UTAH SCIENTIFIC MADI Setup guide

MADI Terminal
Setup and Operations Guide

ii MADI Terminal
MADI Terminal - Operations Guide
• Document Number: 82102-0083
• Document Version: 1.0
• Date: November 23, 2015
• Printed in U.S.A.
Copyrights and Trademarks
© 2015 Utah Scientific, Inc., All rights reserved. Any use or reproduction of this guide’s contents with-
out the prior written consent of Utah Scientific, Inc. is strictly prohibited.
•MADI is a trademark of Utah Scientific, Inc.
•Windows, Windows XP, and Windows 7 are registered trademarks of Microsoft Corporation.
•All other product names and any registered or unregistered trademarks mentioned in this guide are
used for identification purposes only and remain the exclusive property of their respective owners.
Notice
Information contained in this guide is subject to change without notice or obligation. While every effort
has been made to ensure that the information is accurate as of the publication date, Utah Scientific, Inc.
assumes no liability for errors or omissions. In addition, Utah Scientific, Inc. assumes no responsibility
for damages resulting from the use of this guide.
FCC Compliance (USA) and Digital Equipment Compliance (Canada)
This equipment has been tested and found to comply with the limits for a Class A, digital device,
pursuant to Part 15, Subpart B of the FCC Rules and the Canadian EMC Requirement (ICES-003).
These limits are designed to provide reasonable protection against harmful interference when the
equipment is operated in a commercial environment. This equipment generates, uses, and can radiate
radio frequency energy and, if not installed and used in accordance with the instruction manual, may
cause harmful interference to radio communications. Operation of this equipment in a residential area is
likely to cause harmful interference, in which case, the user will be required to correct the interference at
their own expense. Shielded cables must be used to ensure compliance with the FCC Class A limits.

Setup and Operations Guide
Declaration of Conformity
Utah Scientific, Inc.
4750 Wiley Post Way, Suite 150
Salt Lake City, Utah 84116-2878 U.S.A.
We declare our sole responsibility that the Utah-400 Digital Routing Switcher is in conformance with
the following standards:
Emission
•EN55022:1994+A1&A2
Immunity
•EN55024:1998
•EN61000-3-2
•EN61000-3-3
Safety
•IEC 60950-1:2001 /EN 60950-1:2001
Following the provisions of the Directive(s) of the Council of the European Union:
•EMC Directive 89/336/EED
•Low Voltage Electrical Directive 72/23/EEC
Utah Scientific, Inc. hereby declares that the product specified above conforms to the above Directive(s)
and Standard(s).

iv MADI Terminal
Important Safeguards and Notices
This section provides important safety guidelines for the Operator and Service Personnel. Specific
warnings and cautions are found throughout the guide where they apply, but may not appear here. Please
read and follow the important safety information, specifically those instructions related to risk of fire,
electric shock, or injury to persons.
Safety Symbols
•Hazardous Voltage symbol
•Caution symbol. The product is marked with this symbol when it is necessary to
refer to the manual to prevent damage to the product.
Warnings
Please observe the following important warnings:
•Any instructions in this guide that require opening the chassis, changing a
power supply, or removing a board, should be performed by qualified personnel
only. To reduce the risk of electric shock, do not perform any service unless you
are qualified to do so.
•Heed all warnings on the unit and in the operating instructions.
•Do not use this product in or near water. Disconnect AC power before installing
any options or servicing the unit unless instructed to do so by this manual.
•This product is grounded through the power cord ground conductor. To avoid
electric shock, plug the power cord into a properly wired receptacle before con-
necting the product inputs or outputs.
•Route power cords and other cables so they won’t be damaged.
•The AC receptacle (socket) should be located near the equipment and be easily
accessible.
•Disconnect power before cleaning. Do not use any liquid or aerosol cleaner -
use only a damp cloth.

Setup and Operations Guide v
•Dangerous voltages exist at several points in this product. To avoid personal
injury, do not touch exposed conductors and components while power is on. Do
not insert anything into either of the systems two-power supply cavities with
power connected.
•Do not wear hand jewelry or watches when troubleshooting high current cir-
cuits, such as power supplies. During installation, do not use the door handles
or front panels to lift the equipment as they may open abruptly and injure you.
•To avoid fire hazard when replacing fuses, use only the specified correct type,
voltage and current rating as referenced in the appropriate parts list for this
product. Always refer fuse replacement to qualified service personnel.
•Have qualified personnel perform safety checks after any service.
Cautions
Please observe the following important cautions:
•When installing this equipment do not install power cords to building surfaces.
To prevent damage when replacing fuses, locate and correct the problem that
caused the fuse to blow, before reconnecting power.
•Use only specified replacement parts
Notices
Please observe the following important notes:
• When the adjacent symbol is indicated on the chassis, please refer to the man-
ual for additional information.
• For the HD-2020 Chassis and Master Control Panel, refer to “Connecting and
Disconnecting Power” - Chapter 2 (Hardware Installation).

vi MADI Terminal
Company Information
Utah Scientific, Incorporated
4750 Wiley Post Way, Suite 150
Salt Lake City, Utah 84116-2878 U.S.A.
•Telephone: +1 (801) 575-8801
•FAX: +1 (801) 537-3098
•Technical Services (voice): +1 (800) 447-7204
•Technical Services (FAX): +1 (801) 537-3069
•E-Mail -General Information: [email protected]
•E-Mail -Technical Services: [email protected]
•World Wide Web: http://www.utahscientific.com
•After Hours Emergency: +1 (800) 447-7204. Follow the menu instructions for Emergency Service.

Setup and Operations Guide
Warranty Policies
Hardware Warranty
Utah Scientific, Inc. warrants to the original purchaser that the Utah Scientific hardware is free
from defects in materials and workmanship and will perform substantially in accordance with
the accompanying written materials under normal use and service for a period of ten (10) years
from the date of shipment. Any implied warranties on hardware are limited to ten (10) years.
Some states/jurisdictions do not allow limitations on duration of an implied warranty, so the
above limitation may not apply to certain specific purchasers.
Software Warranty
Utah Scientific warrants that the software will perform substantially in accordance with the
accompanying written materials for a period of one (1) year from the date of shipment.
Customer Remedies
For the first one (1) year after purchase of the software and the first ten (10) years after the date
of purchase of the hardware, Utah Scientific’s and its suppliers’ entire liability and purchaser’s
exclusive remedy shall be, at Utah Scientific’s option, either:
• Return of the price paid, or
• Repair or replacement of the software or hardware that does not meet the above warranties
and is returned to Utah Scientific under the returned materials authorization (RMA)
process with freight and forwarding charges paid.
After the initial warranty periods, purchaser’s exclusive remedy is the repair or replacement of
the hardware upon payment of a fixed fee to cover handling and service costs based on Utah
Scientific’s then-current price schedule. The above warranties are void if failure of the
software or hardware has resulted from an accident, abuse, or misapplication. Any replacement
software or hardware will be warranted for the remainder of the original warranty period or
thirty (30) days, whichever is longer.

viii MADI Terminal
No other warranties. To the maximum extent permitted by applicable law, Utah Scientific and
its suppliers disclaim all other warranties, either express or implied, including, but not limited
to implied warranties of merchantability and fitness for a particular purpose, with regard to the
software, the accompanying written materials, and any accompanying hardware. This limited
warranty gives the purchaser specific legal rights. These rights may vary in certain states/
jurisdictions.
No liability for consequential damages. To the maximum extent permitted by applicable law,
in no event shall Utah Scientific or its suppliers be liable for any damages whatsoever
(including without limitation, damages for loss of business profits, business interruption, loss
of business information, or any other pecuniary loss) arising out of the use of or inability to use
Utah Scientific products, even if Utah Scientific has been advised of the possibility of such
damages. Because some states/jurisdictions do not allow the exclusion or limitation of liability
for consequential or incidental damages, the above limitation may not apply in those
circumstances.

MADI Terminal i
Table of Contents
Table of Contents
CHAPTER 1 MADI Terminal
General ........................................................................................................ 1-1
System Setup Information ............................................................................ 1-3
Unbalanced AES ................................................................................... 1-3
Balanced AES ....................................................................................... 1-4
Analog Audio ......................................................................................... 1-5
MADI Configuration ...................................................................................... 1-6
MADI Terminal System Boards .................................................................... 1-7
AES Audio Input (121360-1) ................................................................. 1-7
Controls and Indicators ..................................................................... 1-7
ADC Audio Input (121371-1) ................................................................. 1-9
Controls and Indicators ..................................................................... 1-9
DAC Audio Output (121372-1) .............................................................. 1-10
Controls and Indicators ..................................................................... 1-10
MADI Input (121362-1) .......................................................................... 1-12
Controls and Indicators ..................................................................... 1-12
MADI Output (121362-2) ....................................................................... 1-13
Controls and Indicators ..................................................................... 1-13
Balanced Digital Audio/Analog Audio (Pinout Connections) ................. 1-15
Controller (121364-1) ............................................................................ 1-17
Controls and Indicators ..................................................................... 1-17
Fiber Interface - (Optional) ........................................................................... 1-19
Specification Detail ................................................................................ 1-19
SFP Use ............................................................................................ 1-20
Rear Panel Layout (basic configuration) ........................................... 1-20

ii Table of Contents

MADI Terminal 1-1
Chapter
CHAPTER 1 MADI Terminal
General
The MADI Terminal is a 2RU chassis that has two primary functions, it converts AES or analog
audio into a Multichannel Audio Digital Interface (MADI/AES10) and it converts Multichannel
Audio Digital Interface into AES or analog audio. The MADI supports 32 pairs of 48 kHz digital
audio. This unit is capable of reporting signal information and errors via an Ethernet port or
serial port.
The chassis is made up of up to two power supplies, a controller board and two MADI bays.
The system usually arrives with a single power supply unless a redundant one has been
ordered. The controller board carries a CPU board and Timebase module that enable external
communication and distribute clocks for DARS timing of audio signals. Each MADI bays
consist of 3 audio I/O boards and a single MADI I/O board. The bays will be configured as
MADI inputs or outputs and will mate up with their corresponding AES or analog audio boards.
Figure 1-1. Chassis overview
Note: The above illustration contains the AES Unbalanced view. AES Balanced and
analog configurations will contain different rear panel layouts.

1-2 MADI Terminal
The audio signals that make up the MADI streams will come from or be delivered to the
input and output connectors as AES or analog signals. The MADI Output board receives
32 AES pairs that are individually analyzed and synchronized to the digital audio reference
(DARS) and are processed into a MADI Stream that is available at the BNC and Fiber
outputs. The MADI Input board receives a MADI signal from either the BNC or Fiber input
and extracts the 32 AES3 digital audio signals and distributes them to the audio outputs.
In a MADI output configuration there will be three audio input boards and a MADI output
board. In a MADI input configuration there will be a MADI input board and three audio
output boards. These input and output boards each have the capability interfacing to 11
audio signals but because of connector sizes and only needing a total of 32 signals
(3x11=33), some configurations will only use 10 of the 11 signal paths. Below you will find
a detailed explanation of the rear panels and their requirements.

MADI Terminal 1-3
Chapter
System Setup Information
Unbalanced AES
Unbalanced AES Inputs and Outputs will have 10 signals per input or output board making up
30 of the 32 pairs used in a MADI stream. The last two signals come from or are delivered to
two BNCs located on the MADI board rear panel. In this configuration (unbalanced inputs) the
SW1 switch #4 should be toward the CFG B silkscreen (“ON” position) to indicate the onboard
AES input/output ports will be used for the last two signals.
Note: Cabling should always be completed from top to bottom, and right to left.
Figure 1-2. Unbalanced AES Inputs and Outputs

1-4 MADI Terminal
Balanced AES
Balanced AES Inputs and Outputs will have 10 signals at the first board and 11 signals on
the next two boards (10+11+11=32) making up 32 of the 32 pairs used in a MADI stream.
The last two signals come from the last two I/O boards. In the balanced inputs
configuration, the SW1 switch #4 should be toward the CFG A silkscreen (“OFF” position)
to indicate the AES signals come from the I/O boards and not the onboard ports. In the
D-SUB 37 drawing below, pins IOA10, IOB10 and IOC10 will be where signals 30 and 31
are on located in this balanced configuration.
Note:. Signal 30 will be the last signal on the second connector shown in the
illustration (I/O 2). Signal 31 will be the last signal on the third connector
displayed below (I/O 3).
Figure 1-3. Rear Panel Layout (D-Sub 37) – IOA?=Pos, IOB?=Neg and IOC?=Shield.
Note: Cabling should always be completed from top to bottom, and right to left.

MADI Terminal 1-5
Chapter
Analog Audio
Analog audio Inputs and Outputs will have 10 signals at the first board and 11 signals on the
next two boards (10+11+11=32) making up 32 of the 32 pairs used in a MADI stream. The last
two signals come from the last two I/O boards. In the balanced inputs configuration, the SW1
switch #4 should be toward the CFG A silkscreen (“OFF” position) to indicate the AES signals
come from the I/O boards and not the onboard ports. The D-SUB 37 pin connector pinout is
the same as the AES pinout above. Below is the orientation of the left and right channels of
the analog audio connectors.
Note: Signal 30 will be the last signal on the second pair of connectors shown
in the illustration below (I/O 2). Signal 31 will be the last signal on the third pair
of connectors shown below labeled I/O 3.
Figure 1-4. Analog Audio Inputs and Outputs
Note: Cabling should always be completed from top to bottom, and right to left.

1-6 MADI Terminal
MADI Configuration
The MADI I/O boards have some configuration options that are setup with the dipswitch
SW1 found near the middle top half of the board. These should be preconfigured at the
factory before shipment.
.
Figure 1-5. MADI I/O Boards
Table 1-1.
MADI Input Bd Selects the type of MADI board MADI Output Bd
MADI BNC Selects the type of MADI interface MADI Fiber
Sig Det 0-15 elects which 16 signal detects are
assigned to the LEDs at the front of the
board
Sig Det 16-31
CFG A CFG A selects balanced rear panels
CFG B selects unbalanced rear panels
CFG B

MADI Terminal 1-7
Chapter
MADI Terminal System Boards
AES Audio Input (121360-1)
The AES Audio Input board receives up to 11 AES signals that are passed to the MADI Output
board. The number of signals passed is determined by the slot the board is installed in and the
type of rear panel interface used in the system. These signals are received and individually
analyzed to see if they qualify for synchronization to the digital audio reference (DARS).
Figure 1-6. AES Audio Input (121360-1)
Controls and Indicators
There are no controls on this card, other than P1. This is a standard UT400 diagnostic port
that provides detailed operational status and control for this card.
There are four types of LED indicators present on the front edge on this card
1. PWR OK -> Power supply indicator (green). This is illuminated when the local power
supplies are within tolerance.
2. DS1-11 (SIGDET1-11) -> Signal detection LEDs (green). This is illuminated when a valid
digital audio signal is detected on the associated receiver input.
3. DS15-25 (SYNCDET1-11) -> Sync detection LEDs (yellow). This is illuminated when a valid
input signal is found to be in sync with the router reference and is being processed
accordingly.
4. 1.2V and 3.3V -> Power supply fail indicators (red). This is illuminated when local voltages
fall out of 5% tolerance.

1-8 MADI Terminal
This board can be strapped for balanced or unbalanced interfaces by setting the jumpers
JP2-JP12, located at the back of the board, to 1-2 for unbalanced and 2-3 for balanced
(this will be set at the factory before shipping).
AES Audio Output (121361-1)
The AES Audio Output board receives up to 11 AES signals from the MADI Output board
and individually drives them to the system rear panel connectors. The number of signals
passed is determined by the slot the board is installed in and the type of rear panel
interface used in the system.
Figure 1-7. AES Audio Output (121361-1)
Controls and Indicators
There are no controls on this card.
There is only one type of LED indicators present on the front edge on this card.
1. PWR OK -> Power supply indicator (green). This is illuminated when the local power
supplies are within tolerance.
This board can be strapped for balanced or unbalanced interfaces by setting the jumpers
JP1-9 and JP11-12, located at the back of the board, to 1-2 for unbalanced and 2-3 for
balanced (this will be set at the factory before shipping).

MADI Terminal 1-9
Chapter
ADC Audio Input (121371-1)
The ADC Input board receives up to 11 L/R analog signals. These signals are received and
individually converted into AES3 signals that are aligned to the digital audio reference
(DARS). The number of signals passed is determined by the slot the board is installed in and
the type of rear panel interface used in the system.
Figure 1-8. ADC Audio Input (121371-1)
Controls and Indicators
There are no controls on this card, other than P1. This is a standard UT400 diagnostic port
that provides detailed operational status and control for this card.
There are four types of LED indicators present on the front edge on this card.
1. PWR OK -> Power supply indicator (green). This is illuminated when the local power
supplies are within tolerance.
2. DS1-22 -> odds (Left Signal Presence) -> Signal detection LEDs (green). This is illuminated
when a valid audio signal is detected on the associated receiver input.
3. DS1-22 -> evens (Right Signal Presence) -> Signal detection LEDs (yellow). This is
illuminated when a valid audio signal
is detected on the associated receiver input.
4. FPGA OK -> FPGA prom load indicator (yellow). This is illuminated when FPGA device is
loaded correctly.
5. COMMS -> Communications indicator (yellow). This is illuminated when the Frame
Controller

1-10 MADI Terminal
Module addresses this card.
6. DS29 -> 5V low indicator (red). This is illuminated when 5V supply falls out of 5%
tolerance.
7. DS28 -> 3.3V low indicator (red). This is illuminated when 3.3V supply falls out of 5%
tolerance.
8. DS29 -> 1.2V low indicator (red). This is illuminated when 1.2V supply falls out of 5%
tolerance.
9. DS29 -> +12V\-12V low indicator (red). This is illuminated when +12V or -12V supplies
falls out of 5% tolerance.
This board has high impedance inputs (e.g. 100k ohm). In instances when a
600 ohm input impedance is needed, the factory can strap the inputs to provide the
appropriate level.
DAC Audio Output (121372-1)
The DAC Audio output board receives up to 11 AES3 signals that are passed to the MADI
Output board. These signals are individually distributed to the digital to analog converter
outputs and after conversion to analog audio are then driven to the system rear panel
connectors. The number of signals passed is determined by the slot the board is installed
in and the type of rear panel interface used in the system.
Figure 1-9. DAC Audio Output (121372-1)
Controls and Indicators
There are no controls on this card, other than P1. This is a standard UT400 diagnostic port
that provides detailed operational status and control for this card.
There are four types of LED indicators present on the front edge on this card
Table of contents
Popular Touch Terminal manuals by other brands

Mitsubishi Electric
Mitsubishi Electric GOT2000 Series Connection manual

BIXOLON
BIXOLON BCD Series Windows driver manual

ZKTeco
ZKTeco RevFace15 installation guide

Festo
Festo CPV-ASI-8E8A-ZCE Series Brief description

Rockwell Automation
Rockwell Automation Allen-Bradley DeviceNet 193-DNCT user manual

Omron
Omron NS7 Series Setup manual
