Copyright 2011-2012. 1 C-48
Specifications & appearance are subject to change without notice. R201208-V20
16 Input to 48 Output BNC Video Distributor
Model: VD16248BNC
Features:
Real-time color signal
Compatible with NTSC, PAL, and SECAM
Excellent signal restoration
110V AC or 220V AC Power Supply
Application Diagram:
Note: Graphic shown above is 110V AC version.
Panel View:
Front
Rear
USER MANUAL
Copyright 2011-2012. 2 C-48
Specifications & appearance are subject to change without notice. R201208-V20
Specification:
Model
VD16248BNC
Connection Properties
Input Video
16x BNC, 0.7~1.4Vp-p, 75 Ohms
Output Video
48x BNC, 0.7~1.4Vp-p, 75 Ohms
Protection
Anti-Surge Capability
6000V 1.2/50µS
Video Properties
Frequency Response
10MHz + 1dB
S/N
> 60dB
Insertion Loss
0dB
Power Properties
Operating Voltage
110V AC or 220V AC, 50Hz, 5W
Physical Properties
Dimension L x W x H
484 x 90 x 100 mm / 19.06 x 3.54 x 3.94 inches
Weight
2116 g / 4.66 lbs
Environment
Operation Temperature
-25°C ~ 70°C / -13°F ~ 158°F
Humidity
0~95% (non-condense)
*Specifications are subject to change without notice
Package Contents:
One (1) BNC Video Distributor
One (1) User Manual
Caution:
Do not connect this device to any power source other than what is supplied.
Do not handle the unit with wet hands.
The unit is not waterproof and should not be used outdoors.
Limited Warranty:
LIMITED ONE (1) YEAR WARRANTY AND EXCLUSIONS
Manufacturer warrants to the original consumer purchaser and not for the benefit of anyone else that this product at the time of its
sale by Manufacturer is free of defects in materials and workmanship under normal and proper use for one (1) year from the
purchase date. Manufacturer's only obligation is to correct such defects by repair or replacement, at its option, if within such one (1)
year period the product is returned prepaid, with proof of purchase date, and a description of the problem. This warrant excludes
and there is disclaimed liability for labor for removal of this product or reinstallation. This warranty is voided if this product is
installed improperly or in an improper environment, overloaded, misused, opened, abused, or altered in any manner, or is
not used under normal operating conditions or not in accordance with any labels or instructions. There are no other
implied warranties of any kind, including merchantability and fitness or a particular purpose, but if any implied warranty is
required by the applicable jurisdiction, the duration of any such implied warrant, including merchantability and fitness of or a
particular purpose, is limited to one (1) year. Manufacturer is not liable for incidental, indirect, special, or consequential
damages, including without limitation, damage to, or loss of use of, any equipment, loss sales or profits or delay or failure
to perform this warranty obligation. The remedies, provided therein are the exclusive remedies under this warranty, whether
based on contract, tort or otherwise.
