BenQ QS01 User manual

V1.00
User Manual
HDMI Media Streaming | QS01

2
Copyright
© 2020 BenQ Corporation.All rights reserved. No part of this publication may be reproduced, transmitted,
transcribed, stored in a retrieval system or translated into any language or computer language, in any form or by any
means, electronic, mechanical, magnetic, optical, chemical, manual or otherwise, without the prior written permission of
BenQ Corporation.
All other logos, products, or company names mentioned in this document may be the registered trademarks or
copyrights of their respective companies, and are used for informational purposes only.
Disclaimer
BenQ Corporation makes no representations or warranties, either expressed or implied, with respect to the contents
hereof and specically disclaims any warranties, merchantability or tness for any particular purpose. Further, BenQ
Corporation reserves the right to revise this publication and to make changes from time to time in the contents
hereof without obligation of BenQ Corporation to notify any person of such revision or changes.
Screen images and icons in this manual are simulated for illustrative purposes only.Actual displays may vary.
BenQ is not responsible for the content of the websites or of similar resources, which are maintained and controlled
by third parties, that may be linked from this product. Providing links to those websites or to similar resources does
not mean that BenQ makes any warranty or representation to their content by expression or by implication.
Any third party content or service preinstalled in this product is provided “as is”. BenQ does not, by expression or
by implication, make any warrant to the content or to the services provided by third parties. BenQ does not warrant
or guarantee that the content or services provided by third parties are accurate, effective, most up-to-date, legal, or
complete. Under no circumstances shall BenQ be liable for the content or services provided by third parties including
their negligence.
Services provided by third parties may be terminated temporarily or permanently. BenQ does not warrant or
guarantee that the content or services provided by third parties are in good condition at any time, and is not liable for
the termination of the said content and services.
In addition, BenQ is not involved in any transactions you conduct in the websites or similar resources maintained by
third parties.
You should contact the content or service providers for any questions, concerns, or disputes.
To download the latest user manual, go to www.BenQ.com > Support > Download & FAQ > model name > User
Manual.

3
Package contents
QS01
Remote control
(with 2 AAA batteries)
Regulatory
Statements
Regulatory statements
Quick Start Guide
Quick start guide
Warranty card
Available accessories and the pictures shown here may differ from the actual contents and the product supplied for your region.
Overview
1
2
3
No. Item Description
1USB port Connects to the projector’s USB port (or a standard adapter head) via the Micro-USB
cable to supply the dongle with power.
2HDMI connector Connects to the projector.
3LED indicator Lights up blue when power is supplied.

4
Remote control
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
No. Item Description
1Power Toggles the projector between standby mode and on (after initial power up from the
keypad).
2Auto focus (Available on compatible projectors only)Enables auto focus function.
3FamiLand Accesses BenQ FamiLand See “BenQ FamiLand” on page 8 for more information.
4Input Selects an input source.
5Home Returns to the home screen.
6Back Returns to the previous menu.
7Mute Toggles the projector’s audio on or off.
8LED indicator Lights up blue when power is supplied.
9Keystone Displays the keystone correction menu.
10 Amazon Prime
video Accesses Amazon Prime video.A registered account is required.
11 Arrow keys
Moves through the menu items or toggle through the available options.
When the On-Screen Display (OSD) menu is activated, these keys are used as directional
arrows to select the desired menu items and to make adjustments.
12 OK Conrms the selection.

5
No. Item Description
13 Android Settings Accesses the Android menu.
14 Projector menu Brings up the projector’s main menu.
15 Google voice
search / Assistant Enables Google voice search / Assistant.A Google account is required.
16 Volume up Increases the volume.
17 Volume down Decreases the volume.
Placing the remote control batteries
1. Slide to open the battery cover.
2. Insert the provided batteries to the battery compartment as illustrated. Make sure that the positive and negative ends
are positioned correctly.
3. Replace the battery cover.
13
2
Remote control effective range
Effective angle: within 30 degrees
Effective range: within 8 meters (~ 26 feet)
Make sure that there are no obstacles between the remote control and the IR sensor(s) on the dongle or projector
that might obstruct the infra-red beam.

6
Connection with a projector and initial setup
1. Connect the Micro-USB cable to the Micro-USB port on the dongle.
2. Connect the dongle to the HDMI port on the projector.
Micro USB
3. Connect the USB type-A connector of the Micro-USB cable to the USB port on the projector.The USB port on the
projector that you connect the cable to must provide 5V/1A power. If the LED indicator on the dongle does not light
up blue after the projector is powered on,the USB port on your projector may not supply enough power and you may
need to connect the cable to a power socket via a standard USB power adapter.
DC 5V/1A
4. Once the projector is powered on,switch the input source on the projector to the HDMI port where the dongle is
connected to.
5. Press and hold the OK key on the dongle's remote control for 3 seconds to pair it with the dongle.
3 seconds
6. Once the pairing is complete, the Home screen is displayed.See "Home screen" on page 7 for more information.
7. Establish network connection and login to your Google account (or create a new one) to complete the initial setup.

7
Home screen
1
3
2
98 10
4
5 6 7
No. Item Description
1Google voice search / Assistant Enables Google voice search / Assistant.
2All apps Access to all the installed apps.
3YouTube Access to the YouTube app.
4Customized channels Customizes the app channels.
5Search by text Enables text input to search.
6Recommended apps or
services Access to the recommended apps or video on demand services.
7Recommended YouTube videos Access to the videos recommended by YouTube.
8Notications Access to the notication(s).
9Settings Access to the Android Settings.
10 System time Displays system time.

8
BenQ FamiLand
BenQ FamiLand provides a quick access to the channels that are suitable for kids.You can customize a preferred
channel list or simply watch the most popular channels FamiLand collects for you.
1. Make sure the dongle is connected to the Internet.
2. Select FamiLand from the Home screen.
3. Finish reading the privacy policy and select Agree to proceed.
4. Follow the on-screen instructions to pair a smart device (e.g., a mobile phone) with the dongle to edit the channel list.
Or you can pair a device later as instructed in "Pairing with your mobile device" on page 8 .
1
32
No. Item Description
1Customized channel list Watch your favorite channels and edit the list as you wish.
2Recommended channel list Watch the most popular kids video contents.Available contents may vary by
language.
3Settings Access to change channel language, manage the paired devices, and check
version information.
Pairing with your mobile device
The channel list can only be edited from a mobile device (e.g., mobile phone or tablet). Pair with your mobile device
rst.
1. If you did not pair with your mobile device at the rst time the app was launched, go to FamiLand Settings
(indicated as 3in "BenQ FamiLand" on page 8 ).
2. Select Setup mobile control.
3. Go to DownloadAPP, scan the QR code to install the FamiLand app on your mobile device.
4. Launch the FamiLand app just installed on your mobile device, select Add device.
5. You are prompted to input PIN code. Go to Pair device on your projector,a PIN code is displayed. Input the PIN
code on your mobile device.
6. Repeat the steps to pair with more devices.And manage the devices from FamiLand Settings > Paired device list.
