Unior 1693BS-US User manual

Tehni č ki podaci
uniortools.com
Stalak za servisiranje bicikala sa
stegom sa podesivim prihvatom i s
fiksnom plo č om
Profili
1693BS-US

Upotreba (pictures)
Atributi proizvoda
* Slike proizvoda su simboli č ne. Sve dimenzije su u mm, masa je u g.
Stalak za servisiranje bicikala sa fiksnom plo č om dizajniran je za svakodnevnu upotrebu u servisnim
radionicama
●
Plo č a je ergonomskog oblika, nosivosti 30 kg što omogu ć ava servisiranje i težih bicikala.
●
Pogodno za cijevi promjera od min Ø24 mm do max. Ø40 mm.
●
težina stalka je 36 kg
●
Izmjenjive obloge prihvata, art. 1693.11
●
625013 985 1570 726 572 1700 38800

Adjust bike stand
height To adjust the
bike stand height,
release the lever (C) and
adjust the top tube (D).
Adjust jaw angle and
clamp bike safely To
adjust the bike stand jaw
angle, release lever (F)
and adjust/rotate (E).
Adjust opened jaw (G)
to the seatpost or bike
tube. Turn handle (H)
until jaw firmly grabs the
tube.
To adjust the jaw
opening, turn the long
screw (Z) with hand in
needed direction as
shown on picture.
Release bike safely from
stand To release, firmly
hold bike frame. Flip
handle (I) to quickly
release tube from the
jaw.
To mount the stand
without fixed plate to the
floor or ceiling, use
appropriate screw
anchors and screws (P)
according to the
floor/ceiling material, as
shown on picture.
Screws and screw
anchors are not
included.
