Uplus Lighting 12X40ZWASH User manual

User manual
12X40Z WASH
Please read the instructions carefully before use

2
TABLE OF CONTENTS
1. Safety Instructions……………………………………………………………………………3-4
Technical Specifications…………………………………………………………………………4
Control Menu ……………………………………………………………………………………5-6
DMX Channels ……………………………………………………………………………………6-13
Dimension …………………………………………………………………………………………13
Trouble Shooting…………………………………………………………………………………14
Fixture Cleaning………………………………………………………… ………………………14
STATEMENT
The product has well capability and intact packing when leave factory. All of the user should
comply with warning item and manual, any misuse cause of the damages are not included in our
guarantee, and also can not be responsible for any malfunction & problem owing to ignore the
manual.

3
1.Safety Instructions
Please keep this User Guide for future consultation. If you sell the unit to another user, be sure that
they also receive this instruction booklet.
•Unpack and check carefully there is no transportation damage before using the unit.
•Before operating, ensure that the voltage and frequency of power supply match the power
requirements of the unit.
•It’s important to ground the yellow/green conductor to earth in order to avoid electric shock.
•The unit is for indoor use only. Use only in a dry location.
•The unit must be installed in a location with adequate ventilation, at least 50cm from adjacent
surfaces. Be sure that no ventilation slots are blocked.
•Disconnect main power before replacement or servicing.
•Make sure there are no flammable materials close to the unit while operating as it is fire hazard.
•Use safety cable when fixes this unit. DO NOT handle the unit by taking its head only, but always
by taking its base.
•Maximum ambient temperature is Ta: 40℃. DO NOT operate it where the temperature is higher
than this Unit surface temperature may reach up to 85℃. DO NOT touch the housing bare-hand
during its operation. Turn off the power and allow about 15 minutes for the unit to cool down before
replacing or serving.
•the event of serious operating problem, stop using the unit immediately.Never try to repair the unit
by yourself. Repairs carried out by unskilled people can lead to damage or malfunction. Please
contact the nearest authorized technical assistance center. Always use the same type spare parts.
•DO NOT touch any wire during operation as high voltage might be causing electric shock.
Warning:
•To prevent or reduce the risk of electrical shock or fire, do not expose the unit to rain or moisture.
•The housing, the lenses, or the ultraviolet filter must be replaced if they are visibly damaged.
Caution:
•There are no user serviceable parts inside the unit. DO NOT open the housing or attempt any
repairs yourself. In the unlikely event your unit may require service, please contact your nearest
dealer.
Installation:

4
•The unit should be mounted via its screw holes on the bracket. Always ensure that the unit is firmly
fixed to avoid vibration and slipping while operating. And make sure that the structure to which you
are attaching the unit is secure and is able to support a weight of 10 times of the unit’s weight. Also
always use a safety cable that can hold 12 times of the weight of the unit when installing the fixture.
•The equipment must be fixed by professionals. And it must be fixed at a place where is out of the
touch of people.
2.Technical Specifications
Power supply: 110-240V, 50/60HZ
Power consumption: 600W
Light source:12x40W 4inl RGBW LED
DMX Channel:24/28 CH
CCT : 2500-8000k ( adjustable )
Zoom angle: 2.8°- 55 °
Horizontal scanning: 540° (16bit precision scanning) Electronic error correction
Vertical scanning: 270° (16bit precision scanning) Electronic error correction
Construction
Data In/Out : 3-pin XLP socket
Power in/Out : Power Con in / out
Protection Rating: IP20
Strobe: 1-25 times/S or random strobe
Dimming: 0-100% linear adjustment
Dimensions : 470x400x270 mm
Weight: 14.3kgs

5
3.Control Menu
Menu Operation
On the base of the control panel offers a number of features, such as setting DMX fixture address,
switch the lamp, run the test program, the mode selection.
Main Menu
Second
Third
Fourth
Dmx Address
000 - 512
Run Mode
Dmx512
0-255
Slow
Fast
Sound
Manual
Invert
Pan
Yes/No
Tilt
Yes/No
Display Set
Invert word
Yes/No
English/Chinese
LCD Backlight on
Yes
No
Manual Set
Pan
000 - 255
Panmico
000 - 255
Pan fining adjust
Tilt
000 - 255
TiltMICO
000 - 255
Tilt fining adjust
ZOOM
000 - 255
DIM
000 - 255
STROBE
000 - 255
DIM_R
000 - 255
DIM_G
000 - 255
DIM_B
000 - 255
DIM_W
000 - 255
Sound Sence
0-100
Sound Sensitivity adjust

6
System Set
Version information
Vxxx
Pan reset
Normal/wrong
Tilt Reset
Normal/wrong
Default settings
Code settings
Password:↓↓↑↑
Pan_INIT
Pan fine adjust
TILT_INIT
Tilt fine adjust
ZOOM_INIT
Zoom adjust
SET_R
RED color set
SET_G
Green color set
SET_B
Blue color set
SET_W
White color set
Reset
Reset
4.DMX Channels
24 CH Mode
24CH
Function
DMX Value
Detail
CH 1
Pan
0-255
0-540°
CH 2
Pan Fine
0-255
16 bit
CH 3
Tilt
0-255
0-270°
CH 4
Tilt Fine
0-255
16 bit
CH 5
P/T Speed
0-255
Fast to slow
CH 6
Focus
0-255
Near to far
CH 7
Dimmer
0-255
Linear dimmer （dark to brightness)
CH 8
Strobe
0-9
No function
10-154
Slow to fast (1HZ-25HZ)
155-204
Random
205-255
Thunder
CH 9
Led1-2 red dimmer
0-255
Region 1-2 R dimmer Dark and bright
CH10
Led1-2 green dimmer
0-255
Region 1-2 G dimmer Dark and bright
CH11
Led1-2 blue dimmer
0-255
Region 1-2 B dimmer Dark and bright
CH12
Led1-2 white dimmer
0-255
Region 1-2 W dimmer Dark and bright
CH 13
COT (color temperature)
0-9
No
10-255
10000K-2500K
CH14
Color effect
0-9
No
10-19
Color effect 1
20-29
Color effect 2
30-39
Color effect 3
40-49
Color effect 4

7
50-59
Color effect 5
60-69
Color effect 6
70-79
Color effect 7
80-89
Color effect 8
90-99
Color effect 9
100-109
Color effect 10
110-119
Color effect 11
120-129
Color effect 12
130-139
Color effect 13
140- 149
Color effect 14
150-159
Color effect 15
160-169
Color effect 16
170-179
Color effect 17
180-189
Color effect 18
190-199
Color effect 19
200-209
Color effect 20
210-224
Jumping
225-239
Pulse
240-255
Gradual change
CH15
Static Pattern effect
0-9
No
10-19
Static Pattern effect 1
20-29
Static Pattern effect 2
30-39
Static Pattern effect 3
40-49
Static Pattern effect 4
50-59
Static Pattern effect 5
60-69
Static Pattern effect 6
70-79
Static Pattern effect 7
80-89
Static Pattern effect 8
90-99
Static Pattern effect 9
100-109
Static Pattern effect 10
110-119
Static Pattern effect 11
120-129
Static Pattern effect 12
130-139
Static Pattern effect 13
140-149
Static Pattern effect 14
150-159
Static Pattern effect 15
160-169
Static Pattern effect 16
170-179
Static Pattern effect 17
180-189
Static Pattern effect 18
190-199
Static Pattern effect 19
200-209
Static Pattern effect 20
210-255
Static pattern effect
CH16
dynamic Pattern effect
0-9
No
10-19
dynamic Pattern effect 1
20-29
dynamic Pattern effect 2
30-39
dynamic Pattern effect 3
40-49
dynamic Pattern effect 4

8
50-59
dynamic Pattern effect 5
60-69
dynamic Pattern effect 6
70-79
dynamic Pattern effect 7
80-89
dynamic Pattern effect 8
90-99
dynamic Pattern effect 9
100-109
dynamic Pattern effect 10
110-119
dynamic Pattern effect 11
120-129
dynamic Pattern effect 12
130-139
dynamic Pattern effect 13
140-149
dynamic Pattern effect 14
150-159
dynamic Pattern effect 15
160-169
dynamic Pattern effect 16
170-179
dynamic Pattern effect 17
180-189
dynamic Pattern effect 18
190-199
dynamic Pattern effect 19
200-255
dynamic Pattern effect 20
CH17
Back red
0-255
Control CH16
CH18
Back green
0-255
Control CH16
CH19
Back blue
0-255
Control CH16
CH20
Back white
0-255
Control CH16
CH21
Effect direction adjustment
0-127
Dynamic pattern positive direction
128-255
Dynamic pattern reverse direction
CH22
Effect Speed
0-255
Fast to slow
CH23
Macro
0-9
No
10-99
Auto run 1
100-199
Auto run 2
200-255
Sound control
CH24
Reset
0-239
No
240-250
Reset (3s)
251-255
No
28 CH Mode
28CH
Function
DMX Value
Detail
CH 1
Pan
0-255
0-540°
CH 2
Pan Fine
0-255
16 bit
CH 3
Tilt
0-255
0-270°
CH 4
Tilt Fine
0-255
16 bit
CH 5
P/T Speed
0-255
Fast to slow
CH 6
Focus
0-255
Near to far
CH 7
Dimmer
0-255
Linear dimmer （dark to brightness)
CH 8
Strobe
0-9
No function
10-154
Slow to fast (1HZ-25HZ)
155-204
Random
205-255
Thunder
CH 9
Led 1 red dimmer
0-255
Region 1 R dimmer Dark and bright
CH10
Led 1 green dimmer
0-255
Region 1 G dimmer Dark and bright

9
CH11
Led 1 blue dimmer
0-255
Region 1 B dimmer Dark and bright
CH12
Led 1 white dimmer
0-255
Region 1 W dimmer Dark and bright
CH13
Led 2 red dimmer
0-255
Region 2 R dimmer Dark and bright
CH14
Led 2 green dimmer
0-255
Region 2 G dimmer Dark and bright
CH15
Led 2 blue dimmer
0-255
Region 2 B dimmer Dark and bright
CH16
Led 2 white dimmer
0-255
Region 2 W dimmer Dark and bright
CH 17
COT (color temperature)
0-9
No
10-255
10000K-2500K
CH18
Color effect
0-9
No
10-19
Color effect 1
20-29
Color effect 2
30-39
Color effect 3
40-49
Color effect 4
50-59
Color effect 5
60-69
Color effect 6
70-79
Color effect 7
80-89
Color effect 8
90-99
Color effect 9
100-109
Color effect 10
110-119
Color effect 11
120-129
Color effect 12
130-139
Color effect 13
141- 149
Color effect 14
150-159
Color effect 15
160-169
Color effect 16
170-179
Color effect 17
180-189
Color effect 18
190-199
Color effect 19
200-209
Color effect 20
210-224
Jumping
225-239
Pulse
240-255
Gradual change
CH19
Static Pattern effect
0-9
No
10-19
Static Pattern effect 1
20-29
Static Pattern effect 2
30-39
Static Pattern effect 3
40-49
Static Pattern effect 4
50-59
Static Pattern effect 5
60-69
Static Pattern effect 6
70-79
Static Pattern effect 7
80-89
Static Pattern effect 8
90-99
Static Pattern effect 9
100-109
Static Pattern effect 10
110-119
Static Pattern effect 11
120-129
Static Pattern effect 12
130-139
Static Pattern effect 13

10
140-149
Static Pattern effect 14
150-159
Static Pattern effect 15
160-169
Static Pattern effect 16
170-179
Static Pattern effect 17
180-189
Static Pattern effect 18
190-199
Static Pattern effect 19
200-209
Static Pattern effect 20
210-255
Static pattern effect
CH20
dynamic Pattern effect
0-9
No
10-19
dynamic Pattern effect 1
20-29
dynamic Pattern effect 2
30-39
dynamic Pattern effect 3
40-49
dynamic Pattern effect 4
50-59
dynamic Pattern effect 5
60-69
dynamic Pattern effect 6
70-79
dynamic Pattern effect 7
80-89
dynamic Pattern effect 8
90-99
dynamic Pattern effect 9
100-109
dynamic Pattern effect 10
110-119
dynamic Pattern effect 11
120-129
dynamic Pattern effect 12
130-139
dynamic Pattern effect 13
140-149
dynamic Pattern effect 14
150-159
dynamic Pattern effect 15
160-169
dynamic Pattern effect 16
170-179
dynamic Pattern effect 17
180-189
dynamic Pattern effect 18
190-199
dynamic Pattern effect 19
200-255
dynamic Pattern effect 20
CH21
Back red
0-255
Control CH16
CH22
Back green
0-255
Control CH16
CH23
Back blue
0-255
Control CH16
CH24
Back white
0-255
Control CH16
CH25
Effect direction adjustment
0-127
Dynamic pattern positive direction
128-255
Dynamic pattern reverse direction
CH26
Effect Speed
0-255
Fast to slow
CH27
Macro
0-9
No
10-99
Auto run 1
100-199
Auto run 2
200-255
Sound control
CH28
Reset
0-239
No
240-250
Reset (3s)
251-255
No

11
5.Dimension
6.Trouble Shooting
F ollo w ing a r e a few c o mm on p r oble m s th a t m a y occu r d uring ope r a tion . He r e a r e s o m e s ug g es tion s fo r
ea s y tr ou b leshooting :
A. The un it does no t work , no li ght a n d t he f a n d o es no t w o r k
1. Check th e c on nect ion of p owe r a nd m a in fu s e .
2. M eas ure th e m a ins volt a ge on th e m a i n co nn e ct o r .
3. Check th e pow er on LED .
B. N o t responding t o D MX c on t ro ll er
1. D M X LED s h ou ld b e on. If no t, che ck D M X co n nectors, ca b l es to s ee if link p r ope r ly .
2. If th e D M X LE D i s on a nd no r espons e t o th e c h a nn el, che ck th e a dd r ess s etti ng s a nd D M X p ol a r ity .
3. If y ou h a ve i nter m ittent D M X s ig n a l p r oble m s , che ck th e p ins on c onn ecto r s or on
PCB of th e u nit or the p r ev iou s on e.
4. Tr y to us e a no th er D M X co ntroller .
5. Check if th e D M X ca b le s r un ne a r or run a lon g s id e t o h ig h volta ge c a b les th a t m a y c a us e d a m a ge or

12
in terfer ence to D M X inter face circui t.
C . One of the cha nn el s is no t w o r k ing w el l
1. Th e s tep p er moto r m ig h t b e dam a g ed or the c a b le c on nect ed to th e PCB is b r oken.
2. Th e m oto r ’ s d r ive IC on th e PCB m ig h t b e o ut of co ndition
7.Fixture Cleaning
The cleaning of internal and external optical lenses and/or mirrors must be carried out periodically to
optimize light output. Cleaning frequency depends on the environment in which the fixture operates: damp,
smoky or particularly dirty surrounding can cause greater accumulation of dirt on the unit’s optics.
Clean with soft cloth using normal glass cleaning fluid.
Always dry the parts carefully.
Clean the external optics at least every 20 days. Clean the internal optics at least every 30/60 days.
