V-max VX1 User manual

Age 14+
Art. No. 110.52604
With road permission
USER MANUAL
VMAX VX4

2
VX4 User manual
VMAX Global AG
Headquaters Distribution Europa
Industrieweg 32 / 4852 Rothrist - Switzerland
Phone: [phone]
Mail: [email protected]
Website: www.vmax-escooter.ch
Die Marke VMAX
VMAX was founded in 2015 and is a Swiss brand with various mobility
solutions. The compay‘s vision „your mobility solution“ is underpin-
ned with diverse products groups in the field of mobility.
VMAX wants to develop the best e-scooter, pedelec or hoverboard
for each the best e-scooter, the best pedelec or the best hoverboard.
To achieve this goal, the brand maintains a constant exchange of
ideas, comments, suggestions for improvement and knowledge with
the VMAX community (VMAX customers or people interested in the
topic) to always be on the pulse of time and as close to the customer
as possible.
All products are produced according to the highest quality and safety
standards (ISO9001). The VMAX products come from an Amfori BSCI
audited factory.

3
VX4 User manual
Introduction 4
Road approval Switzerland/Germany 5
Disclaimer 6
Symbols used 7
Safety instructions 8–9
Safety instructions lithium ion battery 10
Charging process 11
Maintenance and care 12
Storage 13
Parts description 14
Assembly 15
Display 16
Display functions 17
Adjustments 18
Before the first ride 19
Technical data 20
Legal notice 21
Warranty 22
Service 23
TABLE OF CONTENTS

4
VX4 User manual
Dear Customer
We congratulate you on the purchase of your new VMAX e-scooter
and welcome you to the VMAX family. To ensure that you have a good
knowledge of the device and can experience the greatest possible
driving pleasure with the highest level of safety, it is important that
you read this user manual carefully before using it for the first time
and keep it for any questions that may arise later. We hope you enjoy
using your new e-scooter!
Scope of delivery
Check your VMAX package for the following contents:
• E-Scooter
• Charger
• Smartphone holder
• Tool kit
 • UsermanualDE / FR / EN
CONGRATULATIONS
4

5
VX4 User manual
An e-scooter is a means of locomotion with an electric motor and the-
refore falls into the category of light motor vehicles or, in Germany,
into the category of „miniature electric vehicles“. Your device meets
all the requirements and conditions for the category of light motor
vehicles and „very small electric vehicles“ and also has an operating
permit (ABE) required in Germany.
Both in Switzerland and in Germany, e-scooters are subject to the
rules of public road traffic, which must be complied with.
Road approval Switzerland / Germany
Special registration-related instructions Switzerland:
• From 14 years with driver‘s license category M
• From 16 years without driver‘s license
• No license plate obligation
Special registration-related instructions Germany:
• From 14 years without driver‘s license
• Operating permit scooter (ABE)
• Compulsory insurance (sticker must be attached)
For other road approvals, please refer to the regulations in force in
your country.
5
ROAD APPROVAL

6
VX4 User manual
Since its not possible for us control the handling fo the e-scoo-
ter, the compilance with operating instructions, as well as the
charging/discharging and the maintenance of battery, VMAX Global AG
cannot assume any liability for losses, damages or cost. Any claim fo
damages that may arise from, or in any way be related to, the opera-
tion, failure or malfunction is denied. We accept no liability for perso-
nal injury, damage to property or the consequences therefore arising
from our delivery. To the extent permitted by law, the obligation to pay
damages, on whatever legal grounds, shall be limited to the invoice
value of our products directly affected by the event. This shall not apply
insofar as we are liable according to mandatory statutory provisions or
gross negligence.
DISCLAIMER

7
VX4 User manual
In the manual
WARNING: Warning of possible risks, personal
injury and danger of injury.
CE mark (Conformity Europe) this product is cons-
tructed in conformity with designated european
standards.
ATTENTION: Indication of need for action or
adjustment work by the user.
The battery must not be disposed of with
household waste.
Cells in the battery contain lithium.
Follow instructions!
On the packaging
SYMBOLS USED

8
VX4 User manual
Please note that the instructions and hazard warnings described in the
operating instructions can reduce risk, but not all risks are excluded.
We ask you to handle your e-scooter carefully and responsibly.
• We recommend that you wear a hard hat and other protective
equipment. Make sure you wear good footwear with flat sole.
• Drive only on dry, clean, level surfaces and when road conditi-
ons and weather warrant safe driving, Never drive on snow,
ice, or slushy surfaces, in heavy rain, or in conditions of limited
visibility.
• Never ride on stairs, escalators, ramps, over curbs longer than
2 cm, or in skate parks.
• Do not drive if you feel unwell or tired and stop driving if you
feel tired or unwell during the journey.
SAFETY INSTRUCTIONS
WARNING:
RIDING AN E-SCOOTER CAN RESULT IN SERIOUS INJURY OR DEATH
ATTENTION:
Read user manual before commissioning

9
VX4 User manual
• The e-scooter is designed for use by a single person. Any in-
fringement will be regarded as improper use. The user bears all
risks.
• All interventions to increase the power or speed, as well as general
changes to the characteristics of the e-scooter are punishable by
law and will be prosecuted, furthermore any warranty claims are void.
• The e-scooter must not be driven by children under the age of 14.
• Persons with physical limitations are recommended to have an
accompanying person, especially at the beginning and accor-
ding to the severity of the limitation. If the physical balance is
impaired, do not use the e-scooter.
• The maximum weight for use must be observed (see technical
data, page 20).
• Never drive under the influence of alcohol, medication or drugs.
• Always place both feet on the footboard while riding.

10
VX4 User manual
WARNING:
• The lithium ion battery may only be charged under supervision
and not overnight.
• The li-ion battery must not be charged when your device or the
device or the charging cable are wet or damp.
• Only use the original charger included in the scope of delivery
to charge the li-ion battery.
• Never charge the li-ion battery near flammable materials,
liquids, heat sources or fire.
• Keep the li-ion battery away from children and animals.
• If your li-ion battery is damaged, leaking electrolytes may cause
a risk of poisoning or chemical burns. Avoid inhaling the esca-
ping vapors! Avoid skin contact! In case of accidental skin
contact, rinse the affected area thoroughly with water and
consult a doctor.
• If your li-ion battery catches fire, never extinguish it with water!
Use sand or a CO2 fire extinguisher as an extinguishing agent.
• Do not make any modifications to your li-ion battery. Never
modify, repair or disassemble the li-ion battery.
SAFETY INSTRUCTIONS
LITHIUM ION BATTERY

11
VX4 User manual
CHARGING PROCESS
ATTENTION:
Your device requires regular charging. Proceed as follows:
• Fully charge the li-ion battery before initial operation and do
not interrupt the charging process. Also do not switch on or
operate your device during the charging process.
• Make sure that the charger plugs and the charging socket are
dry before charging and that there is no dirt or dust in or on
them.
• Connect the charging plug to the charging socket on your
e-scooter.
• Connect the charger to the power socket via the power plug.
• During the charging process, the LED control lamp on the
charger lights up red.
• Once the li-ion battery of the e-scooter is charged, the LED
indicator light on the charger will turn green and you can
remove the charger.

12
VX4 User manual
ATTENTION:
Your device requires regular and careful maintenance.
Proceed as follows:
• Your e-scooter is not waterproof. The device is protected
against dust in harmful quantities and protected against splas-
hing water on all sides in accordance with the IP 54 standard.
• Disconnect the e-scooter, if connected, from the charger and
switch it off.
• Check your device for loose parts, damage, excessive wear and
the integrity of the housing and tires. If you find any defects
during the inspection, stop using the e-scooter and contact your
dealer.
PLEASE NOTE:
• Therefore, use a damp rag for maintenance and avoid contact
of water with electronic components in any case.
• Dry the device completely, before each start-up or loading.
MAINTENANCE AND CARE

13
VX4 User manual
STORAGE
ATTENTION:
Your device requires some rules during storage, proceed as follows:
• Charge the li-ion battery to approx. 60% before storage.
• Repeat the procedure at least every four weeks during storage
and when not in use to avoid deep discharge.
• Protect your e-scooter from dust and other external influences,
ideally in the stored original packaging.
• Store the e-scooter in a dry place and at a temperature of 10 to
15°C, which is optimal. Make sure that the room temperature
does not drop below 5°C and do not store the e-scooter outdoors.
• Never store the e-scooter for a long period of time in high heat
(e.g. in the car in summer).
• There is no warranty claim for damage to the li-ion battery due
to improper storage or insufficient charging during storage or
non-use (deep discharge).

14
VX4 User manual
1. Handles
2. Accelerator
3. Display
4. Front light
5. Front reflectors
6. Hook
7. Handlebar
8. Safety lock
9. Folding lever
10. Front fender
11. Front wheel
12. Drum break
13. Stand
14. Footboard
15. Fixing piece
16. Rear light
17. Rear reflector
18. Side reflectors
19. Rear wheel (motor)
20. Charging port
PARTS DESCRIPTION
3
5
4
7
9
8
14
18
17
21
10
12
13
20
11
15
19
6
16

VX4 User manual
ASSEMBLY
15
Step 1
Remove the e-scooter from the packaging and
check whether all parts of the scope of delivery
(page 4) are included. Now adjust the stand so that
the e-scooter stands on its own.
Step 2
Now insert the brake cable into the opening of the
brake lever before placing the steering head on
the handlebar.
Step 3
Now fold the handlebar upwards so that the
folding mechanism engages.
Step 4
Now connect the cable of the handlebar and the
cable of the steering head together and then place
the steering head on the handlebar.
Step 5
Now tighten the four screws supplied so that the
steering head and the handlebar are fixed. Your
device is now completely assembled.
Folding
To fold the e-scooter back together, lift the red
safety catch and pull the folding lever. The handle-
bar can now be moved backwards/downwards.
Now engage the hook in the fixing piece for the
hook

16
VX4 User manual
DISPLAY
1. Gear
2. Bluetooth
3. Light
4. Mph
5. Km/h
6. Battery display
7. Cruise control
8. Speed
9. Mileage
10. Throttle
11. On / Offbutton
12. Light button
7
2
3
12
11
10
4
5
6
9
8
1

17
VX4 User manual
DISPLAY FUNCTIONS
On/off gear shifting
Presstheon / offbutton(11)for2secondstoswitchonthedevice.
Briefly press the on / off button again, to switch between gears:
„S“ = ECO mode, less performance
„Red S“ = SPORT mode, more performance
Presstheon / offbutton(11)againfor4secondstoswitchthedevice
off.
If the e-scooter is not used, the device switches off automatically
after 5 minutes.
Light
Press the light button (12) once briefly to switch the light either on or off

18
VX4 User manual
ADJUSTMENTS
Brake adjustment dum brake
If the brake lever has too much „play“ for your needs,
you can turn the nut on the drum brake clockwise.
Fine adjustment handlebar
and folding mechanism
If you feel that the handlebars are wobbling a bit,
first tighten the four bolts that secure the steering
head with a 2.5 mm allen wrench.
Other screws are located on the folding mechanism
and on the lower end of the handlebar. If you feel
that the folding mechanism has some „play“ or that
it does not engage or close correctly, you can ad-
just these screws. This requires good tuning, as the
mechanism should have no „play“, but should open
smoothly by lifting the safety latch.

19
VX4 User manual
BEFORE THE FIRST RIDE
Make sure that the device is in perfect and undamaged condition.
• Place the e-scooter on a flat surface and check the charging
status of your device.
• Press the on/off button on the handlebar, the display with the
battery indicator lights up.
• Stand directly next to your e-scooter and hold the handlebars
firmly with both hands.
• Place your right or left foot on the footboard and push off with
the other foot. Now also place the second foot behind or next
to the first foot on the footboard and press the accelerator.
• To brake or stop, you can press the brake lever on the handlebars.
• To switch off the e-scooter, press and hold the on/off
button for 4 seconds.
ATTENTION! For safety reasons, the scooter will not start until you
push off lightly with your foot from the ground as described previ-
ously.

20
VX4 User manual
Product description: VMAX VX2
Art. No.: 110.52604
Battery: 48 V / 13‘000 mAh
Engine power: 500 W
Range: max. 40 km
Max. speed: approx. 20 km/h
Max. load: 120 kg
Net. weight: 17.7 kg
Protection class: IP54
Operating temperature: -10 - 50°C
Charger: AC 100-240V 50-60Hz / DC+ 54V/2A
Charging time: approx. 6 hours
Color: black
TECHNICAL DATA
