Unitech TB162 User manual

Desktop Docking
- TB162 -
Package
Please make sure the following contents are in the gift box.
If something is missing or damaged, please contact
your unitech representative.
The basic package contents
TB162 Desktop Docking
Quick Start Guide
V1.0
Product overview
1 RS-232 Port 2 (Function Switch)
To switch between 5V and RI (Ring
Indicator) function.
1 Dock Connector
Connect with external Docking Station to
increase more I/O functions.
2 Boss Hole
Used for locking the boss hole of the dock.

1 DC-in Jack
It is an electrical connector for supplying direct current (DC) power.
2 Microphone
Used for an external microphone.
3 Line Out
A connector for speakers.
4 USB 2.0 / USB 3.0 ( optional )
5 RJ-45 Connector
The Ethernet connector, with optionally supported transmitting rate of
10/100/1000 megabits per second, is used to connect a LAN cable for
network connection.
6 HDMI
7 RS-232 Port 2
To connect other device function.(switch RI to 5V)
8 RS-232 Port 1
To connect other device function.
9 VGA
10 Display Port
