V-Tec VT584 Series User manual

Product Information
VT584 Series
4-Wire Outdoor Staon
DESCRIPTION FEATURES
DIMENSION
4 wire system Color Outdoor Station ► Plastic housing with compact design;
► Camera's angle is adjustable;
► Half-ush mounting;
*1 Rain cover for surface wall mounting;
*1 High white led or Infrade night vision;
*1 Depends on models.
95
150
45

1. Parts and Funcons
2. Door Staon Mounng
35mm
145 cm
1. Dig a hole in 75mm X 75mm X 35mm in the wall. Insert the mounting bracket and x with screws.
2. Wire up the cables, and test the system.
3. Hang the door/bell camera body on top of the mounting box, then tighten the screws rmly on the
bottom.
1
6
7
8
2
3
4
5
1. Microphone
2. Camera
3. Night-View LED
4. Call Button
5. Speaker
6. Angle Adjust
7. Monitor Port
8. Unlock Port LB

3. Specicaon
• Power Supply : DC 12V (supplied by indoor monitor)
• Power Consumption: Standby 50mA; Working status 200mA;
• Camera: 1/4” Color CCD/CMOS
• Unlocking time: 1-9S, set by monitor;
• Talk Time: 90S;
• Lock Power supply: 12Vdc, 300mA(Internal Power)
• Temperature: -100C~+450C
• Wiring: 4 wires (Polarity)
• Dimension: 150(H)×95(W)×45(D)mm
4. Ordering Informaon for Door Staon
Model No. Brief Description Remark
VT584/CS Color CMOS outdoor staon NSTC,PAL must be specied
VT584/C Color CCD outdoor staon NSTC, PAL must be specied
5. Packing Informaon
Dimensions: 228(H)×140(W)×65(D)mm
Gross Weight: 0.89Kg
Carton: 415 (H)×360 (W)×265 (D)mm
Quanlity: 15PCS
