UTC Fire and Security ZP1-X3E Series User manual

ZP1-X3E Series Installation
Manual
www.acornfiresecurity.com
www.acornfiresecurity.com

Copyright
©
2014 UTC Fire & Security. All rights reserved.
Trademark
s and
patents
ZP1
-X3E Series is a trademark of UTC Fire & Security.
Other trade names used in this document may be trademarks or
registered trademarks of the manufacturers or vendors of the
respective produc
ts.
Manufacturer
UTC CCS Manufacturing Polska Sp. Z o.o.
Ul. Kolejowa 24. 39
-100 Ropczyce, Poland
Authorized EU manufacturing representative:
UTC Fire & Security B.V. Kelvinstraat 7, 6003 DH Weert,
Netherlands
Version
This document covers control panels with firmware version 2.0 or
later
.
Certification
European Union
directives
1999/5/EC (R&TTE directive): Hereby, UTC Fire & Security declares
that this device is in compliance with the essential requirements and
other relevant provisions of Directi
ve 1999/5/EC.
www.acornfiresecurity.com
www.acornfiresecurity.com

ZP1-X3E Series Installation Manual i
Content
Important information ii
Chapter 1 Introduction 1
Product description 2
Product compatibility 2
Operating modes 2
Chapter 2 Installation 3
Control panel cabinet layout 4
Cabinet installation 5
Connections 7
Chapter 3 Configuration and commissioning 23
The user interface 25
User levels 26
Configuration overview 27
Basic configuration 31
Advanced configuration 37
Expansion board configuration 60
Fire network and repeaters configuration 62
Commissioning 70
Chapter 4 Maintenance 75
System maintenance 76
Battery maintenance 77
Chapter 5 Technical specifications 79
Zone specifications 80
Input and output specifications 81
Power supply specifications 83
Mechanical and environmental specifications 84
Appendix A Configuration presets 87
Input and output configuration 88
Default delays 88
Basic configuration modes 89
Expansion board functions 91
Appendix B Regulatory information 99
European standards 100
Declared performance 101
Electrical safety 101
Index 103
www.acornfiresecurity.com
www.acornfiresecurity.com

ii ZP1-X3E Series Installation Manual
Important information
This is the installation manual for the ZP1-X3E Series Extinguishing and Fire
Alarm Control Panels. Read these instructions and all related documentation
entirely before operating this product.
Firmware compatibility
Information in this document covers control panels with firmware version 2.0 or
later. This document must not be used as a guide to installation, configuration, or
operation of control panels with an earlier firmware version.
For instructions on how to check the firmware version of your control panel, see
“Configuration, software, and PCB identification” on page 59.
Advisory messages
Advisory messages alert you to conditions or practices that can cause unwanted
results. The advisory messages used in this document are shown and described
below.
WARNING: Warning messages advise you of hazards that could result in injury
or loss of life. They tell you which actions to take or to avoid in order to prevent
the injury or loss of life.
Caution: Caution messages advise you of possible equipment damage. They tell
you which actions to take or to avoid in order to prevent the damage.
Note: Note messages advise you of the possible loss of time or effort. They
describe how to avoid the loss. Notes are also used to point out important
information that you should read.
Limitation of liability
To the maximum extent permitted by applicable law, in no event will UTCFS be
liable for any lost profits or business opportunities, loss of use, business
interruption, loss of data, or any other indirect, special, incidental, or
consequential damages under any theory of liability, whether based in contract,
tort, negligence, product liability, or otherwise. Because some jurisdictions do not
allow the exclusion or limitation of liability for consequential or incidental
damages the preceding limitation may not apply to you. In any event the total
liability of UTCFS shall not exceed the purchase price of the product. The
foregoing limitation will apply to the maximum extent permitted by applicable law,
regardless of whether UTCFS has been advised of the possibility of such
damages and regardless of whether any remedy fails of its essential purpose.
www.acornfiresecurity.com
www.acornfiresecurity.com

ZP1-X3E Series Installation Manual iii
Installation in accordance with this manual, applicable codes, and the instructions
of the authority having jurisdiction is mandatory.
While every precaution has been taken during the preparation of this manual to
ensure the accuracy of its contents, UTCFS assumes no responsibility for errors
or omissions.
www.acornfiresecurity.com
www.acornfiresecurity.com

iv ZP1-X3E Series Installation Manual
www.acornfiresecurity.com
www.acornfiresecurity.com

ZP1-X3E Series Installation Manual 1
Chapter 1
Introduction
Summary
This chapter provides an introduction to your control panel and the available
operating modes
Content
Product description 2
Product compatibility 2
Operating modes 2
www.acornfiresecurity.com
www.acornfiresecurity.com

Chapter 1: Introduction
2 ZP1-X3E Series Installation Manual
Product description
The ZP1-X3E Series control panel provides three fire detection zones (Z1, Z2,
and Z3) and several manual call point (MCP) and control inputs that control the
extinguishing actions for a single extinguishing area.
If a fire detection zone is not configured as part of the extinguishing detection
area, the control panel provides standard fire panel functionality for that fire
detection zone (for example, the panel activates fire sounders, fire routing, and
other auxiliary outputs).
Product compatibility
Products compatible with this control panel are listed in the supplied compatibility
list. Compatibility with products that are not listed in that document cannot be
guaranteed. For further details contact your local supplier.
Note: The CleanMe self-diagnostics feature listed in selected presets is not
available for ZP1-X3E Series devices.
Operating modes
Supported operating modes are shown in the table below. The default operating
mode is EN 54-2 (with EN 54-13 supervision disabled).
Table 1: Operating modes
Operating mode
EN 54-13 option [1] Region
EN 54
-2 (default) Yes [2] European Union
BS 7273
No United Kingdom
Repeater
with fire routing (EN 54-2)
No European Union
Repeater
with fire routing (BS 7273)
No United Kingdom
[1] EN 54
-13 supervision requires compatible system wiring and devices and must be enabled by
the installer in the control panel configuration.
[2] EN 54-13 supervision is available in zones and expansion board outputs.
www.acornfiresecurity.com
www.acornfiresecurity.com

ZP1-X3E Series Installation Manual 3
Chapter 2
Installation
Summary
This chapter explains how to install your control panel, how to connect zones, fire
and extinguishing system devices, and the power supply.
Note: This product must be installed and maintained by qualified personnel
adhering to the CEN/TS 54-14 standard (or the corresponding national standard)
and any other applicable regulations.
Content
Control panel cabinet layout4
Cabinet installation 5
Preparing the cabinet 5
Where to install the cabinet 5
Fixing the cabinet to the wall 5
Connections 7
Recommended cables 7
Connecting zones with initiating devices 7
Connecting inputs 10
Connecting outputs 14
Connecting the mains power supply 17
Connecting the batteries 18
Connecting other equipment 19
Connecting expansion boards 20
Connecting a fire network 20
www.acornfiresecurity.com
www.acornfiresecurity.com

Chapter 2: Installation
4 ZP1-X3E Series Installation Manual
Control panel cabinet layout
Figure 1: Control panel cabinet layout
1. Seven-segment display
2
. Zone, input, output, and relay connectors
3
. Cable knockouts
4
. Mounting screw knockouts
5
. Network board connector (on the back of
the PCB)
6
. Battery area
7. Power supply unit
8
. Key connector (see note)
9
. Fuse terminal block
10
. Power supply connector
11
. Battery connector
12
. Expansion board connector
13. Cable holder
Note: The control panel is available with a key option. The key switch is located
on the panel cover. With this option, either the key or the password can be used
to enter the operator user level. This key can also be configured to be used in
manual-only or manual-automatic mode.
www.acornfiresecurity.com
www.acornfiresecurity.com

Chapter 2: Installation
ZP1-X3E Series Installation Manual 5
Cabinet installation
Preparing the cabinet
Before installing the cabinet, remove the front cover, and then remove cable
knockouts from the top, bottom, and rear of the cabinet as required.
Where to install the cabinet
Make sure the installation location is free from construction dust and debris, and
immune to extreme temperature ranges and humidity. (See “Mechanical and
environmental specifications” on page 84 for more information on the operating
temperature and relative humidity specifications.)
Allow for enough floor and wall space so the panel can be installed and serviced
without any obstructions. The cabinet should be mounted so that the user
interface is at eye level.
Note that the control panel must be assembled and installed according to the
ordinances and codes that are in effect in your market or region.
Fixing the cabinet to the wall
Fix the cabinet to the wall using five M4 × 30 screws and five 6 mm diameter wall
plugs, as shown below.
www.acornfiresecurity.com
www.acornfiresecurity.com

Chapter 2: Installation
6 ZP1-X3E Series Installation Manual
Figure 2: Mounting hole locations
To fix the control panel cabinet to the wall:
1. Mark drill points on the wall, using the cabinet as a template.
2. Drill all required holes and insert a 6 mm wall plug into each.
3. Insert a screw in position (1) and hang the cabinet onto this screw.
4. Insert screws in positions (2) and tighten.
5. Insert screws in position (3) and tighten.
6. Tighten screw in position (1).
www.acornfiresecurity.com
www.acornfiresecurity.com

Chapter 2: Installation
ZP1-X3E Series Installation Manual 7
Connections
WARNING: Electrocution hazard. To avoid personal injury or death from
electrocution, do not make any control panel or system connections while the
control panel is connected to the mains power supply.
Recommended cables
Recommended cables for optimal system performance are shown in the table
below.
Table 2: Recommended cables
Cable
Cable description Cable length
Mains cable
3 x 1.5 mm² N/A
Zone
cable (mixed zone) Twisted-pair (40 Ω and 500 nF max.)
12 to 26 AWG (0.13 to 3.31 mm²) 2 km max.
Zone
cable (automatic or
manual zones)
Twisted-pair (55 Ω and 500 nF max.) 12 to 26 AWG (0.13 to 3.31 mm²) 2 km max.
Fire network cable
Twisted-pair, Cat 5
12 to 26 AWG (0.13 to 3.31 mm²) 1.2 km max.
Note: Other types of cable may be used subject to site-specific EMI conditions
and installation testing.
Use 20 mm cable glands to ensure clean and secure connections at the control
panel cabinet. All cables should be fed through the cable guides in the cabinet
housing to eliminate movement.
Connecting zones with initiating devices
Zone configuration
The control panel has three fire detection zone inputs, marked Z1, Z2, and Z3 on
the control panel PCB to define the extinguishing area.
By default, Z1 and Z2 cover the extinguishing area and are configured for
automatic detection of an extinguishing event. (Both zones must be in fire alarm
condition to determine an extinguishing event.) The default configuration for Z3
provides standard fire detection as a mixed zone (using automatic or manual fire
alarm detection).
Additional zone configuration options are available - see “Extinguishing zones”
on page 45 more information.
www.acornfiresecurity.com
www.acornfiresecurity.com

Chapter 2: Installation
8 ZP1-X3E Series Installation Manual
Connecting zones
Figure 3 below shows connections for the default configuration (option 2).
Figure 3: Connecting zones for the default configuration
1
. Zones in the extinguishing area
2
. Zone for standard (mixed) fire detection
3
. Galvanic barrier (for intrinsically safe
conventional detectors / intrinsically safe
mode only)
4
. Zone termination (see “Terminating zones
”
below)
Line resistance
Line resistance is shown in the following table.
Table 3: Zone line resistance values
Zone type
EN 54-2, BS 7273 EN 54-13 Intrinsically safe
Mixed detection
40 Ω max. Not supported [1] Not supported [1]
Automatic detection
55 Ω max. 50 Ω max 50 Ω max
Manual detection
55 Ω max. 50 Ω max 50 Ω max
[1] Mixed zones are not permitted in installations requiring EN 54-13 or intrinsically safe
configurations.
To measure the line resistance:
1. Disconnect all zone devices.
2. Create a short circuit at the end of the zone line.
3. Measure the resistance between the positive and negative lines with a
multimeter.
Terminating zones
Zone termination is required at all times, whether the zone is used or not. The
type of termination depends on the installation, as shown below.
www.acornfiresecurity.com
www.acornfiresecurity.com

Chapter 2: Installation
ZP1-X3E Series Installation Manual 9
Table 4: Zone termination
Installation type
Termination
EN 54
-2 4.7 kΩ, 5%, 1/4 W end-of-line resistor
BS 7273
Active end-of-line device (see note below)
EN 54
-13 EOL-Z end of line device (polarity sensitive)
Intrinsically safe
4.7 kΩ, 5%, 1/4 W end-of-line resistor
Note: For BS 7273 installations an active end-of-line device must be installed
(instead of an end-of-line resistor). Unused zones must be terminated with an
active end-of-line device or configured as passive end-of-line and terminated with
a 4.7 kΩ, 5%, 1/4 W end-of-line resistor.
The type of zone termination can be configured on a zone-by-zone basis. See
“Zone configuration” on page 55. Advanced installer user level access is
required.
Connecting fire detectors
Connect detectors as shown in Figure 3 on page 8.
The panel supports conventional detectors. To guarantee optimal operation, use
the detectors specified in the compatibility list. For more information on fire
detectors, see Chapter 5 “Technical specifications” on page 79.
Note: For BS 7273 installations a diode must be connected on the detector base
(see your detector installation manual for more details).
Connecting fire alarm manual call points
Connect fire alarm manual call points in parallel. Each fire zone can support a
maximum of 32 manual call points.
In zones used for fire detection, manual call points must have a resistance
installed in series with the normally open (NO) contact for activation. This avoids
reporting a short circuit fault and allows identification of the alarm type (automatic
or manual) based on the impedance.
In zones used for the extinguishing area, alarms are always reported as
automatic (detector), but indications may vary for other panels in a network. A
series impedance is also required to avoid reporting a short circuit fault.
The resistance required depends on the zone type, as shown in the table below.
Resistance must be rated at 1 W minimum.
Table 5: Fire alarm manual call point resistance values
Zone type
EN 54-2, BS 7273 EN 54-13 Intrinsically safe
Mixed detection
100 Ω Not supported Not supported
Manual detection
100 to 680 Ω 100 to 470 Ω250 to 560 Ω
www.acornfiresecurity.com
www.acornfiresecurity.com

Chapter 2: Installation
10 ZP1-X3E Series Installation Manual
Connecting inputs
Input functionality
Each control panel has eight inputs, marked IN1 to IN8 on the control panel PCB.
Input functionality is shown in the table below.
Table 6: Input functionality
Input
Function Supervision
IN1
Start extinguishing manual call point Supervised
IN2
Hold extinguishing manual call point Supervised
IN3
Abort extinguishing manual call point
Disable extinguishing switch (BS 7273 mode) Supervised
IN4
Manual-only mode activation device Unsupervised
IN5
Low pressure indication Supervised
IN6
Extinguishing agent flow Supervised
IN7
Safety door fault monitoring Supervised
IN8
Remote reset Unsupervised
Input termination
Only supervised inputs require a 15 kΩ, 5%, 1/4 W end-of-line resistor for
termination. If a supervised input is not used, the end-of-line resistor must be
installed across the unused terminals.
Connecting inputs
Connect inputs IN1 to IN8 as shown below.
Figure 4: Connecting inputs
See “Input and output specifications” on page 81 for the input circuit parameters.
www.acornfiresecurity.com
www.acornfiresecurity.com

Chapter 2: Installation
ZP1-X3E Series Installation Manual 11
Connecting extinguishing system manual call points
The manual call point inputs require an activation impedance between 100 and
620 Ω, 2 W. These are normally connected in series with a normally open (NO)
contact. An end-of-line resistance of 15 kΩ is required.
When the abort extinguishing or hold extinguishing manual call points are
activated, the control panel activates the related relay outputs on the main board.
Note: MCP Hold faults and MCP Abort faults prevent the panel from entering the
extinguishing activation state (because of life safety issues) and from activating
the actuator (to ensure property protection).
The extinguishing system supports three types of manual call point (MCP):
• MCP Start
• MCP Hold
• MCP Abort
Descriptions of each MCP type follow.
MCP Start. Starts the extinguishing process. When the panel is in the standby,
extinguishing preactivation, or fire alarm state, activation of this device puts the
panel in the extinguishing activation state.
The control panel can be configured to bypass any actuator delay and to activate
the actuator immediately on entering the extinguishing activation state. To
configure this, set the “Actuator delay for Start MCP” to OFF.
MCP Hold. Holds the extinguishing process. When the panel is in the
extinguishing activation state, the actuator output is not activated while the MCP
Hold device is activated (continuously). The MCP Hold input can be configured
for two different operating modes, Mode A and Mode B.
Table 7: MCP Hold operating modes
Mode
Description
Mode A
When the MCP Hold is activated, the actuator delay countdown continues,
but the panel is prevented from entering the extinguishing activation state.
When the MCP Hold is deactivated, the delay countdown determines when
the panel enters the extinguishing activation state.
In this mode, activation of the MCP Hold turns on the MCP Hold LED, which
stays on until the panel is manually reset. The yellow Preactivation LED
flashes to indicate that the panel is being prevented from entering the
extinguishing activation state. The Preactivation LED flashes to show when
the MCP Hold is on; it turns off when the MCP Hold is off.
Mode B
When the MCP Hold is activated, the actuator delay countdown stops, putting
the extinguishing release process on hold. The sounders emit a unique
sound pattern (1 second on, 4 seconds off) while the extinguishing release
process is on hold. When the MCP Hold is deactivated, the delay countdown
restarts and the sounder pattern changes to the tone configured for
extinguishing activation. The MCP Hold LED turns off when the MCP Hold
device is deactivated.
www.acornfiresecurity.com
www.acornfiresecurity.com

Chapter 2: Installation
12 ZP1-X3E Series Installation Manual
See “Hold mode” on page 43 for instructions on setting the MCP Hold operating
mode.
MCP Abort. Aborts the extinguishing process. During the standby, extinguishing
preactivation, extinguishing activation, and fire alarm states, activating the MCP
Abort device prevents the extinguishing process until the MCP Abort device is
deactivated and the control panel is reset.
Connecting a disable extinguishing switch
Use the disable extinguishing input IN3 (BS 7273 mode) to disable the
extinguishing process remotely (requires operator level access).
Connecting an external device for manual-only mode control
When the control panel is in manual-only mode, the extinguishing process can
only be initiated manually, using the MCP Start device. Automatic extinguishing
events reported by the fire detection zones are disabled for extinguishing
activation.
This mode of operation can be used when the user interface is not suitable for
your application and a remote control is needed.
A manual-only mode input device is used to switch the panel to this mode. In
addition to connecting a manual-only mode activation device, you must configure
the system by setting the “Manual-only mode local” option to OFF.
Note: EU ordinances and regulations require the use of a key switch to control
access to this function.
See “Input and output specifications” on page 81 for the required impedance
values for this unsupervised input.
Connecting a low pressure indication switch
Use the low pressure indication input to detect low pressure in the extinguishing
agent container.
The “Pressure switch type” option defines whether the device detects low
pressure when open or when closed. In the device standby state, either normally
open or normally closed, the input is not interpreted as a low pressure fault. The
default setting is normally closed (NC). This results in a low pressure fault when
the switch opens.
See “Input and output specifications” on page 81 to see how the low pressure
indication device impedance is related to the low pressure fault.
Connecting an extinguishing agent flow device
Use the extinguishing agent flow input to connect a device that detects the
release of the extinguishing agent from its container into the extinguishing area.
Note: Before you connect a device to the extinguishing agent flow input, make
sure that it is compatible with the required input impedance levels of the control
panel, as specified in “Input and output specifications” on page 81.
www.acornfiresecurity.com
www.acornfiresecurity.com

Chapter 2: Installation
ZP1-X3E Series Installation Manual 13
The “Extinguishing agent flow” option lets you define the functionality of this
device. Here are the details.
When the extinguishing agent flow option is set to OFF, the panel enters the
extinguishing released state when the actuator output is activated. The panel
does not require confirmation of the flow to enter this state. The extinguishing
agent flow circuitry continues to operate for indication purposes. The panel will
not enter the release state when the extinguishing agent flow device is active
without first entering the extinguishing activation state (that is, when an
extinguishing event is detected).
When the extinguishing agent flow option is set to ON, the control panel can
enter the extinguishing released state from any state, once the extinguishing
agent flow device is activated. In extinguishing released state, the panel activates
all corresponding outputs, except for the actuator output.
Connecting a safety door fault monitoring device
The safety door fault monitoring input lets the panel monitor a door in the
extinguishing area. The monitored door becomes a safety door.
A safety door fault means that the door is in a position that will prevent the
release process, given the current operating mode of the panel. A safety door
fault prevents the panel from entering the extinguishing activation state (because
of life safety issues) and activating the actuator (to ensure property protection).
When the panel is in manual-only mode, the safety door must be open. A closed
door signal is interpreted as a fault.
When the panel is in manual-automatic mode, the safety door must be closed.
An open door signal is interpreted as a fault.
You can configure a delay before the panel interprets a safety door monitor
signal as a fault. This allows for momentary opening or closing of the door for
routine traffic. The delay is bypassed when the panel enters the extinguishing
activation or extinguishing released states.
By default, the control panel is configured for basic applications which do not use
this monitoring function. If your installation requires it, activate the function by
setting the “Safety door monitoring” option to ON, and specifying a “Safety door
fault delay” between 10 and 90 seconds.
Here are the operating details of the function.
When the panel is not in extinguishing activation or extinguishing released states:
• For manual-automatic mode, the panel reports a fault if the door is open and
the door fault delay expires
• For manual-only mode, the panel reports a fault if the door is closed and the
door fault delay expires
When the system is in extinguishing activation or extinguishing released states,
no matter which operating mode, the panel reports a fault if the door is open.
www.acornfiresecurity.com
www.acornfiresecurity.com

Chapter 2: Installation
14 ZP1-X3E Series Installation Manual
Connecting a remote reset device
The remote reset input allows the control panel to be reset from a remote
location. The reset operation is the same as using the Reset button on the
control panel user interface.
Note: EU ordinances and regulations require the use of a key switch to control
access to this function.
The remote reset is executed when the input device switches from deactivated to
activated. See “Input and output specifications” on page 81 for the impedance
values for this unsupervised input.
Connecting outputs
Output functionality
Each control panel has eight outputs, marked OUT1 to OUT8 on the control
panel PCB. Output functionality is shown in Table 8 below.
Table 8: Output functionality
Output
Function Type and status
OUT1
Hold extinguishing manual call point Free-of-voltage (unsupervised switch)
Hold inactive = open
Hold active = closed
OUT2
Abort extinguishing manual call point
Disable extinguishing switch
(BS 7273 mode)
Free-of-voltage (unsupervised switch)
Abort inactive = open
Abort active = closed
Free-of-voltage (unsupervised switch)
Enabled = open
Disabled = closed
OUT3
Manual-only mode Free-of-voltage (unsupervised switch)
Manual-automatic = open
Manual-only = closed
OUT4
Extinguishing released Free-of-voltage (unsupervised switch)
Released inactive = open
Released = closed
OUT5
Fire sounders Supervised (standard)
Off = −11 VDC (supervision)
On = +24 VDC
OUT6
Extinguishing sounders Supervised (standard)
Off = −11 VDC (supervision)
On = +24 VDC
OUT7
Extinguishing released optical warning
panels or signs Supervised (standard)
Off = −11 VDC (supervision)
On = +24 VDC
www.acornfiresecurity.com
www.acornfiresecurity.com
