position (shaft change position).Bring shaft carrier in intermediate position (shaft change position).
Bring shaft carrier in intermediate position (shaft change position).
2.2.
2.2.
2. Loosen two allen screws on backside of frame.Loosen two allen screws on backside of frame.
Loosen two allen screws on backside of frame.Loosen two allen screws on backside of frame.
Loosen two allen screws on backside of frame.
3.3.
3.3.
3. Remove rod with press pads completely (pull out).Remove rod with press pads completely (pull out).
Remove rod with press pads completely (pull out).Remove rod with press pads completely (pull out).
Remove rod with press pads completely (pull out).
4.4.
4.4.
4. Close cover, start carpet strip cutting machine and remove carpet and glue residue with theClose cover, start carpet strip cutting machine and remove carpet and glue residue with the
Close cover, start carpet strip cutting machine and remove carpet and glue residue with theClose cover, start carpet strip cutting machine and remove carpet and glue residue with the
Close cover, start carpet strip cutting machine and remove carpet and glue residue with the
cleaning hook (in asseccories) completely from the grooves.cleaning hook (in asseccories) completely from the grooves.
cleaning hook (in asseccories) completely from the grooves.cleaning hook (in asseccories) completely from the grooves.
cleaning hook (in asseccories) completely from the grooves.

4

5

6

7

8

9

10

11
REPLACEMENT PARTS
Pos. No.
1
2
3
4
5
6
7
7a
8
9
10
11
12
13
14
15
16
17
18
19
20
21
Part No.
999-272NH
999-272NA22
999-272NA3
999-272NA-23
999-106N
999-272NA5
999-272NA24
3444002
95437
999-272NA2
999-272NA20
999-272NA1
95477A
999-272NA32
999-272NA12
999-272NA31
999-272NA30-4Z
999-272NA33
999-272NA25
999-272NA32Z
999-272NAO
999-272NA27
Description
Knife Shaft Assembly with 4 Knives
Presser Spring
Shaft
Ring Seeger
Ball Bearing
Bearing
Ring Seeger
Screw M5x16
Screw M4x12
Ring
Ring Seeger
Flange
Screw M8x16
Flange with Knife Assembly
Lower Shaft
same as Pos. 1, Knife Shaft Assembly, but
without knife (not shown)
same as Pos. 1, Knife Shaft Assembly, but
with 4 serrated knives (not shown)
same as Pos. 10, Ring Seeger but HSS
(not shown)
same as Pos. 10, Ring Seeger but serrated
(not shown)
same as Pos. 13, Flange with Knife Assembly,
but knife serrated (not shown)
same as Pos. 13, Flange complete, but
without knife (not shown)
Cleaner for Roller
Amt. req.
1
1
1
1
1
1
1
2
2
1
1
1
1
1
1
1
1
1
1
1
1
1

12
Pos. No. Part No. Description Amount
999-272NE Protectioncover complete
1 999-272NA40 Panelfront 1
2 999-272NA41 Panelrear 1
3 999-272NA42 Paneltop 1
4 999-272NA43 Panelright 1
5 999-272NA44 Hinge 2
6 99316B ScrewM3x12,5 4
7 999-272NA45 MountingBracket 7
8 95437 ScrewM4x12 14
9 999-272NA46 CoverGuide 2

Carpet Hold Down Device: Cutting widths 5 / 6 / 7 / 8 cm
Pos. No.
1
2
3
4
5
6
7
Part-No.
999-272NG
999-272NA21L
999-272NA21ML
999-272NA21MR
999-272NA21R
999-272NA28
95760
95453
Description
Carpet Hold Down Device complete
HoldDown Plateleft
HoldDown Platemiddle-left
HoldDown Platemiddle-right
HoldDown Plateright
HoldDown Rod
ScrewM4x22
NutM4
Amount
1
1
1
1
1
8
8
13

14

EC DEC D
EC DEC D
EC Declaration of Conformityeclaration of Conformity
eclaration of Conformityeclaration of Conformity
eclaration of Conformity
in accordance with the EC Machinery Directive 2006/42/EC, Annex II, No. 1 Ain accordance with the EC Machinery Directive 2006/42/EC, Annex II, No. 1 A
in accordance with the EC Machinery Directive 2006/42/EC, Annex II, No. 1 Ain accordance with the EC Machinery Directive 2006/42/EC, Annex II, No. 1 A
in accordance with the EC Machinery Directive 2006/42/EC, Annex II, No. 1 A
We hereby declare that the below described machine as designed and delivered by
us is in conformity with the essential safety and health requirements, Annex I of the
Machinery Directive and with the provisions of the further listed EC Directives.
Machine description: Carpet Strip Cutting Machine
Machine type: M312
Applied EC Directives:
- EC Machinery Directive 2006/42/EC
- EC EMC Machinery Directive 2004/108/EC
- EC Low Voltage Directive 2006/95/EC
Applied harmonized standards:
EN ISO 12100-1,
EN ISO 12100-2
EN 60204-1
This declaration is not valid anymore if modifications have been made without our
permission.
Union Special GmbH
Raiffeisenstr. 3
D-71696 Möglingen
Rolf Iseler
Managing Director, authorized person for technical file
Möglingen, 29.12.2009
15

WORLDWIDE SALES AND SERVICE
WELTWEITER VERKAUF UND KUNDENDIENST
Union Special maintains sales and service facilities throughout the
world. These offices will aid you in the selection of the right sewing
equipment for your particular operation. Union Special represen-
tatives and service technicians are factory trained and are able to
serve your needs promptly and efficiently. Whatever your location,
there is a qualified representative to serve you.
Union Special LLC
One Union Special Plaza
Huntley, IL 60142
Phone: US: 800-344 9698
Phone: [phone]
Fax: [phone]
www.unionspecial.com
e-mail: [email protected]
European Distribution Center:
Corporate
Office:
Union Special GmbH
Raiffeisenstrasse 3
D-71696 Möglingen, Germany
Tel.: [phone]
Fax: [phone]
www.unionspecial.de
e-mail: [email protected]
Union Special unterhält Verkaufs- und Kundendienst-Nieder-
lassungen in der ganzen Welt. Diese helfen Ihnen in der Auswahl der
richtigen Maschine für Ihren speziellen Bedarf. Union Special
Vertreter und Kundendiensttechniker sind in unseren Werken
ausgebildet worden, um Sie schnell und fachmännisch zu bedienen.
