V-Show DSP08 User manual

DMX 512 SERIESSPLITTER
DMX 512 SERIESSPLITTER
8 Port DMX Splitter
User Manual
Version:1.0 12 JULY 2022
1.
2.
3.
4.

AC88V 256V
50/60Hz
FU SE :T 2A
~
AC I N AC O UT OU TP UT 6 OU TP UT 4 OU TP UT 2OU TP UT 7 OU TP UT 5 OU TP UT 3 OUTPUT 1OU TP UT 8
IN PU TTH RU
DMX 512 SERIESSPLITTER DMX 512 SERIESSPLITTER
DMX input indicator
DMX output indicators Power indicator
Power input DMX
to connect the DMX
console
inputs: used DMX outputs: used to connect the DMX lighting
Congratulations on purchasing your new . The unit has
one input and eight outputs. Absolutely electric isolation between all input
and outputs. DMX connector (3pin) and DMX indicator for each individual
channel, each DMX output features a independent driver. We strongly
recommend that you take time to read this manual fully before you attempt
to use the DMX splitter.
DMX Signal Splitter
8 PORT DMX SPLITTER USER MANUAL
Power input .......................................................AC88~256V 50/60Hz
Fuse(internal) ............................................................................T2A
Dimension ................................................................482x134x44MM
Weight....................................................................................1.7 KG
1.Technical specification
2.Operating instruction and connection
connector pin designations shall be
as follows:
pin1:signal common(shield)
pin2:dimmer drive complement(data -)
pin3:dimmer drive true(data+)
3Pins XLR(plug)
Pin 1 : GND (SCREEN)
Pin 2: Signa l (-)
Pin 3: Signa l(+)
3Pins XLR(plug)
Pin 1 : GND (SCREEN)
Pin 2: Signa l (-)
Pin 3: Signa l(+)
3. Connection diagram
(1) DMX Controller
(2) DMX Controller
DMX Controller
DMX Controller
DMX Splitter
OUT
OUT
OUT 1
OUT 1
OUT OUT
OUT
OUT
OUT 2
OUT 2
IN
IN
IN
IN IN
IN
IN
IN
IN
IN
Lights
Lights
Lights
Lights
Lights Lights
Lights
Lights
Lights
Lights
Receiver can not more than 32 units on one out channel.
Use one terminator on the last receiver
Lighting can not more than 31 units before DMX splitter.
Lighting can not more than 32 units on one out channel.
Use one terminator on the last Lighting
1 2 3 4 5 6 7 8
OU TP UT I NP UT
OF F
ON
8 Port DMX Splitter
PO WE R
Power output
