Urban A280D Manual

Drinking Fountains
Models: A280, A280D, A280C
INSTALLATION, OPERATION AND MAINTENANCE INSTRUCTIONS
SPECIFICATIONS
CUSTOMER SERVICE
Model: A280 Model: A280D Model: A280C
2year
warranty
Quality Certified
ISO 9001:2015
AU1228-QC
CARE AND MAINTENANCE
WARRANTY
www.urbanff.com.au
[email protected]
07 3382 7372
07 3287 5598
1. Regular washing down of the exterior surface will help prolong the lustre of the painted finish.
2. Painted fountains that become dull due to prolonged exposure to direct sunlight can be
restored with an appropriate surface polish.
3. To maintain the exterior of the fountain carefully remove any loose surface deposits with a wet sponge.
Use a soft (non abrasive) brush and dilute a solution of mild detergent (eg. PH-neurtral liquid hand
washing detergent in warm water (DO NOT use solvents) to remove dust, salt and other deposits.
Rinse thoroughly with clean fresh water to remove residues. To remove any Tea Staining on
Stainless Steel surfaces we recommend Drifter Hull cleaner and stain remover.
4. Do not use any solvents on the surface as this will adversely affect the longevity of the painted
finish.
5. Surface scratches and inconsistencies can be touched up using Dulux touch up paint.
Most colours can be matched.
6. We recommend the use of anti-seize paste on all external fixing bolts to maintain ease of
access over long periods of time.
7. Check the fountain internal connections, water flow and all external access screws and fixing
bolts regularly (every 3mths) to ensure they are tight.
8. In high debris areas (parks, children’s playgrounds etc) where there may be sand or bark or
a lot of leaf letter that may be placed in to the basin, check regularly and remove debris to
prevent blocking of the basin or the waste outlet pipe.
9. After any interruption to the water supply, always flush the lines prior to reconnection to the
fountain to prevent debris entering the valve.
All Urban Fountains and Furniture outdoor drinking fountains are covered by a 2 year manufacturers
guarantee against faulty materials and workmanship under normal wear and tear conditions.
All fountains are date stamped at the time of despatch.
This warranty will only apply under the following conditions:
• The fountain was installed in accordance with our installation instructions that are supplied
with every fountain.
• The fountain was installed by a licensed plumber
• The water lines have been thoroughly flushed prior to connection to the fountain
• The fountain has not been tampered with or repaired in any way without obtaining prior
approval from our factory specialists first.
• The fountain has been serviced and maintained as per our supplied instructions.
These quick release fittings allow instant
connection and disconnection
without the use of spanners. Push outer ring in to
release tube from fitting
ATTENTION PLUMBERS
This fountain uses “Push In Fittings”.
Failure to release these fittings correctly
will result in leakage.
1/2” bsb water inlet (15mm)
40mm waste outlet
Maximum Temperature: 40 c
Maximum Water Pressure: 1000 kpa
Complies with WMTS-105 Technical
Specification. Appliances - Beverage
dispensers and icemakers
Complies with AS/NZS 4020 Testing of
products in contact with drinking water
O
WM-080042
WMTS-105

INSTALLATION TROUBLESHOOTING
1. All UrbanFF Fountains must be installed by a qualified plumber in accordance with National
plumbing and drainage code AS/NZS 3500.1 and AS/NZS 3500.2 and any local authority codes.
2. Before Installation FLUSH ALL EXTERNAL LINES before connecting to fountain.
3. Provide adequate level surface for mounting fountain as specified in local area codes
(approx. 1400mm square x 125 mm deep minimum concrete slab) and install an inground fixing cage
(preferred method of installation) or alternatively (remove main acces panel) and mark the anchor
points for the fountain to be dyna-bolted or chemset in place after the concrete slab has been poured.
4. Allow for waste outlet and water inlet through the slab at dimensions shown on Diagram A
5. Remove the fountain from the packaging preventing scratching and damage.
6. All fountains have been checked for leaks as part of our quality assurance program and some
droplets of water may be evident inside the packaging and/or unit. This is perfectly normal.
7. Remove main access panel from fountain using 4mm allen key.
8. Mount the fountain in place aligning the base holes with the inground fixing cage/anchor markers
and tighten the bolts.
9. Connect the 40mm waste outlet pipe to the waste water connection.
10. If you have not flushed the external water inlet pipes – do it now! Flushing the water inlet pipes from
the mains supply before connecting to fountain will help prevent blockage by any debris that may be
in the external pipes.
11. Connect water supply to 1/2” BSP inlet.
12. Test the bubbler by activating the button.
13. Remove underside access panel and adjust the flow rate via the mini ball valve as required so flow
enters the middle of the basin (mains water pressure varies from city to city).
14. Refer to trouble shooting guide if you experience any problems.
15. Check all connections and waste piping to ensure they are tight & secure.
16. Re-install both the access panels once satisfied the fountain is installed correctly.
There is restricted or
no water flow?
The water continues
to drip / run after
shutting off?
Leaking from the
internal connections?
The water flow is
shooting over the top of
the basin or is not high
enough and trickling
over the nozzle?
Check the inlet lines for kinks in the tubing. Ensure the water
supply valve is fully open. Check the water pressure regulator is open.
The water pressure is too high / low and needs to be adjusted via the
water flow regulator so it flows in to the catchment area of the basin.
Check that they have been installed correctly. (all fountains are leak
tested prior to leaving the factory). Have the push in fittings been pulled?
(see instructions on how to connect and disconnect push in fittings).
Is the water inlet connection tight?
The most common cause of water not shutting off is a leaking valve and
is due to the lines not being flushed adequately and debris getting in to
the valve through the inlet and sitting on the rubber seals.
To check the valve it will need to be removed. Please contact this office
for details instructions to ensure this is done correctly.
1/4 x 90 Fitting
3/8 x 90 Fitting
15-JG8-ELB-1-4X90
15-JG8-ELB-3-8X90
15-JG8-YPIECE
reorder
code:
reorder
code:
reorder
code:
reorder
code:
reorder
code:
reorder
code:
reorder
code:
reorder
code:
15-JG8-STR-1-4
Blue Hose 15-HOS-BL8
Y fitting
15-LEG8M-ELB-8X1-4
1/4 x 90 LF-Fitting
15-TAP-BUB208CSelf Returning Tap
1/4 Straight
15-JG8-STR-3-8
3/8 Straight
1/2 x 90 Fitting
o
o
o
o
SPARE PARTS
reorder
code:
reorder
code:
reorder
code:
reorder
code:
reorder
code:
reorder
code:
reorder
code:
reorder
code:
Maintenance Tap
Bottle Filler
Bubbler
Push Button Valve
Water Regulator
Mini Ball Valve
Stop tap BUB268
15-TAP-VP350
15-BUB-TD90P
15-BUB-TD90P
15-VAL-ENW00415
15-REG-G14
15-VAL-15MINBAL
15-VAL-ENW00120
15-JG12-ELB-1-2X90
Diagram A
