Unitech Ms912+ User manual

MS912+ Wireless

Pocket 2D Scanner

Quick Guide

Version 1.0

For more detailed scanner setting,

please go to www.ute.com to

download the user manual and scanner

configuration manager utility.

- 1--2-

OUT OF THE BOX

Quick Connection Card

Wrist Lanyard

INTRODUCTION

SPECIFICATIONS

Sensor 640 x 480

Resolution 5mil (1D) / 10mil (2D)

PCS 30%

Memory 2MB

Indicator LED, Buzzer

Housing Plastic (PC+ABS)

Profile BT HID, BT SPP

Battery Life 5000 scans

Charge Time 2 hours (fully charged)

Radio Bluetooth 5.0 (Class2)

Coverage 20M/66ft. (line of sight)

Symbologies All major 1D & 2D barcodes

Quick Guide

USB Charger Cable

MS912 Wireless

Pocket 2D Scanner

Quick Guide

NUMERIC BARCODES

*1*

*2*

*3*

*4*

*5*

Wireless Pocket

2D Scanner

LED Indicator

1. Type-C USB port 4.

Exit Window

Trigger

5. Hard

Reset Button

(insert pin into the hole)

- 3--4-

CHARGING THE BATTERY

1. Flip open the Type-C USB port on the scanner.

2. Insert the Type-C USB connector into the port on the

scanner and USB A connector into a USB port on

the host PC or a smartphone charger.

BEEPER INDICATION

LED INDICATION

Single long beep Power up

Single beep Good read

Single short beep The scanner reads a Code39 of

ASCII in configuration procedure

Two beeps i. Wireless connection

ii. The scanner successfully reads

a configuration barcode

Two short beeps Good read (Batch mode/Memory mode)

Several short beeps The scanner switches from one

communication mode to another

Off

Flashing Green

One Green Flash

Flashing Red

Solid Red

Standby or Power off

Disconnected or Discoverable

Good Read

Low power

Charging

GETTING STARTED

To scan a barcode, make sure the aiming beam fully

covers the barcode.

Four beeps (Hi-Lo-Hi-Lo) Out of range/Poor connection

Five beeps Low power

Three beeps Wireless disconnection

Three short beeps i. The scanner reads a barcodes

while disconnected.

ii. The scanner reads an unexpected

barcode during configuration

procedure. (scan [ABORT] to abort

and start over)





USB A

Host Scanner

Type C

- 5--6-

INTERFACE

There are 5 interfaces for data transmission/collection:

1. BT HID - Emulates a Bluetooth HID keyboard that transmits

each barcode data to the host after decode.

(See page 7)

2. BT SPP - Emulates a Bluetooth SPP device that transmits

each barcode data to the host after decode.

(See page 7)

3. Memory Mode - Emulates a USB mass storage device

that saves each barcode data during

off-line data collection (See page 24)

4. USB HID - Emulates a USB keyboard that transmits each

barcode data to the host after decode.

5. USB VCP - Emulates a USB virtual com device that

transmit each barcode data to the host after

decode.

INTERFACE

. C006$

USB VCP

. C008$

USB HID

Memory Mode

BT SPP

. C035$

BT HID

*Note: For Ez Utility(PC-based software utility), please contact your local

distributor.

FuncƟon Support Matrix

Mode Interface Batch Mode Memory Mode Ez UƟlity

USB HID

USB VCP

BT HID

Wireless

Tethered

BT SPP

Memory



. E042$

. E043$

- 7--8-

GETTING CONNECTED PINCODE SETUP

1. Press the trigger for 1 second to activate the scanner.

2. Scan [DISCONNECT]

3. Scan [BT mode - SPP]

4. Select “Wireless Scanner” from discovered device list.

If pincode is requested, enter default pincode “1234”.

5. Open serial communication software with com port

properly set up.

6. The scanner will beep twice to verify the connection.

There are two modes of wireless communication:

. E042$

BT mode - SPP

Pincode Start

. E032$

. E033$

. E043$

BT mode - HID

Disconnect

. E031$

$TX

1. Press the trigger for 1 second to activate the scanner.

2. Scan [DISCONNECT]

3. Scan [BT mode - HID]

4. Select “Wireless Scanner” from discovered device list.

5. If the Bluetooth application request to enter pincode,

please refer to PINCODE SETUP section on the next page.

6. The scanner will beep twice to verify the connection.

Scan numeric barcodes (see NUMERIC BARCODES section

on the next pages) based on the pincode generated

by the Bluetooth application.

STEP 1

Pincode Stop

Enter

STEP 4

STEP 3

STEP 2

[ Recommended ]

- 9--10 -

NUMERIC BARCODES

- 11 --12 -

SMARTPHONE/TABLET TOUCH KEYBOARD

Touch Keyboard - Android

Touch Keyboard - iOS

While connected with the scanner, the Touch Keyboard on the

Android smartphone or tablet might disappear. To resolve this

issue, please change settings on Android device with below steps:

1. Enter “Settings”

2. Enter “Language & input”

4. Turn off “Physical keyboard”, or Turn on “On-screen keyboard”

and the Touch Keyboard will function properly again.

3. Tap on “Default keyboard”

After enabling iOS Hotkey(enabled by default), you may simply

double-click the trigger to toggle the iPhone/iPad Touch Keyboard.

. E047$

ENABLE iOS HOTKEY

Slide to

turn off

SMARTPHONE/TABLET CONNECTION

Getting Connected - iOS & Android

1. Press the trigger for 1 second to power up the scanner.

2. Scan below configuration barcode to clear last pairing record.

3. Scan below configuration barcode to switch to BT HID profile.

. E043$

BT mode - HID

4. Select “Wireless Scanner” from discovered device list.

5. The scanner will beep twice to verify the connection.

Disconnect

. E031$

Tap to

connect

Variable Timeout

No Timeout (Scanner Always On)

POWER OFF TIMEOUT

. B030$

SET MINUTE

. B029$

SET SECOND

. B021$

DISABLE

TIMEOUT

The default timeout is 3 minutes 0 second.

For example, to set the timeout as 5 minutes 30 seconds:

1. Scan [Set Minute]

2. Scan [0] & [5] on page 9 & 10.

(Range: 00 ~60)

3. Scan [Set Minute]

4. Scan [Set Second]

5. Scan [3] & [0] on page 9 & 10.

6. Scan [Set Second]

The period of inactivity before auto power-off.

- 13 --14 -

Once enabled, a checksum will be added to the end of each data

to conduct Xor calculation. For Bluetooth SPP & USB-VCP, the BCC

is 1 byte. For Bluetooth HID, the BCC are 2 bytes.

Example:

The barcode data is “TEST” with terminator <CR><LF>

1. Bluetooth SPP & USB-VCP:

Data Format = <T> + <E> + <S> + <T> + <CR> + <LF> + <BCC>.

BCC = 54h ^ 45h ^ 53h ^ 54h ^ 0Dh ^ 0Ah = 11h

2. Bluetooth HID & USB-HID:

Data Format = <T> + <E> + <S> + <T> + <Enter> + <BCC>

BCC = 54h ^ 45h ^ 53h ^ 54h ^ E7h = F1h

However, since control character cannot be displayed in

Bluetooth HID, BCC will be converted into 2 bytes of characters.

As a result, the data will be: TEST + <Enter> + F + 1

BINARY CHECK CHARACTER

. E030$

. E029$

DISABLE

ENABLE

GENERAL SETTINGS

BEEP MODE

. P023$

. A007$

. F023$

ABORT

CHECK

VERSION

MUTE

. F024$

READING MODE

. F002$

TRIGGER

AUTO-SENSING

CONTINUOUS

. F007$

. F005$

. A001$

DEFAULT

NORMAL

- 15 --16 -

KEYBOARD LAYOUT

. C010$

ENGLISH

(USA)

. C018$

ENGLISH

(UK)

. C011$

GERMAN

. C012$

FRENCH

. C013$

SPANISH

. C014$

ITALIAN

. C009$

JAPAN

(106 key)

CANADIAN

(TRADITIONAL)

. C034$

NORWEGIAN

. C029$

SWEDISH

. C026$

PORTUGUESE

. C031$

CANADIAN

(FRENCH)

. C025$

- 17 --18 -

HUNGARIAN

(101 KEY)

BRAZILIAN

(PORTUGUESE)

SLOVAK

SWISS

(FRENCH)

DUTCH

DANISH

BELGIAN

(AZERTY)

. C016$

SWISS

(GERMAN)

KEYBOARD LAYOUT

. C017$

CZECH

(QWERTY)

. C022$

CZECH

(QWERTZ)

HUNGARIAN

(QWERTZ)

. C021$

. C015$

ALT CODE

. C024$

. C023$

. C033$

. C032$

. C027$

. C028$

. C030$

- 19 --20 -

- 21 --22 -

ENABLE/DISABLE SYMBOLOGIES

ENABLE

ALL CODE

ENABLE ALL

1D CODE

INVERSE BARCODE

DISABLE ALL

1D CODE

ENABLE ALL

2D CODE

. A002$

. G036$

. G035$

DISABLE ALL

2D CODE

. G037$

DISABLE

ALL CODE

. A003$

. G038$

CAPSLOCK ON

. A004$

. A005$

CAPSLOCK FREE

. A006$

CAPSLOCK

INVERSE BARCODE

. D021$

ENABLE

. D022$

CAPSLOCK OFF

DISABLE

INVERSE BARCODE

- 23 --24 -

After scanning the above barcode, the scanner will be able to collect barcode

data off-line. The barcode data will be stored in the format of:

< Date >, < Time >, < Barcode Data > < CR >

To retrieve stored data, please connect the scanner to the host with cable,

access removable storage device “MiniScan” from which you may open

or copy the file “BARCODE.txt” to your computer.

To delete ONE stored data, please scan below barcode:

To delete ALL stored data, simply delete the file “BARCODE.txt” in the

removable storage device “MiniScan” until the scanner emits 2 beeps.

. R005$

MEMORY MODE

TERMINATOR

CR + LF

NONE

SPACE

TAB

. D012$

. D011$

. D013$

. D010$

. D015$

. D014$

. C035$

Memory Mode

Delete Last Data

- 25 --26 -

MEMORY MODE

Default is comma ( , ) . You may replace it with any alphanumeric

characters from the full ASCII table in Full User’s Manual.

Example: To change Field Separator to Semicolon ( ; )

1. Scan [

Field Separator

]

2. Scan [ ; ] from the full ASCII table.

3. Scan [

Field Separator

]

. R010$

FIELD SEPARATOR

MEMORY MODE

Example: To set Date to 2022-08-01 (Year-Month-Day):

1. Scan [

Set Date

]

2. Scan [2], [2], [0], [8], [0], [1] on page 9 & 10.

3. Scan [

Set Date

]

Example: To set Time to 08:10:30 am (Hr:Min:Sec)

1. Scan [

Set Time

]

2. Scan [0], [8], [1], [0], [3], [0] on page 9 & 10.

3. Scan [

Set Time

]

. R006$

SET DATE

. R007$

SET TIME

* To avoid Time and Date being reset to factory default due

to drained battery, please fully charge the scanner for at

least 2 hours before use.

Example:

To change Data Format to

1. Scan [

Data Format

]

2. Scan [4], [5], [2], [3] on page 9.

3. Scan [

Data Format

]

The default Data Format is

below are all items available for display and their codes:

. R011$

DATA FORMAT

2Date

Code Item Code Item

Time

5 Quantity

Barcode Data

- 27 --28 -

The default Date Format is DD/MM/YYYY (Code = 09), below

is full list of available formats and their setup codes:

Example:

To set Date Format to MM/DD/YY (Code =12)

1. Scan [

Date Format

]

2. Scan [1], [2] on page 9.

3. Scan [

Date Format

]

. R008$

DATE FORMAT

MEMORY MODE

DD-MM-YYYY

MM-DD-YYYY

DD-MM-YY

MM-DD-YY

YYYY-MM-DD

YY-MM-DD

DD-MM

MM-DD

Code Format Code Format

DD/MM/YYYY

MM/DD/YYYY

DD/MM/YY

MM/DD/YY

YYYY/MM/DD

YY/MM/DD

DD/MM

MM/DD

The default Time Format is HH:MM:SS (Code = 01), below

are available formats and their setup codes:

Example:

To set Time Format to HH:MM (Code = 02)

1. Scan [

Time Format

]

2. Scan [0], [2] on page 9 & 10.

3. Scan [

TimeFormat

]

. R009$

TIME FORMAT

MEMORY MODE

01 HH:MM:SS

Code Format Code Format

02 HH:MM

- 29 --30 -

When quantity input is enabled, the operation procedure under

memory mode will be:

1. Scan [

MEMORY MODE

] (page 24)

2. Include <Quantity> in DATA FORMAT (page 26). For example,

your data format is <Barcode Data>, <Quantity>.

3. Scan a desired barcode; it will be stored as <Barcode Data>.

4. Scan [

SET QUANTITY

] below.

5. Scan numeric barcodes (range: 1 - 99999) on page 9 &10 ;

it will be stored as <Quantity>.

6. Scan [

SET QUANTITY

] again.

7. Scan [

SAVE DATA

] below.

8. Repeat Step 3 -- 7 to until your task is completed.

9. Retrieve stored data (BARCODE.txt), as instructed on page 24.

. R017$

ENABLE QUANTITY INPUT

QUANTITY

. R015$

SET QUANTITY

. R016$

SAVE DATA

. R018$

DISABLE QUANTITY INPUT

QUANTITY

When quantity input is disabled, the operation procedure under

memory mode will be:

1. Scan [

MEMORY MODE

] (page 24)

2. Set DATA FORMAT (page 26) as appropriate. For example, your

data format is <Barcode Data>, <Quantity>.

3. Scan a desired barcode; it will be stored as <Barcode Data>

4. Repeat Step 3 until your task is completed.

5. Retrieve stored data (BARCODE.txt), as instructed on page 24.

- 31 - - 32 -

QR Code Micro QR Code

PDF417

Data Matrix Aztec

Other manuals for MS912+

Table of contents

Unitech MS912+ User manual

Popular Barcode Reader manuals by other brands
