Unitronics 1
Short-Range Local Expansion Kit Installation Guide
UAG-XKxxx
&UAG-XKPxxx
Use a Short-Range Local Expansion Kit to expand your I/O configuration by connecting a
UniStream™ CPU controller to Uni-I/O™ modules located on a DIN-rail.
Short-Range Local Expansion Kits are available:
Without power supply
With power supply
This enables a single CPU to support a greater
number of modules
The kit is available with cables of different lengths.
Note that the maximum number of modules supported
by a single CPU is provided in the CPU’s technical
specifications.
Before You Begin
Before installing the device, the installer must:
Read and understand this document and related technical specifications and documents
in the Technical library section of the Unitronics website.
Verify the Kit Contents.
Alert Symbols and General Restrictions
When any of the following symbols appear, read the associated information carefully.
Symbol Meaning Description
Danger The identified danger causes physical and property damage.
Warning The identified danger could cause physical and property damage.
Caution Caution Use caution.
All examples and diagrams are intended to aid understanding, and do not guarantee
operation. Unitronics accepts no responsibility for actual use of this product based on
these examples.
Please dispose of this product according to local and national standards and regulations.
This product should be installed only by qualified personnel.
Failure to comply with appropriate safety guidelines can cause severe injury or
property damage.
Do not attempt to use this device with parameters that exceed permissible levels.
Do not connect/disconnect the device when power is on.
Environmental Considerations
Ventilation: 10mm (0.4”) of space is required between the device top/bottom edges
and the enclosure’s walls.
Do not install in areas with: excessive or conductive dust, corrosive or flammable
gas, moisture or rain, excessive heat, regular impact shocks or excessive vibration,
in accordance with the standards and limitations given in the product’s technical
specification sheet.

Do not place in water or let water leak onto the unit.

Short-Range Local Expansion Kit Installation Guide
2 Unitronics
Do not allow debris to fall inside the unit during installation.

Install at maximum distance from high-voltage cables and power equipment.
Kit Contents
Item
Qty
UAG-XKxxx
UAG-XKPxxx
Local Expansion Base Unit
1
√
√
Local Expansion End Unit with
an integrated xxx cm cable.
1 √-
Local Expansion End Unit with a
power supply and an integrated
xxx cm cable.
1 - √
Terminal Block
1
√
√
Kit Diagram
1
Bus connector
2
Base Unit plug
3 Clips
4
Base Unit’s cable port
5
RJ45 connector
6
End Unit LED indicators
7
DIN-rail clips, top and bottom
8
End Unit I/O bus connector
9
I/O Bus - Left side connector
10 Model-dependent:
UAG-XKPxxx power supply connector
UAG-XKxxx earth point connector
Installation Space Considerations
Allocate space for the Base Unit and End Unit according to the dimensions in the kit’s
technical specifications. Also, consider the space required to install and connect them, as
shown in the following Installation instructions.
Installation
Turn off system power before connecting or disconnecting any modules or devices.

Use proper precautions to prevent Electro-Static Discharge (ESD).
This kit enables you to connect a UniStream™ controller to a row of Uni-I/O™ modules
located on a DIN-rail. To do this, you must:
Connect the Base Unit to the last device installed on the back of the HMI panel. This may
be the CPU-for-Panel, a Uni-COM™ module, or another Uni-I/O™ module.
Connect the End Unit to the first module in a row of Uni-I/O™ modules.
Link the End Unit into the Base Unit via the connecting cable.
If you are using a:
UAG-XKPxxx with power supply, connect it to a power source
UAG-XKxxx without power supply, earth it.

UniStream™Uni-I/O™
Unitronics 3
Connecting the Base Unit
1. Check the unit to which you will connect the
Base Unit to verify that its Bus Connector is
not covered.
2. Hold the Base Unit as shown in the
accompanying figure, and plug it into the last
device installed on the back of the HMI panel.
3. Click the top and bottom clips into the Guide
Tunnel of the last device.
Connecting the End Unit
1. Push the End Unit onto the DIN-rail until the clips located at the top and bottom of the
unit have snapped onto the DIN-rail.
2. Install Uni-I/O™ modules to the right of the End unit. Please refer to the specific
Installation Guide of each Uni-I/O™ module.
3. Slide the Bus Connector Lock of the first module all the way to
the left.
4. Link the units by plugging the RJ45 of the End Unit’s cable into
the port on the bottom of the Base Unit.
5. If you are using a:
UAG-XKPxxx with power supply, connect it to a power source
as described on page 4.
UAG-XKxxx without power supply, earth it.
Do not connect the cable to any device other than the Base Unit.
Do not connect the Base Unit’s cable port to any other cable or device.
Wiring
This equipment is designed to operate only at SELV/PELV/Class 2/Limited Power
environments.
All power supplies in the system must include double insulation. Power supply
outputs must be rated as SELV/PELV/Class 2/Limited Power.
Do not connect either the ‘Neutral’ or ‘Line’ signal of the 110/220VAC to device’s 0V
point.
Do not touch live wires.
All wiring activities should be performed while power is OFF.
Use over-current protection, such as a fuse or circuit breaker, to avoid excessive
currents into the UAG-XKPxxx supply port.
Unused points should not be connected (unless otherwise specified). Ignoring this
directive may damage the device.
Double-check all wiring before turning on the power supply.
Caution To avoid damaging the wire, use a maximum torque of 0.5 N·m (5 kgf·cm).
Do not use tin, solder, or any substance on stripped wire that might cause the
wire strand to break.
Install at maximum distance from high-voltage cables and power equipment.

Short-Range Local Expansion Kit Installation Guide
4 Unitronics
Wiring Procedure
Use crimp terminals for wiring; use 26-12 AWG wire (0.13 mm2–3.31 mm2).
1. Strip the wire to a length of 7±0.5mm (0.250–0.300 inches).
2. Unscrew the terminal to its widest position before inserting a wire.
3. Insert the wire completely into the terminal to ensure a proper connection.
4. Tighten enough to keep the wire from pulling free.
Wiring Guidelines
In order to ensure that the device will operate properly and to avoid electromagnetic
interference:
Use a metal cabinet. Make sure the cabinet and its doors are properly earthed.
Use wires that are properly sized for the load.
Connect the 0V point of the UAG-XKPxxx directly to the power supply 0V terminal.
Connect the functional ground point ( ) to the earth of the system (preferably to the
metal cabinet chassis).
Use the shortest and thickest wires possible: less than 1m (3.3’) in length, minimum
thickness 14 AWG (2 mm2).
Connect the power supply 0V to the earth of the system.
N
OTE
For detailed information, refer to the document System Wiring Guidelines, located in
the Technical Library in the Unitronics’ website.
13BWiring the Power Supply (UAG-XKPxxx)
The UAG-XKPxxx requires an external 12 or 24VDC power supply.
The 0V of the UAG-XKPxxx end unit must be connected to the HMI Panel’s 0V.
Ignoring this directive may damage the device.
In the event of voltage fluctuations or non-conformity to voltage power supply
specifications, connect the device to a regulated power supply.
Connect the +V and 0V terminals as shown in the
accompanying figure.
7BRemoving the Expansion Cable
1. Turn off the system power.
2. Unplug the cable from the Base Unit.
3. To remove the Base unit, pull the top clip up and the bottom clip down; and pull it
slowly away until the plug disengages.
4. To remove the End unit:
•Locate the Bus connector lock of the Uni-I/O™ module connected to the End Unit
and slide it to the right.
•Pull the End Unit’s top DIN-rail clip up and the bottom clip down.
•Pull the End Unit out of its place (away from the DIN rail).
