Usl JSD-100MA User manual

JSD-100MA Manual
Cinema Processor
USL, Inc.
181 Bonetti Drive
San Luis Obispo, CA 93401-7397
USA
Phone: [phone] Fax: [phone] www.uslinc.com

Version 160624 Page 2
TABLE OF CONTENTS
1. SAFETY NOTICE 5
2. REGULATORY COMPLIANCE 5
2.1 Declaration of Conformity 5
2.2 Equipment Class 6
2.3 Disposal and Recycling 6
3. SYSTEM VERSION 7
4. SYSTEM OVERVIEW 7
4.1 System Description 7
4.2 Block Diagrams 8
4.3 Channel Descriptions 11
4.4 Sound Field Configurations 12
4.5 Processing Channels 12
5. SPECIFICATIONS 13
5.1 Features 13
5.2 Audio Inputs 13
5.3 Sixteen Channel Analog Audio Outputs (JSD-100MA) 13
5.4 Communication Ports 13
5.5 Front Panel Interface 13
5.6 Format Selection 13
5.7 Rear Panel Connectors-Main Chassis 13
5.8 Rear Panel Interface Module 14
5.9 Processing 14
5.10 Sleep Mode 14
5.11 Bypass Mode 14
5.12 Graphical User Interface 14

Version 160624 Page 3
6. INSTALLATIONS 15
6.1 Initial Power-up 15
6.2 System Hardware Mounting, Grounding, and Ventilation 15
6.3 Sixteen Channel Analog Output Rear Panel Connections (JSD-100MA) 15
6.4 Audio Input Connections 16
6.4.1 16 Channel AES Input 16
6.4.2 8 Channel Analog Input 16
6.5 Analog Audio Output Connections 17
6.5.1 Main Audio Outputs 17
6.5.2 HI/VI-N Outputs 17
6.6 Automation Interface 17
6.6.1 Parallel Interface 17
6.6.2 RS-232 Interface 17
6.6.3 Ethernet Interface 18
6.6.4 RS-485 18
7. GRAPHICAL USER INTERFACE CONFIGURATION 18
7.1 System Configuration Using the Graphical User Interface 18
7.2 GUI File Organization 18
7.3 Windows JSD-100MA Installation 19
7.3.1 Windows Installer 19
7.3.2 USB Driver Installation 19
7.4 Set IP Utility 21
7.5 JSD-100MA Configuration 21
7.5.1 File Management 22
7.5.2 Communications 22
7.5.3 Main Fader 23
7.5.4 Front Panel View 23
7.5.5 Tabs 24
7.6 Channel Crossover and Equalization Procedure 34
7.6.1 Crossover Adjustment 34
7.6.2 Auditorium Equalization 35
8. SYSTEM OPERATION 37
8.1 Front Panel 37
8.2 Automation 38
8.3 System Monitoring 38
8.3.1 GUI View of Multiple JSD-100MAs 38
8.3.2 JSD-100MA Web Interface 39

Version 160624 Page 4
9. JSDV-100 REMOTE VOLUME CONTROL 40
10. PRODUCT SUPPORT 41
APPENDIX A –CONNECTOR PIN OUTS 41
APPENDIX B –AUTOMATION COMMANDS 45
APPENDIX C –SYSTEM RESTORE AND POWER-UP BUTTONS 46
APPENDIX D –INI FILE FORMATS 47

Version 160624 Page 5
1. Safety Notice
Review the following safety precautions to avoid injury and prevent damage to this product. To avoid
potential risk, use this product only as specified and only for the purpose described in the instruction manual.
To Avoid Fire and Personal Injury:
Use correct power cable. Use only the power cable provided. Ensure that the AC power outlet is
located near the product and is easily accessible.
Use a correctly grounded power source. The power supply earth ground is established through the
ground conductor in the power cable. To avoid the potential of electric shock, the ground conductor
must be correct.
Observe source ratings. To avoid risk of fire or electric shock, the power source must be 100 –240
VAC, 50 –60 Hz.
Do not operate with suspected failures. If you suspect there is damage or malfunction with this
product, call the factory.
Do not attempt repair. Only a trained factory service person is authorized to repair this product.
Do not operate this product near heat sources. This product should not be located near heat sources
such as radiators, heat registers, or stoves.
Provide proper ventilation. The operating temperature range is between 0º C and 40º C. The
humidity range is between 20% and 80%, non-condensing. The cooling method is convection.
Keep product surfaces clean and dry. Disconnect the power cable from the power source before
cleaning. Do not use liquid cleaners or aerosol cleaners. Use a damp cloth for cleaning.
Do not push objects into openings of this product. Never insert objects into the product through
openings.
Do not operate in wet or damp conditions.
Do not operate in an explosive atmosphere.
Inspect the power cable and all cables prior to use. Confirm that the power cable and other
interconnecting cables are free from damage.
2. Regulatory Compliance
EN 60950-1
The EN 60950-1 standard specifies the safety design requirements that reduce or eliminate the risk of personal
injury to both the product user and service personnel. This product is designed and tested to meet the
standards of the International Electrotechnical Commission (IEC) European Norm EN 60950-1, IEC 60950-1 (the
standard for information technology equipment including electrical business equipment).
2.1 Declaration of Conformity
The JSD-100MA meets the intent of Directive 89/336/EEC for Electromagnetic Compatibility and Low Voltage
Directive 73/23/EEC for Product Safety. Compliance was demonstrated to the following specifications as listed
in the Official Journal of the European Communities:
EN 55022: 2006 Conducted and Radiated Emissions
Conducted Emissions
Radiated Emissions, Class A Limits
EN 55024: 1998 + A1: 2001 & A2: 2003 Immunity
Electrostatic Discharge Immunity
RF Electromagnetic Field Immunity
Power Line Surge Immunity

Version 160624 Page 6
Conducted RF immunity
Power Frequency Magnetic Field Susceptibility
Voltage Dips, Short Interruptions and Variations
EN 61000-3-3: 1995 +A1: 2001 & A2: 2005 Voltage Fluctuation and Flicker
FCC Part 15, Subpart B
This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to
part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful
interference when the equipment is operated in a commercial environment. This equipment generates, uses,
and can radiate radio frequency energy and, if not installed and used in accordance with the instruction
manual, may cause harmful interference to radio communications. Operation of this equipment in a
residential area is likely to cause harmful interference in which case the user will be required to correct the
interference at user’s own expense.
Certifications
Low Voltage Directive 73/23/EEC.
EN 60950 Information Technology, Video, and similar Electronic Apparatus.
IEC 60950 Safety Requirements.
CE, UL, cUL Safety and Overall Compliance.
VDE Certified Power Cords.
Pollution: Not intended for environments where conductive pollutants may be present.
2.2 Equipment Class
Type A: Equipment that is intended for connection to the building power supply wiring via nonindustrial plugs
and sockets or via appliance couplers, or both.
2.3 Disposal and Recycling
Wheelie-Bin Symbol
The Wheelie-Bin symbol is attached to this product in compliance with the EU Directive 2002/96/EC on
Waste Electrical and Electronic Equipment (WEEE). Its purpose is to deter the improper disposal of this
product and to promote reuse and recycling.
Proper Disposal
In conformance with the Directive, at end of life this product should be either sent to an appropriate recycling
facility for disassembly and recycling or returned to the supplier. Under no circumstances should this product
be deposited in a landfill for disposal.
Hazards of Noncompliance
Electrical and electronic products may contain chemicals which can leach into the groundwater and cause
health concerns through contaminated drinking water. Failure to dispose of this product in compliance with
the WEEE Directive may result in penalties as determined by local ordinance.

Version 160624 Page 7
3. System Version
The JSD-100MA is continuously being improved. New features are added through software/firmware updates
and replacement of plug-in modules. This manual describes the JSD-100MA versions available at this writing.
Firmware/software versions for the systems described in this manual are listed in the table below:
4. System Overview
4.1 System Description
The JSD-100MA cinema sound processor is specially designed for digital cinema applications. Low noise and
low distortion 96 kHz processing ensures superb presentations. In addition to the eight standard formats, the
JSD-100MA offers two fully configurable formats. The two user-configurable buttons can be configured to
support a variety of existing and future formats. They may also be used to duplicate an existing format but at
a different fader level to simplify desired volume changes between content types. The front panel display
shows the current fader level, the format name (which is user configurable), and the measured audio level on
each channel of the main audio output. The built-in bypass audio circuitry Ensures that the presentation goes
on in the unlikely event of a system failure.
The JSD-100MA is “automation friendly.” It features the standard DB25 parallel automation interface, an RS-
232 (EIA232) interface, and Ethernet. The Ethernet interface accepts 5 simultaneous TCP connections to allow
control by a digital cinema server and other equipment while simultaneously being monitored over another
TCP connection.
The Graphical User Interface runs on Windows XP®, Windows 7®, Windows 8®, and Windows 10® operating
systems. It allows for complete system configuration, monitoring, and firmware updates over USB, Ethernet,
or RS-232. The JSD-100MA graphical user interface simplifies installation by including sound pressure level
measurement and automatic equalization. System monitoring, control, and firmware update functions are
also available on a standard web browser.
The JSD-100MA includes a precision 1/3 octave RTA that uses the filters specified in ANSI S1.11-1986. The JSD-
100MA also does sound pressure measurements using the C-weighted filter specified in ANSI S1.4-1983. The
RTA and SPL meter can be used to equalize an auditorium manually or automatically.
The JSD-100MA includes an automatic equalization feature (auto-EQ). Auto-EQ uses user-defined microphone
calibration files and standard or user-defined equalization curves to automatically adjust the graphic equalizer
on each channel.
The JSD-100MA is also “diagnostic friendly.” The system logs the last 32,000 events (format changes, level
changes, internal temperature, loss of AES audio, etc.) to internal flash memory. Log data can be reviewed on
the GUI or the web interface. Current operational status, including selected format, fader level, and measured
audio output levels, is available on the GUI and on the web interface. The current status of the system is also
available over SNMP (Simple Network Management Protocol).
Component
Version
Graphical User Interface (GUI)
1.0.1
Main PIC
160610
DSP 1
1151217
DSP 2
2151217

Version 160624 Page 8
4.2 Block Diagrams
The following pages contain simplified block diagrams to assist the user in understanding the structure and
operation of the JSD-100MA.
Figure 1 shows a simplified overall view of the JSD-100MA system. Two channel analog inputs are converted to
digital. There is a "simple matrix" in the DSPs that can convert stereo inputs to 5.1. The JSD-100MA allows for a
16 channel digital input. All these signals are routed through various input select switches based on the
selected format, then sent to the DSPs.
DSP1 handles the screen channels, while DSP2 handles the surround channels. All channels except LFE go
through a graphic equalizer. The LFE channel goes through a parametric equalizer and a 125Hz low pass filter
as specified by SMPTE EG0432-2-2006. Similarly, the surround channels go through a graphic equalizer.
Provision is made to select the source of the surround channels (discrete channels or synthesized sources).
Surround delays (individual delays for each channel pair) are added to the surround channels.
All channels have a synchronization delay to compensate for projector and other system delays. Sync delays
are configurable for each format. Note that the JSD-100MA can support multiple LFE and surround outputs.
Because of this, the LFE parametric equalizer is actually located in the crossover section of the DSP and GUI
XO, Etc tab. Similarly, individual Ls/Rs output delays are also available in the crossover section where multiple
Ls/Rs outputs are available. See the following crossover figures for more detail.
Figure 1 Audio Processing
Figure 2 Audio Processing

Version 160624 Page 9
Figure 3 Output Module
The bottom section of figure 3 shows what a typical analog output looks like. The appropriate DSP drives a
digital to analog converter, which drives the output trim controls, and then the balanced line driver. The
output is disconnected when the system is muted. Separate bypass audio circuitry is switched to the output
when bypass is enabled. Output module circuitry measures the actual audio level on the outputs for
presentation on the front panel bar graph.
The following figures show the details of the crossovers. In most installations, the user merely loads crossover
settings from the supplied speaker library, and then adjusts the output trims as required to compensate for
amplifier gain differences and speaker efficiency differences.
Figure 4 shows a typical biamp crossover for a screen channel. The audio leaving the graphic equalizer drives a
high pass filter (filter #16). The cutoff frequency and the Q can be adjusted by the user. The audio is then split
into high band and low band components with high pass filter #0 and low pass filter #9. These are both 4th
order Linkwitz-Riley filters. These are followed by a series of parametric filters. The high band includes a pair of
shelving filters (#2 and #3) to compensate for the high frequency characteristics of the high frequency horn
and the screen. Each band ends up with a delay block. Individual band delays can be set as required to get the
high and low frequency acoustic signals in phase. This block also includes a provision to flip the phase in case a
speaker is wired incorrectly. The delay block also has adjustable gain, though this gain is normally set to 0dB.
band gains are adjusted using the output trim shown in the bottom section of figure 4.2a. Use of this analog
control instead of a digital control provides the widest possible dynamic range. Figure 5 shows a typical triamp
crossover for a screen channel. The details are very similar to the biamp crossover of figure 4.2b except that
the channel is split into three bands.
Figure 5 shows the LFE "Crossover." It is not really a crossover since it does not split the channel into multiple
frequency bands. It is similar to a crossover, however, in that a single audio channel is split into multiple
outputs and separate equalization (parametric) and delay can be applied to each output. Because of this
similarity, the LFE equalizer is located in the crossover section of the DSP and in the "XO, etc." tab on the GUI.
The multiple LFE outputs are only available on output modules with enough outputs, but the LFE equalization
is always in the "XO, etc." tab on the GUI. For convenience, the LFE parametric equalizer settings are shown in
both the Equalizer and XO, etc. tabs in the GUI.
Figure 6 shows the Ls "Crossover." The Rs “Crossover” is identical. Similar to the LFE, this is not a true
crossover since it does not split the channel into frequency bands. It does, however, split a channel into
multiple outputs with individual delays, similar to a crossover. For that reason, the "XO, Etc." tab on the GUI
contains delay and gain settings for multiple Ls/Rs outputs. The Surround Outputs tab has level adjustments
and surround delays for individual surround channel pairs. These can be thought of as "master" level settings
and delays with individual level and delay settings available for Ls and Ls1 outputs (and similarly for Rs). The
total delay is the sum of the delay shown on the Surround Outputs tab and the delay on the "XO, etc." tab.

Version 160624 Page 10
Figure 4 Screen Channel Biamp Crossover
Figure 5 Screen Channel Triamp Crossover
Figure 6 LFE Channels

Version 160624 Page 11
4.3 Channel Descriptions
JSD-100MA has 16 AES input channels. In the transition to digital cinema, the industry is adopting new names
and abbreviations for speaker locations. Generally, the first letter is capitalized and either L for left, C for
center or R for right. The second and third letters, if present, are lower case and further define the position. In
some cases the second letter is upper case to eliminate confusion with bi-amp and tri-amp speaker output
labels such as Left High Band (Lh). The actual speaker placement is determined by the auditorium room size
and shape. The following is a general speaker placement description to aid in distinguishing the JSD-100MA
output channels for an object base sound environment.
New Name
(abbreviation)
Description
Previous Name
(abbreviation)
Left (L)
Typically positioned behind the screen to the far left edge,
horizontally, of the screen center as viewed from the seating area.
Left (L)
Left High (LH)
Located above the front left at approximately screen height top
region of the screen.
Right (R)
Typically positioned behind the screen to the far right edge,
horizontally, of the screen center as viewed from the seating area.
Right (R)
Right High (RH)
Located above the front right at approximately screen height top
region of the screen.
Center (C)
This loudspeaker position is typically behind the screen
corresponding to the horizontal center of the screen as viewed from
the seating area. Also the intended speaker position for mono
reproduction.
Center (C)
Low Frequency
Effects (LFE)
Screen low frequency effects subwoofer loudspeaker(s). This is
typically one or more band-limited low frequency only loudspeakers
at the screen end of the room.
Subwoofer (SW)
Left Side Front (Lsf)
Located on the left side at about 1/2 the distances from the screen
and before the surround speaker array located at about 1/3 the
distance from the front.
Right Side Front
(Rsf)
Located on the right side at about 1/2 the distances from the screen
and before the surround speaker array located at about 1/3 the
distance from the front.
Left Side surround
(Lss)
Typically an array of loudspeakers positioned along the left side of
the room starting approximately 1/3 of the distance from the screen
to the back wall and the left side of the rear wall. Left surround may
not extend to the back wall of the auditorium.
Left Surround (LS)
Left Side High (Lsh)
Located above the left surrounds near the ceiling, an array of
speakers starting at approximately 1/3 the distance from the screen
and rear wall.
Right Side surround
(Rss)
Typically an array of loudspeakers positioned along the right side of
the room starting approximately 1/3 of the distance from the screen
to the back wall and the right side of the rear wall. Right surround
may not extend to the back of the auditorium.
Right Surround
(RS)
Right Side High
(Rsh)
Located above the right surrounds near the ceiling, an array of
speakers starting at approximately 1/3 the distance from the screen
and rear wall.
Left rear surround
(Lrs)
One or more loudspeakers typically on the back wall of the room to
the left horizontally.
Back Surround Left
(BSL)
Right rear surround
(Rrs)
One or more loudspeakers typically on the back wall of the room to
the right horizontally.
Back Surround
Right (BSR)
Ceiling Channel A
(CEA)
An array of speakers that can be located as rows parallel to the side
or front (screen) producing audio above from front to back Or left to
right.
Ceiling Channel B
(CEB)
An array of speakers that can be located as rows parallel to the side
or front producing audio above from front to back Or left to right.

Version 160624 Page 12
5.1
Ls
CL R
Rs
7.1SDDS
Lc Rc
7.1DS
Lrs Rrs
LFE
CL R
LFE
CL R
LFE
Ls Rs
Ls Rs
4.4 Sound Field Configurations
The standard sound field configurations (or speaker configurations) as defined by SMPTE are shown in the
diagram below. Note there are two defined 7.1 configurations. One (7.1DS) has rear surround speakers, while
the other (7.1SDDS) extends the side surround speakers to the rear wall and adds left center and right center
speakers. The JSD-100MA by default is configured as a 16.1 channel cinema processor not shown in the
illustration below.
The JSD-100MA is configured for the particular speaker configuration in the auditorium. Each format is then
configured as to how the speakers in that auditorium are driven. For example, when an auditorium is
configured for 7.1DS, which includes rear surround speakers, and 5.1 content is played, the rear surround
speakers can be driven by the surround channels, or a mix of the surround channels.
4.5 Processing Channels
The JSD-100MA has 16 “processing channels.” Each of these receives audio from a variety of sources. The
“processing channel” includes the main fader control, equalization, synchronization or input delay, surround
delay (on the surround channels), and, as an option, crossovers on the screen channels. Outputs on the rear
panel are identified by the channel usage (i.e., L for left). The table below describes the processing channels,
their inputs, and how their outputs are identified on the rear panel.
Input Channel
AES-EBU
Processing Channel
Channel
Label
Output Panel
Identifier
1
Left
L
L
2
Right
R
R
3
Center
C
C
4
Low Frequency Effects
LFE
LFE
5
Left Side Surround
Lss
Ls
6
Right Side Surround
Rss
Rs
7
Left Screen Height
LH
Lrs(Lc)
8
Right Screen Height
RH
Rrs(Rc)
9
Left Side Front Surround
Lsf
Lm/LCh (CH9)*Note1
10
Right Side Front Surround
Rsf
Rm/RCh (CH10)*Note 1
11
Left Rear Surround
Lrs
Lrs *Note 1
12
Right Rear Surround
Rrs
Rrs *note 1
13
Left Side Height
Lsh
Cm (CH13)*Note 1
14
Right Side Height
Rsh
Ch (CH14)*Note 1
15
Ceiling Channel A
CEA
Lh (LFE2)*Note 1
16
Ceiling Channel B
CEB
Rh (LFE3)*Note 1
Notes: 1. Signal located in the Optional Outputs connector.

Version 160624 Page 13
5. Specifications
5.1 Features
A processor specially designed for Digital Cinema applications. Low noise and low distortion processing
ensures superb presentations. In addition to eight standard formats, the JSD-100MA offers two fully
configurable optional formats to address such details as audio level changes and 3 or 5 stage channels. Built-in
bypass audio circuitry ensures that the presentation goes on.
5.2 Audio Inputs
PA Microphone –XLR 0.7mV sensitivity.
Calibration Microphone –3.5mm stereo jack 0.7mV sensitivity with 10V power.
Non-Sync analog input –RCA 75mV to 4.775V.
Auxiliary analog input –RCA 300mV.
Eight Channel analog input –DB25F 300mV.
COAX1 –RCA PCM.
COAX2 –RCA PCM.
TOSLINK –Optical PCM.
AES/EBU 16 Channel 48-96KHz sample rates
5.3 Sixteen Channel Analog Audio Outputs ( JSD-100MA)
Sixteen Channels Balanced 300mV adjustable outputs that can be configured as 5.1, 7.1, 13.1, 15.1 broadband,
biamp , or triamp.
5.4 Communication Ports
DB25F pulse automation.
Serial control –RS-232.
USB for laptop setup.
Ethernet 10/100 - RJ45.
5.5 Front Panel Interface
Eleven buttons: COAX1, COAX2, TOSLINK, DIGITAL 16 CH, USER 1, USER 2, ANALOG 8 CH, NON/SYNC, AUX,
MIC, and MUTE.
Main Fader –0-10 used for main audio and bypass audio.
Front panel displays fader level and selected format. Bar graphs display output levels.
USB connector.
Power switch and power supply status LEDs. Turning power off activates bypass mode.
5.6 Format Selection
Digital (COAX1, COAX2, TOSLINK, 8 or 16 Channel AES/EBU).
Analog (8 channel, Non-Sync, Auxiliary, Microphone).
User 1, User 2 (Configurable in software, e.g., digital 16 channel at lower level, 7.1, 13.1, etc.).
5.7 Rear Panel Connectors -Main Chassis
PA Microphone –XLR / ¼” phone jack.
Calibration Microphone –3.5mm stereo jack.
Eight Channel Analog –DB25F

Version 160624 Page 14
Non/Sync –two RCA jacks.
AUX –two RCA jacks.
Hearing Impaired and Visual Narration –pluggable Phoenix connector.
COAX1 and COAX2 –RCA Jacks with transformer input
TOSLINK –Optical.
16 Channel Digital AES/EBU –DB25 and Dual RJ45.
Removable Memory Card –SD compatible.
Serial Control –RS-232 on DE9F.
Pulse Automation –DB25F.
10/100M Ethernet –RJ45.
DC 12V Power Connector –5mm with 2.5mm pin.
AC Power –IEC socket. 100-240VAC, 50/60Hz, 18W typical, 7.5W sleep.
5.8 Rear Panel Interface Module
All rear panel interface modules include an RJ-style connector for “RS-485.” This IEEE 485 bus is used for
remote volume controls and other control functions. Two DB25M and two Phoenix connectors have 16
channels of analog signals that are typically connected to a monitor and then routed to the amplifiers. The
outputs can be configured as crossover outputs in which the signals are reassigned to provide the respective
low, mid, and high bands.
5.9 Processing
96 kHz processing.
One-third octave equalization on all channels except LFE, HI, and VI-N.
Parametric equalizers on LFE.
Synchronization delays for all inputs.
Surround delays for all surround channels.
Internal crossovers on systems with 16 or more outputs. Crossovers support biamp and triamp of up to
five screen channels plus individual parametric equalization on one to three LFE outputs. Crossover
includes a speaker library and allows for user defined speaker systems.
5.10 Sleep Mode
With an Ethernet command or preset timeout, the unit can go into a sleep mode. Another Ethernet command,
“button press,” or automation pulse will wake up the unit.
5.11 Bypass Mode
In an emergency situation, the JSD-100MA can be switched off, automatically enabling the bypass circuitry.
Front panel buttons, LEDs and fader will still function, allowing the operation of the unit in various analog and
digital formats. Final output is a monophonic signal feed to the left and right channels. Note: The 12 VDC
bypass power supply must be connected for this functionality.
5.12 Graphical User Interface
The JSD-100MA Graphical User Interface (GUI) operates under Windows XP, Windows 7, Windows 8 and
Windows 10. It communicates with one or more JSD-100MA systems simultaneously over USB, Ethernet, or
RS232. The GUI is used for system configuration including auditorium equalization (both manual and automatic
equalization).
Dynamic Range: Typically 105dB.
Power Requirements: 100-240VAC, 50/60Hz, 30 watts maximum (18 watts typical, 7.5 watts sleep).
Dimensions: Standard 2U rack-mount chassis.
Agency Approvals: UL, cUL, CE and FCC.

Version 160624 Page 15
6. Installations
6.1 Initial Power-up
A “Quick Power-up” test of the JSD-100MA is suggested before mounting it in the equipment rack and wiring it
up. This test can quickly detect shipping or other damage.
Turn the AC power switch to the off position.
Using the supplied AC line cord or one appropriate for the installation location (the power supply is a
universal input supply 100-240 VAC, 50/60 Hz), connect the JSD-100MA to the AC line.
Connect the supplied 12 VDC bypass power supply to the bypass power input on the rear panel of the
JSD-100MA and plug it in to the AC line. The front panel “Bypass Mode” LED should flash, the bypass
power LED should light, and one of the format buttons should light.
Press each of the format buttons and the mute button, one after another. The appropriate button
should light.
Turn on the AC power switch. The display should immediately light, but be blank. All the green
power LEDs on the bottom right of the front panel should light. The “Bypass Mode” LED should stop
flashing.
After approximately 25 seconds, the format buttons will flash and then a single format LED will light.
The display should show the fader level and the selected format.
Press each of the format buttons, verifying that the corresponding LED lights and that the display
changes accordingly. Note that the format button LEDs for digital formats will flash when no digital
input is provided.
Press the mute button verifying that its LED toggles each time the button is pressed.
Rotate the fader in each direction verifying that the fader numbers on the display change.
6.2 System Hardware Mounting, Grounding, and Ventilation
The JSD-100MA is designed to mount in a standard 19 inch (482.6mm) rack and is two rack units high (3.5
inches, 137.8mm). The JSD-100MA should be mounted at “eye level” in the equipment rack for optimum
display contrast and visibility. We recommend vented panels above and below the JSD-100MA whenever
space permits. Mounting the unit immediately above a major heat-producing component, such as a power
amplifier, is not recommended. Equipment mounted immediately above the JSD-100MA should not be more
than 9 inches (225mm) deep to ensure adequate airflow through the rear ventilation slots on the JSD-100MA.
The JSD-100MA includes a three-prong grounding plug and a three-wire power cord to accommodate a safe
ground path from the chassis to the electrical system ground. Defeating this ground by removing the ground
prong is not recommended.
6.3 Sixteen Channel Analog Output Rear Panel Connections ( JSD-100MA)
A set of clip-on ferrite “beads” is supplied with the JSD-100MA. To ensure the JSD-100MA continues to meet
FCC and CE radio emissions requirements, one of these beads should be clipped around each cable connected
to the rear panel of the JSD-100MA except for the TOSLINK, AC Power, and Bypass Power connection.

Version 160624 Page 16
1. Bypass Power Supply –12VDC at 1.25A.
2. Power entry Module –Accepts IEC-type line cord from 100-240VAC power source. Also contains a 500mA
Slo-Blo 5x20mm fuse.
3. Sixteen Channel Analog Output Module
a. Bypass crossover adjustments.
b. Main outputs cover the first 8 output channels. The Phoenix connectors normally drive the power
amplifiers, and the DB25M connectors drive the booth monitor.
c. Extra outputs cover the second 8 output channels.
d. RS-485 - An RJ25 connector that provides an RS-485 interface for remote volume control and other
functions.
4. Ethernet –Network communications with GUI, web browsers, automation, etc.
5. RS-232 on a DE9F connector for communications with GUI or automation.
6. Automation DB25F Connector –A bidirectional port for receiving and sending automation pulses between
the JSD-100MA and other system components. 12 Control lines, 11 Status lines and +5V are provided.
Standard pulse to ground system.
7. SD Card - Stores a backup copy of unit configuration. Can also be used to transfer settings to another.
8. AES connector (DB25F) –Channels 1-16
9. AES connectors (Dual RJ45s) –parallel connections to the DB25F above.
10. TOSLINK Port –Optical Fiber input for SPDIF (PCM).
11. COAX 1, COAX 2 - RCA type connectors for SPDIF (PCM).
12. Hearing Impaired/Visual Narration Outputs.
13. AUX connectors –L and R analog inputs, 300mV sensitivity.
14. Non Sync (N/S) connectors –L and R analog inputs.
15. RTA microphone –3.5mm stereo jack with +10V on the ring, designed for use with a powered electret
microphone.
16. 8 Channel Analog Input on DB25F –Balanced line inputs. Six channels are fixed (L, C, R, LFE, Ls, Rs) and
two can be set up as either Lc/Rc or Lrs/Rrs.
17. Public Address Microphone –Dual connector with XLR and ¼” phone jack in the center.
6.4 Audio Input Connections
6.4.1 16 Channel AES Input
The JSD-100MA accepts 16 channel AES audio. This input is typically driven by the digital cinema server (DCS).
The JSD-100MA includes a DB25F connector using an industry standard
1
pin out and a pair of RJ-45 connectors
using the StudioHub
2
pin out. The first six channels are assigned speakers by industry convention. The
remaining channels are configured by default to provide a 15.1 channel sound field. The input sources for
HI/VN are user configurable. For convenience, all connector pin outs are listed in Appendix A.
6.4.2 8 Channel Analog Input
The JSD-100MA eight channel analog input is on a DB25F connector. The analog inputs are active balanced
(differential) inputs. They may be driven by balanced or unbalanced sources. When driven by an unbalanced
source, the negative input should be connected to the low side of the source at the source equipment to
1
The XSP-1000 DB25 AES input uses a de-facto industry standard pin out. The pin out was the subject of a draft SMPTE Engineering
Guideline in 2004. Though SMPTE never adopted the guideline, much of the industry adopted the pin out specified in this draft.
2
Please see the Studio Hub website: www.StudioHub.com

Version 160624 Page 17
minimize ground loop noise. The cable should be twisted pair with individual shields, even when driven by an
unbalanced source.
6.5 Analog Audio Output Connections
The JSD-100MA provides sixteen main channel outputs. All outputs are balanced and may drive balanced or
unbalanced loads. When driving unbalanced loads, run two conductor shielded cable and connect the “ – ”
terminal of the JSD-100MA output to the low side of the unbalanced load at the load instead of at the JSD-
100MA to minimize ground loop noise.
6.5.1 Main Audio Outputs
The main audio outputs are on a module that can be replaced from the rear. To allow for proper bypass
operation, a passive crossover is included. For full band operation, set all four DIP switches to OFF and set the
MID and HIGH trim pots to full counter-clockwise. Adjust the LOW trim pot for the desired full range bypass
audio level. Remember that the front panel fader also affects output level when in bypass. For bypass
operation with crossovers, see Section 7.5.1. The connections for these output modules are detailed in
Appendix A.
6.5.2 HI/VI-N Outputs
The JSD-100MA has balanced HI and VI-N outputs that can drive balanced or unbalanced loads. As with other
outputs, the use of twisted pair shielded cable is suggested whether the load is balanced or unbalanced. When
driving an unbalanced load, connect the “–” output of the JSD-100MA to low side of the unbalanced input at
the destination end of the cable to minimize ground loop noise. The source of audio to drive the HI and VI-N
outputs is configurable on a per-format basis. The USL supplied ferrite block should be clipped on to the
cables adjacent to the connectors to comply with FCC and CE emission requirements. See Appendix A for pin
out information.
6.6 Automation Interface
The JSD-100MA includes the traditional parallel automation interface plus RS-232 and Ethernet. See appendix
B for a list of the automation commands.
6.6.1 Parallel Interface
Pins 1 through 10 of the DB25F automation connector are “control” pins that accept contact closure or open
collector pulses to ground to select formats. On a format change, the corresponding pin is also pulsed low
allowing this interface to drive other equipment. Pulsing pin 11 low toggles the mute state. Pins 14 through
24 are “status” pins. One of the pins 14 through 23 is pulled low continuously by the JSD-100MA to indicate
the selected format. These pins could drive LEDs with a 470 ohm series resistor to provide a remote format
indication. The JSD-100MA pulls pin 24 low when the system is muted. Pins 1 through 11 are internally pulled
up to +8.4V. They each source 400uA when grounded. A pin needs to be pulled below 2.6V for 10ms or more
for the JSD-100MA to recognize it as low. On a format change, the JSD-100MA pulls the appropriate pin low for
500ms. +5V at 100mA is available on pin 13 to drive external LEDs or relays. The individual control and status
outputs can sink up to 150mA with an open circuit voltage of +12VDC for inductive loads like relays or +24V for
non-inductive loads (indicator lamps, etc.). Pin 12 is the “automation return.” Use this as the low side of
switches and indicators instead of using chassis ground. It is ground through a 10 ohm resistor to limit ground
loop current. The USL supplied ferrite block should be clipped on to the cables adjacent to the connectors to
comply with FCC and CE emission requirements. See Appendix A for pin out information.
6.6.2 RS-232 Interface
The RS-232 interface appears on a DE9F connector on the rear panel. The connector is wired as a DCE device.
A command interpreter accepts ASCII commands over the RS-232 and Ethernet interfaces. The RS-232 port
operates at 38.4kbps, 8N1 (8 data bits, no parity, 1 stop bit), hardware handshake. In most situations, no
handshake is required, and the RTS and CTS pins can be left open. The USL supplied ferrite block should be
clipped on to the cables adjacent to the connectors to comply with FCC and CE emission requirements. See
Appendix A for the connector pin out.

Version 160624 Page 18
6.6.3 Ethernet Interface
The JSD-100MA includes a standard 10/100Mbps Ethernet interface. The same automation commands are
available on TCP connections to port 10001 on the Ethernet interface. The JSD-100MA accepts up to 5
simultaneous TCP connections, allowing multiple control and monitor devices to be used. The Ethernet
interface also includes a web server. System status and basic control are available on internally generated
web pages. System status is also available over SNMP. The JSD-100MA also includes a Network Time Protocol
(NTP) client that can be used to keep the internal real time clock accurate. Use a CAT5 or better Ethernet cable
to connect the JSD-100MA to the control network. The supplied ferrite block should be clipped on to the cable
adjacent to the connector to comply with FCC and CE emission requirements.
6.6.4 RS-485
The RS-485 bus used to interface the JSD-100MA to other compatible devices such as the remote volume
control (See Section 9 and Appendix A). The supplied ferrite block should be clipped on to the cables adjacent
to the connectors to comply with FCC and CE emission requirements. See Appendix A for the connector pin
out.
7. Graphical User Interface Configuration
7.1 System Configuration Using the Graphical User Interface
The graphical user interface (GUI) allows for configuration and
monitoring of the JSD-100MA. When the application has been
installed there are two programs available through the Windows
Start Menu. The JSD-100MA Cinema Processor is an application
used for setting up sound processing. The JSD-100MA SetIP is a
utility used for configuring the network parameters that requires
a USB connection to the cinema processor.
7.2 GUI File Organization
The GUI installer places the executable program files in the Program
Files\USL\JSD-100MA directory. Configuration files are placed in My
Documents\USL\JSD-100MA as shown.
The EQ Curves directory holds data for generating limit curves for the RTA and
automatic equalization. Standard curve data for several auditorium sizes are
provided. Since these are plain text files, custom limit curves can be easily
created. The Microphone Library holds calibration data on microphones used
on the RTA. A separate file can be created for each microphone used with the
system. The file includes the required preamp gain and frequency response
adjustment. The Speaker Library holds crossover configuration files for a wide
range of biamp and triamp speaker systems. These are also text files; so
appropriate crossover settings for additional speaker systems can be created.
See Appendix E for configuration file formats.

Version 160624 Page 19
7.3 Windows JSD-100MA Installation
The JSD-100MA.exe user interface and SetIP.exe
applications are supported on Windows® XP,
Windows® 7, Windows® 8, or Windows® 10 operating
systems.
7.3.1 Windows Installer
The installation CD contains an electronic copy of the
user manual, Windows Setup application, and USB
drivers. When the CD is inserted into the drive on the
computer, an auto-run executable starts the installer.
When manually running the installer, launch the
Setup.exe as this contains setup conditions that are
required for proper application installation. This is
especially the case with Windows 10, an attempt to
install by invoking the setup.msi will result in an
installation error.
7.3.2 USB Driver Installation
Windows 10 USB driver signing and certification requirements for device drivers being installed on the
computer require selecting a mode that will bypass the signing requirement via the Advance Startup Options.
In addition to accessing the startup options, Bit Locker must be disabled. Access to Bit Locker settings can be
found by entering “Manage BitLocker” in the task bar search field. As a note BitLocker is only available in the
Windows 10 Pro edition.
The following are the steps required for Windows 10 to disable driver signature enforcement by accessing the
advance startup options.
Activate the Windows Start menu and select the Power item. When the
power options appear, hold the shift-key and then with the mouse
select the “Restart” option.
Windows will appear to shut down with the typical wait status displayed
and on restart the “Choose an option” menu is displayed.
Select the “Troubleshoot” menu item and then the “Advanced options.” The next menu group it will
contain the “Startup Settings” item that will then prepare the computer to restart with the settings
menu interface.

Version 160624 Page 20
When Windows 10 restarts, the startup settings menu is displayed with option 7, typically is “Disable
driver signature enforcement.” To continue the restart process, press the F7 key.
Windows 10 will then complete its booting and will appear as it does
normally. Activate the Start Menu and select “All apps.” In the list
select USL and then “JSD-100MA DPInst64.exe.” The User Account
Control prompt will be displayed requesting permission to run the
Driver Package Installer utility.
A “Welcome to the Device Driver Installation
Wizard!” will be displayed. Following the
activation of the next button a Windows Security
dialog will appear. Proceed with the “Install this
driver software anyway” option.
After the installation wizard completes, the driver
is now loaded and ready for activation.
Connect the USB to the computer and JSD-100MA
to initiate the next driver installation phase.
Basically you will see a status in the task bar’s far
right side indicating a driver installation process.
On most computers Windows can take about 45 seconds to a couple of minutes. By activating the up-
arrow an installation icon may appear in the task bar near the tray items such as network connection
status. The driver will be ready for use once the installation completes.
As another alternative, Device Manage can be used to manually select the driver using Device Manager’s
Update option. For manual driver installation execute the following steps:
For Windows 10 activate the Start menu button with a right mouse click and then select Device
Manager. With Windows 7 launch Control Panel and then activate Device Manager from with its
programs group.
With the USB cable connected to the computer and the JSD-100MA, the device will appear as either
“Others” or “Unknown” with a name of “USL JSD-100MA Cinema Processor” in the tree.
Use the right mouse button on the device item (USL JSD-100MA…) to display its properties. Select the
driver tab to access the update driver option.
In the next window select the “Browse my computer for the driver software.” Use the browse button
to select the desired driver folder and then check “include subfolder” option followed by next button
activation. An installer warning will be displayed and select the “Install this driver software anyway.”
As a note the drivers are stored with the application in the following folder:
C:\Program Files (x86)\USL\JSD-100\WinUSB_Drivers
