Urban Oasis Collapsible Water Storage Barrel User manual

Collapsible Water Storage Barrel
Parts List: Barrel, Barrel Legs, Drain Spigot, Overow cap.
1A
2A
1D
1B
2B
1E
1C
2C
Installation:
1. Connect the drain spigot to the tting at the
bottom side of the water storage barrel.
[See Fig 1A,B]
2. Install the cap on the overow tting at the top
side of the water storage barrel.
[See Fig 1C]
3. Install the cap and lter assembly on the lid of
the water storage barrel.
[See Fig 1D,E]
4. Unfold the water storage barrel and lay it on its
side. Install the support legs into the built-in
sleeves on the sides of the water storage barrel
making sure the leg caps are positioned at the
bottom of the water storage barrel.
[See Fig 2A,B,C]
5. Zipper the lid closed.
Water Storage Barrel Location:
Note: Choose a downspout that has a level and rm
surface beneath so that the water storage barrel will
be level.
6. Position the water storage barrel under the
downspout and mark the downspout at the
midway point from the top of the water storage
barrel to the bottom of the water storage barrel.
Cut o the downspout at this mark.
[See Fig 3A]
Note: It may be necessary to remove the
downspout from the wall to cut it.
7. Move the water storage barrel into position
against the wall on the level surface and insert
the downspout on the wall into the water storage
barrel. Zip the lid tightly around the downspout
inserted into the water storage barrel.
[See Fig 4A]
Note: The inserted downspout will add stability
to the empty water storage barrel until it gets
lled with water. However, it is recommended
to add a couple inches of tap water to the water
storage barrel for added weight and stability
to prevent movement by heavy wind etc. Once
water is collected in the water storage barrel, it
can be emptied through the bottom spigot or
unzip the top and use a watering can.
O Season Storage:
At the end of the season the water storage barrel should be emptied
and stored in a heated place in order to prevent freezing or damage to
your water storage barrel.
Warning:
Never allow children to play in or around the water storage barrel.
Always securely attach the lid to avoid a child drowning.
Never drink water from the water storage barrel. Use water from the
water storage barrel for watering or outdoor cleaning purposes only.
Always place the water storage barrel on a at and solid surface. Check
the downspout does not contain heating cables before cutting when
installing use safety glasses and protective gloves.
4A3A
™

IMPORTANT — PLEASE READ
1Push the tap through the tank, fitting the
rubber washers as shown; one on each side .
Fit the tap upside down tightening as tight
as you can by hand.
AA
2Insert the poles.
3Position on a smooth, flat surface.
Half fill with water. With the spigot in an
inverted position.
4
Twist the tap clockwise to the upright position.
Rotate the spigot clockwise to position with
flow in a downward direction
5Caution: Never drag or move the tank
when it is full of water. The tank should be
completely drained before it is moved.
6 month limited liability warranty against manufacture defect and workmanship.
Punctures and/or dragging product lled with water are not covered by the warranty.
