UV ANGEL ADAPT™
OPERATIONS MANUAL

888.277.2596 • [e-mail] • UVANGEL.COM
Copyright UV Partners, Inc. All rights reserved. UV Angel® and
UV Angel Air® are registered trademarks of UV Partners, Inc.
WARNINGS
IT IS ESSENTIAL THAT THE USER OF THIS MANUAL IS AWARE OF THE POTENTIAL HAZARDS
ASSOCIATED WITH THIS PRODUCT.
IF THE UNIT IS USED IN A MANNER NOT SPECIFIED BY THE MANUFACTURER, THE PROTECTION
PROVIDED BY THE EQUIPMENT MAY BE IMPAIRED.
The following symbols are used in this manual and on the UV Angel Adapt:
Ultra Violet Light Hazard
Caution / Warning
This manual must be consulted in all cases were these symbols are marked.
Ultra Violet Light Hazard
UV-C light should always be directed AWAY from the eyes and skin, as serious skin burn and eye
inammation from prolonged exposure can occur. UV-C radiation can be harmful to the eyes and skin.
Warning
• Do not position such that it is difcult to disconnect the Micro-USB power cable from the back of the
product.
• This product should not be handled or used by children.
• This product is not intended for use on humans or animals.
• Do not expose this product to excessive moisture to prevent re or shock hazard. Not intended for
use in uids. Avoid use if device, cables, or attached equipment becomes wet.
• The lamp in this product contains a trace amount of mercury, a chemical known to the state of
California to cause birth defects or other reproductive harm. This substance may also cause injury if
inhaled or ingested.
Caution
• No serviceable parts. For service of this product please contact UV Angel.
• Changes or modications to this product will void warranty.
• Take care to prevent lamp breakage.
• The product should not be exposed to any uids. Exposure to uids will void warranty.
• Not intended for use on food.
• With prolonged or overexposure, UV-C light may degrade or discolor fabrics, plastic and rubber.
• Lamps should be disposed of per local regulations. For more information on clean-up and disposal,
see www.lamprecycle.org.
• Changes or modications to this product not expressly approved by UV Angel could void the user’s
authority to operate the product.

888.277.2596 • [e-mail] • UVANGEL.COM
Copyright UV Partners, Inc. All rights reserved. UV Angel® and
UV Angel Air® are registered trademarks of UV Partners, Inc.
Reminder
Before you accept delivery of product, please check unit
for any damage that may have occurred during shipment.
Please report damage immediately to the carrier who
delivered the unit before acknowledging receipt.
Please keep a copy of this manual in your records for
future reference.
Disclaimer: This document is subject to change at any
time without notication. Please reference www.uvangel.
com or contact [email protected] for the latest
information on all UV Angel products.
DIRECTIONS FOR USE
Step 1 - Unpack contents from box.
Follow specic Installation & Operating instructions included with your package.
Step 2 - Attach UV Angel Adapt
Step 3 - Connect to power
Step 4 - Mobile provisioning

888.277.2596 • [e-mail] • UVANGEL.COM
Copyright UV Partners, Inc. All rights reserved. UV Angel® and
UV Angel Air® are registered trademarks of UV Partners, Inc.
1. With no interaction UV Angel Adapt will treat the surface every hour. The indicator is BLUE during treatment and
GREEN between treatments.
2. When UV Angel Adapt detects an interaction with the monitored surface the indicator changes from GREEN to
RED.
3. Once interaction ceases, UV Angel Adapt will start a treatment cycle turning the UV-C lamp on and change the
indicator from RED to BLUE.
4. When the treatment is completed the indicator light will change to and remain GREEN until the next interaction.
NOTES:
UV-C light hazard during treatment. Avoid looking directly at light.
• User interaction is detected by motion, vibration and orientation sensors.
• Interaction detection turns off treatment.
Lamp Life
UV Angel Adapt keeps track of the treatment lamp 30,000 hour affective life.
• The indicator will ash purple for 30 seconds upon the start of treatment when 5% life remains.
• The indicator will ash purple continuously when the lamp is expired and must be serviced at a UV Angel
authorized service center.
• Lamp life varies based on usage and treatment time.
• Treatment times vary based on the application.
OPERATION
How it Works
UV Angel Adapt treats monitored surfaces with a low-dose UV-C light treating pathogens around the clock.
Status Indicator

888.277.2596 • [e-mail] • UVANGEL.COM
Copyright UV Partners, Inc. All rights reserved. UV Angel® and
UV Angel Air® are registered trademarks of UV Partners, Inc.
UV ANGEL ADAPT SPECIFICATIONS
Model No. 100-1208
Mechanical
Dimensions 6.0” X 1.4” X 1.0” (LxWxH)
Weight 2 oz
Electrical
Power Requirements 5Vdc, 500mA (2.5 W) Maximum
Comm/Power Port USB Micro-B
LPS External Power 5Vdc at a Minimum 500mA
Limited Power Supply not provided
Environmental
Indoor Use Only
Operating Temperature 10°C to 50°C (50°F to 122°F)
Storage Temperature -30°C to 70°C (-22°F to 158°F)
Operating Humidity 10% to 95% RH (non-condensing)
Storage Humidity 95% RH Maximum (non-condensing)
Pollution Degree 2
Altitude of Operation 3000m Maximum
Approvals
FCC 47 CFR Part 15 Subpart B
UL-CSA 61010-1
IEC 62471
Bandwidth / Data Logging
UV Angel Adapt will Communicate via WIFI when:
Device is powered A treatment cycle is paused
The USB connection changes A treatment cycle is stopped

888.277.2596 • [e-mail] • UVANGEL.COM
Copyright UV Partners, Inc. All rights reserved. UV Angel® and
UV Angel Air® are registered trademarks of UV Partners, Inc.
TERMS OF USE
Purposefully removing or damaging any labeling on the device will void all product
warranties.
All UV Angel Adapt devices are expected to be installed by or under the guidance of UV
Angel or a UV Angel Certied Technician. Failure to do so will void all product warranties
and release UV Angel of all liability.
MAINTENANCE
Repairs
Repairs and/or upgrades are not to be performed on this product. These services are to
be performed only by an authorized service center. Please see Customer Support at www.
uvangel.com/support or 888.277.2596.
Maintenance
UV Angel Adapt provides reliable and efcient operation with a minimum of care. Specic
maintenance is not required. Cleaning of the device should be performed with a microber
cloth, if required, unplug the device and slightly dampen the cloth.

888.277.2596 • [e-mail] • UVANGEL.COM
Copyright UV Partners, Inc. All rights reserved. UV Angel® and
UV Angel Air® are registered trademarks of UV Partners, Inc.
SUPPORT & WARRANTY
UV Angel warrants this product to be free from defects in material and workmanship
for a period of two years from the date of original retail purchase from UV Angel or an
authorized UV Angel distributor. Proof of purchase is required for all warranty claims.
During the limited warranty period, UV Angel Inc. will, at its option, repair or replace
defective parts of this product, at no charge to the customer, subject to the following
limitations: This limited warranty does not include any postage, freight, handling, and
insurance or delivery fees. This warranty does not cover damage, defect or failure
caused by or resulting from accident, external destruction, alteration, modication,
abuse, misuse or misapplication of this product. This warranty does not cover damage
to the product resulting from return shipping or handling. The use of shipping insurance
is recommended to help protect your product. Return Authorization is required for all
returns. For further information, please contact the UV Angel Support at 888.277.2596 or
[email protected]
NOTE: The unauthorized use, or operation outside intended use of equipment voids
warranty.
Due to ongoing improvements, actual product may have slight variations from the
product described in this manual.
2
YEAR LIMITED
WARRANTY

888.277.2596 • [e-mail] • UVANGEL.COM
Copyright UV Partners, Inc. All rights reserved. UV Angel® and
UV Angel Air® are registered trademarks of UV Partners, Inc.
FCC COMPLIANCE AND ISED
INFORMATION
Contains FCC ID: 2AC7Z-ESPWROOM32
Contains IC: 21098-ESPWROOM32
This device complies with Part 15 of the FCC Rules and ICES-003 of the ISED Rules.
Operation is subject to the following two conditions:
1) This device may not cause harmful interference, and
2) This device must accept any interference received, including interference that may cause undesired
operation.
This equipment has been tested and found to comply with the limits for a class B digital device, pursuant
to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates, uses and can radiate radio frequency
energy and if not installed and used in accordance with the instructions, may cause harmful interference
to radio communications. However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or television reception, which
can be determined by turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
• Reorient or relocate the module/product.
• Increase the separation between the equipment and module/product.
• Consult the dealer or an experienced radio/TV technician for help.
• Changes and modications made to the equipment without the approval of manufacturer could void
the user’s authority to operate this equipment.
• To comply with FCC/IC RF exposure limits set forth for an uncontrolled environment, the equipment
should be installed and operated with a minimum distance of 20cm between the radiator and your
body.
SCIENTIFIC CLAIMS AND USAGE
Neutralizes >99% of bacteria and fungus on treated keys in 12 minutes when used in accordance with UV
Angel Adapt’s labeled directions-for-use
a. Requires operating in accordance with the UV Angel Adapt’s labeled directions for use.
b. UV Angel Adapt works most effectively when surfaces have been cleaned prior to use.
EPA Est. No. 094778-MI-001
UV ANGEL
233 Washington Ave., Suite L1
Grand Haven, MI, 49417
100-1208 | 11.19.20 | v3
