Unipower Aspiro 1U Enclosure User manual

Power Supply System
Aspiro 1U in a 2U Enclosure
Instruction Manual
www.unipowerco.com
Document Number: PM110-6500-00 rev2a © 2017 UNIPOWER LLC
All Rights Reserved
PM110-6500-00-rev2a-0117.indd
UNIPOWER LLC • 3900 Coral Ridge Drive, Coral Springs, Florida 33065, USA • [email protected]
North America: [phone] • Latin America: [phone] • Europe: [phone]
POWERING TECHNOLOGY

Page 2
POWERING TECHNOLOGY
Manual No. PM110-6500-00 rev-2a
PM110-6500-00-rev2a-0117.indd
Copyright © 1999-2017 UNIPOWER LLC
All Rights Reserved
Restricted Rights Legend:
Use, duplication, or disclosure by the Government is subject to restrictions as set forth in
subparagraph © (1)(ii) of the Rights in Technical Data and Computer Software clause at DFARS
252.227-7013 or sub-paragraphs © (1) and (2) of Commercial Computer Software - Restricted
Rights at 48 CFR 52.227-19, as applicable.
For Contact Information, please go to http://www.unipowerco.com/contact/
RefertotheUNIPOWERLicenseAgreementinthispackagebeforeinstallingorusingthisproduct.
Unless specically noted, all addresses, data characters and persons referenced herein, and all
examples involving names of companies and products, are ctitious examples and are designed
solely to illustrate the use of UNIPOWER products.
Product names, logos, brands, and other trademarks featured or referred to within this product
manual are the property of their respective trademark holders. These trademark holders are not
aliated with UNIPOWER LLC or our products. They do not sponsor or endorse our products.
LIMITATIONS AND AUTHORIZATIONS FOR USE AND PERMITTED APPLICATIONS
UNIPOWER’s products are not designed, intended for use in, or authorized for use as critical
componentsin,humanlifesupportsystems/equipment,equipmentusedinhazardousenvironments,
or equipment used in nuclear control equipment or systems. Any such use requires the prior
express written consent of an authorized executive ocer of UNIPOWER LLC, which consent
may be withheld by UNIPOWER LLC in its sole discretion. Users assume all risk and liability for,
and agree to indemnify and defend UNIPOWER from and against any claims for personal injury
(including death) or property damage resulting from any such use or application which is made in
the absence of such prior express written consent.
If you nd errors or problems with this documentation, please notify UNIPOWER. UNIPOWER
does not guarantee that this document is error-free. The information in this document is subject to
change without notice.

Page 3
POWERING TECHNOLOGY
Manual No. PM110-6500-00 rev-2a
PM110-6500-00-rev2a-0117.indd
Contents
Chapter 1 About This Manual......................................................................................................6
1.1 Objectives.................................................................................................................................6
1.2 Audience ..................................................................................................................................6
1.3 Document Key .........................................................................................................................6
1.4 Feedback & Support.................................................................................................................7
1.6 Disclaimer................................................................................................................................7
Chapter 2Aspiro System Description..........................................................................................8
2.1 Overview..................................................................................................................................8
2.2 System Congurations .............................................................................................................8
2.3 System Parameters...................................................................................................................9
2.4 System Components...............................................................................................................11
2.4.1 System Controller .....................................................................................................11
2.4.2 DC Distribution.........................................................................................................11
2.4.3 Low Voltage Battery Disconnect (LVBD)................................................................11
2.4.4 Rectier Module .......................................................................................................12
Chapter 3 System Safety..............................................................................................................13
3.1 Safety Warnings and Guidelines............................................................................................13
3.1.1 System Markings ......................................................................................................13
3.1.2 Safety Recommendations..........................................................................................13
3.1.3 Installation Warning..................................................................................................13
3.1.4 Electrical and Fire Enclosure....................................................................................14
3.1.5 System Enclosure......................................................................................................14
3.1.6 Operating Temperature Warnings .............................................................................14
3.1.7 Electrical Safety Warnings........................................................................................14
3.1.8 EMC Considerations.................................................................................................15
3.1.9 Grounding.................................................................................................................15
3.1.10 Batteries ....................................................................................................................16
3.1.10.1 Lead Acid Batteries....................................................................................16
3.1.11 In Case of an Accident..............................................................................................16
3.2 Caution...................................................................................................................................17
3.2.1 Storage and Transportation.......................................................................................17
3.2.2 Disposal.....................................................................................................................17
3.2.3 Handling Electrostatic Sensitive Devices.................................................................17
3.2.4 Traceability ...............................................................................................................17
3.2.5 Breakers ....................................................................................................................17
3.2.5.1 Circuit Breaker Limitations ........................................................................17

Page 4
POWERING TECHNOLOGY
Manual No. PM110-6500-00 rev-2a
PM110-6500-00-rev2a-0117.indd
Chapter 4 Installation Guide ......................................................................................................18
4.1 Introduction............................................................................................................................18
4.2 Unpacking..............................................................................................................................18
4.3 Tools.......................................................................................................................................18
4.4 Rack Mounting.......................................................................................................................19
4.5 Rear Connections...................................................................................................................20
4.5.1 Earth Connection (FRAME GROUND)...................................................................21
4.5.2 Mains Connection.....................................................................................................21
4.5.3 Alarm and Signal Connections .................................................................................21
4.5.4 DC Load Connections...............................................................................................24
4.5.5 Battery Connections .................................................................................................25
4.5.6 Symmetry Connection ..............................................................................................25
4.5.7 Temperature Sensor Connection...............................................................................26
Chapter 5 Commissioning...........................................................................................................28
5.1 Commissioning Overview......................................................................................................28
5.2 Tools and Test Equipment......................................................................................................28
5.2.1 Tools List ..................................................................................................................28
5.2.2 Test Equipment .........................................................................................................28
5.3 Preparation .............................................................................................................................28
5.4 Commissioning procedure .....................................................................................................29
5.5 Test of output voltage.............................................................................................................30
5.5.1 Float charge (U1)......................................................................................................30
5.5.2 Adjustment of Float Charge, U1...............................................................................30
5.5.3 Boost charging (U2) (if applicable)..........................................................................30
5.6 Battery supervision.................................................................................................................31
5.7 Battery test .............................................................................................................................31
5.8 Commissioning record...........................................................................................................32
Chapter 6 Maintenance & Troubleshooting..............................................................................33
6.1 Maintenance...........................................................................................................................33
6.2 Troubleshooting .....................................................................................................................33
Chapter 7 Replacing Modules.....................................................................................................37
7.1 Controller Replacement .........................................................................................................37
7.2 Rectier Replacement ............................................................................................................38
7.2.1 XR04.48 / XR08.48 Replacement ............................................................................38
7.2.2 XPGe12.48 Replacement..........................................................................................39
7.3 Breaker Replacement.............................................................................................................39
Appendix A - Block Diagram .......................................................................................................40
Appendix B - Mating Connector Details ......................................................................................41

Page 5
POWERING TECHNOLOGY
Manual No. PM110-6500-00 rev-2a
PM110-6500-00-rev2a-0117.indd
FIGURES
Figure 2-1 Power System Overview.............................................................................................8
Figure 2-2 XPGe12.48 and XR04.48/XR08.48..........................................................................12
Figure 4-1 Dimensional Drawing (Front and Top View)............................................................19
Figure 4-2 System Mounting (19” mount) .................................................................................20
Figure 4-3 Rear Connections......................................................................................................20
Figure 4-4 Mains Connection (viewed from rear)......................................................................21
Figure 4-5 Signal Pin Designations............................................................................................23
Figure 4-6 Signal Connection Detail..........................................................................................24
Figure 4-7 Load and Battery Connections (Rear View).............................................................24
Figure 4-8 Battery Cable Detail..................................................................................................25
Figure 4-9 Symmetry Measurement (for illustration only) ........................................................26
Figure 4-10 Temperature Sensor Connection...............................................................................27
Figure 7-1 Unlocking the Controller / Removing the Blanking Panel.......................................37
Figure 7-2 Removing the Controller...........................................................................................37
Figure 7-3 Replacing an XR04.48 or XR08.48 Rectier ...........................................................38
Figure 7-4 Replacing an XPGe12.48 Rectier ...........................................................................39
TABLES
Table 4-1 Recommended Mains Circuit Protection..................................................................21
Table 4-2 Cable Sizes - Load....................................................................................................25
Table 4-3 Cable Sizes - Battery.................................................................................................25
Table 5-1 Float/Boost Charge Voltages.....................................................................................30
Table 5-2 Commissioning Record.............................................................................................32

Page 6
POWERING TECHNOLOGY
Manual No. PM110-6500-00 rev-2a
PM110-6500-00-rev2a-0117.indd
1. About This Manual
This chapter contains an overview of the information that is presented in this Power System
Manual. This includes information on objectives, the intended audience, and the organization
of this manual. In addition, this chapter also denes the conventions used to indicate warnings,
cautions and noteworthy information.
1.1 Objectives
This manual describes the Power System, explains how to unpack and install the system,
how to perform the initial power-up and operational system check.
The information presented in this document is current as of the publication date.
1.2 Audience
This manual is to be used by installers and technicians who are preparing the site for a new
installation and installing the power system. This manual assumes that the technician has an
understanding of power systems in general and understands safety procedures for working
around AC and DC voltage.
The user of this document should be familiar with electronic circuitry and wiring practices
and have some expertise as an electronic, power, or electromechanical technician.
1.3 Document Key
This manual uses the following conventions:
WARNING This symbol indicates a situation that could cause bodily injury. Always
be aware of hazardous conditions when working in or around the power system.
CAUTION Thissymbol indicates asituation that mightresult in equipmentdamage.
The reader should be aware that their actions could result in equipment or data
loss.
NEED MORE INFORMATION? This symbol is used to reference information
either in this manual or in another document.
NOTE This symbol means the reader should take note. Notes are helpful
suggestions or reminders.
Chapter 1 About This Manual

Page 7
POWERING TECHNOLOGY
Manual No. PM110-6500-00 rev-2a
PM110-6500-00-rev2a-0117.indd
Table 1-1 Abbreviations
Abbreviation Description
PCC Prime Controller Card
ACC Advance Controller Card
LVBD Low Voltage Battery Disconnection
PLD Partial Load Disconnection
XR04.48 400 W Rectier
XR08.48 800 W Rectier
XPGe12.48 1200 W Rectier
DB22 Distribution Drawer (4 x load, 1 x battery)
1.4 Feedback & Support
For technical support or feedback, please visit http://www.unipowerco.com/contact/.
Alternatively, email: [email protected]
1.5 Layout, Numbering and Printing
This manual is intended for two-sided black and white printing. Some pages are intentionally
left blank.
1.6 Disclaimer
UNIPOWER is not responsible for system problems that are the result of installation or
modication of the instructions provided in this manual.

Page 8
POWERING TECHNOLOGY
Manual No. PM110-6500-00 rev-2a
PM110-6500-00-rev2a-0117.indd
2.1 Overview
Aspiro DC power systems oer a range of solutions for diverse applications such as broadband
access, cable head ends, micro/pico BTS Cells, Enterprise, E911, and GSM-R.
The Aspiro shelf system utilizes ecient, dense, and reliable plug-in rectier modules
XR04.48, XR08.48 or XPGe12.48, with output power available at either 400W, 800W or
1200W per rectier, based upon a soft-switching approach. Features include wide input
operating range, wide operating temperature, full self-protection and three LEDs for
immediate rectier status indication.
The power system can be managed locally through messages and alarm displayed on the
LCD screen of the system controller or remotely, using the PC-based PowCom™ software,
or through a web browser with Ethernet connection.
2.2 System Congurations
Aspiro 1U system consists of:
1. System Controller (not shown), user dened.
2. 4 x 15A Load and 1 x 40A Battery breakers including LVBD
3. XR04.48 / XR08.48 / XPGe12.48 Rectiers (Maximum 2), user dened.
CAUTION Do not mix rectier types in a single system.
4. Rear Connections
1
2
3
4
Figure 2-1 Power System Overview
Chapter 2 Aspiro System Description

Page 9
POWERING TECHNOLOGY
Manual No. PM110-6500-00 rev-2a
PM110-6500-00-rev2a-0117.indd
2.3 System Parameters
OUTPUT
Power (max) 2400W @ >180VAC, 800W @ <180VAC
Output Current 52A max. @ 46VDC, 45A nominal
Voltage 46-57VDC
INPUT
Voltage 10-250VAC (per plug)
Frequency 50-60Hz
Input Current <10.5A
Power factor >0.98
DC DISTRIBUTION
Battery Breakers 1 x (AIRPAX, IER Series)
Ratings 40A
Load Breakers 4 x (NADER NDB3 Series)
Ratings* 15A
MONITORING AND CONTROL
Controller None, PCC or ACC Extended (ACX)
Local Interface 4 x 20 LCD, 4-key menu, USB (ACC only) and RS232
Remote Interface Ethernet / Modem using PowCom™ software
Visual Indication Green LED - System On
Yellow LED - Message(s)
Red LED - Alarm(s)
Analog Inputs 12 x voltage inputs (range 0-100VDC) - used for symmetry inputs
Analog Outputs 4 x potential free relays (C, NC, NO)
Digital Inputs 2 x, Logic 0: U<10VDC, Logic 1: U>12VDC
Digital Outputs 2 x, open collector type
Temperature measurement 2 x Temperature probe (Battery, Ambient)
CONNECTIONS
Battery connections Anderson power Products SB-50 Blue
AC connections IEC Power Entry Connector 15A
Load breaker connections Tyco Electronics Mate - N - Lock 2-position
Alarm connections Stripped cable with ferule, max. 1.5mm2, screw type connector
Cooling Air ow direction front lower (intake) to front upper (exhaust)
* For load breaker derating limitations see chapter 3.2.5 Breakers on page 17.

Page 10
POWERING TECHNOLOGY
Manual No. PM110-6500-00 rev-2a
PM110-6500-00-rev2a-0117.indd
RECTIFIER MODEL XPGe12.48 XR08.48 XR04.48
E󰀩ciency 95% typical @ Iout nom. 90% typical @ Iout nom. 88% typical @ Iout nom.
Input Current (max) <7.3A <10.5A <5.3A
Output Current (max)
53.5V oat
22.4A 15.0A 7.5A
Output Power 1200W @ >180VAC
750W @ 90-180VAC 800W 400W
Operating Temperature
(without derating) 55°C 65°C 65°C
Input Voltage
(Nominal 100-240VAC) 90-300VAC 85-300VAC
Output Voltage 46-57VDC
Load sharing < 5% of nominal current
Dimensions (W x H x D) 40.6 (1.6”) x 101.62(4”) x 228.5(9”) mm
Weight 1.1 kg
Cooling Fan-cooled, speed and alarm controlled, air ow direction rear to front
Protection Short circuit proof, automatic current limiting, selective shutdown of modules at
excessive output voltage.
Alarms High output voltage/ shutdown, Low voltage/ module failure
LED Indication Green: Power ON
Yellow: Current limit/ thermal protection
Fan failure / Over temperature
Pre-warning / thermal protection
Communication Failure (ashing)
Red: Module failure / high output voltage shutdown
Audible noise <55dBA according to ISO7779
MECHANICAL
Dimensions, inches (mm) 18.89 (480) W x 3.48 (88.4) H x 12.28 (312) D
Weight of the system
(fully equipped) ~29lb (13kg)
Mounting Options 19”/ ETSI
Cable Entry Rear Access
STANDARD COMPLIANCE / ENVIRONMENTAL
EMC and Immunity ETSI EN 300 386 V.1.5, FCC part 15, ICES-003
EN 55022
EN 55024, EN 61000-4
Safety UL Listed, EN 60950-1
Operating Temperature -40°C to +75°C, derating over +47°C
Storage Temperature -40°C to +85°C

Page 11
POWERING TECHNOLOGY
Manual No. PM110-6500-00 rev-2a
PM110-6500-00-rev2a-0117.indd
2.4 System Components
The Aspiro system components are described below and in later chapters of the manual.
2.4.1 System Controller
As standard the system operates without a controller. A cover plate must be installed
when using no controller to protect against injuries. The system can also be controlled
by the ACC Extended (ACX) or PCC controller. The description and operation of these
controllers is covered in separate manuals which are available at:
ACC Extended (ACX): http://www.unipowerco.com/pdf/acc-man.pdf
PCC: http://www.unipowerco.com/pdf/pcc-man.pdf
The system can be remotely managed using UNIPOWER’s PowCom™ which works in
conjunction with the controller. This is covered in its own manual which is available at
http://www.unipowerco.com/pdf/powcom-man.pdf.
2.4.2 DC Distribution
DC Distribution consists of 1 x 40A battery and 4 x 15A load breakers.
The distribution unit is designed for switching the battery and load on and o.
The battery and load breakers are supervised by measuring the voltage drop across each
breaker. In the case of load breakers, those which are not connected to any load will not
cause a breaker alarm even if they are left open.
A battery fuse alarm is generated after the battery voltage drops below a certain level,
depending on the actual battery capacity and condition.
2.4.3 Low Voltage Battery Disconnect (LVBD)
The system is equipped with a low voltage battery disconnect which prevents the
batteries from deep discharging, thus prolonging the battery life. The disconnect requires
a detected mains failure at the supervision unit (controller).
If disconnection occurs, the batteries will not supply power to the load until they have
been recharged to a set voltage level, which can be adjusted by the user.
If disconnection occurs, the batteries will be reconnected when the mains supply returns.

Page 12
POWERING TECHNOLOGY
Manual No. PM110-6500-00 rev-2a
PM110-6500-00-rev2a-0117.indd
2.4.4 Rectier Module
The Fan-Cooled XPGe12.48 (1200W), XR08.48 (800W) and XR04.48 (400W) rectiers
are modular power supplies designed for parallel operation and hot-plug installation in
the Aspiro Power Systems.
CAUTION Do not mix rectier types in a single system.
Each rectier provides extremely reliable DC power in a very high density. The module
incorporates power monitoring through an internal microprocessor, giving up to the
second updates to the system controller and companion rectiers. This guarantees
tightly controlled load sharing among rectiers, and provides status and identication
information to the controller.
The rectiers operate in parallel using active load sharing. They incorporate soft-start
at both the input and the output, which protects against high incoming and outgoing
currents. The output voltage of the rectier is automatically adjusted to the required
voltage by the controller.
Figure 2-2 XPGe12.48 and XR04.48/XR08.48
XPGe12.48 rectiers cannot be used in the same rack as XR04.48 / XR08.48 rectiers.

Page 13
POWERING TECHNOLOGY
Manual No. PM110-6500-00 rev-2a
PM110-6500-00-rev2a-0117.indd
Chapter 3 System Safety
3.1 Safety Warnings and Guidelines
Thefollowingwarnings and guidelines should befollowedbyproperlytrained and authorized
personnel when installing, operating, commissioning or maintaining this equipment.
Neglecting the instructions may be dangerous to personnel and equipment.
3.1.1 System Markings
The following markings are found on the Power System:
Product Label - The product label contains the system part number, model number, system
ratings and safety approvals. The label is located on the left side of top cover.
3.1.2 Safety Recommendations
Any device that uses electricity requires proper guidelines to ensure safety.
• The Power System should only be installed or serviced by qualied personnel.
• Always keep tools away from walkways and aisles. Tools present a tripping hazard
in conned areas.
• Keep the system area clear and dust-free during and after the installation.
• Always know the location of emergency shut-o switches in case of an accident.
• Always wear appropriate eye protection and use appropriate tools for working with
high voltage equipment and batteries.
• Do not perform any action that creates a potential hazard to other people in the system
area.
• Never work alone in potentially hazardous conditions.
• Always check for possible hazards before beginning work.
• Remove watches, rings and jewelry that may present a hazard while working on the
power system.
3.1.3 Installation Warning
The following safety guidelines should be observed when transporting or moving the system:
• Before moving the Power System, read the system specications sheet to determine
whether the install site meets all the size, environmental, and power requirements.
• The system and the equipment included, should only be moved and installed by
qualied personnel to prevent bodily injury or any other hazardous conditions.

Page 14
POWERING TECHNOLOGY
Manual No. PM110-6500-00 rev-2a
PM110-6500-00-rev2a-0117.indd
3.1.4 Electrical and Fire Enclosure
This system is designed for being used in 19 inch open relay racks. Suitable Electrical and
Fire enclosure requirements have been integrated into the system.
3.1.5 System Enclosure
Appropriate measures need to be taken to avoid intrusion of any unwanted objects or insects
into conductive areas of the power system as there is a potential risk of system damage.
Disclaimer: UNIPOWER LLC assumes no liability or responsibility for system failures
resulting from inappropriate enclosure around the system.
3.1.6 Operating Temperature Warnings
To prevent the Power System from overheating, an automatic shutdown mechanism has been
installed. It is not recommended to continually operate the Power System in an area that
exceeds the maximum recommended operating temperature.
3.1.7 Electrical Safety Warnings
The following are electrical safety recommendations for working near the Power System:
WARNING Observe low voltage safety precautions before attempting to work on the
system when power is connected. Potentially lethal voltages are present within the system.
WARNING Caution must be exercised when handling system power cables. Damage to
the insulation or contact points of cables can cause contact with lethal voltages. For safety
reasons, cables should be connected to the power system before power is applied.
• Remove all metallic jewelry like watches or rings that may present a hazard while
working on the power system.
• Before connecting the AC input source to the power system, always verify voltage.
• Verify the AC source capacity. See system specications for AC information.
• All AC connections must conform to local codes and regulations, e.g. ANSI, CEC,
NEC, etc.
• When makingAC connections, all DC load distribution breakers should be in the OFF
position.
• All circuit breakers should meet the original design specications of the system. In
addition, equipment connected to the system should not overload the circuit breakers
as this may have a negative eect on over-current protection and supply wiring,
causing system or user harm.

Page 15
POWERING TECHNOLOGY
Manual No. PM110-6500-00 rev-2a
PM110-6500-00-rev2a-0117.indd
• Verify the DC capacity before making connections. See system specications for DC
information.
• Potentiallylethalvoltages are present within the system. Ensurethatallpowersupplies
are completely isolated by turning all power switches OFF, disconnecting all relevant
connectors and removing all relevant breakers before attempting any maintenance
work. Do not rely on switches alone to isolate the power supply. Batteries should also
be disconnected.
• Potentially lethal voltages are present within this system. Ensure that low voltage
safety requirements are implemented before attempting to work on the system with
power connected.
• Potentially lethal voltages can be induced if the equipment is not grounded (earthed)
correctly. Ensure that allAC cords are 3 wired with ground.
3.1.8 EMC Considerations
This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable
protectionagainstharmfulinterference inaresidentialinstallation. Thisequipmentgenerates,
uses and can radiate radio frequency energy and, if not installed and used in accordance with
the instructions, may cause harmful interference to radio communications. However, there
is no guarantee that interference will not occur in a particular installation. If this equipment
does cause harmful interference to radio or television reception, which can be determined by
turning the equipment o and on, the user is encouraged to try to correct the interference by
one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit dierent from that to which the
receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
WARNING changes or modications not expressly approved by UNIPOWER could void
the user’s authority to operate the equipment.
3.1.9 Grounding
WARNING Proper 3-wire AC power cord must be connected to a properly grounded
outlet. Grounding connection is required before operating the system. Refer to local codes,
e.g. ANSI, CEC, NEC, T1-333, ETSI 300-386-TC specifying the connection of power
system to building ground. In case of any doubt regarding the grounding connection, please
contact a person responsible for the system.

Page 16
POWERING TECHNOLOGY
Manual No. PM110-6500-00 rev-2a
PM110-6500-00-rev2a-0117.indd
3.1.10 Batteries
WARNING When installing or replacing batteries, there is risk of explosion if an incorrect
battery type is used.
3.1.10.1 Lead Acid Batteries
WARNING This equipment may use Lead Acid Batteries. When handling batteries,
follow the instructions included with the battery set, as the uids contained within these
batteries are known to be a health hazard. The disposal of lead acid batteries is subject to
legal requirements for hazardous waste disposal. Local guidelines should be followed for
disposal.
Ensure the following guidelines are observed when dealing with equipment that may contain
lead acid batteries:
• Any attempt to burn these batteries may result in an explosion and the generation of
toxic fumes.
• Should a lead acid battery suer damage, it must be moved into a well-ventilated area.
Contact with the corrosive uid must be avoided.
• Neutralize any acid corrosion with copious amounts of a solution of baking soda and
water, and then wipe o all traces of soda.
• If the lead acid battery is removed from the equipment, any exposed contact must be
insulated prior to disposal.
• Ensure that protective full-face shields, rubber gloves and aprons are worn and
insulated tools are used when working with the batteries. It is advised also to have
water available in case acid gets in contact with the eyes.
3.1.11 In Case of an Accident
In the event of an accident resulting in injury:
1. Use caution and check for hazards in the area.
2. Disconnect power to the system.
3. If possible, send someone to get medical aid. If not, check the condition of the victim
and call for help.

Page 17
POWERING TECHNOLOGY
Manual No. PM110-6500-00 rev-2a
PM110-6500-00-rev2a-0117.indd
3.2 Caution
3.2.1 Storage and Transportation
CAUTION During storage and transportation, the units must remain in their original
packages in order to avoid mechanical damage, maintain traceability, and protect the units
against electrostatic discharge.
3.2.2 Disposal
CAUTION The product should not be disposed with other wastes at the end of its working
life so as to prevent possible harm to the environment or human health from uncontrolled
waste disposal.
3.2.3 Handling Electrostatic Sensitive Devices
CAUTION An electrostatic sensitive device is an electronic component that may be
permanently damaged by the discharge of electrostatic charges encountered in routine
handling, testing and transportation.
3.2.4 Traceability
CAUTION Units are labeled with permanently attached product identication labels.
The labels are designed to be indelible throughout the life span of the equipment, unless
mistreated. Make sure that the product identication labels are present on the equipment
and are not subjected to unusual wear or mistreatment.
3.2.5 Breakers
CAUTION Breakers should always be replaced with the same type and rating in order to
avoid damage to system components.
3.2.5.1 Circuit Breaker Limitations
1. Limitations for ambient temperature up to 55°C
15A load circuit breakers should be rated at 80% of their nominal rate.
2. Limitations for ambient temperature up to 75°C
15A load circuit breakers should be rated at 30% of their nominal rate.

Page 18
POWERING TECHNOLOGY
Manual No. PM110-6500-00 rev-2a
PM110-6500-00-rev2a-0117.indd
Chapter 4 Installation Guide
WARNING There are potential hazards related to installing this power system. It is
important to carefully read and understand the contents of Chapter 3 System Safety before
performing system installation.
CAUTION Make sure sucient room is left around the system, enabling optimal air
circulation and thus preventing the system from overheating. Keep vent openings from
being blocked.
4.1 Introduction
This chapter provides detailed instructions for installing the Aspiro 1U Power System.
4.2 Unpacking
Check that the received equipment is in accordance with the packing list. Ensure that the
cabinet and the equipment have not been damaged during transportation.
Report any parts that are damaged, missing or incorrect. If possible, correct the problem
before continuing.
4.3 Tools
The following tools are required for a safe installation of the system:
WARNING Useonlysingle-ended,fullyinsulatedtools.Shaftsofforexamplescrewdrivers
should be insulated.
• Anti-static hand strap.
• Insulated screwdrivers, at, sizes 1, 2 and 3.
• Insulated screwdrivers, Pozidrive (cross-slot), sizes 1, 2 and 3.
• Insulated torque wrench (for battery connection).

Page 19
POWERING TECHNOLOGY
Manual No. PM110-6500-00 rev-2a
PM110-6500-00-rev2a-0117.indd
4.4 Rack Mounting
The power system is designed for 19 inch rack mounting with 1” c-c mounting holes. See
Figure 4-1.
The brackets are front mounted. There needs to be sucient clearance at the front for rectier
installation, and at the rear for connections. When using side mains and DC connectors,
sucient space should be allowed for access in this case.
17.28”
(438.8mm)
0.78”
(19.7mm)
[typical]
19.00”
(482.6mm)
18.38”
(466.8mm)
11.78”
(299.2mm)
12.10”
307.4mm)
12.26”
(311.4mm)
0.16”
(4.0mm)
3.48”
(88.5mm)
3.12”
(79.2mm)
2.13”
(54.2mm)
1.40”
(35.6mm)
0.42”
(10.6mm)
0.25” x 0.5” Slot
(6.35mm x 12.70mm Slot)
Figure 4-1 Dimensional Drawing (Front and Top View)

Page 20
POWERING TECHNOLOGY
Manual No. PM110-6500-00 rev-2a
PM110-6500-00-rev2a-0117.indd
Aspiro system can be easily mounted to a rack using the taptite screws to fasten the mounting
brackets to the rack as shown in Figure 4-2.
NOTE It is recommended to remove the rectiers before installing the shelf to the cabinet
or rack.
Figure 4-2 System Mounting (19” mount)
NOTE Mounting hardware is not supplied with the system.
4.5 Rear Connections
All cable connections for theAspiro system are available at the rear of the system, see Figure
4-3.
CAUTION Use UL-listed power cords.
WARNING Before inserting signal cables into the connector, remove as little insulation
on the cable as possible, to prevent the stranded conductor to come loose and touch any
other conductive parts.
4321
LOAD
+
_+ _+ _+ _
BATTERY
+_
AC INPUT 2 AC INPUT 1
SIGNAL
CONNECTIONS
BATTERY
AC
INPUTS
DC
OUTPUTS
+
-
+
-
+
-
+_
Figure 4-3 Rear Connections
