USX-MOUNT SMS005-01 User manual

SMS005-01
INSTRUCTION MANUAL
R
USA-B0
For 13-32" TV
If you have any questions along the way, just message
to us. We’re ready to help!

Before getting started, let’s check below lists to make sure it is just right for you!
2
3
4
5
2
Does your TV
(including accessories)
weigh MORE than
55 lbs. (25 kg)?
What is your
wall made of?
Do you have
all the tools
needed?
(NOT INCLUDE) Tape
Measure
CAUTION
Pencil Level Screw
driver
Electric
Drill
No? Perfect – you may continue.
Yes? This mount is NOT compatible.
Drywall with
wood studs?
CAUTION: DO NOT exceed the maximum weight
indicated. This mounting system is intended for use only
with the maximum weights indicated. Use with products
heavier than the maximum weights indicated may result
in collapse of the mount and its accessories, causing
possible injury.
3/8 in.
(10 mm)
Socket
Wrench
Stud
Finder
1/8 in.
(3.18 mm)
Wood
Drill Bit
● This product is designed for use in wood stud, solid concrete walls - DO NOT install into drywall alone
● The wall must be capable of supporting five times the weight of the TV and mount itself
● Do not use this product for any purpose not explicitly specified by manufacturer
● Manufacturer is not responsible for damage or injury caused by incorrect assembly or use
3/8 in.
(10 mm)
Masonry
Drill Bit
Hammer
1
Check your TV
VESA is within
Min and Max size
No? This mount is NOT compatible.
Yes? Perfect !
MAX:200mm/7.87"
(MIN:75mm/2.95")
MAX:200mm/7.87"
(MIN:75mm/2.95")
CAUTION: Solid concrete ?Unsure?
Mail to us via Amazon.

TV INTERFACE 3-D
WALL PLATE
FULLY ASSEMBLED MOUNT TOP VIEW - RETRACTED
TOP VIEW - EXTENDED SIDE VIEW - EXTENDED
3
+5°
-15°
TOP VIEW - EXTENDED
+90° -90°
MAX:200mm[7.87in]
MAX:200mm
[7.87in]
MIN: 75mm
[2.95in]
MIN:75mm[2.95in]
114mm
[4.49in]
Ø8mm
[Ø0.31in]
233mm
[9.19in]
233mm
[9.19in]
120mm
[4.72in]
152mm
[5.98in]
120mm
[4.72in]
51mm
[2.01in]
71mm
[2.81in]
222mm
[8.72in]

WARNING: This product contains small items that could be a choking hazard if swallowed. Before starting assembly, verify all parts
are included and undamaged. If any parts are missing or damaged, do not return the damaged item to your dealer; contact
Customer Service.
Never use damaged parts!
NOTE: Not all hardware included will be used.
Parts and Hardware for STEP 1
4
Extenders Spacers
TV Screws
M4x12mm
M6x12mm
M8x25mm
M4x30mm
M6x35mm
M6x17mm
M4 M6
10mm 2.5mm
Washers
x4 x4
x4
x4
x4
x4
x4 x4
x8
x4
x4
M5x12mm
x4
M5x30mm
x4

Lag Bolt
x2
Wall Plate
x1
Parts and Hardware for STEP 2
5
Allen Key
x1
M6x8mm Bolt
x8
Velcro x3
Concrete Wall Anchor
2pcs
Contact us and message to us
to have these additional pieces shipped
directly to you.

6
1-2 Choose Correct Configuration Per VESA Size on the Back of Your TV.
① 75X75
② 100X100
③ 150X150
④ 200X200
If your TV VESA size is bigger than 100x100, you must use bolts and allen key to attach
4pcs of extenders onto TV plate .
1-1 Disassemble Wall Plate Unit into Two Pieces
①Wall plate
TV plate
①①
①①
② ②
②
②
③
③③
③
④ ④
④④

M8
M6
M4
1-3 Select TV Screws
7
M5

VESA ≤ 100mm x 100mm
100mm x 100mm < VESA ≤ 200mm x 200mm
Tips: If you need to combine M6/M8(g/f) screws with
2.5mm spacers( i ), you have to remove the inner circle.
Yes, choose suitable screws, washers and spacers.
1-5 Attach the TV Plate
No!
No, choose suitable screws and washers.
1-4 Need Spacer?
8

CAUTION: Avoid potential personal injury or property damage!
● Drywall covering the wall, must not exceed 5/8 in. (16 mm)
● Minimum wood stud size: common 2 x 4 in. (51 x 102 mm) nominal 1½ x 3½ in. (38 x 89 mm)
● Stud center must be verified
1. Locate your studs. Verify and mark the center of the stud by finding the stud edges using a thin nail,
or an edge to edge stud finder.
2. Position the wall plate at your desired height and line up the holes with your stud center line. Level
the wall plate and mark the hole locations.
Centre line
Wall plate
9
Wall Wall
level

3. Drill pilot holes using a 1/8 in. (3.18 mm) diameter drill bit.
IMPORTANT: Pilot holes must be drilled to a depth of 2.16 in. (55 mm). Be sure to drill into the center
of the studs.
4. Install wall plate using lag bolts . Tighten the lag bolts only until they are pulled firmly against
the wall plate.
CAUTION: Improper use could reduce the holding power of the lag bolt.
DO NOT over-tighten the lag bolts.
Go to STEP 3 on PAGE 13
2.16"(55mm)
1/8"
(3.18mm)
No!
Wall plate
10
Wall Wall
level

CAUTION: Avoid potential personal injury or property damage!
● Mount the wall plate assembly directly onto the concrete surface
● Minimum solid concrete thickness: 8 in. (203 mm)
1. Position the wall plate on the wall at your desired height. Level the wall plate and mark the hole
locations.
2. Drill two pilot holes using a 3/8 in. (10 mm) diameter masonry drill bit.
IMPORTANT: Pilot holes must be drilled to a depth of 2.16 in. (55 mm).
2.16"(55mm)
3/8"
(10mm)
Wall plate
11
Wall Wall
level

3. Insert anchors.
CAUTION: Be sure the anchors are seated flush with the concrete surface.
CAUTION: Improper use could reduce the holding power of the lag bolt.
DO NOT over-tighten the lag bolts.
4. Insert wall plate using lag bolts .Tighten the lag bolts only until they are pulled firmly against
the wall plate.
Concrete Wall Anchor
(Not included)
No!
Wall plate
12
Wall Wall
level
Please contact us and message to us
to have these additional pieces shipped
directly to you.

Before hanging TV, please try to pull the mount to make sure that it has been assembled on the wall
tightly.
13

TV
1 2
Hang pre-assembled TV unit on the wall plate and fix them using screws ①.
14
①

5-1 TV leveling adjustment (±4°):
Loosen 2 leveling bolts on the rear of TV plate by maximum 2 turns, adjust to level and retighten
to secure.
±4°
Loosen
Tighten
15

5-2 Tilting angle adjustment (+5°/-15°)：
Loosen handle and tilting bolt, adjust TV to your desired position,
then tighten handle and tilting bolt.
+5°
-15°
Tilting bolts
Tilting bolts
+5°
-15°
16

5-3 Cables manage:
Manage TV cables orderly and guide them through the velcros.
Velcro
17
