Unisen iPazzPort KP-810-30 User manual

Wireless Keyboard
with Air Mouse
Model (型号):KP-810-30
无线键盘+空中飞鼠
联力胜科技
www.iPazzPort.com
艾宝
Rev.1.0

使
用
说
明
(User Manual)

Introduction
Contents
.......................................................... 1
Package ................................................................. 1
Features ................................................................. 1
Specifications ........................................................... 1
System Requirement ................................................ 2
............................ 5
Notice to customers ..................................................
5
Function desciption of keyboard ................................ 3
WEEE Directive & Product Disposal
Caution ....................................................................
5
应用 ................................................................. 7
包装清单 ................................................................. 7
特点 ..................................................................... 7
规格 ..................................................................... 7
使用说明 ............................................................. 8
支持系统 ............................................................. 8
....................................................... 9
键盘功能描述
开机 ........................................................ 8
How to use ............................................................. 2
....................................................... 10
红外学习
Start up ........................................................ 2
IR Learning ............................................................. 4

1.Introduction:
Wireless keyboard with air mouse is small and portable, it is widely used for:
Enhanced tool for teaching, speech, presentation, multi-media home entertainment
External keyboard for car PC, Android PC, smart TV remote
Remote of other home electric appliance, such as DVD player, CD player, TV, with
the feature of IR learning, Wireless Keyboard can quickly learn original code from
other home electric appliance remote
2.Package:
Wireless with Air Mouse 1
User manual 1
USB Receiver 1
Remote
4.Specifications:
Max distance:10m
Wireless connection
Power Supply: DC 3V(1.5V 3A Battery x2)
or DC 5V/300mA(Rechargeable Lithium-ion battery)
Physical Parameter：
Size: 155X46X15mm
Weight: 90g
3.Feature:
Protable and handheld size
Full QWERTY keyboard
Ultra sensitive motion 6 axial Gyro sensor for mouse
Quick learning IR codes from original remotes
Double-faced button design
Supports multi language
1

SET
P - P +V +V -
SET
P - P +V +V -
SET
P - P +V +V -
6.How to use
1. Open the lid 2. Take USB receiver out and
Install the battery
3. Cover the lid
6.1.Start up
5.System Requirement:
Windows
Linux
Mac OS
Android/Google/Smart TV OS
2

7. Function description of keyboard
“Fn+Q to >”=“1 to=” keys
Backspace
Enter
3
LED1(RF communication indicator)
LED2(somatosensory signal)
LED3(IR remote signal)
Power
Previous/Stop(Play)/Next
Volume / /Down Up Mute
Page Up/Down
Switch mode between
mouse and Motion Sensing
Mouse right
Mouse left
Up/Down/Left/Right arrow Enter
Return
Menu
Home
Setting Mute
Fn
SET
P - P +V +V - Channel+/-
Volume /Down Up
Power
Source
IR button
Up/Down/Left/Right

8. IR learning
8.1. Push the switch of air mouse to on
8.2. On this device click on TV or AV(i.e. DVD player), then click the set
button until the little light stays on.
8.3. Face the front of this device toward the face of your remote.
8.4. Click a function on this device(e.g. the volume up button),then click
the equivalent button (the volume up button) on your remote long
enough for the little light on this device to flash & walled,it can now do
that function.
8.5. There are about 8 basic functions you can set & after repeating the
above step until you have copied all the functions you need,press
this devices set button to complete the process.
4

WEEE Directive & Product Disposal
At the end of its serviceable life, this product
should not be treated as household or general
waste. It should be handed over to the applicable
collection point for the recycling of electrical and
electronic equipment, or returned to the supplier
for disposal
Notice to customers:
This symbol on the battery indicates that the battery
is to be collected separately.
The following applies only to users in European countries.
 This battery is designed for separate collection at
an appropriate collection point.
Do not dispose of as household waste
For more information, contact the retailer or local
authorities in charge of waste management.
Caution :
Changes or modifications not expressly approved by the party
responsible for compliance could void the user's authority to operate
the equipment.
Compliance statement:
1: This device is verified to comply with Part 15 of the FCC Rules.
Operation subject to the following two conditions:
(1) this device may not cause harmful interference, and
5

(2) this device must accept any interference received, including interference
that may cause undesired operation.
2: This equipment has been tested and found to comply with the limits for a
Class B digital device, pursuant to Part 15 of the FCC Rules. These limits
are designed to provide reasonable protection against harmful interferenc
in a residential installation. This equipment generates, uses and can radiate
radio frequency energy and, if not installed
And used in accordance with the instructions, may cause harmful interference
to radio communications. However,there is no guarantee that interference
will not occur in a particular installation.If this equipment does cause harmful
interference to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try to correct
the interference by one or more of the following measures:
-- Reorient or relocate the receiving antenna.
-- Increase the separation between the equipment and receiver.
-- Connect the equipment into an outlet on a circuit different from that to
which the receiver is connected.
-- Consult the dealer or an experienced radio/TV technician for help
6

1.应用：
- 家庭娱乐,多媒体教育、培训、会议、演示和控制计算机
- 通过红外功能远程控制其他家电设备
- 车载电视，HTPC，大屏电视，智能电视，硬盘播放器，网络播放器，X-BOX
2.特点：
- 微型外型，方便携带
- QWERTY全键盘布局
- 六轴空中鼠标设计，精确操作鼠标
- 双面按键设计
- 学习型红外遥控器
- 支持多国语言
3.规格：
- RF2.4G无线连接
- USB连接，即插即用
- 电源： 1.5V X 3AAA 2节(可选锂电池)
- 无线发射功率：2dBm
- 接收灵敏度：-85dBm
- 物理参数：
尺寸：155X46X15mm
重量：90g
4.包装清单：
- 无线键盘+空中飞鼠
- USB接收器
- 说明书
7

SET
P - P +V +V -
5.支持系统:
- Windows
- Linux
- Mac OS
- Android/Google/Smart TV OS
6.使用说明
6.1 .开机
1. 打开电池盖 2.拿出接收器和安装电池
3.盖上电池盖
8
SET
P - P +V +V -
SET
P - P +V +V -

7.键盘功能描述
9
LED1(信号指示灯)
LED2( )体感指示灯
LED3( )红外指示灯
Home键
电源
上一曲/暂停,播放/下一曲
音量-/+/静音
鼠标左键 鼠标右键
静音
上/下翻页键
鼠标/体感切换
菜单键
返回
确定
上/下/左/右
频道+/-
设置
“Fn+Q to >”=“1 to=” 键
Fn
上/下/左/右
删除
回车
SET
P - P +
V +V -
声音+/-
红外按键
电源
信源

8. 红外学习
该键盘具有红外学习功能，可以学习其它遥控器的源代码，当作其它家用电器的遥控器
使用，如电视，DVD/CD和空调等.以电视的遥控器为例说明如何使用键盘的红外学习
功能：
8.1. 按SET键5秒,LED3等慢闪,遥控器进入学习模式;
8.2. 当键盘和电视遥控器的红外发射端对准后,按电视遥控上"电源"键,此时键盘右上角LED3
灯快闪,表示电视遥控的码值已发出;
8.3. 按一下键盘上要学习的按键,此时右上角LED3灯变成慢闪,表示键盘已接收到电视遥控
的码值
8.4.学习成功后按下"SET"键退出学习模式,退出后红灯不闪,处于熄灭状态.
10
