Unitec EP-45F User manual

EP- 45F Paper Folder Operation Manual
1.
Contents
1.Safety Instructions ··················································································································2
2. Accessories ·······························································································································3
3. Part Name···································································································································4
4. Designation and Functions of Operation Panel ···································································5
5. Preparation
5-1.Install the roller ·················································································································6
5-2. Install Table A and B, Preparation before start the machine ······································7
6. Indication of the Counter
6-1. Addition Counter·················································································································9
6-2. Subtraction Counter ··········································································································9
6-3. Input non-standard-size paper length···············································································9
7. How to use
7-1. Standard Folding of Standard-size Paper ·····································································10
7-2. Standard Folding of Non-Standard-size Paper ······························································11
8. Cross Folding···························································································································13
9. Adjustment ······························································································································14
10. Storage ································································································································18
11. Cancellation of storage ········································································································19
12.Check lamp······························································································································20
13.Control Speed··························································································································20
14. Change roller Rubber pad ···································································································21

EP- 45F Paper Folder Operation Manual
2.
1.Safety Instructions
Danger：Stands for immediate danger threatening the life and health of persons and loss of
property. Disregarding these instructions may cause severe damage to health and even serious
injuries.
Caution：Stands for an endangering situation that may occur. Disregarding these instructions may
lead to slight injures or damage to property.
Danger
Make sure that the machine is electrically grounded. This prevents an electric shock when
there is a leak of electricity.
Use the machine at 110 –120VAC, 220 –240VAC with a frequency of 50Hz to 60Hz.
Do not place any object on this machine. A fire may start or electricity may leak if water or a
foreign object enters inside the machine.
Handle the power cord with care. A fire may start or an electric shock may be caused if
the cord is damaged, broken, or processed, if a heavy object is placed on the cord, or if the
cord is bent forcibly.
Do not remove the cover of this machine. Otherwise, an electric shock or injury may be
caused.
Do not remodel this machine. Otherwise, a fire may break out or an electric shock may be
caused.
If the machine is used when it is in an abnormal condition, such as generating heat,
emitting smoke, and giving out a strange smell, a fire may break out or an electric shock
may be caused. Turn off the power switch immediately and then pull the Power plug out of
the electric outlet. Afterward, consult with your dealer.
If thunder approaches, pull the power cord out of the electric outlet to prevent a fire or
breakdown caused by the falling of a thunderbolt.
Caution
Do not let hairs, a necktie, or necklace hang above the drive of the machine. Doing so may
cause an injury.
Do not put the machine on an unstable place such as a shaky stand and a slant floor.
Doing so may cause the machine to drop or fall down, causing an injury.
Do not put the machine in a moist or dusty place. Doing so may start a fire or cause an
electric shock.
Be sure to pull the power plug out of the electric outlet first when moving this machine.
Otherwise, the cord may be damaged, causing a fire or an electric shock.
Be sure to pull the power plug out of the electric outlet for safety purposes when this
machine is not used for consecutive holidays or for other reasons.

EP- 45F Paper Folder Operation Manual
3.
2
345
1
2. Accessories
Make sure that the following accessories are included in the package after opening it.
Contact your dealer immediately if there are missing accessories.
Number Accessories Quantity
①Table A 1
②Table B 1
③Roller 2
④Operation Manual 1
⑤Power cord 1

EP- 45F Paper Folder Operation Manual
4.
3. Part Name
Part Name Part Name
1 Roller cover 10 Control panel
2 Left side cover 11 Right side cover
3 Paper feed roller 12 Table B
4 Paper guide 13 Paper feed table lever
5 Feed table 14 Table A socket
6 Auxiliary feed table 15 Table B socket
7 Paper ejection roller 16 Power switch
8 Paper stacking table 17 Inlet
9 Table A

EP- 45F Paper Folder Operation Manual
5.
SPEED
10
CLEAR/RESET
SELECT
STORE
TYPE
1001000
RUN
START/STOP
JAM
TEST
1
NONE
1
7
8 9
11
12 13
56
24
15
3
10 14
4. Designation and Functions of Control Panel
No. Designation/Indication Function
1 Speed adjustment key Used for adjusting the speed.
2 Store key Select Memory 1/2 stored folding position and the folding position
after adjustment is stored.
3 Memory 1/2 lamp Two special folding types are stored.
4 Select key Used for selecting paper length, the feed position of table A and B,
indicating of the counter when the lights are off.
5 Paper length input mode lamp It is on when paper length is input; If non-standard-size paper,
press CLEAR/RESET, input correct paper length.
6 Table A stopper move mode lamp It lights when the position of stopper of Table A can be adjusted.
7 Table B stopper move mode lamp It lights when the position of stopper of Table B can be adjusted.
8 +/–key Used for adjusting the position of the stopper of Table A and B,
9 Fold type key Six folding types & six types of paper can be selected and stored.
10 Numerical key1 Used for inputting the reduced number for subtraction counting and
the length of non- standard-size paper
11 Counter Shows the number of sheets, the position of the stopper pin of
Table A and B, and paper size.
12 Clear/Reset key Clears counter indication and resets error. When the Paper length
lamp is on, press this key, can input non-standard-size paper
length
13 Test key Test fold one sheet (stopper of Table A and B move to the position)
14 Start/Stop key Starts and stops the machine
15 Statues lamp It lights when paper stock runs short, or indicates the location when
paper feed trouble occurs.

EP- 45F Paper Folder Operation Manual
6.
Roller-A
Roller-B
6
2
Roller-B
3
1
Roller-A
2
4
Roller-B
1
Roller-B
5
2
Right
!
A
B
Left Right
A
Bearing B
Left
Bearing
5. Preparation
5-1. Install the roller

EP- 45F Paper Folder Operation Manual
7.
1
3
2
13
2
5
6
4
6
5
4
5-2.Install Table A and B, Preparation before start the machine
5-2-3. Position of Table B’s notch and 5-2-4. Insert the front notched part of
connector Table 2 into the stud (4) of the machine
and drop its rear notched part on the
and drop its rear notched part on the
connector (6).
5-2-2. Insert the front notched part of
Table A into the stud (1) of the
machine and drop its rear notched part
on the stud (2). Insert the plug into the
connector (3)
Caution:
The connector has its direction.
Insertion by force may cause trouble.
5-2-1. Position of Table A’s notch and
connector

EP- 45F Paper Folder Operation Manual
8.
5-2-5. Pulling the paper stacking table 5-2-6. Insert the power cord into the inlet
out and set it while lifting the auxiliary table.
5-2-7.Caution:
Be sure to undo before use.
Insert the power cord into the outlet.
When the power switch is on, the stoppers
of Table A and B move to the origin.

EP- 45F Paper Folder Operation Manual
9.
PAPER LENGTH INPUT MODE LAMP
6. Indication of the Counter
6-1. Addition Counter
6-2. Subtraction Counter
6-3.Input non-standard-size paper length
.
When the three lamps are off, the number
indicates the counter. Press start/stop key
after choosing the fold type, it counts
automatically the folded paper.
Press the Clear/Reset key and reset the
number at zero (0)
When the three lamps are off, the number
indicates the counter. Input the desired
number using the Numerical keys.(40 is
input in this case)
Subtraction Mode Lamp will light. Press
start/stop key after choosing the fold type.
The number on the counter decrease by one
each time a sheet of paper is folded. When
the number is finished, the counter will
return to the desired number again.
Press the Select key, Paper length input
mode lamp is on, press Clear/Reset key.
Input the paper length using the Numerical
keys (300mm is input in this case, micro
meter can be input after decimal point).
Press store key, and store under 1 or 2
memory indication.

EP- 45F Paper Folder Operation Manual
10.
321
Paper guide set screw
Paper feed table
Paper feed table lever
Paper eject roller
7.How to Use
7-1. Standard Folding of Standard-size Paper
7-1-1. Set the standard-size paper
,
7-1-2. Setting the paper ejection roller
.
Change the roller position to fit the paper size
1
2
3
Standard-size
paper
A3 A4/B4 B5/A5/B6
Non-standard-
size paper
Setting the designated position
according to the paper length
Set the standard-size paper. Loosen the paper
guide. Set screw and set the paper guide to fit the
width of the paper.
Stack the paper on the paper feed table with its
printed side facing up (its printed side down in
case of fold-out) after neatly arranging it. Make
the paper guide closely contact the paper, and
tighten the setscrew. Lower the paper feed table
lever to raise the table,
Move the paper ejection roller to the position that
fits the size of paper being used. If the roller
doesn’t run smoothly,change the roller position.

EP- 45F Paper Folder Operation Manual
11.
(mm)
TYPE KEY TEST KEY
START/STOP KEY
SELECT KEY
START/STOP KEY
7-1-5. Continuous folding
7-2. Standard Folding of Non-standard-size Paper
7-2-1. Measure the paper length 7-2-2. Input the paper length
7-1-3. Selecting of folding type
One of the six folding types (Single, Gate, Letter,
Zigzag, Double, Parallel Fold-out) can be selected.
Press the desired folding type key.
7-1-4. Test folding
Before start folding, press Test key, Table A/B move
to the position of designated fold type, one sheet will
be folded. Check if the paper has been folded
correctly. (In case of correcting slanting folding, refer
to Adjustment on Chapter 9)
Note：If the Table A or B has been adjusted, press Test key before continuous folding, or the
adjustment will not be accepted, Table A / B will return to origin before the adjustment.
Press the Start/Stop key, the machine will continuously fold the paper, and the counter is in addition
counting. When the Start/Stop key is pressed while the machine is in operation, the machine w ill
stop the operation.
If only required number of sheets need to be folded, please refer to chapter 6 Subtraction Counter.
Press the Select key and select the Paper
Length Input Mode. Press Clear/Reset key.
Input paper length by using numerical key
Note: Input length number should be
bigger than B6, smaller than A3，otherwise
can’t work.

EP- 45F Paper Folder Operation Manual
12.
TEST KEYSTORE KEY
7-2-3. Store the paper length
Note：The position of the table A and table B stopper in relation to the measurement value L.
Example：In the case of performing the Double Parallel fold using sheets of paper 300mm in length:
Table A=300 x (1/2)=150 mm
Table B=300 x (1/4)=75 mm
Fold type
Table A
Table B
SINGLE Original
position“O” 1/2
GATE
1/4
1/2
LETTER
1/3 1/3
DOUBLE
PARALLEL
1/2 1/4
ZIGZAG
2/3 1/3
FOLD-OUT
3/4
1/4
After input the paper length, press store key,
choose store at 1 or 2. (press store key and
release memory lamp will shift light between 1
and 2; hold pressing store key until “bee
”
sound, means paper length stored) When
paper length is stored, machine will adjust 6
fold types according to paper length.
Choose one fold type; Press Test key to check
if the fold is correct. (In case of correcting
slanting folding, refer to Adjustment on
Chapter 9)

EP- 45F Paper Folder Operation Manual
13.
8. Cross Folding
Note:
Note：
Cross folding can be used if, for example,
the sheet of A3-size paper folded using the
double parallel folding method is still too
large to be enclosed in envelope.
The maximum weight of paper that can be
used for cross folding is 105g/m2.
This requirement, however, varies according
to the following conditions:
Paper type; Paper size; Whether grains run
lengthways or sideways; Temperature and
relative humidity; Printing condition
The folding position may be displaced to a
greater extent than when the paper is folded
using a regular fold method, or a corner of
the folded paper may be folded inside as
indicated in the figure.
These, however, do not mean that the
machine has broken down.
(1) Adjust the paper feed roller position, so
the three rollers feed paper together.
(2) Press the crease hard using the hand.
Do not stack too many sheets of paper on
the paper feed table.

EP- 45F Paper Folder Operation Manual
14.
9. Adjustment
9-1．Slant Adjustment
If the folding position is slanted because
the edges of the paper are slanted or for
other reasons, it can be adjusted using
the slant adjustment knob.
After testing paper fold, check the folded
paper. If the paper is like shown in the
right photo (lower paper is to the right),
adjust the knob clockwise.

EP- 45F Paper Folder Operation Manual
15.
FINE ADJUSTMENT KNOB
9-2．Table Stopper Adjustment
.
After moving the stopper by stopper
fine adjustment knob, make sure press
Test key before press Start/Stop key.
Otherwise, adjustment will not be
accepted.
Note ：If press Start/Stop key, after
adjusting the stopper, stopper will
return to origin to fold.
When the stopper is moved largely, it
will be convenient to use the +/–key.
(A). Press the Select key and select
the Table A Stopper Move Mode. Press
the +/- key and move the stopper to
the desired position.
(B). Press the Select key and select the
Table B Stopper Move Mode. Press the
+/- key and move the stopper to the
desired position.
Note：
To store the stopper position, after
adjusting stopper by using stopper fine
adjustment knob or +/- key, please refer
to chapter 10 Storage

EP- 45F Paper Folder Operation Manual
16.
A
A
A
A
A
A
A
A
9-3. Fine Adjustment for Table A
Fold type Plane A
Plane A at “O” position
Long
Short
Long
Short
Long
Short
Long
Short
Long
Short
Direction to turn the Table
A fine adjustment knob
Single
Folding
Gate
Folding
Double
parallel
Folding
Letter
Folding
Fold-out
Folding
Zigzag
Folding

EP- 45F Paper Folder Operation Manual
17.
B
B
B
B
B
B
9-4. Fine Adjustment for Table B
Fold type Plane B
Long
Single
folding
Short
Gate Long
folding
Short
Letter Long
folding
Short
Double Long
parallel
folding Short
Zigzag Long
folding
Short
Fold-out Long
folding
Short
Direction to turn the Table B
fine adjustment knob

EP- 45F Paper Folder Operation Manual
18.
STORE KEY SELECT KEY TYPE KEY
10.Storage
10-1.Standard-size paper fold storage
After adjusting the standard paper (A3,B4,A4,B5,A5,B6), it would be stored into fold type key. One
fold type key can store 6 kinds of standard-size paper. (Maximum storage: 6 x 6=36)
What can be stored is the folding speed, the positions of the Table A and B.
.
.
10-2.Non-Standard-size paper fold storage
Measure non-standard-size paper length, press Select key to Paper length input mode, press
Clear/Reset key. Input paper length using numerical keys,
(Note: number should be bigger than B6, smaller than A3，otherwise can’t work.Non-standard-size paper length storage
(Refer to Chapter 7, 7-2))
After inputting paper length, press Store key, select 1or 2 to be stored. (Press Store key, and release,
store lamp will light shiftly between 1 and 2; Hold press Store key until the “bee” sound, means paper
length stored) When paper length is stored, machine will adjust 6 fold types according to the length.
Select one fold type, press Test key to check if fold is correct. (If fold incorrect or slating, refer to
chapter 9 Adjustment)
(Note：For non-standard-size paper, to store adjustment of table A’s stopper position, hold press Store key until “bee”
sound. Same for Table B, hold press Store key until “bee” sound to store.)
Example：Paper length has been store; Store lamp 1 is on; Adjust fold speed; Select one fold type; Press Select Key to
choose Table A stopper move mode lamp, use +/-key to adjust and press Store key to store. Same for Table B stopper
move mode lamp, use +/-key to adjust and press Store key to store. Next time, choose same paper same fold type.
Prepare for the fold type to be stored:
Choose standard-size paper, choose fold type, (in this
case, A4, Letter folding are selected) Adjust the Table A
and B position, (refer to Chapter 9 Adjustment), adjust
fold speed.
After all adjustment are set, hold press the Select key,
until “bee” sound. The lamp of the fold typeyou chose
will flash. Select the same paper, same fold type next
time, this lamp will flash.

EP- 45F Paper Folder Operation Manual
19.
11. Cancellation of storage
11-1．Cancel single storage
11-2．Cancel all storage
Recover the folding storage set by the
manufacturer by Clear/Reset key.
Select the key in which the storage needs to
be cancelled, keep pressing Clear/Reset
key until “bee” sound, and
release
immediately.
Recover folding storage set by the
manufacturer by cancel all storage.
Keep pressing Clear/Reset key, do not
release the key at first beep; Release the
key until the second beep. All stored
information is canceled, machine return to
manufacturer’s original set.
