Manufacturer/Brand
Set-Up Code Number
TV
Manufacturer/Brand
Set-Up Code Number
TV
Quick Set-up Code Tables
6
1 SCIENTIFIC ATLANTA/CISCO, PACE
SAMSUNG
2 MOTOROLA
CISCO/SA 001 003 041 042 045 046
PIONEER 001 103 034 051 063 076 105
PACE 001 005 002
SAMSUNG 001 030
MOTOROLA 002 111 148
CE-LABS 164
DIGEO 153
EVOLUTION FTA 158
GENERAL INSTRUMENT
005 103 104
HAMLIN 049 050 055
HITACHI 103 055
JERROLD 005 004 103 005 003 008 009 010 069
MAGNAVOX 010 012
MEMOREX 052
MOXI 111 252 153
NFUSION 192
PANASONIC 044 047
PHILIPS 006 012 013 020 085
PULSAR 052
RCA 047
REGAL 049 050
REGENCY 057
SKY 230 204
SONY 108
SPRUCER 047
TELNET 354
TOCOM 039 040 056
TOSHIBA 052
VIEWSTAR 012 015
ZENITH 052 060 093 100
A MARK 112 143
ABEX 025
ACCURIAN 036
ADMIRAL 072 251 333
AD NOTAM 672
ADVENT 247 388
ADVENTURA 002
AIKO 103
AKAI 116 146 248 404 405 473 475 323 387
391 615
ALBATRON 017
ALERON 028
AMERICA ACTION 043
AMPRO 073
AMSTRAD 052
ANAM 043 054 056 080 112
AOC 116 363 112 058 616
APEX 572
APEX DIGITAL 006
AQUAVISION 573 574
ASTAR 477
AUDIOVOX 076 454 388
AVENTURA 052
AVIELO 627 628
AVION 441
AXION 039
BELCOR 116
BELL&HOWELL 333 072
BENQ 423 600
BOXLIGHT 266
BRADFORD 043
BROCKWOOD 116
BROKSONIC 238
BYDESIGN 031 032
CANDLE 116 002 003 363
CAPEHART 058
CARY AUDIO DESIGN
266
CELEBRITY 001
CENTURION 116
CETRONIC 043
CHANGHONG 247
CITIZEN 116 002 003 363 043 258 103 143
CLARION 043
CLASSIC 043
CLP CLASSIC 333
COBY 640 641 671
COLORTYME 116
CONCERTO 363
CONCIERGE 073
CONTEC 043 050 051
CORNEA 116
CORONADO 143
CRAIG 043 054
CROSLEY 164
CROWN 043 143
CURTIS MATHES 116 258 363 143
CXC 043
CYBERHOME 015
DAEWOO 363 016 043 044 076 103 114 125 127
143
DAYTRON 363 143
DELL 320 164 363 618
DIGITAL PROJECTION
570
DIMENSIA 333
DREAMVISION 235
DUKANE 011 025
DUMONT 116 073
DURABRAND 096 052
DWIN 257
DYNASTY 043
DYNEX 400
EIKI 187
ELECTROBAND 001
ELECTROGRAPH 466
ELECTROHOME 143 024 076 196
ELEKTRA 072
ELEMENT 363 494 526 622
EMERSON 028 048 043 155 005 116 363 047 050
051 076 096 143 153 154 052 514
ENVISION 116
EPSON 324 590
ESA 323
FISHER 007 057
FUJITSU 246 198 410
FUNAI 028 043 052
FUSION 642
FUTURETECH 043
GATEWAY 242 268
GE 073 116 008 009 034 056 074 155 333
363
GEM 391
GIBRALTER 116 073
GO VIDEO 026
GOLDSTAR 113 116 102 363 106 112 127 143
GRUNPY 028 043
HAIER 363 501 623
HALL MARK 363
Quick Number
Manufacturer/Brand
CBL
0 SANYO
1 SONY
2 SAMSUNG
3LG
4 TOSHIBA
5 PANASONIC
6 PHILIPS
7 HITACHI
8 SHARP
9 VIZIO
Quick Number
Manufacturer/Brand
TV
0 ROTEL
1 DENON
2 YAMAHA
3 MARANTZ
4 SONY
5 INTEGRA
6 HARMAN KARDON
7 PIONEER
8 ONKYO
9 LEXICON
Quick Number
Manufacturer/Brand
AUDIO
0 HITACHI
1 SONY
2 PHILIPS
3 SAMSUNG
4 PHILIPS MAGNAVOX
5 PANASONIC
6LG
7 JVC
8 DENON
9 PIONEER
Quick Number
Manufacturer/Brand
DVD
0 BOSE
1HP
2 APPLE / iPod
3 APPLE / iPod
4 MICROSOFT / XBOX
5 SONY / PS2
6 LUTRON
7X-10
8X-10
9 MICROSOFT / XBOX
Quick Number
Manufacturer/Brand
AUX
A. Quick Set-Up Method
STEP1 Turn on the equipment you want to
program. To program your TV, turn on
the TV.
STEP2 Point the remote at the component and
press and hold the [DEVICE] key for 5
seconds until the Device LED blinks off
and turns back on. Continue holding
the [DEVICE] key and press the num-
ber keys, one at a time, starting with 1,
then 2, 3...0. Stop pressing the number
keys when the device turns off.
STEP3 Release the [DEVICE] key to save the
code. The Device LED will blink twice
to confirm the code is stored.
Repeat the steps above for all components
(CBL, TV, AUD, DVD, AUX).
B. Pre-Programmed 3-Dight Code Method
STEP1 Turn on the equipment that you want
the remote control to operate (Cable
Box, TV, DVD, etc.).
STEP2 Press the [DEVICE] button and the
[OK/SEL] button simultaneously for
three seconds. The corresponding
device LED will turn on indicating that
it is ready to be programmed. The LED
will remain on for 30 seconds. The
next step must be entered while the
LED is on.
STEP3 Point the remote control toward the
equipment and enter the three-digit
code number assigned to your brand
from the code tables. If there are more
than one three-digit number listed for
your brand, try one code number at a
time until your equipment turns off.
*Note : You can verify that you have selected the
correct code by pressing the [POWER]
button. The equipment should turn back
on. Then try all of the functions on the
remote control (i.e. volume, mute, etc.)
to ensure you have the correct code. If
any of the functions do not operate as
they should, repeat the instructions from
STEP 3 above using the next three digit
code number from the brand list.
STEP4 Store the three-digit code by pressing
the same [DEVICE] button once again.
The device LED will blink twice to
confirm that the code has been
stored.
C. Auto-Search Method
If none of the three digit code numbers
assigned to your brand of equipment works, or
the code table does not list your brand, you can
use the Auto Search Method to find the correct
three-digit code number for your equipment by
following steps:
STEP1 Turn on the equipment that you want
the remote control to operate (Cable
Box, TV, DVD, etc.).
STEP2 Press the [DEVICE] button and the
[OK/SEL] button simultaneously for
three seconds. The device LED will
turn on indicating that it is ready to be
programmed. The LED will remain on
for 30 seconds. The next step must be
entered while the LED is on.
STEP3 Press the [CH] or [CH] button one
at a time or keep it pressed. The
remote will emit a series of Power
ON/OFF code signals. Release the
[CH+] or [CH-] button as soon as the
equipment turns off.
*Note : You can verify that you have selected the
correct code by pressing the [POWER]
button. The equipment should turn back
on. Then try all of the functions on the
remote control (i.e. volume, mute, etc.) to
ensure you have the correct code. If any of
the functions do not operate as they should,
repeat the instructions from STEP 3 above
to continue the Auto Search Method.
STEP4 Press the same [DEVICE] button to
store the code. The Device LED will
blink twice to confirm that the code
has been stored.
D.To Identify the 3-Digit Code
Programmed for a Device
STEP1 Press the appropriate [DEVICE] button
and the [OK/SEL] button simultaneously
for three seconds. The device LED will
turn on for 30 seconds. The next step
must be performed while the LED is on.
STEP2 Press the [INFO] button. The device LED
will blink a number of times indicating
the number of each digit for the code.
Each digit is separated by a one second
interval of the LED being off.
Example :One blink, (pause) three blinks,
(pause) eight blinks indicates the
code number 138.
*Note : Ten blinks indicates the number 0.
STEP4 Press the [CH] button to save the
power commands you stored. The
[CBL] button will blink twice to confirm
the commands have been saved.
G. Programming Volume Control
Volume and Mute control are factory programmed
to automatically transfer to the respective Device
mode You select, as follows:
CBL : CBL T V :TV AUD : AUD
DVD :TV AUX : AUX
If you wish to store the TV volume control in
CBL mode, use the following steps.
STEP1 Press the [OK/SEL] button and [CBL]
button simultaneously for three
seconds. The device LED will turn on
for 30 seconds. The next step must
be performed while the LED is on.
STEP2 Press the [VOL] button. The device
LED will blink.
STEP3 Press [TV] button. The device LED will
blink twice to confirm the programming.
*Note : To return CBL device to CBL volume
repeat steps above replacing [TV] with
[CBL] in Step 3.
H. Programming Channel Control
You can program the channel controls (Channel
Up, Channel Down, Last and Numbers) from
one Device to operate in another Device mode.
Default channel control settings on the remote
control are as follows:
CBL : CBL T V : CBL AUD : AUD
DVD : DVD AUX : AUX
If you wish to store the TV channel controls in
TV mode, use the following steps.
STEP1 Press the [OK/SEL] button and [TV] button
simultaneously for three seconds. The
device LED will turn on for 30 seconds.
The next step must be performed while
the LED is on.
STEP2 Press the [VOL] button. The device
LED will blink.
STEP3 Press [TV] button. The device LED will
blink twice to confirm the programming.
*Note : To return TV device to CBL channel
repeat steps above replacing [TV] with
[CBL] in Step 3.
I. Programming a ‘Macro’ button.
If your remote model has custom-programmable
Macro buttons available(See Section 4), they
can be programmed to act as a 'Macro' or
Favorite Channel button in CABLE mode. This
allows you to program up to five 2-digit channels,
four 3-digit channels or three 4-digit channels
that can be accessed with one button press.
STEP1
Press the [CBL] button to select the CBL
mode.
STEP2 Press the [MACRO] button and
[OK/SEL] button simultaneously for 3
seconds. The [CBL] button will turn on
for 30 seconds.
STEP3 Enter the the 2, 3 or 4-digit code for the
channel you want programmed first (for
example, 007) using the Number Pad,
then press the [STOP] button. Then
enter the code for the next channel (for
example, 050), then press the [STOP]
button. Repeat this process for the third
channel. The [CBL] button will blink
once for each channel entered.
STEP4 Press the [CH] button to store the
channels that were selected. The
[CBL] button will blink twice to confirm
the storage of commands.
To access the programmed channels, press
the [MACRO] button once. This will bring up
the first channel. Press once again and it will
bring up the second channel. Press again and
it will bring up the third channel.
J. Low Battery Warning
When the batteries are low and need to be
replaced with fresh batteries, the Device LED
lights will blink 2 times in sequence whenever a
[POWER] button is pressed to turn on equipment.
K. Memory Lock System
This remote control is designed to retain pro-
grammed memory for 10 years even after batteries
are removed from the remote control.
L. Record Your Component Set-up Codes
TV Set-up Code Number:
AUD Set-up Code Number:
DVD Set-up Code Number:
AUX Set-up Code Number:
For additional information about your remote
control, go to www.universalremote.com
E. Programming the AUX Device
You can take advantage of the AUX function to
program a devices such as a media PC, gaming
console or satellite radio receiver. Follow the
instruction in section B to program an AUX
device. You can also program the AUX button
for a second TV, DVD or Audio Device. To do
this follow the instructions below.
STEP1 Turn on the 5th device you want to
program (TV, AUD, DVD, etc.).
STEP2 Press the [AUX] button and the
[OK/SEL] button simultaneously for 3
seconds. The [AUX] device LED will
turn on for 30 seconds.
STEP3 Press the [Device] button For the type
of device you want to setup. Point the
remote control toward the device and
enter the 3-digit code number
assigned to your brand.
*Note : To program a second TV press TV, etc.
STEP4 When the equipment turns off verify
that you have selected the correct
code by pressing the [POWER] button.
The equipment should turn back on.
Then try all of the functions on the
remote control (i.e. volume, mute, etc.)
to ensure you have the correct code.
If any of the functions do not operate
as they should, enter the next 3-digit
code number from the brand list.
STEP5 Once you have found the correct
3-digit code, save it by pressing the
[AUX] button one more time. The [AUX]
LED light will blink twice to confirm the
code was stored.
F. Programming the System On/Off Button
This allows you to program the System On/Off
button so it can send up to five power On/Off
commands with one button press.
STEP1 Press the [CBL] button.
STEP2 Press the [SYSTEM ON/OFF] button
and the [OK/SEL] button simultaneously
for 3 seconds. The [CBL] button will turn
on for 30 seconds.
STEP3 Press the first [DEVICE] button you want
to store in the [SYSTEM ON/OFF] button
and then press [POWER]. Repeat this for
the other components you want to turn
on/off with the [SYSTEM ON/OFF] button.
Button Functions
4
Programming the Remote Control
5
IMPORTANT SETUP NOTE!
In this section when you are instructed to press a [DEVICE] button, that means to press either the CBL, TV,
AUD, DVD or AUX button, depending on what device you are programming the remote to operate.
There are three ways you can program your remote:
* Quick Set-Up Method
* The Pre-Programmed 3-Digit Code Method
* The Auto-Search Method
The Quick Set-Up Method is a unique feature that enables the fastest and easiest setup by using a 1 digit code.
This is the quickest way to set up devices made by popular manufacturers.
The Pre-Programmed Code Method allows you to setup all of the buttons at once by entering 3-digit code
numbers that correspond with the components manufacturer/brand. Code tables for this method are on the
backside of the operating instructions.
The Auto-Search Method scans through all of the codes in the remote control, one at a time allowing you to
identify the correct code.
IMPORTANT SETUP NOTE!
This pertains to all programming steps. When you are in setup mode the device LED will light for 30 seconds. If you do
not press a button within 30 seconds, the LED light will turn off and exit setup mode, and you will need to start over.
Universal Remote Control, Inc.
www.universalremote.com
OCE-0081A Rev 11 (06/08/12)
Operating Instructions For
PHAZR-5
Cable Remote Control
The PHAZR-5 UR5U-9000L & UR5U-9020L
is designed to operate the CISCO / SA,
Pioneer, Pace Micro, Samsung and
Motorola digital set tops, Plus the majority
of TV, AUD, DVD and AUX equipment on
the market as shown below.
CBL : Cable Set-top Box TV : Televisions
AUD : Audio Receivers DVD : DVD Players
AUX : Media PC, Gaming System, etc.
Introduction
1
DEFAULT STATE:
Device Default: Cable Set-Top Box (STB)
Channel Default: CABLE channel and numbers
through the CABLE STB. You have the option of
controlling your CABLE channel and numbers
through the TV or AUD. Refer to section Hfor pro-
gramming steps.
Volume Default: Volume and Mute control are
automatically transferred to the respective
Component based on the Device selected:
CBL:Cable Set-Top Box ; TV:TV ; AUD:AUD.
DVD:TV ; AUX:AUX. You have the option of
controlling CABLE Volume and Mute through
the TV, DVD or AUD. Refer to section Gfor
programming steps.
Operations
3
Replacing Batteries
2
Before you program or operate the remote control,
you must install two new AA alkaline batteries.
STEP1 Remove the battery compartment cover
on the back of your remote control.
STEP2 Check battery polarity carefully, and
install the batteries as shown in the
illustration below.
STEP3 Replace the battery compartment cover.
UR5U-9000L & UR5U-9020L
Set-up Code Tables
7
Manufacturer/Brand
Set-Up Code Number
CBL-CABLE Converters
