Unitech Tashi mt65em1 User manual

MT650 Video T&A Terminal

MT650

User’s Manual

400815G Version 1.1

About This Manual

Preface

This manual explains how to install, operate and maintain the MT650 Video

T&ATerminal. No part of this publication may be reproduced or used in any

form, or by any electrical or mechanical means, without permission in writing

from the manufacturer. This includes electronic or mechanical means, such as

photocopying, recording, or information storage and retrieval systems. The

material in this manual is subject to change without notice.

Unitech global website address: http:\\www.unitech-adc.com

Microsoft, Windows and ActiveSync are either registered trademarks or

trademarks of Microsoft Corporation. Other product names mentioned in this

manual may be trademarks or registered trademarks of their respective

companies and are hereby acknowledged.

Regulatory Compliance Statements

FCC Warning Statement

This equipment has been tested and found to comply with the limits for a Class

B digital device, pursuant to part 15 of the FCC rules. These limits are

designed to provide reasonable protection against harmful interference in a

residential installation.

This equipment generates, uses and can radiate radio frequency energy and, if

not installed and used in accordance with the instructions, may cause harmful

interference to radio communications. However, there is no guarantee that

interference will not occur in a particular installation. If this equipment does

cause harmful interference to radio or television reception, which can be

determined by turning the equipment off and on, the user is encouraged to try

to correct the interference by one or more of the following:

¾Relocate the receiving antenna.

¾Increase the separation between the equipment and receiver.

¾Connect the equipment into an outlet on a circuit that is different from

the receiver.

¾Consult the dealer or an experienced radio/television technician for

help.

1. This Transmitter must not cohabitate or operate in conjunction with any

other antenna(s) or transmitter(s).

2. This equipment complies with FCC RF radiation exposure limits set forth

for an uncontrolled environment. To maintain compliance with FCC RF

exposure compliance requirements, avoid direct contact to the

transmitting antenna during transmission.

3. Any changes or modifications (including the antennas) made to this device

that are not expressly approved by the manufacturer may void the user’s

authority to operate the equipment.

This equipment must be installed and operated in accordance with provided

instructions and the antenna(s) used for this transmitter must be installed to

provide a separation distance of at least 20 cm from all persons and must not

be co-located or operating in conjunction with any other antenna or transmitter.

Canadian Compliance Statement

This Class B Digital apparatus meets all requirements of the Canadian

Interference-Causing Equipment Regulations.

Cet appareil numérique de la classe B respecte les exigences du Règlement

sur le matériel broilleur du Canada.

European Conformity Statement

Declaration of Conformity with Regard to the R&TTE 1999/5/EC and EMC 89/336/

EEC directives.

RoHS Statement

This device conforms to RoHS (Restriction of Hazardous Substances)

European Union regulations that set maximum concentration limits on

hazardous materials used in electrical and electronic equipment.

Notices

The unit is equipped with a Lithium-Ion battery pack.After extended storage

periods, however, the unit may not power-on without external power due to

battery discharge. In this case connect the unit to the power cable and

recharge the unit for about 6 hours to charge the battery to full capacity.

The battery supplies operational power to the unit for approximately 1 hour

iii

(depending on hardware configuration and with limited backlight use) or

provides backup RTC data for 6 days when there is no external power

connected.

Battery Charge Notice

It is important to consider the environmental temperature whenever the

Lithium-Ion battery pack is charged. Charging is most efficient at normal room

temperature or in a slightly cooler environment. It is essential that the battery

are being charged within the stated range of 0°C to 45°C. Charging the battery

outside of the specified range could damage the battery and shorten their

charging life cycle

Storage and Safety Notice

Although charged Lithium-Ion battery may be left unused for several months,

their capacity may be depleted due to build up of internal resistance. If this

happens they will require recharging prior to use. Lithium-Ion battery may be

stored at temperatures between -20°C to 60°C, however they may be depleted

more rapidly at the high end of this range. It is recommended to store the

battery within normal room temperature ranges and replace the used battery

with a new one every year.

Warranty

Under unitech limited Warranty, the following items are covered:

zThe MT650 Video T&ATerminal is covered by one-year limited warranty.

zCables are covered by one-year limited warranty.

zBattery is covered by a one-year warranty.

Table of Contents

Preface

Regulatory Compliance Statements...........................................................i

Notices......................................................................................................ii

Warranty .................................................................................................. iii

Chapter 1

Introducing the MT650..............................................................................1

Package Contents ....................................................................................3

Tour of the MT650.....................................................................................4

Setting up the MT650 ...............................................................................5

Turning the MT650 on for the First Time...................................................6

Chapter 2

Using the Keypad .....................................................................................9

Using the Stylus......................................................................................11

Using Proximity, MSR, or Barcode Reader.............................................11

Testing Reader Data........................................................................12

Using the Mifare Reader.........................................................................12

Using the Finger Print Reader ................................................................15

Using the Camera...................................................................................17

Chapter 3

Establishing Device-PC Connection.......................................................19

Setting up the Wireless Local Area Network Card...........................20

Using ActiveSync....................................................................................21

Installing Microsoft ActiveSync.........................................................22

Connecting the Device to Your Computer........................................22

Chapter 4

Charging the Backup Battery for the First Time......................................25

Checking the Battery Status ............................................................25

Extending Battery Life.............................................................................26

Changing the Automatic Power Settings..........................................26

Adjusting the Backlight ....................................................................27

Performing a Hardware Reset ................................................................27

Performing a Cold Boot ...................................................................27

Appendix A System Specification ................................................................29

Appendix B Overview of the Terminal Block................................................31

Terminal Block Pin Assignment........................................................32

Relay ...............................................................................................32

Digit Input ........................................................................................32

Appendix C Worldwide Support...................................................................33

Getting Started

Chapter 1

Introducing the MT650

Thank you for purchasing the MT650 Video T&ATerminal. Your MT650 was

designed for users needing a compact and durable computer for data

collection and real time transactions.

The MT650 is a T&A(Time management and access control) terminal with a

large 480 x 640 pixel color touch screen and the Windows CE operating

system. The MT650 was designed to meet the requirements of Time &

Attendance, Loyalty Programs, and Work-In-Process applications.

The MT650 communicates with central host security and T&Asystems through

standard Ethernet or WLAN networks. The built-in CMOS digital camera,

microphone, and audio speaker provide complete area security with a small

footprint.

The MT650 features a variety of built-in readers including proximity and finger

print identification. Powered by Windows CE.NET 6.0, the MT650 package

includes programming tools and support software for developing custom

security and provides cost-efficient solution for T&A applications.

Features

Powerful system

zMicrosoft Windows CE 6.0

Professional Plus operating

system

zSamsung 6410 processor with

speeds up to 667Mhz

System memory

z256 MB SDRAM

z256 MB Flash ROM

Expansion slot

zSD memory slot

Proximity reader

zEM, 125kHz

zHID, 125kHz

zMifare, 13.56MHz

Wireless connectivity

z802.11b/g

Communication

zRS232/485

zUSB 1.1 host

zOutput relays x 2

zEthernet connection

zPower over Ethernet

Display

z5.7inch VGA LCD touch-sensitive

screen

z480 x 640 resolution

Multimedia

z2.0 megapixel CMOS camera

zAudio output via 0.8 watt speaker

zBuilt-in microphone

Fingerprint reader

zSensor: Suprema SFM3020-OP

zVerification time: 1 second

zEqual Error Rate: <0.1%

zEnrollment time: 1 second

zTemplate capacity: 1900 at 1MB

flash

zTemplate format: Suprema or ISO

19794-2 standard

Battery life

zNormal usage: 1 hour

zCharging time: 6 hours

User interface

zSix hard keys

zTouch-sensitive screen with stylus

Software programming tools

zVisual Studio

zC++, C#, VB.NET

Package Contents

After opening the box, ensure the following items are present:

MT650 Proximity + Finger

Print Model

MT650 Proximity Model

MT650 with Barcode Model

Power Adapter and Cable Stylus

RS232 Cable Manual CD-ROM and unitech MT650 Quick

Reference Guide

If anything is missing or appears damaged in any way, contact your dealer.

NOTE: The MT650 screen ships with a protective plastic film. You may

remove it if desired by peeling from one corner. The screen will be

more susceptible to scratching without the film, but will be more

readable.

Tour of the MT650

The following sections describe the main components and features of the

MT650.

MT650 Proximity + Finger Print Model

Rear

Speaker

Proximity

Reader

Finger Print

6 Key Keypad

5.7-Inch Color

Touch Pnel

2 Megapixel

CMOS Camera

Microphone

Back Plate Tabs

Mounting

Holes

Key Lock

Terminal block

Mounting

Holes

Setting up the MT650

This section explains how to charge the battery and how to turn on the MT650

for the first time.

Opening the Back-plate

Follow these instructions to open the back-plate for accessing the MT650’s

internal components.

1. Insert the key provided into the

security lock and then turn the

key counterclockwise.

2. Lift the back-plate up to a

45-degree angle (1) and pull the

plate in the direction of the arrow

slightly to free the cover from the

back plate tabs (2).

3. Flip the back plate over to the

left.

Warning:

1. Be careful not to stretch

this cable!

2. Power off the terminal

before plugging and

unplugging the ribbon

cable.

Be careful

not to stretch

this cable

Connecting Power

Follow these instructions to connect power to the MT650.

1. Plug the 12V DC connector into the terminal block (1)

2. Plug the adapter into a power socket (2).

3. Switch on the battery switch to

charge the battery.

Charging the Battery

Before using the MT650 for the first time, you need to charge it for about 22

hours. The battery begins charging as soon as you connect the power cable

and then turn ON the battery switch.

Turning the MT650 on for the First Time

After you have initially charged your device for about 22 hours, the device is

ready to be used. You can now start up your device where you’ll calibrate the

display, and set up the system time zone, date and time.

Powering On

The MT650 automatically starts when the 12V DC power adapter is plugged-in.

The MT650 welcome screen appears followed by the Windows CE screen.

Terminal Block connector

Calibrating the MT650 Screen

The calibrate screen automatically appears when the unit is powered-on for

the first time or after the system is reset.

The MT650 prompts you to calibrate the unit by tapping a sequence of screen

locations. Tap gently but firmly with the stylus.

When you have completed the series of taps, press the [E] key to confirm

calibration or press the [ESC] key to cancel it.

After confirming calibration, the Date/Time Properties screen appears

prompting you to set the date and time.

Setting the Date and Time

In the Date/Time Properties window, use the stylus to select the current date

and time, time zone, and daylight saving time option.

zTap the Left or Right arrows to scroll the year and month you desire or

directly tap location of year or month to change the year or month setting.

zTap on the Hr/Min/Sec AM/PM to input the Hr/Min/Sec to set the time.

zTap the arrow and set the correct time zone from the drop-down list.

zCheck the box to enable Windows to automatically adjust for daylight

saving.

zTap OK to save the settings and exit the Date/Time Properties dialog or

tap X to exit without saving.

NOTE: To change the time and date at any time tap ÆSettings Æ

Control Panel ÆDate/Time.

Date Setting

Time Setting

Time Zone Setting

Daylight Saving

Using the Hardware

Chapter 2

Using the Keypad

The MT650 is featured with six functional buttons.

The following table describes the keys.

Key Main Function

Clock-in

[F1]: Function Key

Break-out

[F2]: Function Key

Break-in

[F3]: Function Key

Clock-out

[F4]: Function Key

[ESC] Performs the same function as tapping the button on

the touch screen.

[ENTER] Enters a carriage return or executes a command.

Using Windows CE Keyboard

The Windows CE Software provides a touch screen keyboard for

alphanumeric input. The Windows based keyboard replicates the layout of a

standard PC keyboard.

Open the Windows CE keyboard by tapping the “keyboard” icon on the task

bar and tapping Keyboard.

Entering Characters

Character input is the same as on a

standard PC keyboard. Tap the

on-screen button corresponding to the

character you want to input.

International Character Support

Tap the [áü] button to switch from the

Standard English keyboard to the

European keyboard or switch from the

standard keyboard to perform the

desired special characters.

Moving the Keyboard

Tap the title bar and drag the keyboard

to the desired location.

Closing the Keyboard

Tap the keyboard icon and tap Hide

Input Panel to close Windows CE

keyboard.

Keyboard Icon

Tap to enter special characters

Title ba

Using the Stylus

CAUTION! Never use anything other than the MT650 stylus on the screen.

Using an object other than the stylus could cause permanent

damage.

1. Hold the stylus as you would hold a pencil.

2. To make a choice from a menu, lightly tap the tip of the stylus on that

choice.

3. Double-tap to open programs.

4. To write data into a field on a form, use the stylus to print the letters or

numbers.

Using Proximity, MSR, or Barcode Reader

The MT650 features an integrated proximity reader (EM125kHz, HID 125kHz

and 13.56MHz Mifare), MSR, and barcode reader which can read proximity

cards, magnetic stripe cards, and barcode labels respectively.

NOTE: Reading software must be enabled in order to operate the scanner.

This can be a user-loaded application or a pre-loaded utility such as

Scanner Setting.

Testing Reader Data

The MT650 has a built-in Scanner Control Panel that enables you to test the

device’s barcode scan function.

1. To launch Scanner Control Panel, tap

My Device on desktop ÆWindows Æ

ScanCpl. The Scanner Control Panel

opens.

2. To test the barcode scanner, tap the

Test tab and then perform a scan.

Using the Mifare Reader

The MT650 has an optional integrated

Mifare reader that has verification in a

few seconds.

Testing Mifare Card Verification

1. Double-tap the My Device icon on

the Windows CE desktop. Then,

tap the Windows folder.

This manual suits for next models

Table of contents

Other Unitech Intercom System manuals

Unitech

Unitech Tashi MT200 User manual

Unitech

Unitech TASHI MT200-CME0AG User manual

Unitech

Unitech MT650 User manual

Popular Intercom System manuals by other brands

urmet domus

urmet domus DIGIVOICE 1138 manual

Videx

Videx Kristallo Series manual

Cytech

Cytech Comfort manual

FONESTAR

FONESTAR KE-404 instruction manual

Aiphone

Aiphone GF-1DK Features

Akuvox

Akuvox C319 Series quick guide

golmar

golmar Vista Nexa instruction manual

Elvox

Elvox 68TU/93V Installation and operation manual

AVE

AVE 45387C manual

KOCOM

KOCOM KIP-620ML manual

Vingtor Stentofon

Vingtor Stentofon ECPIR-3P Replacing

Alcad

Alcad 4+N quick start guide

Commax

Commax CMV-70MX user manual

Harding Instruments

Harding Instruments dxi MicroComm ICM-400 Series installation instructions

Extel

Extel EASY BUS 3 Installation and user guide

urmet domus

urmet domus 1722 Installation and use handbook

Toa

Toa MS-900 brochure

Micron

Micron IMTB user manual

Unitech Tashi MT65EM1 User manual

Popular Intercom System manuals by other brands
