Uplus Lighting MINI740 User manual

User manual
MINI 740
Please read the instructions carefully before use

2
TABLE OF CONTENTS
1. Safety Instructions………………………………………………………………………………3-4
Technical Specifications……………………………………………………………………………4
Control Menu …………………………………………………………………………………………5
DMX Channels ……………………………………………………………………………………6-7
Dimension ……………………………………………………………………………………………8
Trouble Shooting……………………………………………………………………………………9
Fixture Cleaning………………………………………………………… …………………………9
STATEMENT
The product has well capability and intact packing when leave factory. All of the user should
comply with warning item and manual, any misuse cause of the damages are not included in our
guarantee, and also can not be responsible for any malfunction & problem owing to ignore the
manual.

3
1.Safety Instructions
Please keep this User Guide for future consultation. If you sell the unit to another user, be sure that
they also receive this instruction booklet.
•Unpack and check carefully there is no transportation damage before using the unit.
•Before operating, ensure that the voltage and frequency of power supply match the power
requirements of the unit.
•It’s important to ground the yellow/green conductor to earth in order to avoid electric shock.
•The unit is for indoor use only. Use only in a dry location.
•The unit must be installed in a location with adequate ventilation, at least 50cm from adjacent
surfaces. Be sure that no ventilation slots are blocked.
•Disconnect main power before replacement or servicing.
•Make sure there are no flammable materials close to the unit while operating as it is fire hazard.
•Use safety cable when fixes this unit. DO NOT handle the unit by taking its head only, but always
by taking its base.
•Maximum ambient temperature is Ta: 40℃. DO NOT operate it where the temperature is higher
than this Unit surface temperature may reach up to 85℃. DO NOT touch the housing bare-hand
during its operation. Turn off the power and allow about 15 minutes for the unit to cool down before
replacing or serving.
•the event of serious operating problem, stop using the unit immediately.Never try to repair the unit
by yourself. Repairs carried out by unskilled people can lead to damage or malfunction. Please
contact the nearest authorized technical assistance center. Always use the same type spare parts.
•DO NOT touch any wire during operation as high voltage might be causing electric shock.
Warning:
•To prevent or reduce the risk of electrical shock or fire, do not expose the unit to rain or moisture.
•The housing, the lenses, or the ultraviolet filter must be replaced if they are visibly damaged.
Caution:
•There are no user serviceable parts inside the unit. DO NOT open the housing or attempt any
repairs yourself. In the unlikely event your unit may require service, please contact your nearest
dealer.
Installation:

4
•The unit should be mounted via its screw holes on the bracket. Always ensure that the unit is firmly
fixed to avoid vibration and slipping while operating. And make sure that the structure to which you
are attaching the unit is secure and is able to support a weight of 10 times of the unit’s weight. Also
always use a safety cable that can hold 12 times of the weight of the unit when installing the fixture.
•The equipment must be fixed by professionals. And it must be fixed at a place where is out of the
touch of people.
2.Technical Specifications
Voltage: AC100V～240V 50-60HZ
Rated Power: 350W
LED Source: 7*40W RGBW 4-in-1 LED
Zoom angle: 4.5°-45°
Wash+beam+bee eye 3in1 efect
Strobe: 0-25Hz
Control: DMX512/Auto Run/Master-Slave/Music
DMX Channels: 12/18channel
Dimmer: 0-100% linear dimmer
Pan: 540°+16 bit fine
Tilt: 270°+16 bit fine
Display: LCD colorful display
IP: IP20
Dimension:340*273*170mm ; NW:5.75 kgs

5
3.Control Menu
Menu Operation
Main Menu
2nd Menu
3rd Menu
4th Menu
DMX Address
000 - 512
Fixture
Dmx Mode
STD / HSI
Run Mode
DMX / Host / Sound
Pan Invert
Close / Open
Tilt Invert
Close / Open
Sound Control
1 -- 30
Manual
Pan
000 - 255
Pan Fine
000 - 255
Tilt
000 - 255
Tilt Fine
000 - 255
⁞
⁞
Information
Time
Current Time
xxxH
Total Time
xxxH
Sensor
Pan
FALSE / TURE
Tilt
FALSE / TURE
Zoom
FALSE / TURE
Temp
FALSE / TURE
Fan
FALSE / TURE
Temperature
Head Temp
xxxC
Software Version
Panel
Vx.xx
Vx.xx
Vx.xx
Factory
Password
000 - 255
Pan
000 - 255
Tilt
000 - 255
Zoom
000 - 255
Zoom Rotation
000 - 255
Red
000 - 255
Green
000 - 255
Blue
000 - 255
White
000 - 255
Fixture Reset
Motor Reset
Cance / Run
Factory
Cance / Run
Display
Language
CH / EN
Display Flip
Normal / Reverse
Display Mode
60s / Show

6
4.DMX Channels
12 CH Mode
Channel
Features
value
Function
CH1
Pan
0--255
Pan movement control
CH2
Pan Fine
0--255
Pan fine control
CH3
Tilt
0--255
Tilt movement control
CH4
Tilt Fine
0--255
Tilt fine control
CH5
Pan/Tilt speed
0--255
Speed from fast to slow
CH6
Dimmer
0--255
0-100 linear dimmer from dark to bright
CH7
Strobe
0--3
Close
4--103
Regular Strobe, Slow To Fast
104--107
Open
108--207
Pulse, Slow To Fast
208--212
Open
213--225
Random Slow Strobe
226--238
Random Middle Speed Strobe
239--251
Random Fast Strobe
252--255
Open
CH8
Chroma
0--255
Chroma
CH9
Saturation
0--255
Saturation
CH10
CTO
0
NON
1--27
8500K
28--55
7500K
56--83
6800K
84--111
6200K
112--139
5600K
140--167
5000K
168--195
4500K
196--223
3600K
224--251
3200K
252--255
2800K
CH11
Zoom
0--255
zoom
CH12
Zoom Rotation
0--127
manual rotation
128--190
Rotate clockwise, the speed changes from fast to slow
191--192
stop
193--255
Rotate counterclockwise, the speed changes from slow to fast
18 CH Mode
Channel
Features
value
Function
CH1
Pan
0--255
Pan movement control
CH2
Pan Fine
0--255
Pan fine control
CH3
Tilt
0--255
Tilt movement control
CH4
Tilt Fine
0--255
Tilt fine control
CH5
Pan/Tilt speed
0--255
Speed from fast to slow
CH6
Dimmer
0--255
0-100 linear dimmer from dark to bright

7
CH7
Strobe
0--3
Close
4--103
Regular Strobe, Slow To Fast
104--107
Open
108--207
Pulse, Slow To Fast
208--212
Open
213--225
Random Slow Strobe
226--238
Random Middle Speed Strobe
239--251
Random Fast Strobe
252--255
Open
CH8
R
0--255
1-100% Red linear dimmer from dark to bright
CH9
G
0--255
1-100% Green linear dimmer from dark to bright
CH10
B
0--255
1-100% Blue linear dimmer from dark to bright
CH11
W
0--255
1-100% White linear dimmer from dark to bright
CH12
CTO
0
NON
1--27
8500K
28--55
7500K
56--83
6800K
84--111
6200K
112--139
5600K
140--167
5000K
168--195
4500K
196--223
3600K
224--251
3200K
252--255
2800K
CH13
Macro
0-255
Color macro
CH14
Zoom
0--255
zoom
CH15
Zoom Rotation
0--127
manual rotation
128--190
Rotate clockwise, the speed changes from fast to slow
191--192
stop
193--255
Rotate counterclockwise, the speed changes from slow to fast
CH16
Effect
0
No function
1--25
Effect 1
26--51
Effect 2
52--77
Effect 3
78--103
Effect 4
104--129
Effect 5
130--155
Effect 6
156--181
Effect 7
182--207
Effect 8
208--233
Effect 9
234--255
Effect 10
CH17
Effect speed
0--255
Effect speed
CH18
Reset
0--239
No function
240--244
Motors Reset (Value Stops 5 Seconds)
245--249
Sound Control (Active From Low to Hight)
250--255
Bulit-In Programming Auto Run

8
5.Dimension

9
6.Trouble Shooting
F ollo w ing a r e a few c o mm on p r oble m s th a t m a y occu r d uring ope r a tion . He r e a r e s o m e s ug g es tion s fo r
ea s y tr ou b leshooting :
A. The un it does no t work , no li ght a n d t he f a n d o es no t w o r k
1. Check th e c on nect ion of p owe r a nd m a in fu s e .
2. M eas ure th e m a ins volt a ge on th e m a i n co nn e ct o r .
3. Check th e pow er on LED .
B. N o t responding t o D MX c on t ro ll er
1. D M X LED s h ou ld b e on. If no t, che ck D M X co n nectors, ca b l es to s ee if link p r ope r ly .
2. If th e D M X LE D i s on a nd no r espons e t o th e c h a nn el, che ck th e a dd r ess s etti ng s a nd D M X p ol a r ity .
3. If y ou h a ve i nter m ittent D M X s ig n a l p r oble m s , che ck th e p ins on c onn ecto r s or on
PCB of th e u nit or the p r ev iou s on e.
4. Tr y to us e a no th er D M X co ntroller .
5. Check if th e D M X ca b le s r un ne a r or run a lon g s id e t o h ig h volta ge c a b les th a t m a y c a us e d a m a ge or
in terfer ence to D M X inter face circui t.
C . One of the cha nn el s is no t w o r k ing w el l
1. Th e s tep p er moto r m ig h t b e dam a g ed or the c a b le c on nect ed to th e PCB is b r oken.
2. Th e m oto r ’ s d r ive IC on th e PCB m ig h t b e o ut of co ndition
7.Fixture Cleaning
The cleaning of internal and external optical lenses and/or mirrors must be carried out periodically to
optimize light output. Cleaning frequency depends on the environment in which the fixture operates: damp,
smoky or particularly dirty surrounding can cause greater accumulation of dirt on the unit’s optics.
Clean with soft cloth using normal glass cleaning fluid.
Always dry the parts carefully.
Clean the external optics at least every 20 days. Clean the internal optics at least every 30/60 days.
