UTP BALUN P12DC4P-3 User manual

P-80
R201208-V20
4 Port 12V DC CCTV Power Supply
Model: P12DC4P-3
Features:
•4-port 3Amps 12V DC Power Supply Box
•Output current 1.1Amps (max.) for each port
•Built-in PTC (positive temperature coefficient) for short protection and auto rework and LED indicators on each port
•High voltage protection
•Over current protection
•Applicable for CCTV camera, PTZ, IR illuminator, video processor, access control, etc.
•100V~240V AC input
▲Battery not included
Specification:
Model P12DC4P-3
Port 4 ports
Power Properties
Output Voltage 12V DC +/- 5% - Can be adjusted from 12V~14.8V at VR1
Output Current 3Amps
Input Voltage 100V~240V AC
Input Voltage Frequency 50Hz / 60Hz
Max. Amp per Channel 1.1Amps
Fuse Type PTC (Resettable)
Physical Properties Dimensions L x W x H 17 x 6 x 17 cm / 6.7 x 2.4 x 6.7 inches
Weight 0.8 kg / 1.76 lbs
Environment Storage Temperature -30ºC ~ 70ºC / -22ºF ~ 158ºF
Operation Temperature -10ºC ~ 45ºC / 14ºF ~ 113ºF
*Specifications are subject to change without notice.
Package Contents:
•One (1) CCTV Power Supply
•One (1) User Manual
Caution:
•Do not connect this device to any power source other than the specified power.
•Do not handle the unit with wet hands.
•The unit is for indoors only.
USER MANUAL
W: 6.7” / 17cm
D: 2.4” / 6cm
H: 6.7” / 17cm
▲Battery not included

P-80
R201208-V20
Limited Warranty:
LIMITED ONE (1) YEAR WARRANTY AND EXCLUSIONS
Manufacturer warrants to the original consumer purchaser and not for the benefit of anyone else that this product at the time of
its sale by Manufacturer is free of defects in materials and workmanship under normal and proper use for one (1) year from the
purchase date. Manufacturer's only obligation is to correct such defects by repair or replacement, at its option, if within such one
(1) year period the product is returned prepaid, with proof of purchase date, and a description of the problem. This warrant
excludes and there is disclaimed liability for labor for removal of this product or reinstallation. This warranty is voided if this
product is installed improperly or in an improper environment, overloaded, misused, opened, abused, or altered in any
manner, or is not used under normal operating conditions or not in accordance with any labels or instructions. There
are no other implied warranties of any kind, including merchantability and fitness or a particular purpose, but if any
implied warranty is required by the applicable jurisdiction, the duration of any such implied warrant, including merchantability and
fitness of or a particular purpose, is limited to one (1) year. Manufacturer is not liable for incidental, indirect, special, or
consequential damages, including without limitation, damage to, or loss of use of, any equipment, loss sales or profits
or delay or failure to perform this warranty obligation. The remedies, provided therein are the exclusive remedies under this
warranty, whether based on contract, tort or otherwise.
