Universal Remote Contorl RM-1 User manual

Owner’s Manual
RM-1
RF Remote

RM-1 Owner’s Manual © 2013 Universal Remote Control, Inc.
The information in this Owner’s Manual is copyright protected. No part of this
manual may be copied or reproduced in any form without prior written consent
from Universal Remote Control, Inc.
UNIVERSAL REMOTE CONTROL, INC. SHALL NOT BE LIABLE FOR
OPERATIONAL, TECHNICAL OR EDITORIAL ERRORS/OMISSIONS MADE IN
THIS MANUAL.
The information in this Owner’s Manual may be subject to change without prior
notice.
ccGEN2 is a registered trademark of Universal Remote Control, Inc.
URC - Control the Experience is a registered trademark of Universal Remote
Control, Inc.
All other brand or product names are trademarks or registered trademarks
of their respective companies or organizations.
500 Mamaroneck Avenue, Harrison, NY 10528
Phone: [phone] Fax: [phone]

TABLE OFCONTENTS
Congratulations! 1
Displaying the Settings Screen 2
Color Screen 2
Button Light 3
System 4
Button Beep 4
Date/Time 5
Erasing and Resetting 5
Join to Network 6
Specifications 6
Limited Warranty Statement 7
End User Agreement 10
Federal Communication Commission
Interference Statement 11
Declaration of Conformity 12

Page 1
RM-1 OWNER’SMANUAL
Congratulations!
You’ve purchased a unique synthesis of hardware and software
engineering, the ccGEN2 RM-1 remote control. The RM-1 achieves a
magnificent combination of power and flexibility by simplifying and
automating the operation of even the most complex systems.
The CP-1 Central Processor and the AZ-1 RF Antenna are required to
make the RM-1 work. The combination of the RM-1, AZ-1 and CP-1
create a robust and powerful system.
Backlit Color OLED Screen Buttons
When any button is pressed, the color OLED screen as well as the
remote buttons light up. Once the screen is lit, each of the six buttons
on either side of the screen will have a label. These button labels
change based on what you are watching or listening. Thus, if you have
selected Watch TV, you will see a list of buttons that are useful to that
activity. If you are listening to your iPod through a PSX-2, you will be
able to browse the iPod content.
RF “No Rules” Operation
The RM-1 communicates to the AZ-1 RF Antenna which sends the
signal to the CP-1 Central Processor via 2.4 GHz bidirectional RF. This
gives the RM-1 the ability to control your system without being in
direct line of sight of the equipment.
Your custom installer may have installed a ZR-2 Z Repeater to improve
communication between the RM-1 remote controls, AZ-1 RF antenna
and the CP-1 Central Processor in your system.
Replacing the Batteries
Unlock the battery cover by pushing up on the spring lock at the
bottom of the cover. Remove the cover.
Observe the + and – polarity
indicators inside the battery
compartment and the batteries.
Place the four AA batteries into their
positions in the battery compartment.
Now, replace the battery cover and
snap it into place.

Page 2
RM-1 OWNER’SMANUAL
Displaying the Settings Screen
You can adjust settings of the RM-1 whenever
you like by pressing and holding the MAIN + ENT
button for three seconds. When you do the screen
will change to the Settings Menu. If you do not press
any button on the Settings screen, the RM-1 will beep
signifying a time-out after 30 seconds and
return to the previous setting or main screen.
There are two pages of Settings screens. To access
the other page, press either of the page buttons.
To select a setting, press the corresponding button.
To go back a step or to get out of the settings screen,
press either the MAIN button or the EXIT button on
the RM-1.
Color Screen
Color screen settings give two configurable options.
1. Brightness: Adjust the screen brightness by
pressing the screen buttons on the left and right
side of the slider bar. Once the brightness is
adjusted, press the Save button. Pressing the
Cancel button will revert to the remote’s last
saved brightness setting.
Note: The higher the brightness, the faster the
batteries will deplete.
2. Automatic Turn Off: Adjust the duration the
OLED screen will stay illuminated after a button
is pressed. Pressing the left and right screen
buttons, next to the slider bar, will change how
long the OLED screen will stay on. Pressing the
Less side will decrease the time in steps down to

RM-1 OWNER’SMANUAL
a minimum time of 5 seconds. Pressing the More
side will increase the time in steps up to a
maximum of 60 seconds. Once the setting is
adjusted, press the Save button. Pressing the Cancel
button will revert the remote’s Automatic Turn Off
setting to the last saved setting.
Note: The longer the OLED screen stays on, the faster
the batteries will deplete.
Button Light
The Button Light settings page provides two
configurable options for how the RM-1’s
hard buttons should behave.
1. Automatic ON: Adjusting this setting will
control when the hard button backlight
turns on.
a. Automatic Light Yes: Every time a button is pressed the
button back light will automatically turn On.
b. Automatic Light No: The only way to turn on the hard
button back-light is to press the dedicated Lights button
located on the right side of the remote control.
Once all changes have been made, press the Save button.
Pressing the Cancel button will revert to the remote’s last saved
setting.
Note: The more often the back light turns ON, the faster the
batteries will deplete.
2. Automatic Turn Off: You can adjust the amount of time the
backlight will remain after a button is pressed.
Press the left and right screen buttons next
to the slider bar to change the duration.
Pressing the Less side will decrease the time
in steps down to a minimum of 5 seconds.
Pressing the More side will increase the time
in steps up to a maximum of 60 seconds.
Once the setting has been adjusted, simply press
the Save button. Pressing the Cancel button
will revert to the remote’s last saved Automatic Turn off setting.
Note: The longer the backlight stays on, the faster the batteries
will deplete.
Page 3

Page 4
System
The System Settings page provides two options.
1. Power Remaining: This option shows you
how much battery life is remaining. You
can adjust when the low battery warning
screen will appear by pressing the screen
buttons to the left and right of the slider bar.
The battery indicator will blink when the
batteries are low and need to be replaced.
Once the setting is adjusted, press the Save
button. Pressing the Cancel button will revert
to the remote’s last saved Power Remaining setting.
2. System Info: The System Info screen displays
data about the RM-1’s memory
usage, and operating system version.
Pressing the Next screen button will take
you to the Operating System information,
and pressing the OK button will take you
back to the System Memory information.
Button Beep
Use the screen buttons to the left and right of
the slider bar to adjust the button sound.
Once the setting is adjusted, press the Save
button. Pressing the Cancel button will revert
to the remotes last saved button beep setting.
RM-1 OWNER’SMANUAL

Page 5
RM-1 OWNER’SMANUAL
Date/Time
The Date and Time are automatically sent from the
CP-1 to the RM-1. If you would like to adjust the
date or time you can do so on the remote control.
Note: Any Date or Time adjustment made on the
RM-1 will automatically go out to all the other
remotes and keypads in the system.
1. Change Date: Tap the button beside Day, Month,
or Year, then use the numeric keypad to enter
in the new date information. When you are
finished, press the Save button.
2. Change Time: Tap the button beside Hour or
Minutes, then use the numeric keypad to enter
in a new time. Set AM/PM by toggling the
button. When you are finished, press the Save
button.
3. Display Date/Time: The RM-1 can display
either the Date or Time, but not both.
Select which one you would like to display.
Press the screen button next to Date or Time.
Once you are finished, press the Save button.
Erasing and Resetting
WARNING! Only use this button when instructed by Technical
Support. It resets the memory of the RM-1 to the factory condition. All
your programming will be lost!
To set the remote to its factory default setting,
press "Erase." A secondary screen opens and
requires your confirmation.

RM-1 OWNER’SMANUAL
Join to Network
This feature is only used by the installer at the
remote's initial setup. You will only need to
access this screen if directed by your installer or
technical support. Press the MAIN button to exit
the Join to Network screen. If you do not press a
button, it will timeout after 5 minutes.
Specifications
Microprocessor: ARM7TDMI
RAM: 8Mbit SRAM
FLASH: 32Mbit Nor FLASH
Display: 1.46” PMOLED (128 x 128)
RF Range (radio frequency): 50 to 100 feet, depending upon the
environment
RF Frequency: 2.405~2.480GHz
Provides: Two-Way communication with CP-1(or higher) network
system controller.
Weight: 8.5 oz. (with battery)
Size: 8.7”H x 2.2”W x 1.3”D
Battery Life: 18 Hours of continuous button pressing with back-
lighting and LCD ON (months of use for most users).
Users should expect some variation based on the
brand of alkaline batteries used.
Note: In actual use, the RM-1 protects itself if it gets stuck between
couch cushions (with a button being continuously pressed).
After 30 seconds the RM-1 will turn off, and will
not turn on again until the button is released.
Page 6

RM-1 OWNER’SMANUAL
Page 7
Limited Warranty Statement
1. Limited Warranty and Disclaimers
Universal Remote Control, Inc. (“URC”) warrants that the URC equipment
shall be free from defects in material and workmanship under normal usage
for one (1) year from purchase when such is purchased from URC. This
limited warranty is valid only in the United States of America. URC warrants
that the software will substantially conform in any material respect to its
functional specifications at the time of delivery. URC SHALL NOT BE LIABLE
FOR OPERATIONAL, TECHNICAL OR EDITORIAL ERRORS AND/OR
OMISSIONS MADE IN THE URC DOCUMENTATION. URC DOES NOT
WARRANT THAT THE URC SOFTWARE IS BUG-FREE OR ERROR FREE
OR THAT THERE ARE NO ERRORS/BUGS IN THE URC SOFTWARE.
URC warrants that at the time of purchase the URC equipment and the URC
software complied with all applicable regulations and policies of the Federal
Communications Commissions (“FCC”) regarding electromagnetic
interference caused by electronic/computing devices and to the extent that the
URC equipment and/or the URC software fails to so comply, URC shall, at its
own expense, take all reasonable measures to promptly cause such to
comply.
URC equipment purchases from other than an authorized URC dealer or
distributor are without warranty.
THIS LIMITED WARRANTY DOES NOT COVER TECHNICAL ASSISTANCE
FOR HARDWARE OR SOFTWARE USAGE EXCEPT AS EXPRESSLY
PROVIDED FOR HEREIN, THE EQUIPMENT, SOFTWARE AND
DOCUMENTATION OF URC ARE SUPPLIED “AS IS” WITHOUT ANY
WARRANTY, EXPRESS, STATUTORY OR IMPLIED, OF ANY KIND. TO
THE MAXIMUM EXTENT PERMITTED BY APPLICABLE LAW, URC
EXPRESSLY DISCLAIMS ALL WARRANTIES, EXPRESS, STATUTORY OR
IMPLIED, INCLUDING BUT NOT LIMITED TO THE WARRANTIES OF
MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE. URC
DOES NOT WARRANT, GUARANTEE, OR MAKE ANY
REPRESENTATIONS REGARDING THE USE OF, OR THE RESULTS OF THE
USE OF, THE EQUIPMENT, SOFTWARE OR DOCUMENTATION IN
TERMS OF CORRECTNESS, ACCURACY, RELIABILITY OR OTHERWISE.
EXCEPT AS EXPRESSLY PROVIDED FOR HEREIN, TECHNICAL SERVICES
ARE SUPPLIED “AS IS”, WITHOUT ANY WARRANTY, EXPRESS,

Page 8
RM-1 OWNER’SMANUAL
STATUTORY OR IMPLIED, OF ANY KIND. TO THE MAXIMUM EXTENT
PERMITTED BY APPLICABLE LAW, URC EXPRESSLY DISCLAIMS ALL
WARRANTIES, EXPRESS, STATUTORY OR IMPLIED, INCLUDING BUT
NOT LIMITED TO THE WARRANTIES OF QUALITY OR REASONABLE
SKILL AND CARE, OR OUTCOME OR RESULTS.
WITHOUT IN ANY WAY LIMITING THE GENERALITY OF THE OTHER
PROVISIONS HEREIN, WARRANTY DOES NOT COVER: (I) DAMAGE
FROM MISUSE, NEGLECT OR ACTS OR NATURE, (II) MODIFICATIONS,
(III) INTEGRATION WITH THIRD PARTY CONTENT (IV) BEYOND THE
WARRANTY PERIOD AND/ OR FAILURE TO FOLLOW URC WARRANTY
CLAIM PROCEDURE.
The warranty limitations and warranty disclaimers may not apply to end user
in whole or in part, where such are restricted or excluded by applicable law
and such shall apply to the maximum extent permitted by applicable law.
In the event of any warranty claim, URC will, at its sole option, repair the URC
equipment using new or comparable rebuilt parts, or exchange the URC
equipment for new or rebuilt equipment. In the event of a defect, these are
the end user’s exclusive remedies.
All the URC equipment returned for service, exchange or repair require an
RGA number. To obtain an RGA number, you must complete a Return
Request Form which you may obtain by calling [phone] or contacting
URC at [email protected]. To obtain warranty service, end
user must deliver the URC equipment, freight prepaid, in its original packaging
or packaging affording adequate protection to URC at 420 Columbus Avenue,
Valhalla, NY 10595. It is end user’s responsibility to backup any macro
programming, artwork, software or other materials that may have been
programmed into the unit. It is likely that such data, software, or other
materials will be lost during service and URC will not be responsible for any
such damage or loss. A dated purchase receipt, bill of sale, installation contract
or other verifiable proof of purchase is required. For the URC equipment
support and other important information, please visit URC's website available
at www.universalremote.com or call the Customer Service Center at (914)
835-4484.
This limited warranty only covers the URC equipment issues caused by
defects in material or workmanship during ordinary consumer use. It does not
cover product issues caused by any other reason, including but not limited to
product issues due to commercial use, acts of God, third-party installation,
misuse, limitations of technology, or modification of or to any part of the URC

RM-1 OWNER’SMANUAL
Page 9
equipment. This limited warranty does not cover the URC equipment sold as
used, as is, refurbished, so called "B stock" or consumables (such as batteries).
This limited warranty is invalid if the factory applied serial number has been
altered or removed from the URC equipment. This limited warranty
specifically excludes the URC equipment sold by unauthorized resellers.
With the exception of URC’s IR-only, broad-based consumer remotes, none of
URC’s PC programmable remotes or any of our ccGEN2™ whole-house
equipment are authorized for online internet sales. Buying URC’s PC
programmable remotes or any of our ccGEN2™ whole-house equipment
online means buying equipment that does not have a URC’s limited warranty.
Such equipment is not eligible for URC tech support or software support,
either.
2. URC’S Limitations of Liability
IN NO EVENT SHALL URC BE LIABLE FOR INDIRECT, SPECIAL,
INCIDENTAL, EXEMPLARY, PUNITIVE OR CONSEQUENTIAL DAMAGES
OF ANY KIND OR LOSS OF PROFITS OR BUSINESS OPPORTUNITY,
EVEN IF URC IS ADVISED OF THE POSSIBILITY OF SUCH DAMAGES.
IN NO EVENT SHALL URC BE LIABLE FOR LOSS OF OR DAMAGE TO
DATA, COMPUTER SYSTEMS OR COMPUTER PROGRAMS.
URC’S LIABILITY, IF ANY, FOR DIRECT DAMAGES OF ANY FORM SHALL
BE LIMITED TO ACTUAL DAMAGES, NOT IN EXCESS OF AMOUNTS
PAID BY END USER FOR THE URC EQUIPMENT.
IN NO EVENT SHALL URC BE LIABLE FOR ANY EVENTS BEYOND ITS
CONTROL, INCLUDING ANY INSTANCE OF FORCE MAJEURE.
IN NO EVENT SHALL URC BE LIABLE FOR THE ACTS OR OMISSIONS OF
END USER OR ANY THIRD PARTY.
THE LIMITATIONS OF LIABILITY MAY NOT APPLY TO END USER IN
WHOLE OR IN PART, WHERE SUCH ARE RESTRICTED LIMITED OR
EXCLUDED BY APPLICABLE LAW AND SUCH SHALL APPLY TO THE
MAXIMUM EXTENT PERMITTED BY APPLICABLE LAW.
URC SHALL NOT BE HELD RESPONSIBLE FOR THE STATEMENTS MADE
BY OTHERS.
SOME STATES OR JURISDICTIONS DO NOT ALLOW THE EXCLUSION
OR LIMITATION OF INCIDENTAL OR CONSEQUENTIAL DAMAGES, OR
ALLOW LIMITATIONS ON HOW LONG AN IMPLIED WARRANTY LASTS,
SO THE ABOVE LIMITATIONS OR EXCLUSIONS MAY NOT APPLY TO

RM-1 OWNER’SMANUAL
Page 10
END USER. THIS LIMITED WARRANTY GIVES END USER SPECIFIC LEGAL
RIGHTS AND END USER MAY HAVE OTHER RIGHTS WHICH VARY
FROM STATE TO STATE OR JURISDICTION TO JURISDICTION.
End User Agreement
The terms and conditions of the End User Agreement available at
www.universalremote.com/eua.php shall apply.

Page 11
RM-1 OWNER’SMANUAL
Federal Communication Commission
Interference Statement
This equipment has been tested and found to comply with the limits for
a Class B digital device, pursuant to part 15 of the FCC Rules. These
limits are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates, uses
and can radiate radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference to
radio communications.
However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference
to radio or television reception, which can be determined by turning
the equipment off and on, the user is encouraged to try to correct the
interference by one more of the following measures:
uReorient or relocate the receiving antenna.
uIncrease the separation between the equipment and receiver.
uConnect the equipment into an outlet on a circuit different from
that to which the receiver is connected.
uConsult the dealer or an experienced radio/TV technician for
help.
Warning!
Changes or modifications not expressly approved by the manufacturer
could void the user's authority to operate the equipment.
Note : The manufacturer is not responsible for any Radio or TV
interference caused by unauthorized modifications to this equipment.
Such modifications could void the user's authority to operate the
equipment.
FCC Caution
This device complies with Part 15 of the FCC Rules. Operation is
subject to the following two conditions: (1) this device may not cause
harmful interference, and (2) this device must accept any interference
received, including interference that may cause undesired operation.
Any changes or modifications not expressly approved by the party
responsible for compliance could void the authority to operate
equipment.
Federal Communication Commission (FCC) Radiation Exposure Statement
The device and the antenna for this device must be installed to ensure
a minimum separation distance of 20 cm more from a person's body.
Other operating configurations should be avoided.

Page 12
RM-1 OWNER’SMANUAL
Declaration of Conformity
Company Name : OH SUNG ELECTRONICS CO., LTD.
Company Address : #181 GONG DAN-DONG, GUMI, GYEONG BUK,
REPUBLIC OF KOREA
Contact Information : Phone: [phone], Fax: [phone]
Brand Name : UNIVERSAL remote control
Product Name : RF Remote Controller
Model Name : RM-1
This product herewith complies with the requirements of EMC Directive (2004/108/EC)
and R&TTE Directive(1995/5/EC) issued by the Commission of the European Community
Compliance with these directives implies conformity to the following European Community
n EMC Directive
l AN/NZS CISPR 22 (2006)
l EN 55022 (2006) + A1 (2007)
l EN 55024 (1998) + A1 (2001) + A2(2003)
n R&TTE Directive
l ETSI EN 301 489-1 V1.8.1 (2008)
l ETSI EN 301 489-17 V2.1.1 (2009)
l ETSI EN 300 328 V1.7.1 (2006)
l EN 50385 (2002)
l EN 50383 (2002)
List of test reports and/or certificate verified compliance with the standards above
Date of issue : March 16, 2012
Name and signature of authorized person :
n EMC Directive
l Report No.
l Testing Laboratory : Gumi College EMC Center
n R&TTE Directive
l Certificate No.
l Certificate Body : TUV Rheinland (No. 0197)
Quality Assurance Team
OH SUNG ELECTRONICS CO., LTD.

Page 13
NOTE

Page 14
NOTE

Page 15
NOTE

500 Mamaroneck Avenue, Harrison, NY 10528
Phone: [phone] Fax: [phone]
www.universalremote.com
OCE-0066H Rev 01
