Universal 976LR User manual

SMOKE & FIRE ALARM WITH SILENCE FEATURE
Table of Contents:
Page #
Smoke Alarm Limitations and Functions ................................. 2
Recommended Location of Alarms.......................................... 2
Avoid These Locations ............................................................ 3
Early Warning .......................................................................... 4
Locking/Tamper Feature.......................................................... 4
Mounting Instructions .............................................................. 4
Operation, Testing & Maintenance .......................................... 5
RV Installation ......................................................................... 5
QUICK FIND®Alarm Originating Feature & Reset................... 5
Cautions/Warnings .................................................................. 5
Silence Feature ....................................................................... 5
Battery Replacement............................................................... 6
Develop and Practice a Plan of Escape .................................. 6
Operational Summary.............................................................. 7
Warranty ..................................................................Back Cover
MODEL 976LR
READ ALL INSTRUCTIONS
This smoke alarm uses an extremely small amount of a radioactive
element in the ionization chamber. Do not tamper with radioactive sealed
source or try to repair the smoke alarm yourself.

Page 2
RECOMMENDED LOCATION OF ALARMS
• Locatetherstsmokealarmintheimmediateareaofthebedrooms.Trytoprotecttheescape
routeasthebedroomsareusuallyfarthestfromanexit.Ifmorethanonesleepingareaexists,
locate additional smoke alarms in each sleeping area. If a hall is more than 40 feet (12 meters)
long, install a smoke alarm at each end.
• Locate additional smoke alarms to protect any stairway as stairways act like chimneys for smoke
and heat.
SMOKE ALARM LIMITATIONS AND FUNCTIONS
 Therearethreebasicsmokealarmtypes:IoPhic®, Ionization and Photoelectric.
IoPhic®is an ionization alarm containing a patent-pending Universal Smoke Sensing Technology. IoPhic®
alarmsareveryeffectiveatdetectingfastamingresandalsorespondveryquicklytoslowsmoldering
res- up to87% fasterthan the maximumallowable alarmlimit (UL217Smoldering Smoke Teston
5/26/2010,UnderwritersLaboratoriesProject#09CA38078).
Ionizationsmokealarmsaretypicallymoreeffectiveatdetectingfastamingres-reswhichconsume
combustiblematerialsrapidlyandspreadquickly.Sourcesoftheseresmayincludepaperburningina
wastebasket,orkitchengreaseres.
Photoelectric smoke alarms, on the other hand, are typically more effective at detecting slow smoldering
res-reswhichburnforhoursbeforeburstingintoame.Sourcesoftheseresmayincludecigarettes
burningincouchesorbedding.
Installing IoPhic®smokealarmsensuresmaximumdetectionofbothtypesofresfromasinglealarm,
whileeliminatingtheneedforacombinationofionizationandphotoelectricsmokealarms.
The enclosed alarm is an Ionization smoke alarm.
SMOKE ALARMS WILL NOT WORK DURING A LOSS OF POWER. SINCE A SMOKE ALARM WILL
NOT WORK WITHOUT POWER, having an alarm(s) that works from two completely different power
sources,suchasanACdirectwirewithbatterybackupsmokealarm,cangiveyouanextrameasureof
protectionincaseofanACpowerfailureoradeadbattery.Batteryoperatedalarmscannotworkifthe
batteriesaremissing,disconnectedordead,ifthewrongtypeofbatteriesareusedorifthebatteriesare
not installed correctly. AC (only) powered alarms cannot work if the AC power is cut off for any reason.
IfyouareconcernedaboutthelimitationsofthebatteryorACpower,installbothtypesofalarms.
USING AN IONIZATION SMOKE ALARM IN A SMOKY AREA, SUCH AS A KITCHEN, OR IN A HIGH
HUMIDITY AREA NEAR A SHOWER, CAN CAUSE NUISANCE FALSE ALARMS. IT IS PREFERABLE
TO USE PHOTOELECTRIC ALARMS IN THESE AREAS. DO NOT TURN OFF THE AC POWER TO
QUIET THE ALARM. A SMOKE ALARM WILL NOT HELP PROTECT YOU IF IT IS NOT POWERED.
Properly locate your alarm to avoid nuisance alarms.
 A SMOKE ALARM MAY NOT ALWAYS WARN YOU ABOUT FIRES CAUSED BY CARELESSNESS
AND SAFETY HAZARDS LIKE SMOKING IN BED, VIOLENT EXPLOSIONS, ESCAPING GAS,
IMPROPER STORAGE OF FLAMMABLE MATERIALS, OVERLOADED ELECTRICAL CIRCUITS,
CHILDREN PLAYING WITH MATCHES, NATURAL CAUSES SUCH AS LIGHTNING, OR ARSON. FIRE
PREVENTION IS YOUR BEST SAFEGUARD.
INSTALLING SMOKE ALARMS MAY MAKE YOU ELIGIBLE FOR LOWER INSURANCE RATES, BUT
SMOKE ALARMS ARE NOT A SUBSTITUTE FOR INSURANCE. Homeowners and renters alike should
continue to insure their lives and properties.
 SMOKE ALARMS CANNOT DETECT FIRES IF THE SMOKE DOES NOT REACH THEM. Smokefromres
maynotreachthesensingchamberandsetoffthealarm.Onealarmshouldbeinstalledinsideeachbedroom
orsleepingarea.Donotobstructairowaroundthesmokealarmorplaceinareasofobstructedairow.
 BE AWARE OF VARIOUS SITUATIONS AGAINST WHICH THE SMOKE ALARM MAY NOT BE
EFFECTIVE.Forexample:(1)Fireswherethevictimisintimatewithaaminginitiatedre;forexample,
whenaperson'sclothescatchrewhilecooking;(2)Fireswherethesmokeispreventedfromreaching
thealarmduetoacloseddoororotherobstructionor(3)Incendiaryreswheretheregrowssorapidly
thatanoccupant'segressisblockedevenwithproperlylocatedalarms.
SMOKE ALARMS MAY NOT DETECT FIRE ON ANOTHER FLOOR OR AREA OF THE HOME.
Recommendedminimumprotectionisatleastonesmokealarmineverysleepingareaandeverybedroom
on every level of your home. Interconnected smoke alarms may provide earlier warning than stand-alone
smoke alarms since all smoke alarms alarm when one detects smoke.
SMOKEALARMSMAYNOTBEHEARD.Thealarmhorninthisalarmmeetsorexceedscurrentstandards,
butitmaynotbeheardif:(1)thesmokealarmislocatedoutsideaclosedorpartiallycloseddoor;(2)
residentsrecentlyconsumedalcoholordrugs;(3)thealarmisdrownedoutbynoisefromstereos,TV's,
airconditionersorotherappliances;(4)residentsarehearingimpairedor(5)ifresidentsaresleeping.
CURRENT STUDIES HAVE SHOWN SMOKE ALARMS MAY NOT AWAKEN ALL SLEEPING
INDIVIDUALS AND THAT IT IS THE RESPONSIBILITY OF INDIVIDUALS IN THE HOUSEHOLD WHO
ARE CAPABLE OF ASSISTING OTHERS TO PROVIDE ASSISTANCE TO THOSE WHO MAY NOT
BE AWAKENED BY THE ALARM SOUND OR TO THOSE WHO MAY BE INCAPABLE OF SAFELY
EVACUATING THE AREA UNASSISTED.
SMOKE ALARMS ARE NOT FOOLPROOF. You must test the smoke alarm weekly to ensure your
continuedprotection.Smokealarmscannotpreventorextinguishres.
SMOKEALARMSHAVEALIMITEDLIFE.Thesmokealarmshouldbereplacedimmediatelyifitisnot
operating properly. You should always replace a smoke alarm after 10 years.
SMOKE ALARMS ARE NOT TO BE USED WITH DETECTOR GUARDS UNLESS THE COMBINATION
HAS BEEN EVALUATED AND FOUND SUITABLE FOR THAT PURPOSE.

• Locateatleastonesmokealarmoneveryoorlevel.
• Locate a smoke alarm in any area where a smoker sleeps or where electrical appliances are
operated in sleeping areas.
• Smoke,heatandothercombustionproductsrisetotheceilingandspreadhorizontally.Mounting
the smoke alarm on the ceiling in the center of the room places it closest to all points in the room.
Ceilingmountingispreferredinordinaryresidentialconstruction.However,inmobilehomes,
wallmountingonaninsidepartitionispreferredtoavoidthethermalbarrierthatmayformatthe
ceiling.
• When mounting smoke alarm on the ceiling, locate it a minimum of 4" (10cm) from a side wall
or corner (see Diagram A).
• When mounting smoke alarm on a wall, if local codes allow, use an inside wall with the top edge
ofthesmokealarmaminimumof4"(10cm)andamaximumof12"(30.5cm)belowtheceiling/
Page 3
Sloped Ceilings (Peaked Ceilings):
Smoke alarms or smoke detectors mounted on a peaked ceiling shall be located within 36 in. (914 mm)
horizontally of the peak, but not closer than 4 in. (102 mm) vertically to the peak.
Sloped Ceilings (Shed Ceilings):
Smoke alarms or smoke detectors mounted on a sloped ceiling having a rise greater than 1 ft. in 8 ft. (1
m in 8 m) horizontally shall be located within 36 in. (914 mm) of the high side of the ceiling, but not closer
than 4 in. (102 mm) from the adjoining wall surface.
Tray-Shaped Ceilings:
Smoke Alarms or smoke detectors shall be installed on the highest portion of the ceiling or on the sloped
portion of the ceiling within 12 in. (305 mm) vertically down from the highest point.
Mobile Home Installation:
For minimum protection, smoke alarms should be installed in compliance with H.U.D. Manufactured
Home Construction Safety Standards, Title 24 CFR, Section 3280.208 and Section 3282. For additional
protection, see Single Story Residence smoke alarm requirements/recommendations for Existing Homes
and New Construction Homes.
Note: For mobile homes built before 1978, install smoke alarms on inside walls between 4” and 12” from
the ceiling (older mobile homes have little or no insulation in the ceiling). This is especially important if
the ceiling is unusually hot or cold.
Install a smoke alarm inside each bedroom and in the hallway outside each separate sleeping area.
Existing Homes:
The NFPA requires a smoke alarm on every level and outside each sleeping area in existing construction.
An existing household with one level and one sleeping area is required to have one smoke alarm.
New Construction Homes and Manufactured Homes:
The NFPA requires AC-powered, interconnected smoke alarms to be installed inside each bedroom, outside
each bedroom area, and on every level of the home. They also require a minimum of two AC-powered,
interconnected smoke alarms in any new construction home.
AVOID THESE LOCATIONS
• thegarage–productsofcombustionareproducedwhenyoustartyourvehicle.
• nearappliancesorareaswherenormalcombustionregularlyoccurs(kitchens,nearfurnaces,
gas hot water heaters). Use smoke alarms with photoelectric sensors or smoke alarms with
Silence Feature for these areas.
• inareaswithhighhumidity,likebathroomsorareasneardishwashersorwashingmachines.
Install at least 3 feet (0.9 meters) away from these areas.

THIS SMOKE ALARM WILL NOT WORK WITHOUT A GOOD BATTERY PROPERLY INSTALLED.
THE SMOKE ALARM SHOULD BE TESTED WHEN INSTALLED AND THEN TESTED WEEKLY
AFTER THAT.
Early warning re detection is best achieved by the installation of re detection equipment in all
rooms and areas of the household as follows: A smoke alarm installed in each separate sleeping
area (in the vicinity of, but outside of, the bedrooms); and, as appropriate, heat or smoke alarms
in living rooms, dining rooms, kitchens, hallways, attics, furnace rooms, closets, utility storage
rooms, basements and attached garages. Test the alarms weekly to assure proper operation.
CAUTION: THIS SMOKE ALARM IS SEALED. THE COVER IS NOT REMOVABLE!
• Amountingbracketisprovidedonthebackofthealarm.
• Removethemountingbracketfromthebackofthealarmbyholdingthemountingbracketandtwisting
the alarm.
OPTIONAL TAMPER RESISTANT FEATURE: There is a separate tamper resistant locking feature
provided for this model. Activating this feature deters someone from removing the smoke alarm from the
mountingbracket.Thebreakawaylockingpinisclearlymarkedandmoldedintothemountingbracket.
Refer to the diagram.
TO ACTIVATE THE LOCKING FEATURE: Do not activate the locking feature until you have activated
thebattery,mountedthesmokealarmtothebracketandtestedthesmokealarm.RefertoOPERATION,
TESTING & MAINTENANCE instructions on Page 6.
1. Detachthebreakawayalarmlockingpinfromthemountingbracket.
• inareasofturbulentairsuchasairreturnsorheatingandcoolingsupplyvents,smokealarmsshall
notbelocatedwhereairowpreventssmokefromreachingthealarms.
• inextremelydusty,dirtyorinsect-infestedareas.Looseparticlesinterferewithsmokealarmoperation.
• inareaswheretemperaturemayfallbelow400F (4.40C)orriseabove1000F(37.80C).
• closerthan1foot(0.3m)fromuorescentlights,electrical"noise"andickeringmayaffectthealarm's
operation.
• closerthan3feet(0.9m)horizontalpathfromthetipofthebladeofaceilingsuspended(paddle)fan.
• onapoorlyinsulatedceilingorexteriorwall(mountsmokealarmonaninsidewall).
Page 4
2. Insertthepinintotheholeforthetamperresistantfeature.Refertothediagrambelowforcorrect
placement.
TO DEACTIVATE THE LOCKING FEATURE: To remove the smoke alarm for cleaning or servicing or to
replacethebattery,youmustrstremovethelockingpin,ifithasbeeninstalled.
1. Use long nose pliers to pull the locking pin out of the hole.
2. Itisnowpossibletoremovethesmokealarmorreplacethebattery.
MOUNTING INSTRUCTIONS
1. Attachthemountingbracketintheproperlocationonthewallorceiling(screwsandanchorsprovided).
2. Toactivate9voltbatteryandalarm,holdthebattery,pullandremovethePULL-TAB.Conrmthat
theentirePULL-TABhasbeencompletelyremoved.DiscardPULL-TAB.
3. Pushandtwistthealarmclockwiseontothemountingbracket.
4. See "OPTIONAL TAMPER RESISTANT FEATURE" and "TO ACTIVATE THE LOCKING FEATURE"
instructions on Page 4.
5. TheredLEDwillblinkonapprox.every40-45secondstoindicateproperoperation.
ALARM/BRACKET
LOCKING PIN
INSERT ALARM
LOCKING PIN
HERE
LOCKING PIN

Page 5
OPERATION, TESTING & MAINTENANCE
OPERATION:Thesmokealarmisoperatingoncethebatterypowerisconnectedbyremoving
thePULL-TAB.Whenproductsofcombustionaresensed,thealarmsoundsaloudalarmwhich
continues until the air is cleared.
This alarm incorporates the NFPA recognized horn signal for evacuation. During alarm mode, the
hornproducesthreelongbeepsfollowedbyatwosecondpauseandthencontinuallyrepeats.
READY/ACTIVE CONDITION:TheredLEDblinksononceapprox.every40-45secondstoindicate
the alarm is properly functioning.
ALARM CONDITION:TheredLEDblinksononceapprox.everysecondandthealarmemitsa
loud, pulsating alarm sound.
NUISANCE ALARMS: The smoke alarm is designed to minimize nuisance alarms. Smoking will
notnormallysetoffthealarmunlesssmokeisblowndirectlyintothesmokealarm.Combustion
particles from cooking may set off the alarm if the smoke alarm is located close to the kitchen
cookingsurface.Largequantitiesofcombustionparticlesaregeneratedfromspillsorbroiling.
Ifthesmokealarmdoessound,checkforresrst.Ifareisdiscovered,getoutandcallthere
department.Ifnoreispresent,checktoseeifoneofthereasonslistedabovemayhavecaused
thealarm.UsetheSilenceFeatureifitisanuisancealarm,orresetthealarmbypressingand
holdingthetestbuttonfortenseconds.RefertoRESETbelow.
NOTE:Itisbestto"reset"thealarmsbeforeinitialtestisperformed.SeebelowforResetprocedures.
TESTING: Test by pushing the Test button on the smoke alarm cover until the alarm sounds,
thenrelease.Thealarmsoundsifallelectroniccircuitry,hornandbatteryareworking.Ifnoalarm
sounds, the alarm may have a power supply failure. Test the smoke alarm weekly to assure
proper operation.
RV INSTALLATION
WARNING: TEST SMOKE ALARM OPERATION AFTER VEHICLE HAS BEEN IN STORAGE,
BEFORE EACH TRIP AND AT LEAST ONCE PER WEEK DURING USE. An identical marking is
tobeprovidedbytherecreationalvehiclemanufacturerthatshallbepermanentandlocatedvisibly,
within 24 inches (610mm) of the smoke alarm.
ALARM ORIGINATION: The QUICK FIND®feature will allow you to immediately locate the
originating alarm (once the alarm has stopped sounding). To initiate QUICK FIND®, press the
Test/Silencebuttononeachalarm.Afterreleasingthebutton,theoriginatingalarmwillcontinue
tosoundforapprox.60seconds.Inanon-interconnectedinstallation,itisnecessarytotesteach
alarm to determine the originating alarm.
RESET: To reset the QUICK FIND®Alarm Origination Mode - Hold the Test/Silence button
for approx. 10 seconds, or temporarily remove (and then replace) the battery. This will clear
alarm origination indicator.
If you choose to use an aerosol smoke product to test the smoke alarm, be certain to use
one that has been Listed to Underwriters Laboratories, Inc. Safety Standards and use it
only as directed. Use of non-UL Listed products or improper use of UL Listed products may
affect the smoke alarm's sensitivity.
NUISANCE ALARM SILENCE FEATURE: Thisfeatureistobeusedonlywhenaknownalarm
condition, such as smoke from cooking, activates the smoke alarm. The smoke alarm Silence Feature
isactivatedbypushingandreleasingtheSilencebuttononthesmokealarmcoverwhileinalarm
condition.ThesmokealarmwillautomaticallyreducesensitivityandtheredLEDwillblinkonapprox.
every 10 seconds to indicate the alarm is in the Silence mode. The smoke alarm will gradually
regainnormalsensitivityandsoundthealarmifparticlesofcombustionarestillpresent.The8-12
minuteSilencefeaturemaybeusedrepeatedlyuntiltheairhascleared,bypushingandreleasing
theSilencebuttonagain.Resettingthesmokealarmafteranuisancealarmisrecommended.
NEVER use an open ame of any kind to test this smoke alarm. You might accidentally
damage or set re to the smoke alarm or to your home. The built-in test switch accurately
tests the smoke alarm's operation as required by Underwriters Laboratories Inc. (UL).

NOTE:IftheTestbuttonispressedandheldduringtheSilencemode,thesmokealarmwillbe
testednormally.UponthereleaseoftheTestbutton,theSilencemodewillberestarted.
Before using the alarm Silence Feature, identify the source of smoke and be certain that
safe conditions exist.
Clean the smoke alarm at least once a monthtoremovedust,dirt,insectsordebris.Usinga
softbrushorwandattachmenttoavacuumcleaner,vacuumallsidesandcoverofsmokealarm.
Besurealltheventsarefreeofdebris.
Ifthesmokealarmisfalsealarmingandcannotberestoredtonormaloperation,thesmokealarm
shouldbereplaced.
BATTERY REPLACEMENT
Thesmokealarmusesa9Voltbattery.Thebatteryshouldlastforatleastoneyearundernormal
operatingconditions.Thesmokealarmhasalowbatteryindicator,anaudiblebeeporchirp.It
willoperateatapprox.40secondintervalsforaminimumof7days.Whenthisindicationoccurs,
replace the battery with anAlkaline type (Energizer #522, Duracell #MN1604) or Lithium type
(Ultralife U9VL-J) from your local retailer.
LITHIUM Battery Models only-TheLITHIUMbatteryiswarrantedtolastfor10yearsundernormal
operatingconditions.ReplacethebatterywithonlyLITHIUMtype:(ULTRALIFE:U9VL-J).
Removethebattery.Whileobservingpolarity,pushthereplacementbatteryintothebatterytray
until it is held securely in place.
Test the smoke alarm by pushing the TEST button on the smoke alarm cover until the alarm
sounds, then release.
REPAIRS AND SERVICES
Thissmokealarmcontainslessthan1microcurie(37kilobecquerel)ofAmericium241,aradioactive
material. The distribution of these ionization-type smoke alarms is licensed by the U.S. Nuclear
Regulatory Commission; the consumer is exempt from any licensing or requirements. If the
smoke alarm is defective in any way, do not tamper with the smoke alarm. Return the smoke alarm
forservicing.(Seewarrantyforinstructionsorin-warrantyreturns.)Therewillbeaservicecharge
for repairing out of warranty smoke alarms.
DEVELOP AND PRACTICE A PLAN OF ESCAPE
BASICS OF ESCAPE PLAN
o Makeaoorplanindicatingalldoorsandwindowsandatleasttwoescaperoutesfromeachroom.
Second story windows may need a rope or chain ladder.
o Haveafamilymeetinganddiscussyourescapeplan,showingeveryonewhattodoincaseofre.
o Determineaplaceoutsideyourhomewhereallofyoucanmeetifareoccurs.
o Familiarize everyone with the sound of the smoke alarm and train them to leave your home when
they hear the sound.
o Identifychildren'sbedroomswithredstickersplacedintheupperleftcornerofthewindows.They
areavailablefromyourlocalredepartment.
o Practicearedrillatleasteverysixmonths.Practiceallowsyoutotestyourplanbeforeanemergency.
Youmaynotbeabletoreachyourchildren.Itisimportanttheyknowwhattodo!
WHAT TO DO WHEN THE ALARM SOUNDS
o Leaveimmediatelybyyourplanofescape.Everysecondcounts,sodon'twastetimegettingdressed
orpickingupvaluables.
o Inleaving,don'topenanyinsidedoorwithoutrstfeelingitssurface.Ifhot,orifyouseesmoke
seeping through cracks, don't open that door!Instead,useyouralternateexit.Ifinsidedooris
cool,placeyourshoulderagainstit,openitslightlyandbereadytoslamitshutifheatandsmoke
rush in.
o Stayclosetotheoorifairissmoky.Breatheshallowlythroughacloth,wetifpossible.
o Once outside, go to your selected meeting place and make sure everyone is there.
o Calltheredepartmentfromyourneighbor'shome–not from yours!
o Don'treturntoyourhomeuntilreofcialssaythatitisallrighttodoso.
Page 6

Page 7
NATIONAL FIRE PROTECTION ASSOCIATION REQUIRED INFORMATION
Foryourinformation,theNationalFireAlarmCode,NFPA72,readsasfollows:
"11.5.1*RequiredDetection-Whererequiredbyapplicablelaws,codes,orstandardsforaspecic
typeofoccupancy,approvedsingleandmultiple-stationsmokealarmsshallbeinstalledasfollows:
(1) *In all sleeping rooms and guest rooms
(2) *Outside of each separate dwelling unit sleeping area, within 6.4 m (21 ft) of any door to a
sleeping room, the distance measured along a path of travel
(3)Oneverylevelofadwellingunit,includingbasements.
(4)Oneverylevelofaresidentialboardandcareoccupancy(smallfacility),includingbasements
andexcludingcrawlspacesandunnishedattics
(5) *In the living area(s) of a guest suite
(6)Inthelivingarea(s)ofaresidentialboardandcareoccupancy"
Theequipmentshouldbeinstalledusingwiringmethodsinaccordancewiththe
National Fire Protection Association's Standard 72.
(National Fire Protection Association, Batterymarch Park, Quincy, MA 02269)
Blinks On once
approxevery
40-45 seconds
Condition: DC Power is present.
Recommendation: None, alarm is operating properly.
OPERATIONAL SUMMARY
Silent
Blinks On once
approxevery
second
Condition: Nuisance Alarm.
Recommendation: If there is no hazard present, verify the alarm is mounted in the
correct location (see User's Manual, "AVOID THESE LOCATIONS" section). Reset
alarmasinstructedbelow.
3 Beeps,
2 second pause,
Repeat
Blinks On once
approxevery
second
Condition: Originating Smoke Alarm.
Recommendation:Ifhazardis identied,pleasetake allprecautionsifanalarm
soundsbycallinganEmergencyServiceandgettingoutofthehome.
Blinks On once
approxevery
40-45 seconds
(normal operation
mode) or Blinks On
onceapproxevery
10 seconds
(silence mode)
Condition: One alarm has sensed smoke and is now silent.
Recommendation: QUICK FIND®Alarm Origination - The QUICK FIND®feature will
allow you to immediately locate the originating alarm (once the alarm has stopped
sounding). To initiate QUICK FIND®, presstheTest/Silencebuttonon any alarm.
Afterreleasingthebutton,theoriginatingalarmwillcontinuetosoundforapprox60
seconds. In a non-interconnected installation, it is necessary to test each alarm to
determine the originating alarm. Reset the originating alarm.
Condition:Alarmneedstoberesetduetovaryingconditions/previousalarms.
Recommendation: To Reset the Alarm, hold the Test/Silence button for approx
10seconds, or temporarily remove (and then replace)thebattery.This will clear
alarm origination.
Silent
3 Beeps,
2 second pause,
Repeat
3 Beeps,
2 second pause,
Repeat
Condition: Alarm has sensed smoke.
Recommendation:SilenceFeatureisactivatedbypressingandreleasingtheTest/
Silencebuttonontheinitiatingalarmwhileinalarmcondition.Silencemodewilllast
forapprox8-12minuteswiththeredLEDblinkingonceapprox.every10seconds.
Blinks On once
approxevery
second
Silent
(alarmed
previously)
CONDITION / RECOMMENDATION
HORN RED LED
Blinks On once
approxevery
40-45 seconds
(normal operation
mode) or Blinks On
onceapproxevery
10 seconds
(silence mode)
ALARM AUDIBLE & VISUAL SIGNALS
THIS PRODUCT IS LISTED TO UL STANDARD FOR SAFETY,
UL217 BY UNDERWRITERS LABORATORIES, INC.
Blinks On once
approxevery
40-45 seconds
1 Chirp
approxevery
40 seconds
Condition: Low Battery
Recommendation: Checktomakesurethebatteryactivationpulltabhasbeen
completelyremoved,batterypolarityiscorrectandthebatteryterminalsaremaking
contactwiththesmokealarmcontactsinthebatterydrawer.Ifchirpcontinues,replace
the9Vbattery(seeUser'sManualforrecommendedbatterytypes).

288-3445-05
MODEL 976LR
PRODUCT THREE YEAR LIMITED WARRANTY
USI ELECTRIC, INC. / UNIVERSAL SECURITY INSTRUMENTS, INC. (“USI”) warrants your
product to be free from defects in material and workmanship for a period of three (3) years
from the date of purchase.Thiswarrantyshallnotapplytoanybatteriesusedintheproductor
toanydamagewhichmaybecausedbysuchbatteries.Thiswarrantyappliesonlytotheoriginal
consumer purchaser and only to products used in normal residential use and service. If this
productisfoundtobedefective,USI’sonlyobligation,andyourexclusiveremedy,istherepairor
replacementoftheproduct,atUSI’sdiscretion,providedthattheproducthasnotbeendamaged
throughmisuse,abuse,accident,modications,alteration,neglectormishandling.ThisWarranty
shallnotapplytoanyproductwhichisfoundtohavebeenimproperlyinstalled,set-up,orusedin
any way not in accordance with the instructions supplied with the product.
ALARM RETURNS
For replacement of this alarm under the terms of this Warranty, contact Customer Service at
1-800-390-4321,Ext.238, forcurrent postageand handlingfees.USI DOES NOT WARRANT
AND SPECIFICALLY DISCLAIMS ANY WARRANTY, WHETHER EXPRESS OR IMPLIED, OF
FITNESS FOR A PARTICULAR PURPOSE, OTHER THAN THE WARRANTY CONTAINED
HEREIN. NO IMPLIED WARRANTY ON THIS PRODUCT, CREATED BY STATE LAW, SHALL
EXTEND BEYOND THE TERM OF THIS WARRANTY UNLESS SUCH LAW OTHERWISE
PROVIDES. USI SPECIFICALLY DISCLAIMS ANY LIABILITY AND SHALL NOT BE LIABLE
FOR ANY CONSEQUENTIAL OR INCIDENTAL LOSS OR DAMAGE, INCLUDING, BUT NOT
LIMITED TO, DAMAGES TO ANY EQUIPMENT WITH WHICH THIS PRODUCT IS USED. Some
statesdonotallowtheexclusionorlimitationofincidentalorconsequentialdamages,sotheabove
limitationsorexclusionsmaynotapplytoyou.Noagent,representative,dealer,oremployeeof
thecompanyhastheauthoritytoincreaseoraltertheobligationsortermsofthisWarranty.This
Warrantygivesyouspeciclegalrightsandyoumayalsohaveotherrightswhichvaryfromstate
to state. This Warranty is only valid for merchandise purchased from outlets in the United States
andCanada.Thiswarrantyexpiresuponproductend-of-servicelifesignal.
©2010 UNIVERSAL SECURITY INSTRUMENTS, INC., Rev. 7/2015
Printed in China
11407 Cronhill Drive, Suite A
Owings Mills, Maryland 21117 USA
VisitUsontheWebwww.UniversalSecurity.com
