Uplus Lighting AZ-SPOT PR 300 User manual

(Auto zoom 15-50°)
User manual
300 AZ-SPOT PR
Please read the instructions carefully before use

2
TABLE OF CONTENTS
1. Safety Instructions……………………………………………………………………………3
2.Technical Specifications………………………………………………………………………4
3.Descriptions………………………………………………………………………………………5
4.Unpacking…………………………………………………………………………………………5
5.Control Menu ……………………………………………………………………………………6-7
6.DMX Channels ……………………………………………………………………………………8
7.Dimension …………………………………………………………………………………………9
8.LUX Date ……………………………………………………………………………………………9
9.Trouble Shooting…………………………………………………………………………………10
10.Fixture Cleaning………………………………………………………… ………………………10
STATEMENT
The product has well capability and intact packing when leave factory. All of the user should
comply with warning item and manual, any misuse cause of the damages are not included in our
guarantee, and also can not be responsible for any malfunction & problem owing to ignore the
manual.

3
1.Safety Instructions
Please keep this User Guide for future consultation. If you sell the unit to another user, be sure that they also
receive this instruction booklet.
•Unpack and check carefully there is no transportation damage before using the unit.
•Before operating, ensure that the voltage and frequency of power supply match the power requirements of the
unit.
•It’s important to ground the yellow/green conductor to earth in order to avoid electric shock.
•The unit is for indoor use only. Use only in a dry location.
•The unit must be installed in a location with adequate ventilation, at least 50cm from adjacent surfaces. Be sure
that no ventilation slots are blocked.
•Disconnect main power before replacement or servicing.
•Make sure there are no flammable materials close to the unit while operating as it is fire hazard.
•Use safety cable when fixes this unit. DO NOT handle the unit by taking its head only, but always by taking its
base.
•Maximum ambient temperature is Ta: 40℃. DO NOT operate it where the temperature is higher than this Unit
surface temperature may reach up to 85℃. DO NOT touch the housing bare-hand during its operation. Turn off
the power and allow about 15 minutes for the unit to cool down before replacing or serving.
•the event of serious operating problem, stop using the unit immediately.Never try to repair the unit by yourself.
Repairs carried out by unskilled people can lead to damage or malfunction. Please contact the nearest
authorized technical assistance center. Always use the same type spare parts.
•DO NOT touch any wire during operation as high voltage might be causing electric shock.
Warning:
•To prevent or reduce the risk of electrical shock or fire, do not expose the unit to rain or moisture.
•The housing, the lenses, or the ultraviolet filter must be replaced if they are visibly damaged.
Caution:
•There are no user serviceable parts inside the unit. DO NOT open the housing or attempt any repairs yourself.
In the unlikely event your unit may require service, please contact your nearest dealer.
Installation:
•The unit should be mounted via its screw holes on the bracket. Always ensure that the unit is firmly fixed to
avoid vibration and slipping while operating. And make sure that the structure to which you are attaching the unit
is secure and is able to support a weight of 10 times of the unit’s weight. Also always use a safety cable that can
hold 12 times of the weight of the unit when installing the fixture.
•The equipment must be fixed by professionals. And it must be fixed at a place where is out of the touch of
people.

4
2.Technical Specifications
Light Source:
LED POWER: 300W
Cool White 5600K or Warm White 3200K (200W) COB LED
Led Lamp: Imported LED
Color Rendering Index(CRI): Ra≥90
LED Life Time: over 50,000 hours
Power supply:
Voltage: AC100-240V
Max.power: 300W
Optics:
Zooming Scale: 15-50°
DMX auto zoom optional
Soft and even field of light
Features:
House Material: Aluminum Alloy
House Color: Black
Strobe :1-25times/sec
Control:
Control Protocol: DMX
Control System: DMX, Auto run and Master/Slave
DMX auto zoom: 2/5 CH
Working Environment :
Environment Temperature: -30°C~40°C
Cooling system : No noise fan of Pccooler
IP Grade: IP20
Package :
Dimensions: 397(D)*211(W)*378(H)mm
Net weight: 8.5kgs
Gross weight: 11kgs
Packing Size: 58x32.5x32cm (1pc/carton)

5
3.Descriptions
·· Works perfectly on conventional dimmers or constant power with DMX
·Motorized zoom angle between 15° to 50°, manually
·Ultra smooth 16-bit dimming of master dimmer
·Soft and even field of light
·Simple and complex DMX channel profiles for programming versatility
·Warm white and cool white Fresnel-style lighting fixture
·Virtually silent operation for use in studio and theatre applications
4.Unpacking
Thank you for choosing our 300 AZ-SPOT PR. For your own safety, please read this manual before installing the
device. This manual covers the important information on installation and applications. Please install and operate
the fixture with following instructions. Meanwhile, please keep this manual well for future needs.
The 300 AZ-SPOT PR is made of a new type of high temperature strength of cast aluminum casing with nice
outlook. The fixture is designed and manufactured strictly following CE&RoHS standards, complying with
international standard DMX512 protocol. It's available independently controlled and linkable with each other for
operation. And it is applicable for large-scale live performances, theater, studio, nightclubs and discos.
The 300 AZ-SPOT PR adopts 1PCS 300W COB LED (available for CW Or WW) which features high brightness
and stability. Please carefully unpack it when you receive the fixture and check whether it is damaged during the
transportation. And please check whether the following items are included inside the box:

6
5.Control Menu
Menu Data
Menu
State
Main Menu
Vice Menu
Operative Mode
DMX address
DMX channel Mode
Speed of Dimmer
No DMX signal
Screen Savers
Screen Rotation
Language switching
Speed of Dimmer
Manual mode
System information
Reset
Restore the default settings
Key Operation
Vice Menu
State
Operative Mode
DMX
Master/Slave Mode：Receive DMX signal from control console or host
DMX address
1~512
Press “ENTER” to edit state. Adjust ID address by the Key of Up/Down.
Press “ENTER” to ensure again
DMX channel
mode
5CH
5 DMX Default channel
2CH
No DMX signal
maintain
Running by Original state
Clear
Stop running
Screen Savers
Turn off
Backlight always on
blank screen
Backlight turn off after idle 10 seconds
DMX address
ID address displayed after idle 10 seconds
Screen
Rotation
Press“ENTER”twice, 180°flip screen display
Language
switching
Press”ENTER” twice, switch between Chinese and English
Speed of
Dimmer
Turn off
Close without delay, fast on/off
Dimmer 1
4 linear dimmer pattern：1~4 (the fastest and slowest )
Dimmer 2
Dimmer 3
Dimmer 4

7
Manual mode
Press “ENTER” to Manual mode, Not receive control signals
System
information
Press “ENTER” to ensure，View the version number and the elapsed time
Reset
Ensure/Cancel
Press “ENTER”to confirmation dialog box, then press”ENTER” again to
reset motor. Press "Cancel" to exit the dialog box.
Restore the
default settings
Ensure/Cancel
Press “ENTER”to confirmation dialog box, then press”ENTER” again to
restore the default settings.Press "Cancel" to exit the dialog box.
Language switching
Option
State
English/ Chinese
Pressed twice in a row "ENTER" button, switch in English/Chinese
Screen Rotation
Option
State
180°flip screen display
Pressed twice in a row "ENTER" button, 180°flip screen display
System information
Option
State
Software Version NO.（Ver)
Displays the current version number of the software
Using of time
Displays the total using time information
Total using time
Displays the time using of this
Manual mode
Option
State
Dimmer
0~255
Press”ENTER”to edit. Change value by press UP/DOWN, press “ENTER”
to ensure .
Speed of dimmer
Strobe
zoom
Speed of zoom
Special Instructions
At the main menu, press “ENTER” to get in to Reset Calibration Interface, to micro debugging Gobo location. (Hide
feature)
State
Operation
Focus Calibration
Press”ENTER”to edit, Calibration values can be set by the Key of UP/DOWN. Press
“ENTER” to ensure .
.

8
6.DMX Channels
Model – CH5
Channel
Data
Function
Mark
1
0~255
dimmer
0-255 linear dimmer
2
speed of dimmer
0~9
speed of dimmer 2
Default
10~29
Turn off speed of dimmer
speed of dimmer 4 (the slowest and
softest)
30~69
speed of dimmer 1
70~129
speed of dimmer 2
130~189
speed of dimmer 3
190~255
speed of dimmer 4
3
0~10
no strobe
11~255
the speed of strobe (255 is the fastest)
4
0-255
focus
5
0-255
Speed of focus (0 is the fastest)
Model – CH2
channel
data
Function
Mark
1
0~255
Dimmer
0-255 linear dimmer
2
0~255
focus

9
7.Dimension
Size of the fixture: 379(D)*211(W)*378(H)mm
8.LUX Date

10
9.Trouble Shooting
F ollo w ing a r e a few c o mm on p r oble m s th a t m a y occu r d uring ope r a tion . He r e a r e s o m e s ug g es tion s fo r
ea s y tr ou b leshooting :
A. The un it does no t work , no li ght a n d t he f a n d o es no t w o r k
1. Check th e c on nect ion of p owe r a nd m a in fu s e .
2. M eas ure th e m a ins volt a ge on th e m a i n co nn e ct o r .
3. Check th e pow er on LED .
B. N o t responding t o D MX c on t ro ll er
1. D M X LED s h ou ld b e on. If no t, che ck D M X co n nectors, ca b l es to s ee if link p r ope r ly .
2. If th e D M X LE D i s on a nd no r espons e t o th e c h a nn el, che ck th e a dd r ess s etti ng s a nd D M X
p ol a r ity .
3. If y ou h a ve i nter m ittent D M X s ig n a l p r oble m s , che ck th e p ins on c onn ecto r s or on
PCB of th e u nit or the p r ev iou s on e.
4. Tr y to us e a no th er D M X co ntroller .
5. Check if th e D M X ca b le s r un ne a r or run a lon g s id e t o h ig h volta ge c a b les th a t m a y c a us e d a m a ge or
in terfer ence to D M X inter face circui t.
C . One of the cha nn el s is no t w o r k ing w el l
1. Th e s tep p er moto r m ig h t b e dam a g ed or the c a b le c on nect ed to th e PCB is b r oken.
2. Th e m oto r ’ s d r ive IC on th e PCB m ig h t b e o ut of co ndition
10.Fixture Cleaning
The cleaning of internal and external optical lenses and/or mirrors must be carried out periodically to
optimize light output. Cleaning frequency depends on the environment in which the fixture operates:
damp, smoky or particularly dirty surrounding can cause greater accumulation of dirt on the unit’s optics.
Clean with soft cloth using normal glass cleaning fluid.
Always dry the parts carefully.
Clean the external optics at least every 20 days. Clean the internal optics at least every 30/60 days.
