Universal 914GX User manual

You’ll need these basic tools:
Fing Instrucons
Extendable metal curtain pole kit
Before fing your new curtain pole, please read the
following instrucons and check the contents of your
pack against the table below.
Should any component be missing, please call the
Customer Care Department on 0330 005 2233
Installaon & Assembly
Safety Recommendaon
Always use a Step Ladder when working at heights.
DO NOT over reach. Always move the Step
Ladder so that you are in a safe working posion.
DO NOT hold or lean on the pole to support
your weight.
We recommend you use two people for installaon
of larger poles.
Take care when using power tools, use of a
Residual Current Device (RCD) is recommended.
Always use eye protecon when drilling. Beware
of hidden pipe runs and cables.
No liability will be accepted for damage or injury
caused by incorrectly installed or assembled
product.
PLEASE KEEP OUT OF THE REACH OF
YOUNG CHILDREN. SMALL PARTS - CHOKING
HAZARD
PLEASE KEEP THESE INSTRUCTIONS AND THE
BATCH CODE ON THE PACKAGING FOR FUTURE
REFERENCE IF ANY QUERIES
SCREWDRIVERDRILL
PENCIL MEASURE SPIRIT LEVEL
4
2
1
3
1
2
3
4
Pole
Bracket
Finial
Rings
Parts
Pole Length
120cm to 220cm 180cm to 330cm
11
33
22
22 34
Image for illustraon only, finial may vary
5Fings pack 11

1
6614 L-CL-01
2c
Measure the windows.
Approx.
10cm
d1+d2+d1=Pole Length
d1
Approx.
10cm
d1d2 (distance between end brackets)
3
Calculate the length of the pole.
Adjust the length of the pole.
2a 2b
45
Slide on the rings, ensuring an
equal amount each side.
(leaving 2 rings aside)
4
6 7
Fit the pole into the brackets. Fit the finial.(place the remaining
ring between the brackets and the finial)
10cm
10cm
Reference line
Slide the inner pole out of the outer pole, take care to leave the joining piece in place between
two poles.
Tighten screw Tighten finial screw
Reference line
Measure the bracket hole
posion.
Drill the hole and fit the correct
plugs if fixing on masonry wall.
Fix the brackets.
