usha SPEEDMAX SP500M23 User manual

Pored
to Perrm
[email protected]om
To explore our range of
product and recipe log
on to www.ushacook.com COOK
Instruction Manual
USHA INTERNATIONAL LTD.
Plot No. 15, Institutional Area, Sector 32, Gurugram - 122 001 (Haryana)
Tel : [phone], Fax : [phone], E-mail: [email protected] , Website: www.usha.com
Regd. Oce : Surya Kiran Building, 19 Kasturba Gandhi Marg, New Delhi 110 001, (India) Tel : [phone] Fax : [phone]
ISO 9001 : 2015 Certied Company
TM

Dear Customer,
Congratulations!
You are now the proud owner of USHA Mixer Grinder.
Innovatively designed, using only the highest quality material and components, your
USHA Mixer Grinder is designed for years of trouble free performance.
Please read this Instruction Manual carefully before using and keep it cautiously after
reading for future reference.
Best Wishes
Important Precautions
Do’s and don’ts ................................................................................ 3
Identication of Parts -1 ............................................................... 4
Identication of Parts -2 ............................................................... 5
Technical Data
How to t jars..................................................................................... 6
How to Use Your Mixer Grinder
Usage of Control Panel .................................................................. 7
How to x the Blades
How to Fix the Blades .................................................................... 8
Overload Protector .......................................................................... 8
Cleaning of Stainless Steel Jars .................................................. 8
Important Notes
Notes .................................................................................................... 9
Warranty Card................................................................ 10
CONTENTS
HIGH TORQUE
COPPER
MOTOR
FOR LONGER LIFE SERVICE
FREE
BLADE
TECHNO
4 FIN HARDENED
STAINLESS STEEL
BLADES
FOOD SAFE
1 2

DO’S
- Place your Mixer Grinder (“MG”) at a convenient
height so that you can operate it easily.
You should be able to look down
into the attachments to check the
circulation of ingredients.
- Clear out some space around
the machine. You will need it for
keeping various items required while
operating the MG.
- Keep the MG away from direct heat
or sun.
- In dry grinding, friction may heat up
the jar. It has nothing to do with the
motor, so do not worry.
- Remember MG operates at optimum
eciency at the specied voltage
only. Wide voltage uctuations
during operation may aect quality
of grinding even though the motor
may still be safe. If your area faces
such periodic uctuations and if you
cannot get a voltage stabilizer try to
operate the machine during steadier
voltage stretches.
- Hold down the jar cover lightly with
hand while mixer is in operation.
Basic Unit
Stainless Steel Jar
Speed Switch
with pulse
Jar Socket
IDENTIFICATION OF PARTS
DON’TS
Suction Feet
IMPORTANT PRECAUTIONS
- Do not run the machine unless jar is in
position. Lids too should be rmly placed.
- Do not allow children to handle MG.
- Do not burden motor with loads heavier
than those specied in the instructions.
- Do not grind Hot ingredient in the Mixer
grinder.
- Do not use Mixer on Wet Surface
- Do not use accessories or parts which are
not recommended or are made by other
manufacturer.
- Do not immerse the motor unit in water or
any other liquid. Do not rinse it either
- Do not open the lid when the mixer is
running & do not add solid ingredients
while mixer is running.
- Do not use the appliance if the Mains cord,
the plug or other components are
damaged.
- Do not run MG without any load.
- Do not run the Mixer for 5 minutes
continuously. Give a gap of 2 minutes if you
need to use it for more time. Stop for 10
minutes before starting again. When hot air
comes out of the ventilator, switch it o for
a while.
- Your MG cannot substitute for a storage
container. So avoid storing food in the jar.
- Never lay any thin plastic sheet or cloth
under the basic unit. It may get sucked up
and block ventilation holes in the base.
- Blades should not be left inside the jar.
- Do not grind sugar in your MG. It may cause
damage to the MG motor.
- Do not attempt to repair MG at home or
allow any unauthorized person to do it
either. In the event your MG needs
attention, contact Usha Care.
Caution: Always hold the jar lid gently with your hand while the mixer is in operation
This appliance is STRICTLY FOR HOUSEHOLD USE ONLY
Note: In view of USHA policy of continual development, specications may change without notice.
Images are used for representation only.
3 4

BASIC UNIT /
BLENDING JAR
MIXER / DRY
GRINDER JAR
Basic Unit
1. Basic Unit
2. Speed Switch with pulse
3. Overload Switch
4. Cord Plug
5. Spatula
1.5 L Wet Jar
6. Wet Grinding Jar Assembly
7. Jar Socket
8. Wet Jar Lid
9. Wet Jar Lid Gasket
10. Coupler
11. Wet Grinding Blade
1 L Dry Jar
12. Dry Grinding Jar Assembly
13. Dry Grinding Jar lid
14. Dry jar lid gasket
15. Dry Grinding Blade
400 mL Chutney Jar
16. Chutney Grinding Jar Assembly
17. Blade / Shaft Assembly
18. Chutney Jar lid
19. Chutney Jar gasket
20. Chutney Grinding Blade
IDENTIFICATION OF PARTS TECHNICAL DATA
HOW TO FIT JARS
RECOMMENDED USAGE CAPACITY - JARS
Jar Type Actual Recommended Jar Capacity
Capacity Dry Grinding Wet Grinding Blending
150 g of Urad Dal +
Wet Jar 1.5 L NA 350 mL water 500 mL
Multiprupose 1 L 150 g Turmeric/ 100 g of Urad Dal + 300 mL
Jar Spice Grinding 225 mL water
Chutney / 400 mL
50 g Turmeric/ 100 g of NA
Small Jar Spice Grinding Coconut/Onion
Hold the jar in one hand and check if the blade moves freely and rotates. Place
ingredients in the Steel Jar. Cover the Jar with dome / lid. Place the jar on the basic
unit, press it slightly downward and then turn it clockwise to lock it in the top body
socket. Plug in, support cover gently by hand and switch on using the slowest speed
(position 1 of switch) and then moving on to higher speeds as per requirements
(position 2, 3 of switch). Switch o after operation. For unlocking the jar, press the jar
downward, then turn it anti clockwise and lift the jar from the basic unit.
Note: The ambient working temperature range is from 10° C to 43° C
Model Name / Model No. SPEEDMAX / SP500M23
500 W
Power consumption No load 21 000 ( + - 1 000 ) rpm approx. on 3rd speed
Full Load 12 000 rpm approx. on 3rd speed
Voltage and frequency 230 V AC / 50 Hz - 60 Hz (working range)
Insulation F class overall insulation
Rating 30 Minutes rating (5 Minutes ON, 2 Minutes OFF)
Material of body ABS
Material of jars Stainless steel
Blade assembly Stainless steel
Speed control 3 speed with pulse
Power cord 3 Pin plug & 3 core exible PVC cord
Country of origin India
5 6

P
0
1
2
3
P
0
1
2
3
P
0
1
2
3
P
0
1
2
3
P
0
1
2
3
Usage of Control Panel
The control panel is a 3 speed rotary
switch with an inbuilt 4th position as inching
for whipping operation. For Whipping,
turn the rotary switch in the anti clockwise
HOW TO FIX THE BLADES
underside of the jar with one hand and hold
the plastic nut of the blade with the spanner
(provided on the handle of spatula). Tighten
by rotating plastic nut anti clockwise, till the
blade is rmly locked.
direction.
For the usage of control panel refer
following table / gures.
FUNCTION & PURPOSE
FUNCTION & PURPOSE
IMPORTANT INSTRUCTIONS
IMPORTANT INSTRUCTIONS
Dry Grinding
(To be done in medium jar)
Coriander seed, Wheat for porridge etc.
Roasted coee, Red chilli, Pepper, Bajra,
Whipping / Churning
(To be done in large Jar)
also butter churning and mayonnaise
etc.
1. Ensure that the jar is absolutely clean
and dry.
2. While dry grinding, friction may heat
3. For ne grinding, sieve ground
substance thorough a ne nylon sieve
up the jar, ithas nothing to do with
the motor. So don’t worry.
for consistency required. Leftover
can then be put in the jar, regrind
and sieve again.
1. While whipping, use the rotary
switch by turning it in anti clock
wise direction.
2. The pulse is a momentary position
and as long as it stays in position
the motor will run.
3. For whipping & butter churning
use speed 1 only.
1. Fix the dome on jar wheneverin use.
2. If ingredients need tobe stirred
during use, stop mixer, insert
spatula and stir. You will nd that
such stirring may be necessary in
wet grinding.
3. To remove blade assembly, gently
unscrew in clockwise direction.
1. Hold the cover of jar rmly with
your hands as the jar may vibrate.
Wet Grinding / Liquidising
(To be done in large Jar)
Wet grinding for Urad dal paste for idli
and Dosa, for soaked Raw/ boiled rice,
Liquidising for fruit juices, soups cock-
tails, mild shakes with fresh fruits. etc.
Chutney Grinding
(To be done in Small Jar)
Chutney grinding, small quantity dry
grinding etc.
HOW TO USE YOUR MIXER GRINDER
Inching Position O Position 1st Speed 2nd Speed 3rd Speed
Frothy cold coee, uy omelette,
sti egg whites, fresh cream and
OVER LOAD PROTECTOR
Your mixer grinder is protected against
sudden overload. MG will automatically Trip
o and hence the overload switch lever will
come out. To restart the machine, please
wait for 2-3 minutes to allow the motor
to cool down and also remove the excess
thick paste. Press the Lever & Start Mixer
ingredients/add sucient water in case of
again.
CLEANING OF STAINLESS STEEL
JARS
To prevent the shaft from getting stuck,
once in a fortnight ll about half jar with luke
warm water and add little mild detergent
(do not use abrasive cleaning powders since
these will scratch the jar) and put on cover
and stopper. Switch on the motor and run
it at the lowest speed for about 30 seconds.
This clears out particles sticking under the
blade. To remove the blade assembly hold
the coupler on the underside of jar with one
hand & hold the plastic nut of blade with the
spanner. Loosen by rotating in clockwise
direction.
7 8

IMPORTANT NOTES WARRANTY CARD
1. Please note that initial empty running of
jars will throw out some oil
impregnated in bushes. Therefore, it is
advised to thoroughly clean it before
actual use.
2. Blending/ liquidizing operation should
higher speed is used then chances are
3. Turmeric grinding should be done in
medium & small jar only. For this break
turmeric into small pieces before
grinding.
NOTES
This appliance is warranted for 2 years on
product and 5 years on motor against all
manufacturing defects from the date of
sale. In the event of any complaint,
please contact Usha Care at Toll Free No.
1800 1033 111.
The warranty is valid only when:
1. The appliance has been installed,
used and maintained in accordance
with the instruction manual.
2. The warranty card and cash memo
duly signed by the authorized dealer
are presented with the complaint.
3. The appliance has not been
opened or tampered with, by any
unauthorized person.
This warranty does not apply for:
Liability for consequential loss or damage is neither accepted nor implied.
S. NO: DATE:
CASH MEMO:
DEALER’S NAME AND ADDRESS:
OWNER’S NAME & ADDRESS:
4. Before starting the machine for the
(i) Rotate the motor shaftby hand
through the coupler so that it works
smoothly.
(ii) After connecting, run machine at
speed 1 for few seconds to ensure
that the motor works properly.
on the basic unit, rotate jar shaft by
handto make sure that it turns freely.
1. Damages due to chipping, peeling,
plating and denting.
2. Breakage or damage to components
made out of Bakelite, Urea, ABS, SAN
and such plastic materials, rubber
parts and cord.
3. Normal wear and tear of parts.
4. Damage resulting from accidents,
mishandling or negligence on part
of the customer.
9 10
